GV333365Low Power Personal FM Broadcast Transmitter

POWER OF ATTORNEY To whom it may concern: We, the undersigned, ACCO Brands, Inc, hereby authorize ADT (Shanghai) Corporation of shanghai to act on our behalf in all matters relating to all processes required in the FCC part 15 approval and any communication needed with the national authority. Any and all acts carried out by ADT-SH on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please do not hesitate to contact us. Thank you! Sincerely yours, (Sign the name and date) ------------------------------------------------------------------- Bright Zhou Undersecretary of R&D Dept Tel.: 86-769-7086974 Fax: 86-769-7086663 [email protected] ACCO Brands, Inc. 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, CA 94065, United States TEL: 86-0769-7086974 FAX: 86-769-7086663 ACCO Brands, Inc. 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, CA 94065, United States TEL: 86-0769-7086974 FAX: 86-769-7086663 Date: JAN 11, 2006 FCC ID: GV333365 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Sign the name and date) ------------------------------------------------------------------- Bright Zhou Undersecretary of R&D Dept Tel.: 86-769-7086974 Fax: 86-769-7086663 [email protected]

Model No: K33365 Model No: K33332

FCC ID:GV333365

Product Engineering Specification K33365 (Black) K33332 (White) NanoX Product Information Product Name NanoX Product Description FM Transmitter for ipod Product Number K33332 & K33365 Product Manager Betsy Diaz Project Manager Matthew Hoag Introduction This product will allow an ipod to transmit music to an FM receiver. The ID of this product has been specifically designed to reference the Ipod Nano Dimensions. 1.1 Scope This document outlines the Electrical Specifications, ID Considerations, Mechanical Specifications and Tooling Requirements necessary to produce the product. 1.2 Purpose The purpose of this document is to assist the Contract Manufacturer in the production and testing of this product. 1.3 Reference • Kensington Standards.doc 1.4 Acronyms Table 1 - Acronyms Acronym Description ESD Electrostatic Discharge EMC Electro Magnetic Compatibility FCC Federal Communication Commission 2.0 Functional Specifications The NanoX product contains an FM transmitter and a 3-position shuttle switch. This FM transmitter will connect to the ipod nano via the iPod’s 30pin dock connector and will receive 3.3VDC for power and Line Out stereo for audio transmission. The FM transmitter must report itself as an FM transmitter in accordance to the iPod Omni and Audio/Remote Interface Specification’s. An LCD is not required for this product 2.1 General Description 2.2 System Diagram 2.3 Button Functions Pressing the shuttle switch in will activate the tuning system. Pressing the shuttle switch up briefly will increase the FM transmission frequency by 0.2. Pressing the shuttle switch down briefly will decrease the FM transmission frequency by 0.2. 2.4 Display Functions This product will not use a display. 2.5 Peripheral Devices Support N/A 3.0 Electrical Specifications The NanoX product is a FCC Part 15 compliant FM transmitter that connects to the iPod’s “dock” connector and transmits the iPod’s music in FM Stereo. The NanoX receives Line Level audio for FM modulation and contains no charging components or batteries as it relies on the iPod’s dedicated 3.3V accessory line for power. User interface options are restricted to a Tri-direction Scan Switch whose functions are dependent on the current Mode of the NanoX. In total, the NanoX contains 3 different Modes that will be defined in a later section. Since the NanoX interfaces with the iPod, the NanoX will be required to communicate with the iPod over a Serial Communication link. A brief mention will be provided in a later section. The innovative feature of the NanoX is the ability to use the iPod’s display to convey user interface information. This feature requires the NanoX to follow the iPod Accessory Protocol Interface Specification as well as the iPod Extended Accessory Protocol Interface Specification. 3.1 Mode description The NanoX operates in 3 different Modes: · Tuning Mode: This is the first mode a user will see when the NanoX is first plugged into an iPod. In essence, this Mode replicates the LCD function of a standard FM transmitter in that it displays the current frequency and reacts appropriately to frequency changes defined by user inputs. The difference is that the NanoX uses the iPod’s screen instead of a separate LCD display to convey this information. User input is provided by the use of the Tri-directional Scan Switch and it allows the user to adjust the transmitting frequency or switch Modes. It should be noted that during this mode, the NanoX is not transmitting. The following table lists the button functionality: Button during Tuning Mode Function Switch Up (Hold button for < 3 seconds) Adjust transmitting frequency up 200 kHz. Refresh iPod display to add 0.2 MHz to current frequency. Switch Up (Hold button for > 3 seconds) Advance the transmitting frequency up in 200 kHz steps at fast speed. Refresh iPod’s display to reflect the fast speed scan. Switch Down (Hold button for < 3 seconds) Adjust transmitting frequency down 200 kHz. Refresh iPod display to add 0.2 MHz to current frequency. Switch Down (Hold button for > 3 seconds) Advance the transmitting frequency down in 200 kHz steps at fast speed. Refresh iPod’s display to reflect the fast speed scan. Switch In (Hold button for < 5 seconds) Go to iPod Mode Switch In (Hold button for > 5 seconds) Go to Preset Mode · Preset Mode: This mode is activated only if the user holds the Scan Switch IN for more than 5 seconds while in Tuning Mode. When activated, this Mode allows the user to assign the frequency displayed in Tuning Mode to a Preset. This Mode is entered when the iPod display shows two new annunciators alternately flashing in addition to what was displayed during Tuning Mode. The flashing annuciators is a signal to the user to select a Scan switch position to assign as a Preset for the displayed frequency. When either the Up or Down Switch is pressed, the NanoX will store the currently displayed frequency to that Switch position as a Preset. A successful store is signalled to the user by having the appropriate enunciator remain solid for 3 seconds before transitioning to iPod mode. From then on (until the preset button is reassigned), the appropriate annunciator is displayed whenever the frequency is displayed in Tuning mode. A Preset is recalled only when iPod Mode. It should be noted that during this mode, the NanoX is not transmitting. The following table list the button functionality: Button during Preset Mode Function Switch Up Store currently displayed frequency to the Up position as a Preset Switch Down Store currently displayed frequency to the Down position as a Preset Switch In Go to iPod Mode • iPod Mode: This Mode is where the NanoX is transmitting iPod stored music in FM Stereo on the frequency as determined by the Tuning Mode or by Presets. This is the only mode where FM transmission occurs as well as the only mode where Presets may be recalled. FM Transmission is achieved by the user pushing Play on the iPod. If the NanoX identifies itself correctly, it will…

