G2R-126400Remote Racer Smart Car

User’s Manual © 2011 VTech Printed in China 91-002602-000 美 Remote Racer Smart Car TM Dear Parent, At VTech®, we know how important the first day  school is for your child. To help prepare preschoolers for this important event, VTech ® has developed the Preschool Learning ™ series  interactive ts. Preschool Learning ™ features fun characters and inviting school themes that use technology to capture a child’s aention and teach important preschool skills like spelling, counting and the alphabet. ese vital skills are taught in a way that's bh fun and highly engaging to maintain a child's interest. Children will also be introduced to fun school suects such as art cla, music cla and even rece! With Preschool Learning ™, learning is fun om day one! At VTech ®, we know that a child has the ability to do great things. at’s why all  our electronic learning products are uniquely designed to develop a child’s mind and allow them to learn to the best  their ability. We thank you for trusting VTech ® with the important job  helping your child learn and grow! Sincerely, Your iends at VTech® To learn more about Preschool Learning™ series and her VTech® ts, visit www.vtechkids.com 3 InTR odu CTI on InTRoduCTIon Thank you for purchasing the VTech ® Remote Racer Smart Car TM ! Hit the road of learning fun with the VTech Remote Racer Smart Car TM from VTech ® ! This basic remote control car for preschoolers features a remote control sized steering wheel, just right for little hands. Through interactive play, your child will learn about directions (forwards, backwards, left, right) colors, shapes, logic and memory. For added learning fun, the headlights double as turning signals to help teach left and right directions. Fun theme songs about driving and traffic lights also play to engage your child through racing fun! Four learning sHaPe buTTons Mode seleCTor Two HeadligHTs Two TailligHTs sTeering wHeel Forward buTTon baCkward buTTon MusiC buTTon 4 InCLudEd In THIS PACKAGE one VTech ® Remote Racer Smart Car TM one Remote Controller one user’s manual WARNING: All packing materials, such as tape, plastic sheets, packaging locks and tags are not part of this toy, and should be discarded for your child’s safety. ATTENTION Pour la sécurité de votre enfant, débarrassez-vous de tous les produits d’emballage tels que rubans adhésifs, feuilles de plastique, attaches et étiquettes. Ils ne font pas partie du jouet. DEMO STRIP REMOVAL: When the product is taken out of the packaging, please remove the demo cable from the unit to activate normal play mode. NOTE: Please keep instruction manual as it contains important information. Unlock the packaging locks: GETTInG STARTEd BATTERY InSTALLATIon GETTI nG STARTE d rotate the packaging lock counter-clockwise for 90 degrees Pull out the packaging lock 5 1. Make sure the unit is turned OFF. 2. locate the battery cover on the bottom of the unit. install 4 new “aa” size (lr6/aM-3) batteries following the diagram inside the battery box for rF Vehicle. install 3 new “aaa” size (lr03/aM-4) batteries following the diagram inside the battery box for remote controller. Check signal lamp to indicate “battery installed successfully” and “input received”. 3. The use of new alkaline batteries is recommended for maximum performance. 4. replace the battery cover. BATTERY noTICE • The use of new alkaline batteries is recommended for maximum performance; • Non-rechargeable batteries are not to be recharged. • Rechargeable batteries are to be removed from the toy before being charged (if removable). • Rechargeable batteries are only to be charged under adult supervision (if removable). • Do not mix old and new batteries. • Do not mix batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium). • Only batteries of the same or equivalent type as recommended are to be used. • Batteries are to be inserted with the correct polarity. • Exhausted batteries are to be removed from the toy. • The supply terminals are not to be short-circuited. • The toy is not to be connected to more than the recommended number of power supplies. • Do not dispose of batteries in fire. WE DO NOT RECOMMEND THE USE OF RECHARGEABLE BATTERIES. GETTI nG STARTE d 6 PRoduCT FEATuRES on the Remote Racer Smart Car TM : 1: ModE SELECToR slide the Mode Selector from “off” to any mode to turn the unit on and choose one activity. 2: LEARnInG SHAPE BuTTonS Press the Learning Shape Buttons to learn the colors, shapes and road safety. 3: VoLuME SWITCH slide the Volume Switch on the bottom of the car to adjust the volume. There are 3 volume levels to choose from. 4: SPEEd SWITCH The Speed Switch is on the bottom of the car. slide it to choose fast or slow speed. Tip: If you find the car is not rolling straight, you can use the fine-tune control to adjust. PR odu CT FEATu RES 7 on the Remote Controller: 5: MuSIC BuTTon Press the Music Button to hear the songs. 6: FoRWARd/BACKWARd BuTTonS Press the Forward or Backward Buttons to make the car go forward or backward. The driver will move left and right when the car is going forward or backward. 7: STEERInG WHEEL Turn the Steering Wheel to turn left or right. when the car is turning left or right, the driver will turn his body to match the direction of the car. 8: SIGnAL LAMP The signal light will be on to indicate “battery installed successfully” and “input received”. 9: AuToMATIC SHuT-oFF To preserve battery life, the VTech ® Remote Racer Smart Car TM will automatically turn off after several minutes without input. The unit can be turned on again by pressing the shape buttons or moving the Mode selector. PR odu CT FEATu RES 8 ACTIVITIES Learn Mode 1. Press any learning shape button to learn about colors, shapes and road safety. Quiz Mode 1. You will be asked a question about colors or shapes. 2. Press a shape or color button to hear a reward response for a correct answer, or an encouraging response for an incorrect answer. 3. After three …

