FSUKT001TrackPad

1. Put your receiver into PC. 2. Pull out the insulation sheet. 2. Pair The LED for dongle will blink flash 8 times, then you can use on you PC. 3. Functions 3.1 Mouse functions a. Mouse cursor and button Item Mouse Cursor Mouse button Left button Right button Middle button Method one Method two Have ● ● ● ● ● Action Slide Tap Tap Tap Tap Method Slide Tap + button Tap + button Two fingers tap + button Three fingers tap + button Area Enjoy the perfect trackpad combo for your PC. Reduce desktop clutter with wireless connection and enhance workspace comfort with modern design. HP Wireless Trackpad (ATOLL) b. Mouse wheel Item Mouse wheel Vertical Scroll Horizontal Scroll (Tilt Wheel) Method one Method two Method one Method two Have ● ● ● ● Action Slide Slide Slide Slide Method One finger slide Two fingers slide One finger slide Two fingers slide Area c. Mouse left functions Item Mouse left functions Single tap Double tap Double tap then hold Have ● ● ● Action Tap Tap Tap Method Single tap Double tap Double tap then hold Area 3.2 Gesture function Item Zoom Rotate Edge swipe Out In Lift Right Toggle the charms Toggle the app bar Switch to last application Have ● ● ● ● ● ● ● Action Slide Slide Slide Slide Slide Slide Slide Method Two fingers slide Two fingers slide Two fingers slide Two fingers slide One finger slide One finger slide One finger slide Area Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.

KYE Systems Corp No. 492, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) Tel: +886-2-29956645 Fax: +886-2-29956649 Date: 2012-07-18 FCC ID: FSUKT001 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, P.C Lee / Section Supervisor KYE Systems Corp Tel.: +886-2-2995-6645 Fax.: +886-2-2278-9520 E-mail: [email protected]

KYE Systems Corp No. 492, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) Tel: +886-2-29956645 Fax: +886-2-29956649 Date: 2012-07-18 FCC ID: FSUKT001 A U T H O R I Z A T I O N L E T T E R To whom it may concern: We, the undersigned KYE Systems Corp hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, P.C Lee / Section Supervisor KYE Systems Corp Tel.: +886-2-2995-6645 Fax.: +886-2-2278-9520 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

9. RESTRICTED SUBSTANCE SPEC REFERENCE TO:DKC-QCD-S-095 8. THS SYMBOL INDICATES ALL CRITICAL DIMENSION IQC 100% MATL. INCOMING INSPEC. 80P CHECKED BY: REV APPROVED BY: DRAWN BY: DESCRIPTION: DWG NO.: KYE Systems Corporation. TOLERANCES MM UNLESS OTHERWISE SPECIFIED X.XXX X.XX LINEAR X.X INCH ANGLE SHEET OF 1 1 A 李敏2012/7/10 2012/7/10 ATOLL TRA registered No.XXXX Dealer no.XXXX FCC ID: FSUKT001 IC: 5277A-ATOLL N136 303-ABCDEF Product of China PMS 877C (Silver) Printed Color: PMS 8403C HP, HQ-TRE 71004 Boeblingen Germany Model No. AMPS VOLTS ATOLL TRA registered No.XXXX Dealer no.XXXX FCC ID: FSUKT001 IC: 5277A-ATOLL N136 303-ABCDEF Product of China HP, HQ-TRE 71004 Boeblingen Germany Model No. AMPS VOLTS

Page 2 Page 3 Page 4 Page 5

FCC ID: FSUKT001 Report No.: RF120711C14 Operational Description This device is a TrackPad. The transmitter of the EUT is powered by 3Vdc from batteries. The antenna is PCB antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: RF120711C14 1 of 22 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF120711C14 MODEL NO.: ATOLL FCC ID: FSUKT001 RECEIVED: Jul. 11, 2012 TESTED: Jul. 16, 2012 ISSUED: Jul. 23, 2012 APPLICANT: KYE Systems Corp ADDRESS: No. 492, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120711C14 2 of 22 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD ............................................................................... 3 1. CERTIFICATION ............................................................................................. 4 2. SUMMARY OF TEST RESULTS .................................................................... 5 2.1 MEASUREMENT UNCERTAINTY .................................................................. 5 3. GENERAL INFORMATION ............................................................................. 6 3.1 GENERAL DESCRIPTION OF EUT ............................................................... 6 3.2 DESCRIPTION OF TEST MODES ................................................................. 7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................. 8 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................... 9 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ............................................. 9 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................. 9 4. TEST TYPES AND RESULTS ...................................................................... 10 4.1 RADIATED EMISSION AND BAND EDGE MEASUREMENT ...................... 10 4.1.1 LIMITS OF RADIATED EMISSION AND BAND EDGE MEASUREMENT .... 10 4.1.2 TEST INSTRUMENTS .................................................................................. 11 4.1.3 TEST PROCEDURES .................................................................................. 12 4.1.4 DEVIATION FROM TEST STANDARD ......................................................... 12 4.1.5 TEST SETUP ................................................................................................ 13 4.1.6 EUT OPERATING CONDITIONS ................................................................. 13 4.1.7 TEST RESULTS ........................................................................................... 14 5. PHOTOGRAPHS OF THE TEST CONFIGURATION ................................... 20 6. INFORMATION ON THE TESTING LABORATORIES .................................. 21 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ...................................................... 22 Report No.: RF120711C14 3 of 22 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120711C14 Original release Jul. 23, 2012 Report No.: RF120711C14 4 of 22 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: TrackPad MODEL NO.: ATOLL BRAND: hp APPLICANT: KYE Systems Corp TESTED: Jul. 16, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment (model: ATOLL) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Jul. 23, 2012 Pettie Chen / Specialist APPROVED BY : , DATE :Jul. 23, 2012 Gary Chang / Technical Manager Report No.: RF120711C14 5 of 22 Report Format Version 5.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULTREMARK 15.207 Conducted Emission Test NA Power supply is 3Vdc from battery 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -8.3dB at 2485.50MHz. Note: “NA” means Not Applicable. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
