Parents’ Guide For additional help, please visit vtechkids.com/tutorials/kidibuzz 91-003960-005 USCA 1 Getting Started Register your KidiBuzz ™ 3 device to access: • The full collection of educational games that come with this device • Two FREE apps from Learning Lodge ® , a VTech online store 1 • Kid-friendly messaging with the KidiCom Chat™ app • Access to parent settings where you can manage your child’s apps, set time limits, and more 1. CHARGE your KidiBuzz ™ 3 device using either the included power adapter plugged in to the wall, or the included USB cord plugged into a computer. Do not use a third-party adapter. The Charging Indicator Light may flash red and green if the battery is very low, then will turn red to indicate it is charging, and will turn green when it is fully charged in about 3.5 hours. Please ensure the battery is fully charged before the first use or before attempting a system update. 2. SET UP the device by following the on-screen prompts to connect to Wi-Fi 2 , set your time zone, and register with a Learning Lodge ® account. 3. UNLOCK the KidiCom Chat™ app after system registration and install the app on your mobile device. 4. ENJOY fun learning games, silly photos, kid-friendly messaging and more! 1 For first-time registration and designated content only 2 Supports Wi-Fi 802.11 b/g/n only 2 Microphone Touch Screen MagLensRotatable Camera Key Features Headphone JackSpeaker Micro-USB/Charging Port microSD Card Slot (microSD card not included) Volume + / - Buttons Charging Indicator Light Power Button 3 Parent Settings To enter Parent Settings, touch the Parents icon on the second page of your child's home screen. From Parent Settings, you can control the way your child plays by adding or removing apps, setting time limits, managing access to the Web, and adjusting device settings. Adding or Removing Apps Browse the Learning Lodge ® store for a selection of age-appropriate educational apps that have been approved by VTech learning experts. If you’re looking for common Android apps from outside of the VTech ecosystem, go to Device Settings and select Get More Apps to find instructions to install a third-party app store. You can manage apps and content through the following options: • Storage Manager—Manage your device's memory. • VTech App Manager—Download or uninstall any content purchased from Learning Lodge ® . You can also uninstall some of the apps that are included with the system. • App Settings—Give permission for third-party apps you download to appear on your child's home screen. Setting Time Limits Select Time Controls to limit the amount of time your child can play per day or to mark certain hours of the day as off limits. Managing Web Access This Web browser is OFF until enabled through the passcode-protected App Settings. Although VTech makes every effort to ensure a kid-friendly browsing environment, the content of individual websites may change without VTech's knowledge. Please be sure to monitor your child's online experience and keep your passcode secret. If You Forget Your Parent Settings Passcode If you forget your Parents passcode, go to the passcode screen and enter 9876543210. We'll send a message to the email address provided at registration. 4 Additional Information Using the MagLens • The MagLens can be used to help take close-up photos. To use it, first rotate the camera unit so it's pointing away from the screen, then slide the MagLens switch to position the MagLens over the camera. • Be sure to only use the MagLens switch to move the MagLens to avoid accidentally smudging the camera lens or MagLens. When the MagLens is in position, open the Camera app and hold the device steady at a distance of approximately one to two inches away from your subject. When the MagLens is positioned over the camera, you'll see a special icon in the Camera app to let you know. Charging the Device • To charge the device, first connect the included USB cable or power adapter to the KidiBuzz™ 3 device by inserting the smaller, micro-USB end into the micro-USB port on the device. • If using the power adapter, plug it in to a power outlet. If using the micro-USB cable, plug it in to a computer's USB port (computer not included). • This toy contains batteries that are non-replaceable. Australia/New Zealand WARNING! SAFETY INSTRUCTIONS, PLEASE READ THOROUGHLY BEFORE GIVING THIS PRODUCT TO A CHILD. KEEP AWAY FROM FIRE OR HEAT SOURCE. BATTERIES CANNOT BE REPLACED. The batteries within this toy are permanently encased. Before giving this toy to a child make sure there are no signs of damage. Regularly check the toy and dispose of it immediately if there are any signs of damage. Do not dispose of the toy in a fire, as the batteries may leak and explode. Keep batteries safely out of children’s reach before disposing of them via a safe disposal system. Micro-USB Port ONOFF 5 Guidelines for Charging With Micro-USB Cable Only charge this device using the included micro-USB cable connected to a computer or with the included adapter. Do not charge using a third- party adapter. Before use, inspect the cord to confirm that it is in good condition and that there are no breaks or exposed wires. Ensure there are no particles or liquid (water, juice, etc.) in either of the connectors before plugging in either end of the cable. The device should be completely dry with no debris in the cable connectors when charging. Plug in the cable securely, in the correct orientation. If the device is on when plugged in, a dialog box may open on your computer to allow you to access the device's drive. Never leave the device unattended while charging. Do not charge your device on soft surfaces, as they can trap heat around the device. Typical charging time is between 2-3 hours if the battery is fully depleted. Disconnect the device when it is fully charged. Do not leave the device charging for more than 4 hours. Power Adapter Specifications Output: 5V DC WARNING: Only use the included power supp…

