H4IKB9071Bluetooth Keyboard

User’s Manual SK-9071 Bluetooth Keyboard Product Guide Getting Started Thank you for choosing this Bluetooth Keyboard . SK-9071 is to develop a BT3.0 Keyboard for mobile device, such as Media Tablet or Smart phone. It was designed to be fully compatible with i-OS, Android, Win XP, Vista and win7 system. This specification defines mechanical, reliability, dynamic, electric requirements. Set up the keyboard. 1. Turn on the keyboard 2. Press the Blue connect button. The battery light flashes green. 3. Complete Bluetooth pairing on your device. Insert the battery. ● Remove the battery compartment cover at the bottom of the keyboard by pushing it in the direction of the arrow. ● Insert two AAA batteries. ● Place back the battery compartment cover. CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions. Refer to "Important Battery Information" for disposal instructions. ● Low battery warning Red-colored LED on upper-right edge of keyboard will keep flashing when it operates in low power. ●The following description of keys applies for the operating systems that support these functions: Mute (Fn+F10) Press this key to mute/unmute the audio. Volume Down (Fn+F11) Press this key to decrease the volume. Volume Up(Fn+F12) Press this key to increase the volume. Previous Track (Fn+F7) Multimedia key to skip to the previous track in the active player. Play/Pause (Fn+F8) Multimedia key to play or pause the track or video in the active player. Next Track(Fn+F9) Multimedia key to skip to the next track in the active player. Technical data Designation Value Wireless Bluetooth EDR 2.0 Operating Frequency 2402MHz~2480MHz Storage temperature –20 °C ... +60 °C Operating temperature 0 °C ... +40 °C Battery type two alkaline batteries, type AAA Supply voltage 3V(2.2~3.3V) Current consumption max. 50 mA User’s Manual -2- FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. WARNING: Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS. Take regular breaks and keep a good posture. Consult your physician promptly if you notice any loss of motion or pain in your wrist when using the keyboard. IMPORTANT BATTERY INFORMATION ● Keep batteries out of reach of children. ● Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery compartment. ● Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries). ● Always remove old, weak, or worn-out batteries promptly and recycle or properly dispose of them in accordance with local and national disposal regulations. ● If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacturer's instructions and local and national disposal regulations. Before inserting new batteries, thoroughly clean the compartment with a damp paper towel, or follow the battery manufacturer's recommendations for cleanup. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. ● Remove the batteries if your device is to be stored for an extended period of time without being used. PRODUCT DISPOSAL INFORMATION Dispose of this product in accordance with local and national disposal regulations.

光寶科技股份有限公司 LITE-ON TECHNOLOGY CORP. 18F, 392,Ruey Kuang Road, Neihu, Taipei 11492,Taiwan, R.O.C Tel:886-2-87982888 Fax:886-2-8793-6852 http://www.liteon.com RF_160, Issue 03 Declaration of Authorization We Name: LITE-ON TECHNOLOGY CORP. Address: 18F,392,Ruey Kuang Road,Neihu,Taipei 11492,Taiwan, R.O.C City: Taipei Country: Taiwan Declare that: Agent Company name: Neutron Engineering, Inc. Address: B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Bluetooth Keyboard Type designation: SK-9071 Trademark: LITEON on our behalf. Date: 2012.12.18 City: Taipei Name: Shirly Kuo Function: Engineer Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: LITE-ON TECHNOLOGY CORP. Address: 18F,392,Ruey Kuang Road,Neihu,Taipei 11492,Taiwan, R.O.C City: Taipei Country: Taiwan To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: H4IKB9071 Reference number: SK-9071 Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2012-12.18 Name and signature of applicant: Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

RV-0000000 Project No.: 1212058 Page 2 of 8 Neutron Engineering Inc. 1212058 121205 8 RV-0000000 Project No.: 1212058 Page 3 of 8 Neutron Engineering Inc. 1212058

RV-0000000 Project No.: 1212058 Page 4 of 8 Neutron Engineering Inc. 1212058 121205 8 RV-0000000 Project No.: 1212058 Page 5 of 8 Neutron Engineering Inc. 1212058 RV-0000000 Project No.: 1212058 Page 6 of 8 Neutron Engineering Inc. 1212058 121205 8 RV-0000000 Project No.: 1212058 Page 7 of 8 Neutron Engineering Inc. RF module 1212058 121205 8 Antenna RV-0000000 Project No.: 1212058 Page 8 of 8 Neutron Engineering Inc. RF module 1212058

RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 62 of 65 Neutron Engineering Inc. 11 RF EXPOSURE COMPLIANCE 11.1 LIMIT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 NOTE: f = frequency in MHz ; *Plane-wave equivalent power density. 11.2 MEASUREMENT INSTRUMENTS LIST Item Kind of EquipmentManufacturer Type No. Serial No. Calibrated until 1 Power Meter Anritsu ML2495A 1128008 Feb,20,2013 2 Power Meter Sensor Anritsu MA2411B 1126001 Feb,20,2013 NOTE: N/A: denotes No Model Name, No Serial No. or No Calibration specified. 11.3 MPE CALCULATION METHOD E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 63 of 65 Neutron Engineering Inc. 11.4 TEST SETUP LAYOUT 11.5 DEVIATION FROM TEST STANDARD No deviation 11.6 EUT OPERATING CONDITIONS The EUT tested system was configured as the statements of 4.6 Unless otherwise a special operating condition is specified in the follows during the testing. 11.7 TEST RESULTS The highest output power of this equipment is below threshold of 24 mW (60/f GHz), therefore SAR test is not required.

RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 1 of 65 Neutron Engineering Inc. Radio Test Report FCC ID: H4IKB9071 This report concerns (check one) : Original Grant Class II Change Issued Date : Jan. 02, 2013 Project No. : 1212058 Equipment : Bluetooth Keyboard Model Name : SK-9071 Applicant : LITE-ON TECHNOLOGY CORP. Address : 18F, 392, Ruey Kuang Road, Neihu, Taipei 11492, Taiwan, R.O.C Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 07, 2012 Date of Test: Dec. 07, 2012 ~ Dec. 21, 2012 Testing Engineer : (Rush Kao) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 2 of 65 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 3 of 65 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 6 1 CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 DESCRIPTION OF SUPPORT UNITS 15 4 ANTENNA CONDUCTED SPURIOUS EMISSION 16 4.1 LIMIT 16 4.2 MEASUREMENT INSTRUMENTS LIST 16 4.3 TEST PROCEDURES 16 4.4 TEST SETUP LAYOUT 16 4.5 DEVIATION FROM TEST STANDARD 16 4.6 EUT OPERATING CONDITIONS 16 4.7 TEST RESULTS 17 5 HOPPING CHANNEL SEPARATION 21 5.1 LIMIT 21 5.2 MEASUREMENT INSTRUMENTS LIST 21 5.3 MEASURING INSTRUMENTS SETTING 21 5.4 TEST PROCEDURES 21 5.5 TEST SETUP LAYOUT 21 5.6 DEVIATION FROM TEST STANDARD 21 5.7 EUT OPERATING CONDITIONS 21 5.8 TEST RESULTS 22 6 MAXIMUM PEAK CONDUCTED OUTPUT POWER 26 6.1 LIMIT 26 6.2 MEASUREMENT INSTRUMENTS LIST 26 6.3 TEST PROCEDURES 26 6.4 TEST SETUP LAYOUT 26 6.5 DEVIATION FROM TEST STANDARD 26 6.6 EUT OPERATING CONDITIONS 26 6.7 TEST RESULTS 27 7 RADIATED SPURIOUS EMISSION (9 KHZ TO 1 GHZ) 29 7.1 LIMIT 29 RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 4 of 65 Neutron Engineering Inc. Table of Contents 7.2 MEASUREMENT INSTRUMENTS LIST 30 7.3 MEASURING INSTRUMENTS SETTING 30 7.4 TEST PROCEDURES 31 7.5 DEVIATION FROM TEST STANDARD 31 7.6 TEST SETUP LAYOUT 31 7.7 EUT OPERATING CONDITIONS 32 7.8 TEST RESULTS 33 8 RADIATED SPURIOUS EMISSION (ABOVE 1 GHZ) 35 8.1 LIMIT 35 8.2 MEASUREMENT INSTRUMENTS LIST 36 8.3 MEASURING INSTRUMENTS SETTING 36 8.4 TEST PROCEDURES 37 8.5 DEVIATION FROM TEST STANDARD 37 8.6 TEST SETUP LAYOUT 37 8.7 EUT OPERATING CONDITIONS 38 8.8 TEST RESULTS 39 8.9 TEST RESULTS (RESTRICTED BANDS) 51 9 NUMBER OF HOPPING FREQUENCY 55 9.1 LIMIT 55 9.2 MEASUREMENT INSTRUMENTS LIST 55 9.3 MEASURING INSTRUMENTS SETTING 55 9.4 TEST PROCEDURES 55 9.5 TEST SETUP LAYOUT 55 9.6 DEVIATION FROM TEST STANDARD 55 9.7 EUT OPERATING CONDITIONS 55 9.8 TEST RESULTS 56 10 AVERAGE TIME OF OCCUPANCY 57 10.1 LIMIT 57 10.2 MEASUREMENT INSTRUMENTS LIST 57 10.3 TEST PROCEDURES 57 10.4 TEST SETUP LAYOUT 58 10.5 DEVIATION FROM TEST STANDARD 58 10.6 EUT OPERATING CONDITIONS 58 10.7 TEST RESULTS 59 11 RF EXPOSURE COMPLIANCE 62 11.1 LIMIT 62 11.2 MEASUREMENT INSTRUMENTS LIST 62 11.3 MPE CALCULATION METHOD 62 RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 5 of 65 Neutron Engineering Inc. Table of Contents 11.4 TEST SETUP LAYOUT 63 11.5 DEVIATION FROM TEST STANDARD 63 11.6 EUT OPERATING CONDITIONS 63 11.7 TEST RESULTS 63 12 EUT TEST PHOTO 64 RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 6 of 65 Neutron Engineering Inc. REPORT ISSUED HISTORY Revised Version No. Description Issued Date - Initial Issue. Jan. 02, 2013 RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 7 of 65 Neutron Engineering Inc. 1 CERTIFICATION E q u i p m e n t : Bluetooth Keyboard Brand Name : LITEON Model Name : SK-9071 A p p l i c a n t : LITE-ON TECHNOLOGY CORP. Date of Test : Dec. 07, 2012 ~ Dec. 21, 2012 Standards : FCC Part 15, Subpart C: 2010 ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1212058) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). RV-0000000 Report No.: NEI-FCC…

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 64 of 65 Neutron Engineering Inc. 12 EUT TEST PHOTO Radiated spurious emission test photos Below 1 GHz 1212058 1212058 RV-0000000 Report No.: NEI-FCCP-1-1212058 Page 65 of 65 Neutron Engineering Inc. Radiated spurious emission test photos Above 1 GHz 1212058 1212058
