H4TFM-RIB3HC16-bit ISA Bus Data/Fax/Voice Modem Card

© 1998 PCTEST Lab FCC ID SAMPLE LABEL LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Required FCC statement will be placed in the users manual per § 15.19(c) of the FCC Rules. Fig 12. Sample label FCC ID: H4TFM-RIB3HC

June 19, 1998 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 SUBJECT:Zoltrix Inc. FCC ID: HRTFM-RIB3HC Gentlemen: Transmitted herewith, on behalf of Zoltrix Inc., is an application for certification of the following Data/Fax/Voice Modem Card: FCC ID:HRTFM-RIB3HC MODEL(s):FM-RIB3HC TRADE NAME:ZOLTRIX EUT TYPE:16-bit ISA Bus Data/Fax/Voice Modem Card Max. Baud Rate(s):56,000 (Flex) bps (Data Modem) 14,400 bps (Fax Send/Receive) Attached is the applicant’s attestation statement, measurement report (Radiation emission data, Line Conducted emission data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Andrew Ma General Manager Zoltrix Inc.

June 19, 1998 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 SUBJECT:Zoltrix Inc. FCC ID: H4TFM-RIB3HC Gentlemen: Transmitted herewith, on behalf of Zoltrix Inc., is an application for certification of the following Data/Fax/Voice Modem Card: FCC ID:H4TFM-RIB3HC MODEL(s):FM-RIB3HC TRADE NAME:ZOLTRIX EUT TYPE:PCI Bus Data/Fax/Voice Modem Card Max. Baud Rate(s):56,000 (K56Flex) bps (Data Modem) 14,400 bps (Fax Send/Receive) Attached is the applicant’s attestation statement, measurement report (Radiation emission data, Line Conducted emission data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Andrew Ma General Manager Zoltrix Inc.

Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc. Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc.

© 1998 PCTEST Lab FCC ID SAMPLE LABEL LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Required FCC statement will be placed in the users manual per § 15.19(c) of the FCC Rules. Fig 12. Sample label FCC ID: H4TFM-RIB3HC

Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc. Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc. Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc. Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc.

PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE ZOLTRIX, Inc.Dates of Tests: June 16-17, 1998 41778 Christy StreetTest Report S/N: B.980609407.H4T Fremont, CA 94538Test Site: PCTEST Lab, MD U.S.A. Attn: Andrew Ma, General ManagerJob No.: CHANEY #8009A FCC IDENTIFIER APPLICANT Rule Part(s): FCC Part 15 Subpart B Equipment Class:Class B Digital Device / Peripheral (JBP) EUT Type:16-Bit ISA Bus Data/Fax/Voice Modem Card Max. Baud Rate(s):56,000 (Flex) bps (Data Modem) 14,400 bps (Fax Send/Receive) Crystal/Oscillator(s):28.224 MHz Model:FM-RIB3HC This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 with the following remarks (Note Codes): (#37): * (#68) This Grant does not pertain to Part 68 Registration requirements. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). H4TFM-RIB3HC ZOLTRIX, INC. Lab Code 100431-0 © 1998 PCTEST Engineering Lab., Inc. Certification © 1998 PCTEST Engineering Laboratory, Inc.Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED) 7-9 PLOTS OF EMISSIONS 10 TEST DATA (RADIATED) 11 SAMPLE CALCULATIONS 12 ACCURACY OF MEASUREMENT 13 LIST OF TEST EQUIPMENT 14 TEST SOFTWARE USED 15 RECOMMENDATION / CONCLUSION 16 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Applicant Name:ZOLTRIX, INC. Address:41778 Christy Street Fremont, CA 94538 Attention:Andrew Ma, General Manager •FCC ID:H4TFM-RIB3HC •Class: B Digital Device / Peripheral (JBP) •EUT Type:16-Bit ISA Bus Data/Fax/Voice Modem Card •Trade Name:ZOLTRIX •Model:FM-RIB3HC •Max. Baud Rate(s):56,000 (Flex) bps (Data Modem) 14,400 bps (Fax Send/Receive) •Crystal/Oscillator(s):28.224 MHz •Ports/Connectors:(2) RJ-11C: Line & Phone (2) Mini-jack: Audio IN & OUT •FCC Rule Part(s): Part 15 Subpart B •Test Procedure:ANSI C-63.4 (1992) •Dates of Tests: June 16-17, 1998 •Place of Tests: PCTEST Lab, Columbia, MD U.S.A. •Test Report S/N:B.980609407.H4T •Job No.:CHANEY #8009A Note: This report does not include FCC Part 68 testing and registration. Lab Code 100431-0 Test Report S/N: B.980609407.H4TFCC Class B Test Dates: June 16-17, 1998Certification © 1998 PCTEST LabZOLTRIX, Inc. FCC ID: H4TFM-RIB3HC1 16-Bit ISA Bus Data/Fax/Voice Modem Card Introduction The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40 GHz (ANSI C63.4-1992) was used in determin- ing radiated and conducted emissions emanating from ZOLTRIX, Inc. 16-Bit ISA Bus Data/Fax/Voice Modem Card FCC ID: H4TFM-RIB3HC. These measurement tests were conducted at PCTEST Engineering Laboratory facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the high- est points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39°°11’15" N latitude and 76°°49’38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the PCTEST measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Fig. 1. The map above shows the Columbia vicinity area. The map also shows PCTest Lab, FCC Lab and BWI airport. (Scale 1"=2miles) Test Report S/N: B.980609407.H4TFCC Class B Test Dates: June 16-17, 1998Certification © 1998 PCTEST LabZOLTRIX, Inc. FCC ID: H4TFM-RIB3HC2 16-Bit ISA Bus Data/Fax/Voice Modem Card Product Information Equipment Description: The Equipment Under Test (EUT) is the ZOLTRIX, Inc. (Model: FM-RIB3HC) 16-Bit ISA Bus Data/Fax/Voice Modem Card FCC ID: H4TFM-RIB3HC. The EUT features Speakerphone, and Personal Voice Messaging System. Max. Baud Rate(s):Data: 56,000 (Flex) bps (Data) Fax: 14,400 bps (Send/Receive) Crystal/Oscillator(s):28.224MHz Chipset(s):Rockwell RCVDL56DPGL/SP Rockwell 11229-14 External Port(s):RJ-11C: Telephone Line connector RJ-11C: Telephone Handset connector Mini-jack: audio-IN Mini-jack: audio-OUT Internal Port(s):4-pin audio connector (x2) Cable(s):Unshielded Telco wires Bus Compatibility:16-Bit ISA Bus interface Power Supply:from host computer EMI suppression device(s) installed in production: *see schematics (Attachment G) EMI suppression device(s) added and/or modified during testing: *none Test Report S/N: B.980609407.H4TFCC Class B Test Dates: June 16-17…