Text truncated - open the document above for the full version.

91-003960-002 FRCA Guide de démarrage rapide Le manuel complet de KidiCom ® Advance 3.0 est disponible en ligne sur le site : https://www.vtech-jouets.com/manuels 1 1. Pour commencer L'enregistrement du KidiCom ® Advance 3.0 est nécessaire pour : • Bénéficier de deux téléchargements supplémentaires gratuits sur l'Explor@ Park parmi une large sélection d'applications. 1 • Utiliser l'application KidiCom Chat™ et profiter des conversations instantanées sécurisées. • Accéder aux contrôles parentaux pour gérer les applications de l'enfant, limiter le temps d'utilisation, et bien plus encore. 1. CHARGER 2 le KidiCom ® Advance 3.0 à l'aide du câble micro-USB inclus et du transformateur. La led rouge Témoin de chargement s’allume pour indiquer que le KidiCom ® Advance 3.0 est en charge. Plusieurs heures peuvent être nécessaires pour recharger complètement l'appareil. L'appareil est complètement chargé lorsque la led Témoin de chargement devient verte. Une led qui clignote rouge et vert signifie que le niveau de la batterie est très faible. 2. PARAMÉTRER le KidiCom ® Advance 3.0 pour connecter le Wi-Fi 3 , sélectionner la date et l'heure et créer un mot de passe pour accéder aux Contrôles parentaux. 3. TÉLÉCHARGER et installer les mises à jour sur le KidiCom ® Advance 3.0. Cette étape est indispensable pour optimiser les performances du jouet. Ne pas débrancher ni éteindre l’appareil pendant la mise à jour et l'installation. 4. ACTIVER KidiCom Chat à la fin de l'inscription pour installer l'application sur un portable. 5. KidiCom ® Advance 3.0 est maintenant prêt à jouer ! 1 Uniquement lors de la première inscription et valable sur certaines applications. 2 La batterie est normalement chargée lors de la première utilisation. Se référer à la section Chargement de l'appareil à la page 4 de ce guide. 3 Compatible uniquement sur les réseaux Wi-Fi 802.11 b/g/n. 2 Microphone Écran tactile capacitif Double objectifAppareil photo rotatif Fonctionnalités Prise casque Jack Haut-parleurs Attache dragonne Port micro-USB Emplacement carte microSD (carte microSD non incluse) Boutons Volume sonore + et - Led Témoin de chargement Bouton Marche/Arrêt 3 Contrôles parentaux Depuis les Contrôles parentaux, vous pouvez gérer le contenu des jeux de votre enfant, limiter le temps d'utilisation, l'accès à Internet et modifier les réglages de l'appareil. Pour accéder aux Contrôles parentaux, touchez l'icône Parents sur la 2ème page du menu d'accueil, puis entrer le mot de passe dans la petite fenêtre à l'écran. Ajouter ou supprimer du contenu Naviguer sur l'Explor@ Park pour choisir des applications éducatives présélectionnées par VTech ® . Pour choisir des applications Android non présélectionnées par VTech ® , se diriger dans les Contrôles parentaux, puis Options, choisir Télécharger d'autres applications et suivre les instructions de téléchargement provenant d'une source tierce. Pour visualiser les contenus ajoutés, vous pouvez vous rendre sur : • Le gestionnaire des applications