GV3M01258Bluetooth Keyboard

M01258 使用说明书 1 、产品内容 1.1、蓝牙键盘一只 Bluetooth keyboard1PCS 1.2、说明书一份 Instruction manual1PCS 1.3、USB充电线一条 USB Charging cable 1PCS 2 、产品特点 Product Features 2.1、使用Broadcom20730主控芯片，具备Bluetooth3.0接口； use Broadcom20730 main control chip, have Bluetooth3.0 interface。 2.2、使用业界领先的蓝牙解决方案，WIDCOMM BTW（微软官方指定软件）蓝牙软件； industry leading bluetooth solutions, WIDCOMM BTW (Microsoft officially designated software) bluetooth software。 2.3、内置独有的电源管理软件，可在微软视窗系统中自动显示可用容量； built-in power management software, can be in Microsoft's Windows system automatically usable capacity。 2.4、静音设计：有效地避免了干扰他人休息（特别适合同一房间多人居住人群）；Mute design: effectively avoid other person sleeping(especially for one room with several person). 2.5、剪刀脚架构设计，手感舒适，符合人体工学设计；Architecture design, provides comfortable handling feel. 2.6、加入Caps lock状态指示，在您需要输入英文大小写的时候可以一目了然；Caps lock signal helps in capital letters writing 2.7、同时支持Ipone、Mac、Windows、Android等系统，给您的工作带来更大的方便；Support Iphone,Mac,Windows and Android system etc.It’s more convenient for you. 3 、规格参数 Specifications 3.01、执行标准：蓝牙V3.0 Executive standard: Bluetooth V3.0 3.02、最大操作距离：10米Maximum operating distance: 10 meters 3.03、调制方式：2.4G直序跳频（FHSS）Modulation mode: 2.4 G straight sequence fh (FHSS) 3.04、发射功率:Class2级别Transmit power: Class 2 levels 3.05、工作电压：3.7V Working voltage: 3.7V 3.06、工作电流：2.0mA working current: 2.0 MA 3.07、待机电流：0.5mA standby current: 0.5MA 3.08、睡眠电流：100uA Sleepcurrent: 100uA 3.09、充电电流：150mA charging current: 150mA 3.10、待机时间：120天standby time: 120days 3.11、理论使用时间：40天theoretical use time: 40days 3.12、连续不间断使用时间：180小时 continuousuninterruptedusetime:180hours 3.13、理论充电时间：3-4小时theoretical charging time: 3 - 4 hours 3.14、锂电池容量：380mAh lithium battery capacity:380mAh 3.15、锂电池型号：452447 the lithium battery type: 452447 3.16、按键力度：60±10g the key dynamics: 60 + 10g 3.17、按键寿命：500万次buttons life: 5 million times 3.18、操作温度：0－55°Coperation temperature: 0-55°C 3.19、储藏温度：-20－70°Cstorage temperature: - 20-70°C 4 、设置键盘和 IPAD 或 Iphone KeyboardandIPADorIphonesetting 4.1、键盘使用内置锂电池设计，采用Bluetooth技术与IPAD、手机或电脑连接。Built in lithium battery with bluetooth and connect with IPAD,mobilephone or PC. 4.1.1、以下内容将向您介绍如何使用、设置键盘，以及键盘在什么状态下需要充电以及怎样充电。要了解如何进行以下操 作： Belowinformationwillshowyouhowtousing,settingandcharging. 4.2、关于指示灯Indicator 4.2.1、键盘上的LED指示灯用做电池指示（红色）、 Bluetooth 指示（蓝色),Caps Lock指示(橙色），和充电指示（绿色），首次给 键盘开电时，Bluetooth指示灯会常亮约3秒钟，表示电池状态良好，约3秒种后，如果键盘未与IPAD、手机或电脑等设备配 对，指示灯会闪烁，表示键盘处于发现模式，已经准备好与IPAD、手机或电脑等设备配对。（配对意味着键盘与IPAD、手 机或电脑已经以无线方式连接，并准备好相互通信）。 The LED indicator on the keyboard show Battery indicator(red),Bluetooth indicator(blue),Caps lock indicator(orange).charging indicator(green).If you turn on the keyboard first time,the power indicator constant light and the bluetooth indicator light 3 seconds.The battery is good.After 3 seconds,ifkeyboard didn’t match the IPAD,mobilephone and PC,the indicator will twinkle.The keyboard is seraching and ready to match IPAD,mobilephone and PC etc.(Match means wireless connect with IPAD,mobilephoe and PC,and ready to correspondence.) 4.2.2、如果10分钟内您还没有将键盘与IPAD、手机或电脑等设备配对，Bluetooth指示灯均熄灭，键盘关闭，以节省电 量。 If you don’t put the keyboard match the IPAD,mobilphone and PC etc within 10 minutes.The light of power and bluetooth will colsed.The keyboard be turned off. 4.2.3、键盘与IPAD、手机或电脑配对成功后，Bluetooth指示灯熄灭。 The keyboard and IPAD,mobilephone and PC matched success,the light of bluetooth off,the power constant light. 4.2.4、当键盘与IPAD、手机或电脑配对成功且能正常使用后，如果您超过15分钟没有使用您的键盘，那么键盘进入睡 眠状态，当您需要再次使用键盘时，您只需轻按键盘上的任一按键唤醒键盘，Power指示灯再次亮起，您就可以重新使用键 盘 When the keyboard and IPAD,mobilephone and PC match success and can use.If you don’t use the keyboard over 15minutes,the light of power will off,the keyboard sleeping.When you want to use the keyboard again,you just press any button softly.The power will light again,you can use the keyboard. 。 4.2.5、键盘在正常使用过程中，如果电池指示常亮，此时提示您电池电量不够5%，您需要给键盘充电。 When you use the keyboard in the process,if the power light,advise you the battary is less than 5%,you need charing. 4.2.6、插入充电器到充电接口后，Ch arge指示灯闪烁，电池电量充满后，Charge指示灯常亮。 Plug the charger into the charing interface.The charge light.If the battary isfull enough,the charge willcut off automatically. 4.2.7、在键盘使用过程中，当键盘锁定大小写时，Caps指示灯亮，当键盘解锁大小写时，Caps指示灯灭。 When you use the keyboard in the process, you lock the upper and lowercase letters,the Caps light,when you unlocked,the Caps will off. 4.3 、要将键盘与新的 IPAD 或新的 Iphone 配对：the keyboard with new IPAD and IPHONE connection: 4.3.1、将IPAD横立着放入键盘表面带有磁力的卡槽，键盘bluetooth指示灯亮起约3秒提示开机，按下键盘上面的对码按键 约2秒，随后bluetooth指示灯开始闪烁进入对码状态， Press the switch about 1.5 seconds, power LED and Bluetooth LED light up about 2 seconds at the same time, the keyboard is turn on. Then the Bluetooth LED flash and enter the status of match code. 4.3.2、点击IPAD或Iphone上的Settings按钮，IPAD进入Settings区；然后选择General选项，再选择Bluetooth选项将Bluetooth 打开，此时IPAD进入蓝牙设备搜索状态，寻找蓝牙设备。 Click the setting button of IPAD and IPHONE,Then choose the General and bluetooth.The IPAD is searching bluetooth device. 4.3.3、IPAD或Iphone进入搜索状态，寻找蓝牙设备并搜索到蓝牙键盘（如下图所示），搜索到蓝牙键盘后，IPAD会提示 您在键盘上输入密码与IPAD或Iphone进行连接。 After the IPAD and IPHNE find out the bluetooth device and connect the bluetooth keyboard(see blow picture),IPAD will advise you input the password. 4.3.4、根据IPAD上的提示输入相对应的配对码，注意：输入时没有提示，请确定输入正确并按回车键。 Input the password according to the IPAD advise.Please note there are no advise during the input.Please make sure input correct and press enter button. 4.3.5、IPAD与键盘连接成功后，B luetooth 指示灯熄灭，表示键盘对码成功。 If IPAD and keyboard connect success.the power constant light.Power constant light advise you turn off the keyboard while you don’t use it. 4.4、将键盘与其它IPAD或Iphone配对:keyboard with other IPAD or IPHONE connection： 4.4.1在设置了键盘与一台IPAD或Iphone连接后，你可以再次设置它与其它IPAD或Iphone连接。如果键盘和已连接 的IPAD或Iphone的距离处于10米（33英尺）以外，请按照第4条3.3的说明将键盘与其它IPAD或Iphone配对。 After your keyboard connect with 1PCS of IPAD or IPHONE,you can connect with other IPAD or IPHONE .If your keyboard connected with IPAD or IPHONE over 10 meters(33 feet).Please according to item3.3. 4.4.2如果键盘和已连接的IPAD或Iphone的距离处于10米（33英尺）以内，则您必须解除现有的…

