GV3-21SP0H1SensorPod

ACCO Brands, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Aug 24, 2021
Application Purpose: Original Equipment
Date of Application: Aug 23, 2021
Equipment Note: SensorPod
Frequency Range: 2430.00000000 - 2450.00000000
Company: ACCO Brands, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TruSens N-300 Humidifier Quick Start Guide 7.6 x 7.6 inches (19.3 cm) TrOSens™ N-300 WELCOME TO COMFORTABLE INDOOR AIR. Control your air and achieve your optimal humidity with TruSens. Real-time feedback from a remote SensorPod™ helps your humidifier monitor and adjust to your ideal moisture levels. WARNING Before operation, follow these steps and read our TruSens Owner's Manual at www.trusens.com/support/owners-manuals. Included in your box l Humidifier+ Power Cord l Sensor Pod + 2 AAA Batteries l Water Filter l Absorbent Aromatherapy Pad @ ~ ~ l Water Tank SL (2.l gal) Base Humidifier Controls Battery Chamber (underneath) ©2021 ACCO Brands. All rights reserved. TruSens™, U Design'", SensorPod'" and PureDirect™ are trademarks of ACCO Brands. Directions for use A WARNING Always unplug the humidifier before removing the water tank. Empty all water before cleaning water tank, replacing filter or moving the humidifier. Only place the water tank on a hard, solid surface; do not place on carpeting. l) Prepare the water filter Remove plastic bag from filter. For optimal performance, submerge filter in bowl of water for l hour. 2) Install the water filter a) Unscrew gray cap. b) Secure the filter onto gray cap. c) Tightly secure gray cap with filter onto water tank until indicator meets lock symbol. Return water tank on top of base. b) 3) Fill the water tank Remove water tank lid and fill with room temperature water (preferably distilled) with pitcher. A A WARNING Do not pour water into the mist outlet. CAUTION: Heavy object. To avoid injury always fill tank from the top and use care when lifting. Water Level Indicator Window 4) Set up Place humidifier on a dry, firm, flat surface that is free from obstructions. Do not place humidifier on carpeting or wooden floors; waterproof mats are recommended. Open lid of battery chamber found on SensorPod (bottom) and insert 2 AAA batteries (provided).* SensorPod will automatically begin monitoring if humidifier is on. For optimal results, place SensorPod on a tabletop or counter across the room, within line of sight of the humidifier. Control the humidifier with the touch buttons on SensorPod. Control Panel @ I Power: on/ off 8 I Warm Mist: on/off (;:') I Timer: 2h/4h/8h/72h -/+ I Target Humidity: decrease/increase Filter Change Indicator \if I Speed: AUT0/7/2/3 '-' I Dimmer: on/off Aromatherapy Use Locate the Aromatherapy Tray (back of the base) and pull down the lid. Add a few drops of essential oil* to the absorbant aromatherapy pad (provided) and close tray. * Only use 700% natural essential oils. A WARNING .. Do not add essential oils to the water tank. Do not use synthetic fragrances. "" @ I HUMIDITY LIC ••• '_, \il <w.> 8 . □ Cleaning Instructions We recommend you regularly clean your humidifier with a clean, damp cloth. A 1\ WARNING .. ~ The water and heater may cause burns. Unplug the humidifier and let cool before cleaning. up to 33' (lOm) 8 l Humidity Display(%) 8 SensorPod™ signal indicator CB/ I ,, / Filter Replacement Filter Type Water Filter Suggested Replacement 4 months* Item Number WSF300-0l *Filter Change Indicator on control panel will glow red to notify you to change. Change the water filter before restarting after long periods of non-use. lJ. N-300 [email protected] I 7-833-TRUSENS (l-833-878-7367) Support and Warranty Terms at www.trusens.com EPA Est. No. 97667-CHN-l QuickStart Guide N-300, Warning Page READ AND SAVE THESE INSTRUCTIONS/ READ THE LABEL AND ANY OPERATING MANUAL BEFORE USING PRECAUTIONS This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature. Unplug or disconnect the appliance from the power supply before cleaning the base. A WARNING: To reduce the risk of fire or electric shock, do not use this appliance with any solid-state .. speed control device. Do not operate any humidifier with a damaged cord or plug, or if the wall socket is loose. Do not run cord under carpeting, throw rugs, runners, or similar coverings. Do not run cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over. • Never handle the plug with wet hands. • Do not touch the mist when in warm mist mode. • Remove all packaging, including the filter bag, before use. • Unplug the humidifier and empty the water tank before moving. Always carry by the base. • Always place the appliance on a dry, firm, flat surtace that is free from obstructions. • Appliances that are obviously damaged must not be operated. • Do not pour water into the mist outlet or chimney. • Always fill the water tank with clean, cold water. Do not overtill the water tank. • If you have concerns with your local water quality or if you have especially hard water, use distilled water. • Always place the water tank directly onto the base when there is water in the tank. • Do not add essential oils directly to the water tank. Do not use synthetic fragrances. • Always empty any water from the water tank before cleaning or before replacing the filter. • Locate humidifier near the outlet wall socket and do not use extension cords. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. • KEEP OUT OF THE REACH OF CHILDREN. Children shall not play with the appliance. • Do not attempt to service or repair this product yourself. • Only use the humidifier with the power cable provided. • Only clean this machine with a damp cloth, do not use solvents or bleach. • Do not place any part of the humidifier in a dishwasher. • …

Text truncated - open the document above for the full version.