VTech ® —Ici vous pouvez télécharger ou désinstaller les applications achetées depuis l'Explor@ Park. Vous pouvez aussi désinstaller du contenu intégré lors de l'achat de l'appareil. • Le gestionnaire des applications—Le contenu acheté à partir d'une plateforme tierce ne sera pas visible sur le profil de votre enfant avant que vous ne lui donniez l'autorisation d'utiliser l'application. Réguler le temps d'utilisation Sélectionner une limite de temps d'utilisation à partir des Contrôles parentaux pour limiter un temps d'utilisation quotidienne ou pour interdire l'utilisation de l'appareil à certaines heures. Pour plus d'information sur le bon usage des écrans, merci de consulter notre site : https://www. vtech-jouets.com/conseils_ecrans_enfants Contrôle du navigateur Internet VTech ® a sélectionné un large choix de sites sécurisés pour votre enfant, classés par catégories d'âge. Vous pouvez rajouter ou supprimer des sites en sélectionnant "Sites Internet approuvés" dans le menu contrôles parentaux. Options Il existe d'autres options dans les Contrôles parentaux comme paramétrer la connexion Wi-Fi de l'appareil, modifier le profil de l'enfant, modifier le compte Explor@ Park et gérer les options avancées du système. Pour retrouver le mot de passe des contrôles parentaux Pour retrouver le mot de passe des contrôles parentaux, entrer le code 9876543210 sur l'écran des contrôles parentaux. Un message sera envoyé à votre adresse email. 4 Autres informations Utiliser le double objectif • Le double objectif permet de prendre des photos de très près. Pour utiliser cette fonction, faire glisser le curseur situé en haut de l'appareil vers la position Marche (comme indiqué sur le schéma). • N'utiliser ce curseur que lorsqu'il est nécessaire. Éviter de le manipuler trop régulièrement. Lorsque l'objectif est en position Marche. se diriger dans l'application Photos du menu et prendre une photo à une distance de 2 à 5 cm de l'objet. Lorsque l'objectif est en position Marche, cette icône apparaît en haut de l'écran. Chargement Important : ne pas ouvrir le produit pour changer la batterie. La batterie n'est ni amovible, ni remplaçable. Utiliser le câble micro USB (inclus) : - Insérez l'extrémité la plus large du câble dans le port USB de votre ordinateur et la plus petite dans le port micro USB du KidiCom ® Advance 3.0. OU Utiliser le transformateur secteur (inclus) : - Insérez le câble dans le KidiCom ® Advance 3.0 puis branchez le transformateur secteur à une source d'alimentation. Transformateur : Note : le transformateur secteur n'est pas un jouet et doit être manipulé par un adulte. Il est préférable de ne pas utiliser KidiCom ® Advance 3.0 pendant qu'il charge. Ne pas charger KidiCom ® Advance 3.0 pendant une période prolongée ou pendant toute la nuit. Port micro-USB MARCHEARRÊT Transformateur secteur 5 ATTENTION : Pour la sécurité de votre enfant, débarrassez-vous de tous les produits d’emballage tels que rubans adhésifs, feuilles de plastique, attaches…

Text truncated - open the document above for the full version.

