H4IMS8863Lenovo wireless zone touch mouse

ZTM600 Wireless Touch Mouse /SD-9082 USB Dongle Product Guide Getting Started Thank you for choosing this 2.4G Wireless Mouse Kits. It operates with digital radio technology to ensure no hinder communication among the mouse and your computer without connecting cable. The transmission and receiving of mouse are free from angle restriction. Preparing mouse and Dongle Before working with your new mouse, please look at the "Hardware Installation", and take a few one-time preparations. Designation Value Modulation GFSK Operating Frequency 2403MHz~2480MHz channel 78 channel 2.4GHz ISM Band Storage temperature –20 °C ... +60 °C Operating temperature 0 °C ... +40 °C Mouse Battery type One alkaline battery, type AAA Mouse Supply voltage 1.5V(1.2~1.65V) Mouse Current consumption max. 50 mA Dongle Supply voltage DC 5.0 V ±5 % Dongle Current consumption max..100 mA -7- FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. This Class B device complies with part 15 of the FCC rules, Canada ICES-003,RSS-210.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.

Declaration of Authorization We Name: Lite-on Technology Corp. Address: 18F,392,Ruey Kuang Road,Neihu,Taipei 11492,Taiwan, R.O.C City: Taipei Country: Taiwan Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s), including the signing of the related documents such as 731 forms: Product description: Lenovo wireless zone touch mouse Type designation: ZTM600 Trademark: Lenovo on our behalf. Date: 2014-02-19 City: Taipei Name: Shirly Kuo Function: Engineer Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

RV-0000000 Project No.: 1402013 Page 2 of 7 Neutron Engineering Inc.

41.55 mm 30.43 mm

RV-0000000 Project No.: 1402013 Page 3 of 7 Neutron Engineering Inc. RV-0000000 Project No.: 1402013 Page 4 of 7 Neutron Engineering Inc. Antenna RV-0000000 Project No.: 1402013 Page 5 of 7 Neutron Engineering Inc. Antenna RV-0000000 Project No.: 1402013 Page 6 of 7 Neutron Engineering Inc. RV-0000000 Project No.: 1402013 Page 7 of 7 Neutron Engineering Inc.

RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 1 of 42 Neutron Engineering Inc. FCC Radio Test Report FCC ID: H4IMS8863 This report concerns (check one) : Original Grant Class II Change Issued Date : Feb. 25, 2014 Project No. : 1402013 Equipment : Lenovo wireless zone touch mouse Model Name : ZTM600 Applicant : LITE-ON TECHNOLOGY CORP. Address : 18F, 392 , Ruey Kuang Road, Neihu, Taipei 11492, Taiwan, R.O.C Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Feb. 05, 2014 Date of Test: Feb. 05, 2014 ~ Feb. 24, 2014 Testing Engineer : (Rush Kao) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 2 of 42 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 3 of 42 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 4 1 CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 RADIATED SPURIOUS EMISSION (9 KHZ TO 1 GHZ) 13 4.1 LIMIT 13 4.2 MEASUREMENT INSTRUMENTS LIST 14 4.3 MEASURING INSTRUMENTS SETTING 14 4.4 TEST PROCEDURES 16 4.5 DEVIATION FROM TEST STANDARD 16 4.6 TEST SETUP LAYOUT 16 4.7 EUT OPERATING CONDITIONS 17 4.8 TEST RESULTS 18 5 RADIATED SPURIOUS EMISSION (ABOVE 1 GHZ) 20 5.1 LIMIT 20 5.2 MEASUREMENT INSTRUMENTS LIST 21 5.3 MEASURING INSTRUMENTS SETTING 21 5.4 TEST PROCEDURES 22 5.5 DEVIATION FROM TEST STANDARD 22 5.6 TEST SETUP LAYOUT 22 5.7 EUT OPERATING CONDITIONS 23 5.8 TEST RESULTS 24 5.9 TEST RESULTS (RESTRICTED BANDS) 36 5.10 TEST RESULTS - THE TENTH HARMONIC 40 6 EUT TEST PHOTO 42 RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 4 of 42 Neutron Engineering Inc. REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1402013 Original Issue. Feb. 25, 2014 RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 5 of 42 Neutron Engineering Inc. 1 CERTIFICATION Equipment : Lenovo wireless zone touch mouse Brand Name : Lenovo Model Name : ZTM600 Applicant : LITE-ON TECHNOLOGY CORP. Date of Test : Feb. 05, 2014 ~ Feb. 24, 2014 Standard(s) : FCC Part 15, Subpart C(15.249): 2012 ANSI C63.4- 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1402013) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 6 of 42 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS FCC Part 15, Subpart C(15.249): 2012 Standard Clause Test Item Result 15.207 Conducted Emission N/A 15.249(d) or 15.209 Radiated Spurious Emission PASS 15.205 Restricted Bands PASS NOTE: (1) N/A: denotes test is not applicable in this test report. RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 7 of 42 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report: Radiated emission Test (Below 1 GHz): CB08: (FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Radiated emission Test (Above 1 GHz): CB08: (VCCI RN: G-91; FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) 2.2 MEASUREMENT UNCERTAINTY The measurement uncertainty is not specified by FCC rules and for reference only. The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95%. The measurement instrumentation uncertainty considerations contained in CISPR 16-4-2. Radiated emission test: Test Site Item Measurement Frequency Range Uncertainty NOTE CB08 Radiated emission at 3m Horizontal Polarization 30 - 200MHz 3.35 dB 200 - 1000MHz 3.11 dB 1 - 18GHz 3.97 dB 18 - 40GHz 4.01 dB Vertical Polarization 30 - 200MHz 3.22 dB 200 - 1000MHz 3.24 dB 1 - 18GHz 4.05 dB 18 - 40GHz 4.04 dB Our calcul…

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCP-1-1402013 Page 42 of 42 Neutron Engineering Inc. 6 EUT TEST PHOTO Radiated spurious emission test photos
