GV372258Ci60 Optical Wireless Mouse

Contents ACi60 Optical Wireless Mouse BUSB Wireless Receiver C2 AA Batteries DCD EInstruction Guide Components FBattery Cover GForward Button HBack Button IReceiver Connection Button Getting Started Your Ci60 Optical Wireless Mouse provides unrivaled precision and convenience. To begin using your Ci60 Optical Wireless Mouse, you will need to: 1. Open the battery cover 2. Install the batteries 3. Plug the USB Wireless Receiver into a USB port on your computer. The Ci60 Optical Wireless Mouse will then be ready to use. Ci60 Optical Wireless Mouse Instruction Guide ABED C Instruction Guide Guide d’instructions Bedienungsanleitung Handleiding Istruzioni Manual de instrucciones I G H F Kensington Computer Products Group A Division of ACCO Brands 333 Twin Dolphin Drive, Redwood Shores, CA 94065 Designed in California, U.S.A. by Kensington Made in China www.kensington.com Technical Support United States1 800 535 4242 International Toll+31 53 484 9135 901-1915-00901-1915-00 Federal Communications Commission Radio Frequency Interference Statement Note: The Kensington Ci60 Optical Wireless Mouse has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. MODIFICATIONS: Modifications not expressly approved by Kensington may void the user’s authority to operate the device under FCC regulations and must not be made. Declaration of Conformity Compliance Statement for the Kensington Ci60 Optical Wireless Mouse The Kensington Ci60 Optical Wireless Mouse model no. 72258 complies with Part 15 of the FCC Rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and, (2) this device must accept any interference received, including interference that may cause undesired operation. As defined in Section 2.909 of the FCC Rules, the responsible party for this device is Kensington Computer Products Group, 333 Twin Dolphin Drive, CA 94065, USA. This Class B digital apparatus complies with Candadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. The Following Information is Only for EU-member States: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent poten- tial negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. Kensington is a registered trademark of ACCO Brands. The Kensington Promise is a service mark of ACCO Brands. All other trademarks are the property of their respective owners. ©2006 Kensington Computer Products Group, a division of ACCO Brands. Any unauthorized copying, duplicating, or other reproduction of the contents hereof is prohibited without written consent from Kensington Computer Products Group. All rights reserved. 4/06 Battery Installation Your Ci60 Optical Wireless Mouse requires two (2) AA batteries (C). Insert the batteries as indicated and replace the cover. Average battery life for your wireless mouse is 9–10 months, depending on usage. Making a Connection Plug the USB Wireless Receiver into a USB port on your computer. Within 10 seconds, click any button on the mouse. Your mouse should now be ready to use. IMPORTANT: This wireless device is similar to an FM radio, the position of your computer and surrounding objects (especially metal objects) may affect your wireless reception and range (average range is approximately 10 meters or 30 feet). Establishing a New Wireless Connection If the connection between your mouse and receiver is broken, or if you are experiencing interference, you may need to re-establish a wireless connection. To do so: -With the USB receiver in the USB port, Press the “connect” button on the receiver (I). -Within 10 seconds, click any button on the mouse. -You have now established a new connection. If you continue to have problems, try this procedure again while holding the mouse closer to the receiver. You may need to repeat this procedure 2 – 3 times for the mouse to synchronize. If necessary, repeat this procedure after replacing depleted batteries. Programming Your Mouse You may program your mouse buttons by downloading the latest version of MouseWorks® software available at www.software.kensington.com. The install is optional; your mouse will function without installing the software. MouseWorks is currently only available in English. Product Specific Features Your mouse features two side buttons that are pre-configured to Forward (G) and Back (H) in Internet browsers. You can easily change this setting using MouseWorks software. Common Troubleshooting Steps 1. Unplug and re-plug the receiver. Establish a new wireless connection. 2. Install a fresh set of batteries in the mouse. 3. Test the device on another USB port or computer. 4.…

Text truncated - open the document above for the full version.