Difference Declaration Original Family Model No. : 5411 Deviate Part no. : 5465 To whom it may concern, We, Vtech Electronics Ltd., would like to declare that the model 5411 have deviate part no. , as mention above, which are identical in electrical circuit design and PCB layout. The only difference are model name, language, cosmetic color and no. of books bundle Model No. Model Name color Version Language Features 5411 KidiBuzz 3 Black US English 5411 KidiBuzz 3 Purple US English 5411 KidiBuzz 3 Black CAN English 5411 KidiBuzz 3 Purple CAN English 5411 KidiBuzz 3 Black Germany German 5411 KidiBuzz 3 Purple Germany German 5411 KidiCom advance 3.0 Black UK English 5411 KidiCom advance 3.0 White&Pink UK English 5411 KidiCom advance 3.0 Black FR French 5411 KidiCom advance 3.0 White&Pink FR French 5411 KidiCom advance 3.0 Black CAN French 5411 KidiCom advance 3.0 White&Pink CAN French 5411 KidiCom advance 3.0 Black SP Spanish 5411 KidiCom advance 3.0 White&Pink SP Spanish 5411 KidiCom advance 3.0 Black NL Dutch 5411 KidiCom advance 3.0 White&Pink NL Dutch 5465 KidiCom MAX 3.0 Black FR French 5465 KidiCom MAX 3.0 White&Pink FR French 5465 KidiCom MAX 3.0 Black NL French 5465 KidiCom MAX 3.0 White&Pink NL French Note: 5411 and 5465 share same main board PCBA, the cases are different. There’s a Marco Lens with switch on 5411 Camera, while there’s no Marco Lens on 5465. Sincerely yours, Applicant : Vtech Electronics Ltd. Address : 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, TaiPo, Hong Kong Signature : Name and title : Sun Shouliang Email : [email protected] Tel : 852 26801189

5411 KidiBuzz G3_Engraving_V4 USB door: 30-050969 Bottom Cab: 30-050962 凹面高光 凹面高光 凹面高光 Top Cab30-050961 凹面高光 5V 1A THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. MADE IN CHINA TM & © 2021 VTech FCC ID: G2R-5411 IC: 1135D-5411 Model: 5411 Battery is not replaceable. La batterie n'est pas remplaçable. VTech PO Box 10042, 6000 GA Weert, The Netherlands Napier Court, Abingdon, OX14 3YT, UK Marco Lens Cover: 30-050965

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN218664 002 Auftrags-Nr.: Order no.: 168307031 Seite 1 von 31 Page 1 of 31 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-02-12 Auftraggeber: Client: VTech Electronics Ltd 23/F., Block 1 Tai Ping Industrial Centre, 57 Ting Kok Road, Tai Po, Hong Kong Prüfgegenstand: Test item: KidiBuzz 3, KidiCom advance 3.0 Bezeichnung / Typ-Nr.: Identification / Type no.: 5411, 80-5411xx (xx=00~99, see model differences for details) (Trademark: Vtech) Auftrags-Inhalt: Order content: FCC approval Prüfgrundlage: Test specification: FCC 47 CFR § 2.1093 IEEE Std 1528-2013 IC RSS-102 Issue 5: March 2015 Published RF exposure KDB procedures Wareneingangsdatum: Date of sample receipt: 2021-03-10 Please refer to Photo Document Prüfmuster-Nr.: Test sample no.: A003000308-001 Prüfzeitraum: Testing period: 2021-03-11 - 2021-03-11 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Jackson Yang genehmigt von: authorized by: X Signed by: Winnie Hou Datum: Date: 2021-04-16 Ausstellungsdatum: Issue date: 2021-04-16 Stellung / Position Project Engineer Stellung / Position Technical Certifier Sonstiges / Other: FCC ID: G2R-5411 IC :1135D-5411 HVIN: 5411 Note: There is only one model number 5411 for ISED. Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged: * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhalt P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = failed a.m. test specifications(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] http://www.tuv.com Produkte Products Prüfbericht - Nr.: Test Report No. CN218664 002 Seite 2 von 31 Page 2 of 31 Table of Contents 1. GENERAL INFORMATION ...................................................................................................................... 4 1.1. STATEMENT OF COMPLIANCE .............................................................................................................. 4 1.2. EQUIPMENT UNDER TEST (EUT) INFORMATION .................................................................................... 5 1.2.1. General Information...................................................................................................................... 5 1.2.2. Wireless Technologies ................................................................................................................. 5 1.2.3. List of Accessory .......................................................................................................................... 5 1.3. MAXIMUM CONDUCTED POWER ........................................................................................................... 5 2. TEST SITES ........................................................................................................................................ 6 2.1. TEST FACILITIES ................................................................................................................................. 6 2.2. AMBIENT CONDITION ........................................................................................................................... 6 2.3. LIST OF TEST AND MEASUREMENT INSTRUMENTS................................................................................. 6 3. MEASUREMENT UNCERTAINTY............................................................................................................. 7 4. TEST SPECIFICATION, METHODS AND PROCEDURES ............................................................................. 8 5. SAR MEASUREMENT SYSTEM ............................................................................................................. 9 5.1. DEFINITION OF SPECIFIC ABSORPTION RATE (SAR) ............................................................................. 9 5.2. SPEAG DASY SYSTEM ..................................................................................................................... 9 5.2.1. Robot ..........................................................................................................................................10 5.2.2. Probes ........................................................................................................................................11 5.2.3. Data Acquisition Electronics (DAE) ............................................................................................11 5.2.4. Phantoms ...................................................................................................................................12 5.2.5. Device Holder .............................................................................................................................13 5.2.6. System Validation Dipoles .........................................................................................................13 5.2.7. Tissue Simulating …

