FSUGMZLB2.4GHz Wireless Keyboard and Mouse Combo

Manual instruction Hardware installation 1. Install two AAA Batteries into the mouse and two AAA batteries into the keyboard. 2. Plug in the USB receiver to a USB port on your PC. ID Channel Setting and connection: After you install the receiver: 1. Wait about 5‐10 seconds and the connection will be executed and the kit will be ready for use. 2. For optimum performance, make sure that the distance between the wireless device and the receiver does not exceed 10M. Replace Batteries If the mouse or keyboard does not work properly, then the batteries have lost their charge, so you need to replace them. Warning: do not mix or use different types of batteries at the same time. Mouse Button Assignments 1. Left Button: Provides traditional mouse functions like click, double click and drag. 2. Magic‐Roller: Scroll the button to surf the internet and windows documents. 3. Right Button: Provides traditional mouse right click function. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment 2.4GHzWireless Keyboard and Mouse Combo Model Name GK-140001/R Brand Name Genius Applicant KYE SYSTEMS CORP Address No.492, Sec.5, Chongxin Rd, Sanchong Dist, New Taipei City 24160, Taiwan( R.O.C) Standard(s) FCC Part 15, Subpart B:2013 ANSI C63.4 -2009 Report(s) NEI-FCCE-1-1407C024C The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

RV-0000000 Project No.: 1407C024C Page 2 of 6

13.3x11mm GK-140001/R B Model No:GK-140001/M

RV-0000000 Project No.: 1407C024C Page 3 of 6 RV-0000000 Project No.: 1407C024C Page 4 of 6 RV-0000000 Project No.: 1407C024C Page 5 of 6 RV-0000000 Project No.: 1407C024C Page 6 of 6

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where 豸 f(GHz) is the RF channel transmit frequency in GHz 豸 Power and distance are rounded to the nearest mW and mm before calculation 豸 The result is rounded to one decimal place for comparison Worse case is as below: [2402 MHz -6.69dBm（0.21 mW） output power] ( 0.21mW /5mm) ·[√2.402 (GHz)]=0.07 <3.0 for 1-g SAR Then SAR evaluation is not required

