GKM-XT1040S6Wireless Door Sensor

XT1040S6 Product Manual Page 1 | 6 CONFIDENTIAL AND PROPRIETARY XT1040S6 Product Manual Revised September 27, 2023, Revision A01 XT1040S6 Product Manual Page 2 | 6 CONFIDENTIAL AND PROPRIETARY TABLE OF CONTENTS 1. Functional Description ____________________________________________________________________ 3 2. Installation ______________________________________________________________________________ 4 3. Regulatory Statements ____________________________________________________________________ 5 3.1. FCC _________________________________________________________________________________ 5 3.2. IC __________________________________________________________________________________ 6 3.3. CE __________________________________________________________________________________ 6 3.4. California Proposition 65 Warning: ________________________________________________________ 6 XT1040S6 Product Manual Page 3 | 6 CONFIDENTIAL AND PROPRIETARY 1. FUNCTIONAL DESCRIPTION Xirgo’s XT1040S6 is a wireless door sensor which monitors the state of the trailer door and communicates with Xirgo XT1320. The versatile XT1040S6 offers several mounting options to support swing or roll-up doors. The door sensor utilizes an on-board accelerometer or magnetic sensor to detect door status and report door state changes via Bluetooth to the XT1320. Mechanical Sensor Dimensions 2.15” x 5.7” x 1.0” (5.46 x 14.48 x 2.54 cm) Case Material PC+PBT IP Rating IP66 Vibration SAE J1455 Operating Temperature -40 °F to 140 °F (-40 °C to 60 °C) Power Specifications Batteries 2 L91 Replaceable Lithium AA Certifications FCC, IC XT1040S6 Product Manual Page 4 | 6 CONFIDENTIAL AND PROPRIETARY 2. INSTALLATION Basic install procedure in trailers: Install the length of the door sensor parallel to the length of the trailer on the driver side of the roll up door on the top panel. The push button side faces the driver side wall. Gore vent faces out into the cargo area, away from the driver side wall. 1. Find an area 1.5 inches from the top of the roll-up door top panel and 1.5 inches away from the roll-up door hinge. 2. Clean the surface for the door sensor with 50/50 Isopropyl alcohol or similar such as brake cleaner to clean the surface. 3. Rough up the surface with #000 steel wool and/or a blow torch if the temperature is near 30 °F. 4. Peel back the VHB tape cover to apply and install the door sensor. 5. Push the door sensor button for two seconds and then release. The LEDs will begin to blink. 6. Push the button for six LED blinks. The LEDs will go off to indicate successful activation. XT1040S6 Product Manual Page 5 | 6 CONFIDENTIAL AND PROPRIETARY 3. REGULATORY STATEMENTS 3.1. FCC This equipment with FCC-ID: GKM-XT1040S6 and IC: 10281A-XT1040S6, Model: XT1040S6 is subject to the Federal Communications Commission (FCC) and Industry Canada (IC) rules. NOTICE: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made to this equipment not expressly approved by Xirgo Technologies, LLC may void the FCC authorization to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Radio frequency radiation exposure Information: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. XT1040S6 Product Manual Page 6 | 6 CONFIDENTIAL AND PROPRIETARY 3.2. IC Antenna Statement Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Licence exempt This device complies with Industry Canada licence-exempt RSS standard(s). Operation is sub…

Text truncated - open the document above for the full version.

Letter of Authorization and Anti- Drug Statement Applicant Name: Xirgo Technologies, LLC Address: 1461 Lawrence Drive, Suite 1, Thousand Oaks, CA 91320 Product Name: XT1040S6 Model Number: XT1040S6 FCC ID: GKM-XT1040S6 We authorize: CETECOM Inc., to act on our behalf on all matters concerning the above named equipment. We declare that CETECOM Inc. is allowed to forward all information related to the approval project to the Federal Communications Commission and discuss any issues concerning the approval application. The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? ☒ Yes I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. Signature of Authorized Person Filing: Edward Gabrelian Title: Manager, Hardware Engineering Date: 09/06/2023

Xirgo Technologies, LLC 1461 Lawrence Drive, Suite 1 Thousand Oaks, CA 91307 Federal Communication Commission 7435 Oakland Mills Road Columbia, MD 21046 September 6, 2023 Attestation Statement according to 2.911(d)(5)(i) and 2.911(d)(5)(ii) FCC ID: GKM-XT1040S6 TO WHOM IT MAY CONCERN: Hereby we certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Further we certify that, as of the date of the filing of the application, Xirgo Technologies, LLC is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, _______________ Xirgo Technologies, LLC 1461 Lawrence Drive, Suite 1 Thousand Oaks, CA 91307 Edward Gabrelian, Engineering Manager Phone: 805-568-8466 Email: [email protected] For information on Covered equipment, refer: • 986446 D01 Covered Equipment v01 • FCC 22-84 • List of Equipment and Services Covered By Section 2 of The Secure Networks Act | Federal Communications Commission (fcc.gov)

