GV372271Si670m Bluetooth Wireless Notebook Mouse

Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID: GV372271 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. LABEL

www.kensington.com www.kensington.com FCC ID:GV372271 FCC ID:GV372271 906-1756-00 906-1756-00 Assembled in China Assembled in China Operating Frequency: 2.4 Ghz Operating Frequency: 2.4 Ghz Model# K72271 Model# K72271 Serial #: AYYWWA X X X X X X Serial #: AYYWWA X X X X X X *38.0 mm *38.0 mm * 3 2 . 7 m m * 3 2 . 7 m m *39.7 mm *39.7 mm Si670m Bluetooth Wireless Notebook Mouse r Si670m Bluetooth Wireless Notebook Mouse r R E V O C S I D R E V O C S I D R R BACKGROUND COLOR: COLOR-MATCHED TO DARK BLUE-GRAY TEXT COLOR: PANTONE 8180C 1:1 2:1

Page 2 Page 3 Page 4 Page 5

FCC ID: GV372271 Report No.: RF951025A07 Operational Description The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is Printed Antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the user’s manual.

Report No: SA951025A07 1 RF EXPOSURE REPORT REPORT NO.: SA951025A07 MODEL NO.: 72271, K72271, K72271US, K72271EU, K72271AU ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT : ACCO Brands, Inc. ADDRESS : 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, CA, 94065, U.S.A. ISSUED BY : Advance Data Technology Corporation LAB ADDRESS : No. 47, 14 th Ling, Chia Pau Tsuen, Linko Hsiang 244, Taipei Hsien, Taiwan, R.O.C. Report No: SA951025A07 2 Conclusion No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.480 24.58 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power 0.14 1.033 EIRP Power -2.17 0.607 *Note: The antenna is Printed antenna with -2.31dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 1.033mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold

Report No.: RF951025A07 1 Report Format Version 2.0.5 FCC TEST REPORT REPORT NO.: RF951025A07 MODEL NO.: 72271 – multiple listing on page 7 RECEIVED: Oct. 25, 2006 TESTED: Oct. 26 ~ Nov. 2, 2006 ISSUED: Nov. 6, 2006 APPLICANT: ACCO Brands, Inc. ADDRESS: 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, CA, 94065, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 44 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF951025A07 2 Report Format Version 2.0.5 TABLE OF CONTENTS 1. CERTIFICATION.............................................................................................4 2. SUMMARY OF TEST RESULTS.....................................................................5 2.1 MEASUREMENT UNCERTAINTY..................................................................6 3. GENERAL INFORMATION.............................................................................7 3.1 GENERAL DESCRIPTION OF EUT................................................................7 3.2 DESCRIPTION OF TEST MODES..................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.............................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................9 3.3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................10 3.3.4 DESCRIPTION OF SUPPORT UNITS..........................................................10 4. TEST TYPES AND RESULTS.......................................................................11 4.2 RADIATED EMISSION MEASUREMENT.....................................................11 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................11 4.2.2 TEST INSTRUMENTS..................................................................................12 4.2.3 TEST PROCEDURES...................................................................................13 4.2.4 DEVIATION FROM TEST STANDARD.........................................................13 4.2.5 TEST SETUP................................................................................................14 4.2.6 EUT OPERATING CONDITIONS..................................................................14 4.2.7 TEST RESULTS............................................................................................15 4.3 NUMBER OF HOPPING FREQUENCY USED.............................................19 4.3.1 LIMIT OF HOPPING FREQUENCY USED...................................................19 4.3.2 TEST INSTRUMENTS..................................................................................19 4.3.3 TEST PROCEDURES...................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.........................................................20 4.3.5 TEST SETUP................................................................................................20 4.3.6 TEST RESULTS............................................................................................20 4.4 DWELL TIME ON EACH CHANNEL.............................................................22 4.4.1 LIMIT OF DWELL TIME USED......................................................................22 4.4.2 TEST INSTRUMENTS..................................................................................22 4.4.3 TEST PROCEDURES...................................................................................22 4.4.4 DEVIATION FROM TEST STANDARD.........................................................22 4.4.5 TEST SETUP................................................................................................23 4.4.6 TEST RESULTS............................................................................................23 4.5 CHANNEL BANDWIDTH...............................................................................26 4.5.1 LIMITS OF CHANNEL BANDWIDTH............................................................26 4.5.2 TEST INSTRUMENTS..................................................................................26 4.5.3 TEST PROCEDURE.....................................................................................26 4.5.4 DEVIATION FROM TEST STANDARD.........................................................27 4.5.5 TEST SETUP................................................................................................27 4.5.6 EUT OPERATING CONDITION....................................................................27 4.5.7 TEST RESULTS............................................................................................28 4.6 HOPPING CHANNEL SEPARATION............................................................30 4.6.1 LIMIT OF HOPPING CHANNEL SEPARATION............................................30 4.6.2 TEST INSTRUMENTS..................................................................................30 Report No.: RF951025A07 3 Report Format Version 2.0.5 4.6.3 TEST PROCEDURES...................................................................................30 4.6.4 DEVIATION FROM TEST STANDARD.........................................................31 4.6.5 TEST SETUP................................................................................................31 4.6.6 TEST RESULTS............................................................................................32 4.7 MAXIMUM PEAK OUTPUT POWER............................................................34 4.7.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.............34 4.7.2 TEST INSTRUMENTS…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
