LiteON Technology 第 1 頁 共3 頁 User’s Manual Product Name: Wireless Mouse Model NO.: SM-2056 (27 MHZ Multi-Channel ) Issue Date: Apr-20- 2006 LiteON Technology 第 2 頁 共3 頁 1. Product brief descreption This is product user’s manual of wireless mouse. It is a multi-channels radio (27 MHZ) product. Mouse function includes pointing, left/right button and wheel function (totally 3 button). The Agilent ADNS-2030 optical sensor is built in optical mouse, it offer a high quality performance for mouse function. Need a receiver at PC end for supporting the function of receiving data.. Product Outline of Mouse *Mouse: Operation Voltage: Voltage supplied to device: 3 VDC (AA battery *2) 2 Operation The product needs to make pairing with USB receiver before normal application. In general we can use the product directly by the user because the pairing process has been done at manufacturer site. However, the pairing process needs to be done if there is no response from mouse. * How to make pairing (step by step as below process) by user: 1. Firstly, press the connect button on receiver for more than 0.5s then release. The LED indictor will be on and flashing with correct procedure. It is a normal status while waiting for pairing. 2. Secondly, press the connect button on another remote device and release button. 3. Thirdly, check the LED status of the receiver. It should flash quickly and then turn off. Its means the pairing process have completely done. 4. In order to ensure the pairing work, we need to hit the left/right button or moving mouse to see the response. The LED on the receiver will on when its receive data from remote device.. * Check the batteries installation, life power and orientation in device if pairing was LiteON Technology 第 3 頁 共3 頁 unsuccessfully. Repeats pairing process step 1~4 after verify the battery set. 3 Radio parameter *Table-1 Parameter of radio part Item/ ParameterPerformance Field operation distance2.5m for keyboard Modulation Scheme FSK Channel11 channels (Maximum) RF channel: – 11 channels (programmable) 26.995, 27.020, 27.045, 27.070 27.095, 27.120, 27.145, 27.170 27.195, 27.225, 27.255 (MHZ) Antenna Type A on board trace loop on mouse PC board. Mouse’s FCC- ID H4IMS27RF002 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 6

FCC ID: H4IMS27RF002 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. LABEL

MARK ISSUE DATE REVER SPH-R&D-1002S-02A Note: a. Size: (36.1+/-0.10mm)*(25.0+/-0.10mm) b. Material: Paper; Thickness: 0.08mm c. Color: Black font with Silitek colorbackground d. All mark shall high than 5mm e. Part number:836-01555-00A 22.45+/-0.1mm 38.50+/-0.1 mm 38.00+/-0.1 mm R31.50+/-0.1 R35.50+/-0.1 R2.50+/-0.1mm(2X) R0.50+/-0.1mm(4X) 3 6 . 1 + / - 0 . 1 m m MADE IN CHINA VOLTS:3V AMPS:45mA Model:SM-2056 This device complies with Canada ICES-003 Class B The windos logo is a registered of Microsoft Corporation: Warning:Improper Or Prologed mouse Use May Result In Injury. S/N: P/N: FCC ID:H4IMS27RF002 FEDERAL .COMMUNICATIONS COMMISSION This device complies with part 15 of the FCC Rules.Operation is subject to the following two conditions:(1)this is device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation.