Xirgo Technologies, LLC 1461 Lawrence Drive, Suite 1 Thousand Oaks, CA 91307 Federal Communication Commission 7435 Oakland Mills Road Columbia, MD 21046 September 6, 2023 Attestation Statement according to 2.911(d)(7) FCC ID: GKM-XT1040S6 TO WHOM IT MAY CONCERN: Xirgo Technologies, LLC with FCC Registration Number (FRN) 0021512173 Certifies that, as of the date of this filing of the application with the TCB, Xirgo Technologies, LLC is our designated US agent for service of process for the above referenced FCC ID. Xirgo Technologies, LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. Xirgo Technologies, LLC with FCC Registration Number (FRN) 0021512173 Accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above referenced FCC ID. Sincerely _______________ Xirgo Technologies, LLC 1461 Lawrence Drive, Suite 1 Thousand Oaks, CA 91307 Edward Gabrelian, Engineering Manager Phone: 805-568-8466 Email: [email protected] _______________ Xirgo Technologies, LLC 1461 Lawrence Drive, Suite 1 Thousand Oaks, CA 91307 Edward Gabrelian, Engineering Manager Phone: 805-568-8466 Email: [email protected]

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Date: 09/06/2023 Subject: Request for Permanent Confidentiality FCC ID: GKM-XT1040S6 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, and KDB 726920, Xirgo Technologies, LLC hereby requests permanent confidentiality for documents filed under the following exhibit types: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational description These items contain detailed system and equipment description and related information about the product which Xirgo Technologies, LLC considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Xirgo Technologies, LCL also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best Regards, _______________________________ Signature Name: Edward Gabrelian Title: Manager, Hardware Engineering Company Name: Xirgo Technologies, LLC Address: 1461 Lawrence Drive, Suite 1, Thousand Oaks, CA 91320

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Date: 09/06/2023 Subject: Request for Short Term Confidentiality FCC-ID: GKM-XT1040S6 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, Xirgo Technologies, LLC hereby requests short term confidentiality for documents filed under the following exhibit types: 1. Internal Photographs 2. Test Setup Photos 3. User Manual until the product will be publicly announced. Short term confidentiality release date / period: 180 Days These items contain detailed system and equipment description and related information about the product which Xirgo Technologies, LLC considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Xirgo Technologies, LLC also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are informed and aware of our obligation that we have to inform the involved TCB in written and in due time if we intend to market the product prior to the above specified confidentiality release date so that the short term confidentiality classification can be reset prior to product launch. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best Regards, ____________________________________ Signature Name: Edward Gabrelian Title: Manager, Hardware Engineering Company Name: Xirgo Technologies, LLC Address: 1461 Lawrence Drive, Suite 1, Thousand Oaks, CA 91320

Label Material: LABEL MATERIAL: 3M™ THERMAL TRANSFER POLYESTER LABEL MATERIAL 7816 Label Information Label location

