GUOTH04MMobile phone

English 3 Congratulations on your purchase of a TAG Heuer communication instrument. You have made an excellent choice by selecting a high performance tool of quality and endurance – a perfect combination of high-performance sports and elegance criteria that have been hallmarks of TAG Heuer’s commitment to its craft since 1860. Each TAG Heuer mobile phone is built to meet the strictest requirements. We paid same careful attention to details on this communication instrument from design, conception to finishing that we constantly do on our watches for more than 150 years. The materials used in our communication instrument make them exceptionally resilient, even when used under very rigorous conditions. Before the launch of each TAG Heuer product, it is put through 29 reliability and quality tests. With its modern, unique and timeless design, your new TAG Heuer communication instrument combines Swiss quality watchmaking tradition with technology. We hope it will bring you complete satisfaction. This document is a quick start guide providing information on your TAG Heuer communication instrument’s basic functions only. Please refer to the full user guide for a complete description of your TAG Heuer communication instrument functionalities. Welcome English English 45 Table of contents TAG Heuer packaging content Installing the SIM card and battery 1. On the back of the phone, move the locking battery button to the left and lift the battery door. 2. Insert SIM 1 and SIM 2 into the phone as shown. Ensure that both SIM cards are inserted properly. 3. To place the battery inside the phone, align the top of the battery with the corresponding slots in the phone and close the battery door. The battery and SIM card Note: Before using the phone for the first time, refer to the important safety and legal information section of this manual. 1 TAG Heuer phone, 1 warranty card, 1 quick user guide, 1 battery, 1 international charger, 1 data cable, 1 stereo headset, 1 pouch, 1 cleaning cloth, 1 micro SIM adapter, 1 nano SIM adapter. The packaging content may vary in accordance with regional regulations. TAG Heuer PAckAGING coNTeNT ...........................................................................................................5 THe BATTery ANd SIM cArd ....................................................................................................................5 duAL SIM .......................................................................................................................................................6 4 cHArGING PHoNe’S BATTery ..................................................................................................................6 4 PoWer oN or off your TAG Heuer coMMuNIcATIoN INSTruMeNT ...........................................7 4 TAG Heuer coMMuNIcATIoN INSTruMeNT LAyouT ..........................................................................8 4 dISPLAy IcoNS ANd INdIcATorS ...........................................................................................................10 4 MAkING cALLS ...........................................................................................................................................12 eNTerING TexTS........................................................................................................................................13 4 coNTAcTS ...................................................................................................................................................14 MeSSAGeS ..................................................................................................................................................15 cAMerA .......................................................................................................................................................16 MuLTIMedIA ................................................................................................................................................16 fILe MANAGer ...........................................................................................................................................17 coNcIerGe .................................................................................................................................................18 GMT fuNcTIoN...........................................................................................................................................18 orGANIzer .................................................................................................................................................18 SouNdS .......................................................................................................................................................20 SeTTINGS ..................................................................................................................................................... 20 4 TAG Heuer MANAGer .............................................................................................................................. 25 4 INTerNATIoNAL WArrANTy ....................................................................................................................26 4 AfTer SALeS ServIce ..............................................................................................................................27 English English 67 Your phone package comes with one battery and a travel charger. You can also use USB data cable to charge your phone from your personal computer. Use only TAG HEUER batteries and chargers for your safety. 1. After battery insertion in the phone, insert the Micro USB charging plug into the charging port on the left side of the phone. 2. Connect the travel charger to a standard AC outlet. 3. When phone is completely charged, disconnect the travel charger from the power outlet and from the phone by pulling out the charging plug. charging phone’s battery Note: For the …

Text truncated - open the document above for the full version.

Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M 1. External Photograph of EUT Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 5 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 6 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 7 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M List of Accessory: Specification of Accessory AC Adapter Brand Name MODELABS Model Name STA-U15WS Battery Brand Name TAG HEUER Model Name A20VDP/3ZP USB Cable Signal Line Type 1.2m, shielded cable, without core Earphone Signal Line Type 1.6m, non-shielded cable Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 8 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 9 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M AC Adapter Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 10 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Battery

NEW LP2 TRANSCEIVER DECO UNIVERSAL VERSION 1.000 0.1 J. GONIDEC NLP2-190001-2 GOOD FOR PR2 A 2012 - 11 - 15 1° B 2013 - 05 - 14 C 2013 - 05 - 31 Note: part must be compliant with environmental specifications (including Reach, RoHS...) MARKINGS: - Laser Engraved - Color: White 59.05 44.8

Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 11 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M 3. Internal Photograph of EUT GSM Antenna Bluetooth Antenna Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 12 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 13 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 14 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 15 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 16 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 17 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 18 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 19 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 20 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 21 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 22 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 23 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M Photographs of EUT Report No.: EP351601 Brand Name: TAG Heuer; Model Name: TH04M SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 24 of 24 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M GSM Antenna <Tx / Rx> Bluetooth Antenna <Tx / Rx>

SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 1 of 38 TEL : 86-755-8637-9589 Report Issued Date : Jun. 27, 2013 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : GUOTH04M FCC SAR Test Report Report No. : FA351601 FCC SAR Test Report APPLICANT : ATELIER HAUTE COMMUNICATION SAS EQUIPMENT : Mobile phone BRAND NAME : TAG Heuer MODEL NAME : TH04M MARKETING NAME : MERIDIIST FCC ID : GUOTH04M STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was completely tested on Jun. 03, 2013. We, SPORTON INTERNATIONAL (SHENZHEN) INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (SHENZHEN) INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL (SHENZHEN) INC. No. 101, Complex Building C, Guanlong Village, Xili Town, Nanshan District, Shenzhen, Guangdong, P.R.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 2 of 38 TEL : 86-755-8637-9589 Report Issued Date : Jun. 27, 2013 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : GUOTH04M FCC SAR Test Report Report No. : FA351601 Table of Contents 1. Statement of Compliance ..............................................................................................................................................4 2. Administration Data .......................................................................................................................................................5 2.1 Testing Laboratory ...................................................................................................................................................5 2.2 Applicant .................................................................................................................................................................5 2.3 Manufacturer ...........................................................................................................................................................5 2.4 Application Details ...................................................................................................................................................5 3. General Information .......................................................................................................................................................6 3.1 Description of Equipment Under Test (EUT) ...........................................................................................................6 3.2 Maximum RF output power among production units ...............................................................................................7 3.3 Applied Standard .....................................................................................................................................................8 3.4 Device Category and SAR Limits ............................................................................................................................8 3.5 Test Conditions ........................................................................................................................................................8 4. Specific Absorption Rate (SAR) ....................................................................................................................................9 4.1 Introduction .............................................................................................................................................................9 4.2 SAR Definition .........................................................................................................................................................9 5. SAR Measurement System ..........................................................................................................................................10 5.1 E-Field Probe ........................................................................................................................................................ 11 5.2 Data Acquisition Electronics (DAE) ....................................................................................................................... 11 5.3 Robot ....................................................................................................................................................................12 5.4 Measurement Server .............................................................................................................................................12 5.5 Phantom ................................................................................................................................................................13 5.6 Device Holder .......................................................................................................................................................13 5.7 Data Storage and Evaluation ................................................................................................................................14 5.8 Test Equipment List ...............................................................................................................................................16 6. Tissue Simulating Liquids ...........................................................................................................................................17 7. System Verification Procedures .................................................................................................................................18 7.1 Purpose of System Performance check .....................................................................................................…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : C1 of C1 TEL : 86-755-8637-9589 Report Issued Date : Jun. 27, 2013 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : GUOTH04M FCC SAR Test Report Report No. : FA351601 Appendix C. DASY Calibration Certificate The DASY calibration certificates are shown as follows. SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report D835V2, serial No. 4d091 Extended Dipole Calibrations Referring to KDB 450824, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Justification of the extended calibration> D835V2 – serial no. 4d091 ʳ 835 Head 835 Body Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 11.18.2011 -25.734 ʳ 50.867 ʳ -5.1504ʳ -22.318 ʳ47.082 ʳ -6.8594ʳ 11.17.2012 -25.917 0.7149.7731.09-5.13290.02 -22.4660.6648.683 1.60 -6.35980.50 The return loss is < -20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report <Dipole Verification Data> - D835V2, serial no. 4d091 835MHz - Head 835MHz – Body SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report D1900V2, serial no. 5d118 Extended Dipole Calibrations Referring to KDB 450824, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Justification of the extended calibration> D1900V2 – serial no. 5d118 1900 Head 1900 Body Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) Return-Los s (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 11.21.2011 -22.535 53.449 6.9277 -22.401 47.82 7.1133 11.17.2012 -22.603 0.3053.491 -0.047.10090.17-22.45 0.2246.14 -1.68 6.7234-0.39 The return loss is < -20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report <Dipole Verification Data>- D1900V2, serial no. 5d118 1900MHz – Head 1900MHz - Body