Text truncated - open the document above for the full version.

vtech Wech Electronics Ltd Letter of Aqencv To Whom lt May Concern: l, an officer of VTech Electronics Limited do hereby authorize lntertek Testing Services (Mr. Terry Chan) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice. I further certify that no party (as defined in in S1.2002(b) of CFR 47, 2006) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,862. Dated this ,30th day of Mav 2011 . ANTHONY TSUI Printed Title Senior Enqineerinq Manaqer BlF,f ai Ping Industrial Centre, Block 1 57 Ting Kok Road, Tai Po, Hong Kong Tel (852) 2680 1000 Fax (852) 2667 0202 www.vtech.com

INTERTEK TESTING SERVICE Report No.: HK11041500-1 FCC ID: G2R-126400 Equipment Photographs Model : 1264 (External)

FCC ID: G2R-126400 Labeling Artwork 4 cm 1.9 cm 2.3 cm 0.9 cm

INTERTEK TESTING SERVICE Report No.: HK11041500-1 FCC ID: G2R-126400 Equipment Photographs Model: 1264 (Internal) INTERTEK TESTING SERVICE Report No.: HK11041500-1 FCC ID: G2R-126400 Equipment Photographs Model: 1264 (Internal) INTERTEK TESTING SERVICE Report No.: HK11041500-1 FCC ID: G2R-126400 Equipment Photographs Model: 1264 (Internal) INTERTEK TESTING SERVICE Report No.: HK11041500-1 FCC ID: G2R-126400 Equipment Photographs Model: 1264 (Internal)

Technical Description of TX (FCC ID: G2R-126400) 1. MCU GPC11024 (U1) accepts the input data from keyboard and then encode the data to the RF amplifier (U2) input. 2. IC GRPC205A (U2), crystal Y1 (27.145MHz) and associated network act as the RF amplifier. 3. LED (D1) and associated network act as the light indicating pointer when keyboard is used. 4. Q2 and associated network act as the 3V regulator for the whole circuit.

GPC11024 + GPRC205.sch-1 - Fri May 13 11:19:57 2011 27.145MHz 27.145MHz D1Remark: LED (D1) is used for pointer FCC ID: G2R - 126400

INTERTEK TESTING SERVICES Report No. : HK11041500-1 FCC ID: G2R-126400 Bandedge Plot – Pursuant to FCC Part 15 Section 15. 227 Requirement (Pass)

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report No.: HK11041500-1 VTech Electronics Limited Application For Certification (Original Grant) (FCC ID: G2R-126400) Transmitter Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Engineer Chan Chi Hung, Terry Assistant Supervisor Date: June 10, 2011 INTERTEK TESTING SERVICES Report No.: HK11041500-1 FCC ID: G2R-126400 i GENERAL INFORMATION VTECH ELECTRONICS LIMITED MODEL: 1264 FCC ID: G2R-126400 Grantee: VTech Electronics Limited Grantee Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. Contact Person: Anthony Tsui Tel: 26801201 Fax: 26801228 e-mail: [email protected] Manufacturer: N/A Manufacturer Address: N/A Brand Name: VTech Model: 1264 Type of EUT: Transmitter Description of EUT: Remote Racer Smart Car Serial Number: N/A FCC ID: G2R-126400 Date of Sample Submitted: April 27, 2011 Date of Test: May 09, 2011 Report No.: HK11041500-1 Report Date: June 10, 2011 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: HK11041500-1 FCC ID: G2R-126400 ii SUMMARY OF TEST RESULT VTECH ELECTRONICS LIMITED MODEL: 1264 FCC ID: G2R-126400 TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 Pass Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for Remote Control) 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement(for 902- 928MHz or 2.4GHz) 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 N/A Receiver / Digital Device Radiated Eissions 15.109 / ICES-003 N/A Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. INTERTEK TESTING SERVICES Report No.: HK11041500-1 FCC ID: G2R-126400 iii Table of Contents 1.0 General Description....................................................................................... 1 1.1 Product Description .......................................................................................... 1 1.2 Related Submittal(s) Grants.............................................................................. 1 1.3 Test Methodology............................................................................................. 1 1.4 Test Facility ...................................................................................................... 1 2.0 System Test Configuration ............................................................................ 2 2.1 Justification ...................................................................................................... 2 2.2 EUT Exercising Software.................................................................................. 2 2.3 Special Accessories ......................................................................................... 2 2.4 Equipment Modification .................................................................................... 2 2.5 Measurement Uncertainty................................................................................. 2 2.6 Support Equipment List and Description ........................................................... 3 3.0 Emission Results ........................................................................................... 3 3.1 Field Strength Calculation...............................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Report No: HK11041500-1 FCC ID: G2R-126400 Configuration Photographs Worst-Case Radiated Emissions (Front View) Model: 1264 Radiated Emission HK11041500-1 Model: 1264 Side A INTERTEK TESTING SERVICE Report No: HK11041500-1 FCC ID: G2R-126400 Configuration Photographs Worst-Case Radiated Emissions (Rear View) Model: 1264 Radiated Emission HK11041500-1 Model: 1264 Side B