Text truncated - open the document above for the full version.

Report No.: 151210FIA01 1 Issued: Dec. 19, 2005 FCC TEST REPORT REPORT NO.: 051210FIA01 MODEL NO.: K33365 / K33332 RECEIVED: Dec. 14, 2005 TESTED: Dec. 14 ~ Dec. 19, 2005 ISSUED: Dec. 19, 2005 APPLICANT: ACCO Brands, Inc. ADDRESS: 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, CA 94065, United States ISSUED BY: ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan Rd., 201103, Shanghai, China This test report consists of 22 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. ADT (Shanghai) Corporation Report No.: 051210FIA01 2 Issued: Dec. 19, 2005 TABLE OF CONTENTS 1 CERTIFICATION..............................................................................................3 2 SUMMARY OF TEST RESULTS .....................................................................4 2.1 MEASUREMENT UNCERTAINTY...................................................................4 3 GENERAL INFORMATION ..............................................................................5 3.1 GENERAL DESCRIPTION OF EUT ................................................................5 3.2 DESCRIPTION OF TEST MODES ..................................................................6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..................................6 3.4 DESCRIPTION OF SUPPORT UNITS ............................................................7 3.5 CONFIGURATION OF SYSTEM UNDER TEST .............................................7 4 TEST TYPES AND RESULTS .........................................................................8 4.1. CONDUCTED EMISSION MEASUREMENT...................................................8 4.1.1. LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................8 4.1.2. TEST RESULTS ..............................................................................................8 4.2 RADIATED EMISSION MEASUREMENT........................................................9 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .....................................9 4.2.2 TEST INSTRUMENT.....................................................................................10 4.2.3 TEST PROCEDURE...................................................................................... 11 4.2.4 DEVIATION FROM TEST STANDARD.......................................................... 11 4.2.5 TEST SETUP.................................................................................................12 4.2.6 EUT OPERATING CONDITION.....................................................................12 4.2.7 TEST RESULT...............................................................................................13 4.3 EMISSION BAND MEASUREMENT .............................................................16 4.3.1 LIMITS OF EMISSION BAND MEASUREMENT...........................................16 4.3.2 TEST INSTRUMENTS...................................................................................16 4.3.3 TEST PROCEDURE......................................................................................16 4.3.4 DEVIATION FROM TEST STANDARD..........................................................17 4.3.5 TEST SETUP.................................................................................................17 4.3.6 EUT OPERATING CONDITIONS ..................................................................17 4.3.7 TEST RESULTS ............................................................................................18 5 INFORMATION ON THE TESTING LABORATORIES...................................21 Report No.: 051210FIA01 3 Issued: Dec. 19, 2005 1 CERTIFICATION PRODUCT: NanoX MODEL NO.: K33365 / K33332 APPLICANT: ACCO Brands, Inc. TESTED: Dec. 14 ~ Dec. 19, 2005 TEST ITEM: Engineering Sample STANDARDS: FCC Part 15, Subpart C (Section 15.237), ANSI C63.4-2003 The above equipment has been tested by ADT (Shanghai) Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. TECHNICAL ACCEPTANCE : , DATE:DEC. 19, 2005 Responsible for EMI (Wailand Zhang) APPROVED BY : , DATE: DEC. 19, 2005 (Wallace Pan, Manager ) Report No.: 051210FIA01 4 Issued: Dec. 19, 2005 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C STANDARD PARAGRAPH TEST TYPE RESULTREMARK 15.207 Conducted Emission TestN/A N/A 15.239 Radiated Emission Test PASS Minimum passing margin is –7.05dB at 98.100MHz 15.239(c) Emission Bandwidth Test PASS N/A NOTE: The information of measurement uncertainty is available upon the customer’s request. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. MEASUREMENT FREQUENCY UNCERTAINTY Conducted emissions 9kHz ~ 30MHz 2.44 dB 30MHz ~ 200MHz 3.73 dB 200MHz ~1000MHz 3.74 dB 1GHz ~ 18GHz 2.20 dB Radiated emissions 18GHz ~ 40GHz 1.88 dB Report No.: 051210FIA01 5 Issued: Dec. 19, 2005 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT NanoX MODEL NO. K33365 / K33332 POWER SUPPLY 3.3 Vdc from battery MODULATION TYPE FM CARRIER FREQUENCY OF EACH CHANNEL 88.1-107.9MHz NUMBER OF CHANNELS 100 BANDWIDTH 200kHz ANTENNA TYPE soldered on PCB DATA CABLE N/A I/O PORTS connecter ASSOCIATED DEVICES N/A NOTE: 1. The EUT is a FM trans…
