GV364321Wireless Mouse

ACCO Brands Inc. 2000 Alameda de las Pulgas Second Floor San Mateo, California 94403-1289 TEL: 650-572-2700 FAX: 650-572-9675 e-mail: [email protected] FCC ID: GV364321 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----------------------------------------------- John Cavacuiti ACCO Brands Inc. e-mail: [email protected] Tel: 650-572-2700

ACCO Brands Inc. 2000 Alameda de las Pulgas Second Floor San Mateo, California 94403-1289 TEL: 650-572-2700 FAX: 650-572-9675 e-mail: [email protected] Power of Attorney To whom it may concern: We, the undersigned, ACCO Brands Inc. , hereby authorize Advance Data Technology Corporation (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------------------------- John Cavacuiti ACCO Brands Inc. e-mail: [email protected] Tel: 650-572-2700

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 12, 2002 RE: ACCO Brands Inc. FCC ID: GV364321 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram should show the frequency of all oscillators in the device (CFR2.1033(a)(5)). 2) The FCC logo and phrases "For Home or Office Use/Tested to Comply with FCC Stanadards" are used to show compliance with a DoC authorization. These items are not applicable to the mouse and should be removed from the label. 3) The FCC identifier shown on the label should use the format "FCC ID:". Please provide an updated label. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

FCC ID Label Location

Page 3 Page 4 Page 5 Page 6

FCC ID: GV364321 ADT No.910817R03 Operational Description The transmitter of the EUT (StudioMouse TM Wireless) which uses Enamel Wire Antenna is powered by 3V Battery. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: GV364321 Report No.: RF910817R03 1 Issued: Sep. 4, 2002 FCC TEST REPORT REPORT NO.: RF910817R03 MODEL NO.: 64321 RECEIVED: August 17, 2002 TESTED: August 19 ~ August 29, 2002 APPLICANT:ACCO Brands Inc. ADDRESS:2855 Campus Drive, San Mateo, CA 94403 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: GV364321 Report No.: RF910817R03 2 Issued: Sep. 4, 2002 Table of Contents 1CERTIFICATION..............................................................................................3 2SUMMARY OF TEST RESULTS .....................................................................4 3GENERAL INFORMATION..............................................................................5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .................................6 3.4DESCRIPTION OF SUPPORT UNITS ............................................................7 4TEST PROCEDURE AND RESULT ................................................................8 4.1CONDUCTED EMISSION MEASUREMENT...................................................8 4.2RADIATED EMISSION MEASUREMENT........................................................8 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .....................................8 4.2.2 TEST INSTRUMENT .......................................................................................9 4.2.3 TEST PROCEDURE......................................................................................10 4.2.4 DEVIATION FROM TEST STANDARD..........................................................10 4.2.5 TEST SETUP................................................................................................. 11 4.2.6 EUT OPERATING CONDITION..................................................................... 11 4.2.7 TEST RESULT...............................................................................................12 5PHOTOGRAPHS OF THE TEST CONFIGURATION ....................................13 6INFORMATION ON THE TESTING LABORATORIES ..................................14 FCC ID: GV364321 Report No.: RF910817R03 3 Issued: Sep. 4, 2002 1 CERTIFICATION PRODUCT : StudioMouse TM Wireless BRAND NAME : KENSINGTON MODEL NO : 64321 APPLICANT : ACCO Brands Inc. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility from August 19, 2002 to August 29, 2002. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: GV364321 Report No.: RF910817R03 4 Issued: Sep. 4, 2002 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –6.50dBuV at 54.00MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: GV364321 Report No.: RF910817R03 5 Issued: Sep. 4, 2002 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTStudioMouse TM Wireless MODEL NO.64321 POWER SUPPLY3VDC from battery MODULATION TYPEFSK CARRIER FREQUENCY OF EACH CHANNEL 26.995 MHz & 27.195MHz IF & L.O. FREQUENCY455kHz / 26.54MHz, 26.74MHz NUMBER OF CHANNEL2 ANTENNA TYPEEnamel wire DATA CABLE NA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of StudioMouse TM Wireless. 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: GV364321 Report No.: RF910817R03 6 Issued: Sep. 4, 2002 3.2 DESCRIPTION OF TEST MODES Two channels were provided to this EUT. ChannelFrequency 126.995MHz 227.195MHz NOTE: Channel 1, the worst case, was chosen for final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a StudioMouse TM Wireless. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C (15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. FCC ID: GV364321 Report No.: RF910817R03 7 Issued: Sep. 4, 2002 3.4 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. NO.PRODUCTBRANDMODEL NO.SERIAL NO.FCC ID 1PRINTEREPSONLQ-300+DCGY017096FCC DoC APPROVED 2COLOR MONITOR ADICM100026058T1020061 1 A FCC DoC APPROVED 3PERSONAL COMPUTER HPBrio BA410SG12902766FCC DoC APPROVED 4MODEMACEEX1414980020503IFAXDM1414 5PS/2 KEYBOARD BTC5121WA00801156E5XKB5121WTH0110 6RECEIVERKENSINGTON64321NAFCC DoC APPROVED NO.SIGNAL CABLE DESCRIPTION OF THE ABOVE SUPPORT UNITS 11.2m braid shielded wire, terminated with DB25 and Centronics connector via metallic frame, w/o core 21.8 m braid shielded wire, terminated with VGA connector via metallic frame, w/o core 3NA 41.2 …

Text truncated - open the document above for the full version.

FCC ID: GV364321 Report No.: RF910817R03 13 Issued: Sep. 4, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
