GX7-JCEMDSK3JumpCharge Desktop Unit

DRAFT COPY ``` In the Box • JumpCharge Desktop Unit • AC Power Cable • Ethernet Cable • User Manual Note: This unit is only permitted for use with the provided equipment. Setup Step 1: Go to https://jumpcharge.com/portal and register your unit using the Serial Number on the back of the unit. See the Web Portal Set-Up Instructions for further information. Step 2: Plug the AC Power Cable and Ethernet into your JumpCharge unit. Ethernet connection is required for initial installation. Step 3: Place your batteries into your JumpCharge unit. You’re all set! Anyone with the JumpCharge app can now tap their pass to checkout batteries from your JumpCharge unit. JumpCharge User Manual DRAFT COPY Regulatory Information Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. This device must not be collocated or operating in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: 1. These devices may not cause harmful interference. 2. These devices must accept any interference received, including interference that may cause undesired operation. EMC compliance statement Important: This device and its power adapter have demonstrated Electromagnetic Compatibility (EMC) compliance under conditions that included the use of compliant peripheral devices and shielded cables between system components. It is important that you use compliant peripheral devices and shielded cables between system components to reduce the possibility of causing interference to radios, televisions, and other electronic devices. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Heath Canada’s website www.hc-sc.gc.ca/rpb.

David Gellis Hubbell Incorporated (Delaware) Wiring Devices Kellems Division 40 Waterview Drive Shelton, CT 06484 475-882-4676 (d) [email protected] [email protected] Request for Confidentiality Date: 3/3/20 Subject: Confidentiality Request for FCC ID: GX7-JCEMDSK3 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term User’s Manual Permanent Block Diagrams Permanent Operation Description / Theory of Operation Permanent Schematics Hubbell Incorporated (Delaware) Wiring Devices Kellems Division has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: David Gellis / Electronics Design Engineer David Gellis (Signature/Title) (Print name)

Figure 1 – External Photo of EUT (Front) Figure 2 – External Photo of EUT (Side) Figure 3 – External Photo of EUT (Back) Figure 4 – External Photo of EUT (Charging Mode)

JCEMDS Label located on rear of JCEMDS unit on center of base *NOTE: Label show in picture to be used as visual reference, all specific label information referenced on Hubbell Print D-68712 •Rear Labels to comply to Hubbell Print D-68712 •Label Material: .005 V/M Polycarbonate •Label Adhesive: 9672LE This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Product Information Label & Placement Locations

Figure 1 – Internal Photo of Open Assembly Figure 2 – Internal Photo of Base Electrical Assembly Figure 3 – Internal Photo of NFC Module Installation Figure 4 – Internal Photo of Base PCB Assembly (Top) Figure 5 – Internal Photo of Base PCB Assembly (Bottom) Figure 6 – Internal Photo of Power Supply Assembly (Top) Figure 7 – Internal Photo of Power Supply Assembly (Bottom) Figure 8 – Internal Photo of Processor Assembly with WIFI/BLE Module (Top) Figure 9 – Internal Photo of Processor Assembly with WIFI/BLE Module (Bottom) Figure 10 – Internal Photo of NFC Module (Top) Figure 11 – Internal Photo of NFC Module (Bottom)
