GMHHHPHand Held Programmer

TEST SERVICES TEST REPORT for SCULLY SIGNAL COMPANY COMPANY PRODUCT NAME SAFS HAND HELD PROGRAMMER FCC PART 15 SUBPART C CERTIFICATION Submitted to: Prepared by :Robert Foster J.J. Thiara Date :February 29, 2000 Scully Signal Company Test Report :TR2477.00 70 Industrial Way Purchase Order :8697 Wilmington, Massachusetts 01887 Number of Pages :19 I attest to the accuracy of the test data in this report: Technician/Test Engineer Test Services Approved Signatory Official responsible for marketing this equipment This report shall not be reproduced except in full without the written approval of Chomerics Test Services. TEST SERVICES Document #: TR2477.00 Date: February 29, 2000 Page 2 of 19 ADMINISTRATIVE DATA Purpose of Test :FCC Certification Test Specification :FCC Part 15 Subpart C Manufacturer :Scully Signal Company Manufacturer's Type or Model Number :SAFS Hand Held Programmer Number of Items Tested :One (1) Date of Test :January 12, 2000 Test Observed By :Robert Foster Affiliated With :Chomerics Test Services Test Location :Chomerics Open Area Test Site A Tests Conducted By :Robert Foster Condition of Test Equipment Upon Arrival :Good Customer's Equipment Returned VIA :Held for Certification TEST RESULTS The Scully Signal Company SAFS Hand Held Programmer meets the FCC Part 15 Subpart C 15.209 radiated emissions limits as configured and operated for testing. The Scully Signal Company SAFS Hand Held Programmer is a device that transmits data of mileage and usage via hand held remote. A 12 Volt DC battery was used for normal operation for emissions tests. The equipment under test was set up as illustrated on Form-CTS-014. TEST SERVICES Document #: TR2477.00 Date: February 29, 2000 Page 3 of 19 TEST SERVICES FACILITY INFORMATION Chomerics’ test facility is recognized under the National Voluntary Laboratory Accreditation Program (NVLAP) for NVLAP Codes 12/C01 and 12/R01. Tests within this report not conforming to 12/C01 and 12/R01 NVLAP Codes are not covered under Chomerics NVLAP accreditation. Chomerics’ test facility operates under the current revision of Chomerics Quality Assurance (QA) Manual Document Number QA002. The QA manual has been constructed to reflect a quality program in accordance with the requirements of the National Institute of Standards and Technology (NIST), ISO 9002, ISO Guide 25, NIST Handbook 150, EN 45001, MIL-I-45208A, MIL-STD-461D, 462D and Chomerics Quality Assurance Program (QAP). The QA manual outlines and describes the procedures for establishing and maintaining the quality of analysis, research, inspection, and testing within Chomerics Test Service (CTS). This test report does not represent an endorsement by the U.S. Government. The results and/or conclusions within this test report refer and/or apply only to the unit(s) tested as defined by this report. Measurements performed for this test are traceable to the National Institute of Standards and Technology (NIST) based on the fact that all test equipment used for the measurements were previously calibrated using standards traceable to NIST. No deviations, additions to, or exclusions from the test specification(s) were made. The system amplitude accuracy for the measurements made during the radiated emission tests was ±3dB. TEST SERVICES Document #: TR2477.00 Date: February 29, 2000 Page 4 of 19 TEST SITE DESCRIPTIONS The following is a description of Test Services’ Open Area Test Sites. Refer to Administrative Data on page 2; line 9 for the specific test site used for testing. O PEN A REA T EST S ITE A: Chomerics’ Open Area Test Site "A" is located in the parking lot behind the Seeger Building at Chomerics, 84 Dragon Court, Woburn, Massachusetts (Figure 1). The Open Area Test Site "A" enclosure is a wooden structure measuring 56 x 30 x 25 feet in size with galvanized steel sheet metal used as the ground plate. The structure is sized to allow 3 meter measurements and is heated and/or air conditioned. Photographs of the site and site attenuation data are on file with the Federal Communications Commission. The supporting structure used for support of the equipment under test is a wooden rotatable platform .8 meters high. A similar supporting structure is used for the measuring equipment. The mast supporting the antenna can be adjusted from one to four meters in height. OPEN AREA TEST SITE A Figure 1 3m Antenna Mast R eceiving Equipm ent Turntable & W ooden Table Line Cord 56 Ft 30 Ft Ramp K ey: = Power board D oor TEST SERVICES Document #: TR2477.00 Date: February 29, 2000 Page 5 of 19 O PEN A REA T EST S ITE B: Chomerics’ Open Area Test Site "B" is located in the lower parking lot behind the Seeger Building at Chomerics, 84 Dragon Court, Woburn, Massachusetts (Figure 2). Photographs of the site and site attenuation data are on file with the Federal Communications Commission. Parking is permitted on one side of Test Site "B" at a discrete distance from the imaginary ellipse. The Open Area Test Site “B” enclosure is a wooden structure measuring 56 X 30 X 25 feet in size with galvanized steel sheet metal used as the ground plane. The structure is sized to allow both 3 and 10 meter measurements and is heated and/or air conditioned. Photographs of the site and site attenuation data are on file with the Federal Communications Commission. The structure used to support equipment under test is a 14 foot diameter motorized turntable. The sheet metal surface is flush with the ground plane. To ground the turntable, 175 copper fingers (1" x 1.5") are mounted around the outer edge of the turntable using machine screws. The spring fingers are equally spaced and provide a uniform interface between the turntable metal surface and ground plane. When needed for tabletop equipment, a wooden table measuring 3 x 6 feet in size is positioned at the center of the turntable, at the proper height above the ground plane. The addition at the end of the Open Area Test Site “B” is the location for the test personnel and equipment to ensure…