Report No. : : NEI-FCCP- This rep T D D I T T A 1-1407C02 4 FCC F ort concer Project No Equipmen Model Nam Applicant Address Tested by: Date of Rec Date of Tes Issued Dat Testing En Technical M Authorized N TEL: 0 4C C Rad FCC ID rns (check o. : 1 4 nt : 2 . M me :G : K Y : N S a 24 BTL Inc. EM ceipt: Jul. 0 st: Jul. 01, 2 e: Jul. 11, 2 ngineer Manager d Signatory B No.3, Jinsh Dalang To 0769-8318- dio T D: FSU one): O 407C024C .4GHz Wire Mouse Comb K-140001/R YE SYSTE o.492, Sec . anchong Di 4160, Taiwa MC Laborat 01, 2014 2014~ Jul. 1 2014 : : y: BTL IN hagang 1st own, Dong -3000 FA Test R UGMZL Original Gra eless Keybo bo R MS CORP. .5, Chongxi ist, New Tai an( R.O.C) tory 10, 2014 (David M (Leo Hu (Steven NC. t Road, Sh gguan, Chin AX: 0769-8 Repor LB ant Clas oard and n Rd, ipei City Mao) ung) n Lu) ixia, na. 8319-6000 P rt ss II Chang Page 1 of 79 ge Report No.: NEI-FCCP-1-1407C024C Page 2 of 79 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-1-1407C024C Page 3 of 79 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 19 4.2.5 EUT OPERATING CONDITIONS 20 4.2.6 EUT TEST CONDITIONS 20 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 20 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 21 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 21 5 . NUMBER OF HOPPING CHANNEL 22 5.1 APPLIED PROCEDURES 22 5.1.1 TEST PROCEDURE 22 5.1.2 DEVIATION FROM STANDARD 22 5.1.3 TEST SETUP 22 5.1.4 EUT OPERATION CONDITIONS 22 5.1.5 EUT TEST CONDITIONS 22 5.1.6 TEST RESULTS 22 Report No.: NEI-FCCP-1-1407C024C Page 4 of 79 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 23 6.1 APPLIED PROCEDURES / LIMIT 23 6.1.1 TEST PROCEDURE 23 6.1.2 DEVIATION FROM STANDARD 23 6.1.3 TEST SETUP 23 6.1.4 EUT OPERATION CONDITIONS 24 6.1.5 EUT TEST CONDITIONS 24 6.1.6 TEST RESULTS 24 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 25 7.1 APPLIED PROCEDURES / LIMIT 25 7.1.1 TEST PROCEDURE 25 7.1.2 DEVIATION FROM STANDARD 25 7.1.3 TEST SETUP 25 7.1.4 EUT TEST CONDITIONS 25 7.1.5 TEST RESULTS 25 8 . BANDWIDTH TEST 26 8.1 APPLIED PROCEDURES 26 8.1.1 TEST PROCEDURE 26 8.1.2 DEVIATION FROM STANDARD 26 8.1.3 TEST SETUP 26 8.1.4 EUT OPERATION CONDITIONS 26 8.1.5 EUT TEST CONDITIONS 26 8.1.6 TEST RESULTS 26 9 . PEAK OUTPUT POWER TEST 27 9.1 APPLIED PROCEDURES / LIMIT 27 9.1.1 TEST PROCEDURE 27 9.1.2 DEVIATION FROM STANDARD 27 9.1.3 TEST SETUP 27 9.1.4 EUT OPERATION CONDITIONS 27 9.1.5 EUT TEST CONDITIONS 27 9.1.6 TEST RESULTS 27 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 28 10.1 APPLIED PROCEDURES / LIMIT 28 10.1.1 TEST PROCEDURE 28 10.1.2 DEVIATION FROM STANDARD 28 10.1.3 TEST SETUP 28 10.1.4 EUT OPERATION CONDITIONS 28 10.1.5 EUT TEST CONDITIONS 28 10.1.6 TEST RESULTS 28 Report No.: NEI-FCCP-1-1407C024C Page 5 of 79 Table of Contents Page 11 . MEASUREMENT INSTRUMENTS LIST 29 12 . EUT TEST PHOTO 31 ATTACHMENT A - CONDUCTED EMISSION 35 ATTACHMENT B - RADIATED EMISSION (9KHZ-30MHZ) 38 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 40 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 47 ATTACHMENT E - NUMBER OF HOPPING CHANNEL 60 ATTACHMENT F - AVERAGE TIME OF OCCUPANCY 62 ATTACHMENT G - HOPPING CHANNEL SEPARATION MEASUREMENT 65 ATTACHMENT H - BANDWIDTH 69 ATTACHMENT I - PEAK OUTPUT POWER 72 ATTACHMENT J - ANTENNA CONDUCTED SPURIOUS EMISSION 75 Report No.: NEI-FCCP-1-1407C024C Page 6 of 79 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1407C024C Original Issue. Jul. 11, 2014 Report No.: NEI-FCCP-1-1407C024C Page 7 of 79 1. CERTIFICATION Equipment : 2.4GHz Wireless Keyboard and Mouse Combo Brand Name : Genius Model Name : GK-140001/R Applicant KYE SYSTEMS CORP Manufacturer : SHENZHEN SENBIZ INDUSTRY CO.,LTD Address : Building 11-12,XinQiao XinFa Industrial Zone, Shajing town, Bao An district, Shenzhen Guangdong,China Factory : SHENZHEN SENBIZ INDUSTRY CO.,LTD Address : Building A, No.11,First row,Xinfa Industrial Zone, XinQi…

Text truncated - open the document above for the full version.

Report No.: NEI-FCCP-1-1407C024C Page 31 of 78 12. EUT TEST PHOTO Conducted Measurement Photos Report No.: NEI-FCCP-1-1407C024C Page 32 of 78 Radiated Measurement Photos 9KHz to 30MHz Report No.: NEI-FCCP-1-1407C024C Page 33 of 78 Radiated Measurement Photos 30MHz to 1000MHz Report No.: NEI-FCCP-1-1407C024C Page 34 of 78 Radiated Measurement Photos Above 1000MHz