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 72 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M FCC RF Test Report Report No. : FG351601 FCC RF Test Report APPLICANT : ATELIER HAUTE COMMUNICATION SAS EQUIPMENT : Mobile phone BRAND NAME : TAG Heuer MODEL NAME : TH04M MARKETING NAME : MERIDIIST FCC ID : GUOTH04M STANDARD : FCC 47 CFR Part 2, 22(H), 24(E) CLASSIFICATION : PCS Licensed Transmitter Held to Ear (PCE) The product was received on May 16, 2013 and completely tested on May 28, 2013. We, SPORTON INTERNATIONAL (KUNSHAN) INC., would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI / TIA / EIA-603-C-2004 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (KUNSHAN) INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Manager Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL (KUNSHAN) INC. No. 3-2, PingXiang Road, Kunshan, Jiangsu Province, P.R.C. SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 72 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M FCC RF Test Report Report No. : FG351601 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ..................................................................................................................................... 5 1.3 Feature of Equipment Under Test ..................................................................................................... 5 1.4 Product Specification of Equipment Under Test ............................................................................... 5 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Maximum ERP/EIRP Power, Frequency Tolerance, and Emission Designator ............................... 6 1.7 Testing Site ....................................................................................................................................... 6 1.8 Applied Standards ............................................................................................................................. 7 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1 Test Mode.......................................................................................................................................... 8 2.2 Connection Diagram of Test System .............................................................................................. 10 2.3 Support Unit used in test configuration and system ........................................................................ 10 2.4 Measurement Results Explanation Example .................................................................................. 10 3 TEST RESULT ........................................................................................................................................... 11 3.1 Conducted Output Power Measurement ......................................................................................... 11 3.2 Peak-to-Average Ratio .................................................................................................................... 13 3.3 Effective Radiated Power and Effective Isotropic Radiated Power Measurement ......................... 19 3.4 99% Occupied Bandwidth and 26dB Bandwidth Measurement...................................................... 23 3.5 Band Edge Measurement ................................................................................................................ 37 3.6 Conducted Spurious Emission Measurement ................................................................................. 46 3.7 Field Strength of Spurious Radiated Measurement ........................................................................ 57 3.8 Frequency Stability for Temperature and Voltage Measurement ................................................... 67 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 71 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 72 APPENDIX A. PHOTOGRAPHS OF EUT APPENDIX B. SETUP PHOTOGRAPHS SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 72 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M FCC RF Test Report Report No. : FG351601 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FG351601 Rev. 01 Initial issue of report Jun. 27, 2013 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 72 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M FCC RF Test Report Report No. : FG351601 SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result Remark 3.1 §2.1046 Conducted Output Power N/A PASS - 3.2 §24.232(d) Peak-to-Average Ratio< 13 dB PASS - 3.3 §22.913(a)(2) Effective Radiated Power…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : B1 of B2 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M FCC RF Test Report Report No. : FG351601 Appendix B. Setup Photographs <Radiated Emission> X Plane for 22H LF HF SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : B2 of B2 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 27, 2013 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : GUOTH04M FCC RF Test Report Report No. : FG351601 Y-Plane for 24E LF HF

SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : D1 of D1 TEL : 86-755-8637-9589 Report Issued Date : Jun. 27, 2013 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : GUOTH04M FCC SAR Test Report Report No. : FA351601 Appendix D. SAR Test Setup Photos Right Cheek Right Tilted Left Cheek Left Tilted Front of the DUT with Phantom 1.5 cm Gap Back of the DUT with Phantom 1.5 cm Gap