Text truncated - open the document above for the full version.

ACCO Brands, Inc. 5/8/14 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: ACCO Brands, Inc. FCC ID: GV3M01258 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d) (1)(ii) and 0.459ACCO Brands, Inc.hereby requests permanent confidentiality of the following documents for the subject application: Exhibit TypeFile NameDescription Block DiagramBlock Diagram.pdfDetails of device showing the frequency of all oscillators Operational DescriptionOperational Description.pdfDescription of the circuit functions SchematicsSchemetic diagram.pdfAll circuitry of devices and component values Parts / BOM Tune-Up Procedure Note:Any exhibit NOT granted Confidential status is viewable on the FCC website as soon as the Grant is issued. Reasonwhythe material should be withheld from public inspection: These documents contain detailed system, equipment description and related information about the product whichACCO Brands, Inc.considers proprietary, confidential, and a custom design not otherwise available to the general public. State why the information is a “trade secret;” Since the design is a basis from which future products will evolve,ACCO Brands, Inc.considers that this information would be of significant benefit to its competitors and that disclosure would give competitors an unfair advantage in the marketplace. Trade secret” information is information which is not generally known or reasonably ascertainable, by which a business can obtain an economic advantage over competitors. The information is not normally released to any party or person outside the company. Sincerely, Signature: Name: Maggie Zhang Company: ACCO Brands, Inc. Title: QA Compliance Engineer Date: Apr. 15, 2014

