OPERATION MANUAL LMT-1009 Transmitter & LMR-400 Receiver FEATURES: ● Simple installation, easy operation ● 67 million codes, self program. ● 6 memory scene settings, no memory loss forever. ● Red LED indicator on transmitter. ● Control 2 lights (main and secondary light) ● Can be controlled by transmitter and or existing house hold mechanical switch. ● Security mode. Fig. 1 Main [I] “OFF” Button Main [I] “ON” Button “DELAY OFF” Button Secondary [II] “OFF” Button Secondary [II]“ON” Button ON OFF ON OFF ON OFF [I] [I] [II] [II] [I]+[II] [I]+[II] INSTALLATION: Receiver LMR-400 (Refer to Fig. 1) z Disconnect main power before installation. z Connect AC wire (Live & Neutral) to receiver block terminal IN. z Connect Load wires into receiver block terminal OUT (Port I & Port II) . z Connect main power on. OPERATION : 1. Transmitter LMT-1009 (Refer to Fig. 2) z Main [I] “ON” button: Turns on main [I] light z Main [I] “OFF” button: Turns off main [I] light (Refer to Fig. 3) z Secondary [II] “ON” button: Turns on main [II] light z Secondary [II] “OFF” button: Turns off main [II] light z “DELAY OFF” button: Turns off automatically after 10 seconds. z “Security mode”: Randomly turns on & off the lights. To activate, hold both “ON and OFF” button of Main [I] for 3 seconds. To deactivate, simply press any button on the transmitter. ※REMARK※ In order to operate with a transmitter, the mechanical switch must be powered “ON” 2. Mechanical Switch (Refer to Fig. 4) z 1 st time “ON” will control the main [I] light z 2 nd time “ON” will control the secondary [II] light z 3 rd time “ON” will control both main [I] and secondary [II] light. HOW TO LINK CODE: z To start, program transmitter with receiver. z Connect power to receiver z Switch ON first then OFF and ON cycle for 6 times, this will enter learning mode. While in learning mode, the main [I] light connected to receiver will flash to indicate ready for programming. z Then on transmitter press the main [I] “ON” button once, main [I] and secondary [II] light will flash 2 times to indicate programming is confirmed and completed. ！During leaning mode if within 12 seconds no signal is detected it will automatically return to stand-by mode. Fig. 2 Fig. 3 Fig. 4 TO DELETE CODE : z Switch ON first then OFF and ON cycle for 6 times, this will enter learning mode. While in learning mode, the main [I] light connected to receiver will flash to indicate ready for programming. z Then on transmitter press the main [I] “OFF” button once, main [I] and secondary [II] light will flash 2 times to indicate the memory of this transmitter is deleted. TO DELETE ALL CODE : z Switch ON first then OFF and ON cycle for 6 times, this will enter learning mode. z Follow again switching OFF and ON cycle for 6 times, main [I] and secondary [II] light will flash 2 times to indicate all memories are deleted. BATTERY EXCHANGE: 3V CR2032 lithium battery is included ex-factory. When battery voltage is low, transmission is low. Slide down the battery cover and replace a fresh new battery. SPECIFICATION: LMT-1009 Transmitter: 3V CR2032 BATTERY included LMR-400 Receiver: Frequency: 433.92MHz Input: AC 120V Output [I]: AC 250W max. Output [II]: AC 250W max. Ta: 50 °C Tc: 80°C FAULT FINDING: No activation: Check battery polarity or running out battery Check code link successful. Check if memory setting is full Check correct wiring installation. Warning! DO NOT OVERLOAD Disconnect main power before wiring installation. Do not use in damp places like patios, cellar, flammable liquid, solvents, paints etc.. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

General Appearance of the EUT

GXO-LMT1009

DONGGUAN EMTEK Co., Ltd. REPORT NO.: KAD120328035F FCC ID:GXO-LMT1009 DATE: 04/11/2012 Page 1 of 24 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF REMOTE CONTROL SWITCH MODEL No.: LMT-1009 Trade mark: N/A FCC ID: GXO-LMT1009 REPORT NO: KAD120328035F ISSUE DATE: April 11, 2012 Prepared for WELITE CORPORATION LIMITED No.5, Second North HongYe Road 138 Industrial Park,Tang Xia Town, 523710 Dongguan City, Guangdong, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 DONGGUAN EMTEK Co., Ltd. REPORT NO.: KAD120328035F FCC ID:GXO-LMT1009 DATE: 04/11/2012 Page 2 of 24 VERIFICATION OF COMPLIANCE Applicant: WELITE CORPORATION LIMITED No.5, Second North HongYe Road 138 Industrial Park,Tang Xia Town, 523710 Dongguan City, Guangdong, China Product Description: REMOTE CONTROL SWITCH Model Number: LMT-1009 Serial Number: N/A Modulation: ASK File Number: KAD120328035F Date of Test: March 28, 2012 to April 10, 2012 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.231. The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. DONGGUAN EMTEK Co., Ltd. REPORT NO.: KAD120328035F FCC ID:GXO-LMT1009 DATE: 04/11/2012 Page 3 of 24 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 8 2.5 CONFIGURATION OF TESTED SYSTEM..................................................................................................... 9 3. SUMMARY OF TEST RESULTS ....................................................................................... 10 4. DESCRIPTION OF TEST MODES .................................................................................... 10 5. CONDUCTED EMISSIONS TEST (NOT APPLICABLE IN THIS REPORT).......... 11 5.1 MEASUREMENT PROCEDURE:................................................................................................................ 11 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 11 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 11 5.4 MEASUREMENT RESULT:....................................................................................................................... 11 5.5 CONDUCTED MEASUREMENT PHOTOS: .................................................................................................. 11 6. RADIATED EMISSION TEST ............................................................................................ 12 6.1 MEASUREMENT PROCEDURE................................................................................................................. 12 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 13 6.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 14 6.4 MEASUREMENT RESULT........................................................................................................................ 15 7. DEACTIVATION TESTING ............................................................................................... 19 7.1 REQUIREMENT....................................................................................................................................... 19 7.2 TEST SET-UP ......................................................................................................................................... 19 7.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 19 7.4 TEST PROCEDURE.................................................................................…