Radio Frequency Exposure Evaluation Report FOR: Xirgo Technologies LLC Model: XT1040S6 Product Description: Wireless Door Sensor FCC ID: GKM-XT1040S6 IC:10281A-XT1040S6 Per: CFR Part Part1 (1.1307 &1.1310), Part 2 (2.1091), FCC KDB 447498 D01 General RF Exposure Guidance v06 ISEDC RSS-102 Issue 5 Report number: EMC_XIRGO_193_23001_FCC_ISED_RF_Exposure DATE: 2023-09-29 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected] http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V5.0 2015-10-27 © Copyright by CETECOM Test Report #: EMC_XIRGO_193_23001_FCC_ISED_RF_Exposure FCC ID: GKM-XT1040S6 Date of Report 2023-09-29 Page 2 of 9 IC: 10281A-XT1040S6 Page 2 of 9 1Assessment This RF Exposure evaluation report provides evidence for compliance of the below identified device with the RF Exposure limits for mobile devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091) and IC standard RSS-102 issue 5 under worst case conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated respectively, where relevant. The device meets the limits as stipulated by the above given FCC and IC rule parts based on available specifications for worst case conditions at 20cm distance to the body. CompanyDescriptionModel Xirgo Technologies LLCWireless Door SensorXT1040S6 Report reviewed by: TCB Evaluator 2023-09-29Compliance Arndt Stoecker (Director of Regulatory Services) Date Section Name Signature Responsible for the Report: 2023-09-29Compliance Cheng Song (EMC Engineer) Date Section Name Signature Test Report #: EMC_XIRGO_193_23001_FCC_ISED_RF_Exposure FCC ID: GKM-XT1040S6 Date of Report 2023-09-29 Page 3 of 9 IC: 10281A-XT1040S6 Page 3 of 9 2Administrative Data 2.1Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department:Compliance Street Address:411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone:+1(408) 586 6200 Fax:+1 (408) 586 6299 Director of Regulatory Services: Arndt Stoecker Responsible Project Leader: Akanksha Baskaran 2.2Identification of the Client / Manufacturer Client’s Name:Xirgo Technologies, LLC. Street Address: 1461 Lawrence Dr, Ste 1 City/Zip Code Thousand Oaks, CA 91320 Country USA Identification of the Manufacturer Manufacturer’s Name: Same as Client Manufacturers Address: City/Zip Code Country Test Report #: EMC_XIRGO_193_23001_FCC_ISED_RF_Exposure FCC ID: GKM-XT1040S6 Date of Report 2023-09-29 Page 4 of 9 IC: 10281A-XT1040S6 Page 4 of 9 3Equipment under Assessment Product Description: Wireless Door Sensor Model Name : XT1040S6 HW Version : XT1040S6-001 SW Version : XT1040S6-01 FCC ID : GKM-XT1040S6 IC :10281A-XT1040S6 Frequency Range / number of channels: Nominal band: 2400 MHz –2483.5 MHz; Center to center: 2402 MHz (ch 0) –2480 MHz (ch 39), 40 channels Radio Information: Bluetooth Low Energy (BLE): Module: Silicon Labs EFR32BG22 Modulation: Bluetooth 5.3, GFSK Antenna Information as declared: Trace Antenna, Max Gain 3dBi Max. Peak Output Power:7.34dBm Conducted Power Other Radios included in the device NA Power Supply/ Rated Operating Voltage Range 2 L91 Replaceable Lithium AA: 2.7V to 3.6VDC Operating Temperature Range Low : -40 ºC to ºC High +60 ºC Sample Revision ☐Production ☒ Pre-Production EUT Dimensions 55 mm x 145mm x 25.4mm EUT Diameter ☒< 60 cm ☐ Other __________ Test Report #: EMC_XIRGO_193_23001_FCC_ISED_RF_Exposure FCC ID: GKM-XT1040S6 Date of Report 2023-09-29 Page 5 of 9 IC: 10281A-XT1040S6 Page 5 of 9 4RF Exposure Limits and FCC and IC Basic Rules 4.1Routine Environmental Evaluation Categorical Exclusion Limits acc. to FCC 1.1307(b)(3)(i)(B). Single RF sources is exempt if the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Test Report #: EMC_XIRGO_193_23001_FCC_ISED_RF_Exposure FCC ID: GKM-XT1040S6 Date of Report 2023-09-29 Page 6 of 9 IC: 10281A-XT1040S6 Page 6 of 9 4.2ISED Exemption Limits for Routine Evaluation – RF Exposure Evaluationper IC RSS-102 Issue 5 section 2.5.2 RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: below 20 MHz6 and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1 W (adjusted for tune-up tolerance); at or above 20 MHz and below 48 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 4.49/ƒ0.5 W (adjusted for tune-up tolerance), where ƒ is in MHz; at or above 48 MHz and below 300 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 0.6 W (adjusted for tune-up tolerance); at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10-2 ƒ0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; at or above 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 5 W (adjusted for tune-up tolerance). In these cases, the information contained in the RF…

Text truncated - open the document above for the full version.