ACCO Brands, Inc. Letter of Authorization Company: ACCO Brands, Inc. Address: 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, California, United States Product Name:BLUETOOTH KEYBOARD Model Number:M01258 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following: •Testin g •Approval applications (includes complete product documentation package, including Confidential information) and procedures •Payment of approval fees We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried outby MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Maggie ZhangDate: Apr. 15, 2014 Title: QA Compliance Engineer Signature of applicant:

Externalphoto

LABEL ARTWORK AND LOCATION Label size: L*W=40*35mm FCC ID Label Location P/N:K97233US/K97152US K97248US/K97259US M/N:M01258 BLUETOOTHKEYBOARD900-9059-00 S/N:A1414A000127 FCC ID: GV3M01258IC: 6128A-M01258 Operating Frequency: 2.402 GHz- 2.480 GHz DC 3.7V, 5m AMade in China This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Internal photo

FCC ID TEST REPORT for BLUETOOTH KEYBOARD Model: M01258 FCC ID: GV3M01258 Prepared for:ACCO Brands, Inc. 333 Twin Dolphin Drive, 6th Floor, Redwood Shores, California, United States Prepared by:Shenzhen TCT Testing Technology Co.,Ltd 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, Guangdong, China TEL: +86-0755-27673339 FAX: +86-0755-27673332 Report Number：TCT140403019F2-1 Date of Test：Apr. 05-Apr. 23, 2014 Date of Report：Apr. 23, 2014 The results detailed in this test report relate only to the specific sample(s) tested. It is the Application’s responsibility to ensure that all production units are manufactured with equivalent EMC characteristics. This report is not to be reproduced except in full, without written approval from TCT Testing Technology. FCC ID: GV3M01258Report Number: TCT140403019F2-1Page 2 of 49 Table of Contents 1.0 General Details......................................................................................................................................................3 1.1 Test Lab Details.............................................................................................................................................. 3 1.2 Applicant Details............................................................................................................................................ 3 1.3 Description of EUT........................................................................................................................................ 4 1.4 Statement........................................................................................................................................................ 4 1.5 Test Engineer.................................................................................................................................................. 4 2.0 Test equipments and Associated Equipment used during the test...................................................................5 2.1 Test Equipments..............................................................................................................................................5 2.2 AE used during the test...................................................................................................................................5 3.0 Technical Details................................................................................................................................................... 6 3.1 Summary of test results.................................................................................................................................. 6 3.2 Test Standards.................................................................................................................................................6 4.0 EUT Modification................................................................................................................................................. 6 5.0 Measurement Uncertainty（95% confidence levels, k=2)............................................................................... 6 6.0 Power Line Conducted Emission Test................................................................................................................ 7 7.0 20dB Bandwidth Measurement.........................................................................................................................11 8.0 Maximum Peak Output Power..........................................................................................................................14 9.0 Carrier Frequency Separation.......................................................................................................................... 17 10.0 Number of Hopping Channels.........................................................................................................................20 11.0 Time of Occupancy (Dwell Time)....................................................................................................................22 12.0 Band edge Measurement..................................................................................................................................25 13.0 Spurious Emission Test.................................................................................................................................... 30 14.0 Antenna Requirement...................................................................................................................................... 39 15.0 Photos of Testing............................................................................................................................................... 40 15.1 Conducted Emission Test View..................................................................................................................40 15.2 Radiated Emission Test View.....................................................................................................................41 16.0 Photos for EUT................................................................................................................................................. 42 FCC ID: GV3M01258Report Number: TCT140403019F2-1Page 3 of 49 1.0 General Details 1.1 Test Lab Details Name :Shenzhen Tongce Testing Lab Address:1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China Telephone:13410377511 Fax:-- The test facility is recognized, certified, or accredited by the following organizations: FCC Registration Number: 572331 Shenzhen TCT Testing Technology Co., Ltd., Shenzhen EMC Laboratory: Shenzhen Tongce Testing Lab The 3m Semi-anechoic chamber has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Registration Number: 572331 Industry Canada (IC) The 3m Semi-anechoic chamber of Shenzhen TCT Testing Technology Co., Ltd. has been registered by Certif…

Text truncated - open the document above for the full version.

Setup photo Radiated Emission Test Conducted Emission Test