KENSINGTON TECHNOLOGY GROUP, a division of ACCO Brands, Inc. 333 Twin Dophin Drive, Sixth Floor, Redwood Shore, CA94065, US Date: 2006/5/19 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant.

KENSINGTON TECHNOLOGY GROUP, a division of ACCO Brands, Inc._________ 333 Twin Dophin Drive, Sixth Floor, Redwood Shore, CA94065, US Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: GV372258 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

LABEL FORMAT & LOCATION

Compliance Certification Services (Shenzhen) Inc. Report No.: SZ060420B03-RP FCC ID: GV372258 Date of Issue: May 05, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 17 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Ci60 Optical Wireless Mouse Model: 72258/72270 Trade Name: Kensington Issued to ACCO BRANDS, INC.(Kensington Technology Group) 333 Twin Dophin Drive, Sixth Floor, Redwood Shore, CA94065, US Issued by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No.: SZ060420B03-RP FCC ID: GV372258 Date of Issue: May 05, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 2 2. EUT DESCRIPTION .................................................................................................................... 2 3. TEST METHODOLOGY ............................................................................................................. 2 3.1 EUT CONFIGURATION.............................................................................................................. 2 3.2 EUT EXERCISE......................................................................................................................... 2 3.3 GENERAL TEST PROCEDURES.................................................................................................. 2 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 2 3.5 DESCRIPTION OF TEST MODES................................................................................................. 2 4. INSTRUMENT CALIBRATION................................................................................................. 2 5. FACILITIES AND ACCREDITATIONS ................................................................................... 2 5.1 FACILITIES.............................................................................................................................. 2 5.2 EQUIPMENT............................................................................................................................. 2 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 2 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 2 6.1 SETUP CONFIGURATION OF EUT.............................................................................................. 2 6.2 SUPPORT EQUIPMENT....................................................................................................... 2 7. FCC PART 15.227 REQUIREMENTS........................................................................................ 2 7.1 26 DB BANDWIDTH ............................................................................................................ 2 7.2 RADIATED EMISSIONS............................................................................................................. 2 7.3 POWERLINE CONDUCTED EMISSIONS...................................................................................... 2 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP......................................................................... 2 Compliance Certification Services (Shenzhen) Inc. Report No.: SZ060420B03-RP FCC ID: GV372258 Date of Issue: May 05, 2006 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: ACCO BRANDS, INC.(Kensington Technology Group) 333 Twin Dophin Drive, Sixth Floor, Redwood Shore, CA94065, US Equipment Under Test: Ci60 Optical Wireless Mouse Tr a d e N a m e : Kensington Model: 72258/72270 Date of Test: April 20-May 05, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services (Shenzhen) Inc.. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.227. The test results of this report relate only to the tested sample identified in this report. Approved by: Tested By: Henry Ding / Engineer Reviewed By: Clinton Kao / EMC Manager Eric Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No.: SZ060420B03-RP FCC ID: GV372258 Date of Issue: May 05, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product Ci60 Optical Wireless Mouse Trade Name Kensington Model Number 72258/72270 Model Difference Differ from the appearance color Power Supply TX: Powered by AAA batteries × 2 (Rating: 2 × 1.5Vdc) RX: Powered by the host device Frequency Range 27.04 MHz Modulation Technique FSK Remark: This submittal(s) (test report) is intended for FCC ID: GV372258 filing to comply with Section 15.227 of the FCC Part 15, Subpart C Rules. Compliance Certification Services (Shenzhen) Inc. Report No.: SZ060420B03-RP FCC ID: GV372258 Date of Issue: May 05, 2006 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, and 15.227. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requireme…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No.: SZ060420B03-RP FCC ID: GV372258 Date of Issue: May 05, 2006 Page 17 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP RADIATED EMISSION TEST Below 30MHz Below 1GHz