Page 7 Page 8 Page 9

FCC ID: H4IMS27RF002 Report No.: RF950418A06A Reference No.: 950418A06 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3.0V batteries. The type of antenna is Loop antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF950418A06A1Report Format Version 2.0.5 Reference No.: 950418A06 FCC TEST REPORT REPORT NO.: RF950418A06A MODEL NO.: SM-2056 RECEIVED: Apr. 18, 2006 TESTED: May 8, 2006 ISSUED: May 11, 2006 APPLICANT: Lite-On Technology Corporation ADDRESS: 90,Chien I Road, Chung Ho, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 17 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF950418A06A2Report Format Version 2.0.5 Reference No.: 950418A06 Table of Contents 1CERTIFICATION.............................................................................................3 2SUMMARY OF TEST RESULTS.....................................................................4 2.1MEASUREMENT UNCERTAINTY..................................................................4 3GENERAL INFORMATION.............................................................................5 3.1GENERAL DESCRIPTION OF EUT................................................................5 3.1DESCRIPTION OF TEST MODES..................................................................6 3.2CONFIGURATION OF SYSTEM UNDER TEST.............................................6 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS.................................8 3.4DESCRIPTION OF SUPPORT UNITS............................................................8 4TEST PROCEDURE AND RESULT................................................................9 4.1CONDUCTED EMISSION MEASUREMENT..................................................9 4.2RADIATED EMISSION MEASUREMENT.......................................................9 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.....................................9 4.2.2TEST INSTRUMENT.....................................................................................10 4.2.3TEST PROCEDURE......................................................................................11 4.2.4TEST SETUP................................................................................................12 4.2.5EUT OPERATING CONDITION....................................................................12 4.2.6TEST RESULT..............................................................................................13 5PHOTOGRAPHS OF THE TEST CONFIGURATION....................................15 6INFORMATION ON THE TESTING LABORATORIES..................................16 APPENDIX-A....................................................................................................A-1 Report No.: RF950418A06A3Report Format Version 2.0.5 Reference No.: 950418A06 1 CERTIFICATION PRODUCT: Wireless Mouse BRAND NAME: LITEON MODEL NO.: SM-2056 APPLICANT: Lite-On Technology Corporation TEST SAMPLE: ENGINEERING SAMPLE TESTED: May 8, 2006 STANDARDS: FCC Part 15, Subpart C (Section 15.227), ANSI C63.4 -2003 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:May 11, 2006 ( Jessica Cheng ) TECHNICAL ACCEPTANCE:, DATE:May 11, 2006 Responsible for RF ( Ken Liu ) APPROVED BY:, DATE:May 11, 2006 ( Gary Chang / Supervisor ) Report No.: RF950418A06A4Report Format Version 2.0.5 Reference No.: 950418A06 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 3Vdc from battery 15.227 15.209 Radiated Emission TestPASS Minimum passing margin is –7.72dB at 433.09MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. MeasurementFrequencyUncertainty 30MHz ~ 200MHz3.59 dB 200MHz ~1000MHz3.61 dB 1GHz ~ 18GHz2.26 dB Radiated emissions 18GHz ~ 40GHz1.94 dB Report No.: RF950418A06A5Report Format Version 2.0.5 Reference No.: 950418A06 3 GENERAL INFORMATION 3.1GENERAL DESCRIPTION OF EUT PRODUCT Wireless Mouse MODEL NO. SM-2056 FCC ID H4IMS27RF002 POWER SUPPLY 3Vdc from battery MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 26.995, 27.020, 27.045, 27.070, 27.095, 27.120, 27.145, 27.170, 27.195, 27.225, 27.255MHz NUMBER OF CHANNEL 11 ANTENNA TYPE Loop antenna DATA CABLE NA I/O PORTS NA ASSOCIATED DEVICES NA NOTE: 1. The EUT is a Wireless Mouse, which is a transmitter. 2. The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. Report No.: RF950418A06A6Report Format Version 2.0.5 Reference No.: 950418A06 3.1 DESCRIPTION OF TEST MODES Eleven channels were provided to this EUT. Channel Frequency (MHz) 126.995 MHz 227.020 MHz 327.045 MHz 427.070 MHz 527.095 MHz 627.120 MHz 727.145 MHz 827.170 MHz 927.195 MHz 1027.225 MHz 1127.255 MHz Note: The channel 6 (27.120MHz) was chosen for final test. 3.2 CONFIGURATION OF SYSTEM UNDER TEST Test Table (Powered from batteries) (EUT) Wireless Mouse Report No.: RF950418A06A7Report Format Version 2.0.5 Reference No.: 950418A06 3.2.1 TEST MODE APPLICABILITY…