Cover Letter(s)

ACCO Brands, Inc. 1500 Fashion Island Blvd., 3rd Floor, San Mateo, CA 94404 Date (08/06/2021) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Dear Sir or Madam, We, ACCO Brands, Inc. 1500 Fashion Island Blvd., 3rd Floor, San Mateo California United States 94404 hereby authorize TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District 518052, Shenzhen CHINA Mark Chen Phone: +86 755 3332 3243 Email address: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Type of equipment: SensorPod Model name: SensorPod-H FCC ID: GV3-21SP0H1 This authorization expires one year from the current date. Sincerely, Name/Company Officer: Benjamin Hsu/ Compliance Manager Telephone Number: 886-2-8797-1618 Extension:309 Email: [email protected]

Cover Letter(s)

Date (06/08/2021) Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request FCC ID:GV3-21SP0H1 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, (ACCO Brands, Inc.) hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation (ACCO Brands, Inc.) also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of (can list up to 180) days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Name: Benjamin Hsu Title: Compliance Manager

External Photos

EMC_SZ_FR_20.00 E-I Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 1 of 2 EMC_SZ_FR_20.00 E-I Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 2 of 2

ID Label/Location Info

Note: Rear cover non removable Label Location

Internal Photos

RF Exposure Info

Report Number: 68.910.21.0027.01A TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 RF exposure Estimation Introduction SensorPod-H (FCC ID:GV3-21SP0H1) is a SensorPod operating at 2.4GHz 1.Limit and Guidelines on Exposure to Electromagnetic Fields According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB 447498 D01 General RF Exposure Guidance v06, Mobile Portable RF Exposure, no SAR required if power is lower than the flowing threshold: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation25 • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 2.Calculation method [(max. power of` channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 According to ANSI C63.10-2013 (9.5 Equations to calculate EIRP), Report Number: 68.910.21.0027.01A TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Field Strength (EMeas):100.81 (dBuV/m) (f=2430MHz) Measurement Distance(dMeas):3 (m) Equivalent Isotropically Radiated Power(EIRP):3.67 (mW) Radiated Power + tune up tolerance = 3.67mW Distance = 5 mm f = 2.430 GHz [3.67/5] * SQRT(2.430) =1.144 1.144 ≤ 3.0 Therefore, excluded from SAR testing. TUV SUD China, Shenzhen Branch Reviewed by: Prepared By: John Zhi/ EMC Project Manager Mark Chen/EMC Project Engineer Date: 2021-08-20 Date: 2020-08-20

Test Report

Report Number: 68.910.21.0028.01 EMC_SZ_FR_23.00 IC Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 88285299 Page 1 of 22 ISED - TEST REPORT Report Number:68.910.21.0028.01Date of Issue:August 17 2021 Model:SensorPod-H Product Type:SensorPod Applicant:ACCO Canada Inc. Address:7381 Bramalea Rd Mississauga ON L5S 1C4 Canada Manufacturer:ACCO Canada Inc. :7381 Bramalea Rd Mississauga ON L5S 1C4 Canada Test Result:nPositiveoNegative Total pages including Appendices:22 Any use for advertising purposes must be granted in writing. This technical report may only be quoted in full. This report is the result of a single examination of the object in question and is not generally applicable evaluation of the quality of other products in regular production. For further details, please see testing and certification regulation, chapter A-3.4. Report Number: 68.910.21.0028.01 EMC_SZ_FR_23.00 IC Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 88285299 Page 2 of 22 1 Table of Contents 1 Table of Contents ......................................................................................................................................................... 2 2 Details about the Test Laboratory ................................................................................................................................. 3 3 Description of the Equipment Under Test ..................................................................................................................... 4 4 Summary of Test Standards .......................................................................................................................................... 5 5 Summary of Test Results .............................................................................................................................................. 6 6 General Remarks .......................................................................................................................................................... 7 7 Test setups ................................................................................................................................................................... 8 8 Technical Requirement ................................................................................................................................................. 9 8.1 Field strength of emissions and Restricted bands .................................................................................................... 9 8.2 Out of Band Emissions ........................................................................................................................................ 14 8.3 20dB Bandwidth & 99% Occupied Bandwidth ..................................................................................................... 17 9 Test equipment lists .................................................................................................................................................... 21 10 System Measurement Uncertainty ............................................................................................................................. 22 Report Number: 68.910.21.0028.01 EMC_SZ_FR_23.00 IC Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 88285299 Page 3 of 22 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China IC Registration Number: 10320A Telephone:86 755 8828 6998 Fax:86 755 8828 5299 Report Number: 68.910.21.0028.01 EMC_SZ_FR_23.00 IC Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 88285299 Page 4 of 22 3 Description of the Equipment Under Test Description of the Equipment Under Test Product: SensorPod PMN/HVIN: SensorPod-H Model no.: SensorPod-H IC:6128A-21SP0H1 Options and accessories: NIL Ratings:3VDC (Supplied by 2×1.5V “AAA” Batteries) RF Transmission Frequency: 2430MHz-2450MHz Modulation:GFSK Antenna Type:PIFAAntenna Antenna Gain:2.6dBi Description of the EUT:The product is a SensorPod that operated at 2.4GHz, The TX and RX range is 2430MHz-2450MHz. Auxiliary Equipment Used during Test: DESCRIPTIONMANUFACTURERRATINGSMODEL NO. -------- Report Number: 68.910.21.0028.01 EMC_SZ_FR_23.00 IC Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 88285299 Page 5 of 22 4 Summary of Test Standards Test Standards RSS-Gen Issue 5 A1:2019+ A2:2021 General Requirements and Information for the Certification of Radio Apparatus RSS-210 Issue 10 December 2019 RSS-210 — Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment All the test methods were according to ANSI C63.10-2013. Report Number: 68.910.21.0028.01 EMC_SZ_FR_23.00 IC Release 2014-03-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nan…

Text truncated - open the document above for the full version.

Test Setup Photos

Radiated Emission Test below 1GHz Radiated Emission Test 1GHz-18GHz Radiated Emission Test 18GHz-40GHz