A2LA Accredited IC recognized # 3462B CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected] http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 © Copyright by CETECOM FCC / ISED Test Report For: Xirgo Technologies LLC Model Name: XT1040S6 Product Description: Wireless Door Sensor FCC ID: GKM-XT1040S6 IC: 10281A-XT1040S6 Applied Rules and Standards: 47 CFR Part 15.247 (DTS) RSS-247 Issue 3 (DTSs) & RSS-Gen Issue 5 REPORT #: EMC_XIRGO_193_23001_FCC_15_247 DATE: 2023-09-29 Test Report #: EMC_XIRGO_193_23001_FCC_15_247 FCC ID: GKM-XT1040S6 Date of Report 2023-09-29 Page 2 of 41 IC :10281A-XT1040S6 TABLE OF CONTENTS 1ASSESSMENT .............................................................................................................................................................. 3 2ADMINISTRATIVE DATA ............................................................................................................................................... 4 2.1IDENTIFICATION OF THE TESTING LABORATORY ISSUING THE EMCTEST REPORT ........................................................................... 4 2.2IDENTIFICATION OF THE CLIENT ............................................................................................................................................. 4 2.3IDENTIFICATION OF THE MANUFACTURER ................................................................................................................................. 4 3EQUIPMENT UNDER TEST (EUT) ................................................................................................................................... 5 3.1EUTSPECIFICATIONS ......................................................................................................................................................... 5 3.2EUTSAMPLE DETAILS ......................................................................................................................................................... 5 3.3ACCESSORY EQUIPMENT (AE) DETAILS ................................................................................................................................... 6 3.4TEST SAMPLE CONFIGURATION ............................................................................................................................................. 6 3.5MODE OF OPERATION.......................................................................................................................................................... 6 4SUBJECT OF INVESTIGATION ...................................................................................................................................... 7 5MEASUREMENT RESULTS SUMMARY .......................................................................................................................... 7 6MEASUREMENT UNCERTAINTY.................................................................................................................................... 8 6.1ENVIRONMENTAL CONDITIONS DURING TESTING: ...................................................................................................................... 8 6.2DATES OF TESTING: ............................................................................................................................................................ 8 6.3DECISION RULE: ................................................................................................................................................................. 8 7MEASUREMENT PROCEDURES .................................................................................................................................... 9 7.1RADIATED MEASUREMENT .................................................................................................................................................... 9 7.2POWER LINE CONDUCTED MEASUREMENT PROCEDURE .......................................................................................................... 11 7.3RFCONDUCTED MEASUREMENT PROCEDURE ....................................................................................................................... 11 8TEST RESULT DATA .................................................................................................................................................. 12 8.1MAXIMUM PEAK CONDUCTED OUTPUT POWER ....................................................................................................................... 12 8.2POWER SPECTRAL DENSITY ............................................................................................................................................... 14 8.3DUTY CYCLE .................................................................................................................................................................... 16 8.4BAND EDGE COMPLIANCE .................................................................................................................................................. 17 8.5EMISSION BANDWIDTH 6DB AND 99%OCCUPIED BANDWIDTH ................................................................................................... 22 8.6RADIATED TRANSMITTER SPURIOUS EMISSIONS AND RESTRICTED BANDS ................................................................................... 26 9TEST SETUP PHOTOS ................................................................................................................................................ 40 10TEST EQUIPMENT AND ANCILLARIES USED FOR TESTING ......................................................................................... 40 11HISTORY ................................................................................................................................................................... 41 Test Report #: EMC_XIRGO_193_23001_FCC_15_247 FCC ID: GKM-XT1040S6 …

Text truncated - open the document above for the full version.

Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Issue Amendment History Name of Author Date 01 First Issue Nicolas Henriet 24-08-23 02 Simplified version Nicolas Henriet 29-08-23 03 FCC Nicolas Henriet 30-08-23 04 Signed off Nicolas Henriet 18-09-23 Author: (Name) Author: (Signature) Approver: (Name) Approver: (Signature) Date: Nicolas Henriet (please type this) Name of Approver (Job Title) (please type this) Document #: NH220823 Destination: Internal Use Only Reference: Issue: 04 Date: 24/08/2023 ECN #: Author: Nicolas Henriet Approver: [Manager] Contributors: Door sensor BLE antenna analysis Door sensor antenna analysis DOCUMENT NUMBER: NH240823 03 ISSUE LEVEL: 04 Door sensor Antenna Analysis NH240823 04.docx This hard copy is uncontrolled. Printed for reference only. Page 2 of 7 Table of Contents Table of Contents ..................................................................................................................................................... 2 1. Background ....................................................................................................................................................... 3 2. Return loss ........................................................................................................................................................ 3 3. Antenna Gain .................................................................................................................................................... 4 3.1. Instrumentation: ....................................................................................................................................... 4 3.2. Antenna parameters ................................................................................................................................. 4 3.3. Radiation patterns results in free space ................................................................................................... 5 3.3.1. At 2402MHz .................................................................................................................................. 5 3.3.2. At 2426MHz .................................................................................................................................. 6 3.3.3. At 2480MHz .................................................................................................................................. 6 4. Conclusion: ....................................................................................................................................................... 7 Door sensor antenna analysis DOCUMENT NUMBER: NH240823 03 ISSUE LEVEL: 04 Door sensor Antenna Analysis NH240823 04.docx This hard copy is uncontrolled. Printed for reference only. Page 3 of 7 1. Background This report presents results about BLE Antenna performances of door sensor device. Return loss, Diagram plot, average and peak gain results are provided for all frequencies of interest. The analysis is done in free space. 2. Return loss Door sensor antenna analysis DOCUMENT NUMBER: NH240823 03 ISSUE LEVEL: 04 Door sensor Antenna Analysis NH240823 04.docx This hard copy is uncontrolled. Printed for reference only. Page 4 of 7 3. Antenna Gain 3.1. Instrumentation: Category Mark Type Anechoic Test Site Internal Sensa…

Text truncated - open the document above for the full version.
