H4IKB9660Wireless Keyboard

SK-9660 Wireless Keyboard /SD-9080 USB Transceiver Product Guide Getting Started Thank you for choosing this 2.4G Wireless Keyboard Kits. It operates with digital radio technology to ensure no hinder communication between the keyboard and your computer without connecting cable. The transmission and receiving of keyboard are free from angle restriction. Preparing keyboard and Dongle Before working with your new keyboard, look at the "Hardware Installation", and take a few one-time preparations. Hardware Installation ● Place the dongle at least 20 cm from other electrical devices (e.g. monitor) to achieve optimum performance. ● The distance between the keyboard and dongle should not exceed 10 M. ● Do not place the dongle on metal surfaces. Step 1: Connect the receiver ● Plug the dongle connector into an USB port. ● SYSTEM will take around 10 sec to find your keyboard and mouse automatically. Step 2: Insert batteries Inserting batteries in keyboard The keyboard requires two alkaline batteries (AAA). ● Remove the battery compartment cover on the bottom of the keyboard by pushing it in the direction of arrow. ● Insert two AAA batteries. The illustration in the battery compartment shows how to insert the batteries properly. ● Recover the battery compartment by pushing the locking lug under the battery compartment. CAUTION: Risk of explosion if battery is replaced by an incorrect type. Use and replace only with correct size and type (alkaline or zinc-carbon)of battery. Working Keyboard USB Transceiver and keyboard electrical specification The Transceiver will have one main function: translate radio communications from the mouse to the PC via USB Full Speed USB Specification Compliance., meets Universal Serial Bus Specification version 2.0. Support USB Suspend Mode. Keyboard The following description of few keys applies for the operating systems that support these functions (e.g. Windows 2000/XP/Vista/Windows 7). Vista Key Press Vista key to open Start Manu Application key Press Application key is same as Right Mouse key to open function Manu Previous Track Combine keys to skip to the forward title in the active player. Play/Pause Combine keys to Start or Pause the soundtrack in active player.



Stop Combine keys to end the soundtrack or video. Next Track Combine keys to skip to the next title in the active player. Mute Press this key to On/Off the volume. Volume down Press this key to decreasing the volume. Volume Up Press this key to increasing the volume. Search Activate the OS default search function E-mail Use this key to start the standard e-mail program for your system Technical data Designation Value Modulation GFSK Operating Frequency 2403MHz~2480MHz channel 78 channel 2.4GHz ISM Band Storage temperature –20 °C ... +60 °C Operating temperature 0 °C ... +40 °C Keyboard Battery type two alkaline batteries, type AAA Keyboard Supply voltage 2.2~3.3V Keyboard Current consumption max. 50 mA USB Transceiver Supply voltage DC 5.0 V ±5 % USB Transceiver Current consumption max..100 mA FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. This Class B device complies with part 15 of the FCC rules,Canadian ICES-003,RSS-210.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Any changes of modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. IMPORTANT BATTERY INFORMATION ● Keep batteries out of reach of children. ● Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery compartment. ● Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries). ● Always remove old, weak, or worn-out batteries promptly and recycle or proper disposal of them in accordance with Local and National Disposal Regulations. ● If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacture's instructions and Local and National Disposal Regulations. Before inserting new batteries, thoroughly clean the compartment with a damp paper towel, or follow the battery manufacture's recommendations for cleanup. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. ● Remove the batteries if your device is to be stored for an extended period of time without being used. PRODUCT DISPOSAL INFORMATION Dispose of this product in accordance with Local and National Disposal Regulations

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Date: July 21, 2010 FCC ID: H4IKB9660 (for Wireless Keyboard), H4IMS9063(for Wireless Mouse) Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- Shirly Kuo / Engineer Lite-On Technology Corporation Tel: 886-2-2222-6181#6115 Fax: 886-2- 2223-1519 [email protected]