Text truncated - open the document above for the full version.

Test Laboratory: TÜV Rheinland IoT Excellence CenterDate: 2021/3/11 System Check-D2450V2_H2450 DUT: Dipole 2450 MHz D2450V2 SN:1014 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz; σ = 1.872 S/m; ε r = 38.152; ρ = 1000 kg/m 3 DASY5 Configuration: -Probe: EX3DV4 -SN7506; ConvF(7.58, 7.58, 7.58) @ 2450 MHz; Calibrated: 2020/5/29 -Sensor-Surface: 1.4mm (Mechanical Surface Detection) -Electronics: DAE4 Sn1557; Calibrated: 2020/5/27 -Phantom: SAM 1; Type: QD 000 P40 CB; Serial: 1961 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) Pin=250 mW/Area Scan (71x81x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 22.7 W/kg Pin=250 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 111.7 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 27.2 W/kg SAR(1 g) = 13.1 W/kg; SAR(10 g) = 6.07 W/kg Maximum value of SAR (measured) = 21.8 W/kg

Test Laboratory: TÜV Rheinland IoT Excellence CenterDate: 2021/3/11 P01 802.11b_Rear Face_0.5cm_Ch11 DUT: EUT Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2462 MHz; σ = 1.881 S/m; ε r = 38.13; ρ = 1000 kg/m 3 DASY5 Configuration: -Probe: EX3DV4 -SN7506; ConvF(7.58, 7.58, 7.58) @ 2462 MHz; Calibrated: 2020/5/29 -Sensor-Surface: 1.4mm (Mechanical Surface Detection) -Electronics: DAE4 Sn1557; Calibrated: 2020/5/27 -Phantom: SAM 1; Type: QD 000 P40 CB; Serial: 1961 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) - Area Scan (101x161x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.851 W/kg - Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.796 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 0.941 W/kg SAR(1 g) = 0.469 W/kg; SAR(10 g) = 0.229 W/kg Maximum value of SAR (measured) = 0.761 W/kg

Justification for Extended SAR Dipole Calibrations Dipole Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) Head 2450 MHz Jun. 07, 2018 -24.9 - 55 - Apr. 17, 2019 -24.6 -1.20 52.2 -2.8 Note: The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification results meet the requirement of extended calibration. Justification for Extended SAR Dipole Calibrations Dipole Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) Body 2450 MHz Jun. 07, 2018 -27.7 - 49.8 - Apr. 17, 2019 -27.8 0.36 49.9 0.1 Note: The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification results meet the requirement of extended calibration. Justification for Extended SAR Dipole Calibrations Dipole Date of Measurement Return Loss (dB) Delta (%) Impedance(ohm) Delta(ohm) Head 2450MHz Jun 07, 2018 -24.9 - 55.0 - May 22, 2020 -26.0 4.22 53.1 -1.93 Note: The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification results meet the requirement of extended calibration. Justification for Extended SAR Dipole Calibrations Dipole Date of Measurement Return Loss (dB) Delta (%) Impedance(ohm) Delta(ohm) Body 2450Mhz Jun 07, 2018 -27.7 - 49.8 - May 22, 2020 -29.9 7.76 47.0 -2.85 Note: The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification results meet the requirement of extended calibration.