Power of Attorney Date: July 21, 2010 To whom it may concern: We, the undersigned Lite-On Technology Corporation hereby authorize Bureau Veritas Consumer Products Services(H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. FCC ID: H4IKB9660 (for Wireless Keyboard), H4IMS9063(for Wireless Mouse) If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------- Shirly Kuo / Engineer Lite-On Technology Corporation Tel: 886-2-2222-6181#6115 Fax: 886-2- 2223-1519 [email protected]

Page: 1

FCC ID: H4IKB9660 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

FCC ID: H4IKB9660 IC: 4491A-KB9660 N14939 SCT XXXXXXXX-XXXX M/N():SK-9660 Rating:3V 50mA E 1 4 56 1 4 HPK-SK-9660 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received. Including interference that may cause undesired operation. T3A002 CMIIT ID:XXXXXXXX xxxxx xxxxxxx XXXXXXXX Rating3V50mA

Page: 2 Page: 3 Page: 4

FCC ID: H4IKB9660 Report No.: RF990709D08 Operational Description The transmitter of the EUT (Wireless Keyboard) is powered by 3Vdc from batteries. The type of antenna is Printed Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.:RF990709D08 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990709D08 MODEL NO.: SK-9660 FCC ID: H4IKB9660 RECEIVED: July 9, 2010 TESTED: July 14, 2010 ISSUED: July 22, 2010 APPLICANT: Lite-On Technology Corporation ADDRESS: 90,Chien I Road, Chung Ho, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 25 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.:RF990709D08 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION...........................................................................................3 2. SUMMARY OF TEST RESULTS...................................................................4 2.1 MEASUREMENT UNCERTAINTY................................................................4 3. GENERAL INFORMATION...........................................................................5 3.1 GENERAL DESCRIPTION OF EUT..............................................................5 3.2 DESCRIPTION OF TEST MODES................................................................6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:...............7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................8 3.4 DESCRIPTION OF SUPPORT UNITS..........................................................8 4. TEST TYPES AND RESULTS.......................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT................................................9 4.2 RADIATED EMISSION MEASUREMENT.....................................................9 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................9 4.2.2 TEST INSTRUMENTS................................................................................10 4.2.3 TEST PROCEDURES.................................................................................11 4.2.4 DEVIATION FROM TEST STANDARD.......................................................11 4.2.5 TEST SETUP..............................................................................................12 4.2.6 EUT OPERATING CONDITIONS................................................................12 4.2.7 TEST RESULTS..........................................................................................13 4.3 BAND EDGES MEASUREMENT................................................................20 4.3.1 LIMITS OF BAND EDGES MEASUREMENT.............................................20 4.3.2 TEST INSTRUMENTS................................................................................20 4.3.3 TEST PROCEDURE...................................................................................20 4.3.4 DEVIATION FROM TEST STANDARD.......................................................20 4.3.5 EUT OPERATING CONDITION..................................................................20 4.3.6 TEST RESULTS..........................................................................................20 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................23 6. INFORMATION ON THE TESTING LABORATORIES................................24 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................25 Report No.:RF990709D08 3 Report Format Version 3.0.1 1. CERTIFICATION PRODUCT: Wireless Keyboard BRAND NAME: acer MODEL NO.: SK-9660 APPLICANT: Lite-On Technology Corporation TESTED: July 14, 2010 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 22, 2010 ( Jessica Cheng / Specialist ) TECHNICAL ACCEPTANCE : , DATE: July 22, 2010 Responsible for RF ( Jamison Chan / Supervisor ) APPROVED BY : , DATE: July 22, 2010 ( Ken Liu / Assistant Manager) Report No.:RF990709D08 4 Report Format Version 3.0.1 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –5.7dB at 2390.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Frequency Uncertainty 30MHz ~ 1GHz 3.67 dB Radiated emissions Above 1GHz 2.89 dB Report No.:RF990709D08 5 Report Format Version 3.0.1 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUT Wireless Keyboard MODEL NO. SK-9660 FCC ID H4IKB9660 POWER SUPPLY 3Vdc from batteries MODULATION TYPE GFSK OPERATING FREQUENCY 2403MHz ~ 2480MHz NUMBER OF CHANNEL 78 ANTENNA TYPE Printed antenna with…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