Text truncated - open the document above for the full version.

PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE ZOLTRIX, Inc.Dates of Tests: June 16-17, 1998 41778 Christy StreetTest Report S/N: B.980609407.H4T Fremont, CA 94538Test Site: PCTEST Lab, MD U.S.A. Attn: Andrew Ma, General ManagerJob No.: CHANEY #8009A FCC IDENTIFIER APPLICANT Rule Part(s): FCC Part 15 Subpart B Equipment Class:Class B Digital Device / Peripheral (JBP) EUT Type:PCI Bus Data/Fax/Voice Modem Card Max. Baud Rate(s):56,000 (K56Flex) bps (Data Modem) 14,400 bps (Fax Send/Receive) Crystal/Oscillator(s):28.224 MHz Model:FM-RIB3HC This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 with the following remarks (Note Codes): (#37): * (#68) This Grant does not pertain to Part 68 Registration requirements. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). H4TFM-RIB3HC ZOLTRIX, INC. Lab Code 100431-0 © 1998 PCTEST Engineering Lab., Inc. © 1998 PCTEST Engineering Laboratory, Inc. FCC Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED) 7 TEST DATA (RADIATED) 8 SAMPLE CALCULATIONS 9 ACCURACY OF MEASUREMENT10 LIST OF TEST EQUIPMENT11 TEST SOFTWARE USED12 RECOMMENDATION / CONCLUSION13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Applicant Name:ZOLTRIX, INC. Address:41778 Christy Street Fremont, CA 94538 Attention:Andrew Ma, General Manager •FCC ID:H4TFM-RIB3HC •Class: B Digital Device / Peripheral (JBP) •EUT Type:PCI Bus Data/Fax/Voice Modem Card •Trade Name:ZOLTRIX •Model:FM-RIB3HC •Max. Baud Rate(s):56,000 (K56Flex) bps (Data Modem) 14,400 bps (Fax Send/Receive) •Crystal/Oscillator(s):28.224 MHz •Ports/Connectors:(2) RJ-11C: Line & Phone (2) Mini-jack: Mic, Speaker •FCC Rule Part(s): Part 15 Subpart B •Test Procedure:ANSI C-63.4 (1992) •Dates of Tests: June 16-17, 1998 •Place of Tests: PCTEST Lab, Columbia, MD U.S.A. •Test Report S/N:B.980609407.H4T •Job No.:CHANEY #8009A Note: This report does not include FCC Part 68 testing and registration. Lab Code 100431-0 Test Report S/N: B.980609407.H4TFCC Class B Test Dates: June 16-17, 1998Certification © 1998 PCTEST LabZOLTRIX, Inc. FCC ID: H4TFM-RIB3HC1 PCI Bus Data/Fax/Voice Modem Card Introduction The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40 GHz (ANSI C63.4-1992) was used in determin- ing radiated and conducted emissions emanating from ZOLTRIX, Inc. PCI Bus Data/Fax/Voice Modem Card FCC ID: H4TFM-RIB3HC. These measurement tests were conducted at PCTEST Engineering Laboratory facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the high- est points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39°°11’15" N latitude and 76°°49’38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the PCTEST measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Fig. 1. The map above shows the Columbia vicinity area. The map also shows PCTest Lab, FCC Lab and BWI airport. (Scale 1"=2miles) Test Report S/N: B.980609407.H4TFCC Class B Test Dates: June 16-17, 1998Certification © 1998 PCTEST LabZOLTRIX, Inc. FCC ID: H4TFM-RIB3HC2 PCI Bus Data/Fax/Voice Modem Card Product Information Equipment Description: The Equipment Under Test (EUT) is the ZOLTRIX, Inc. (Model: FM-RIB3HC) PCI Bus Data/Fax/Voice Modem Card FCC ID: H4TFM-RIB3HC. The EUT features Speaker- phone, and Personal Voice Messaging System. Max. Baud Rate(s):Data: 56,000 (K56 Flex) bps (Data) Fax: 14,400 bps (Send/Receive) Crystal/Oscillator(s):28.224MHz Chipset(s):Rockwell RCVDL56DPGL/SP Rockwell 11229-14 External Port(s):RJ-11C: Telephone Line connector RJ-11C: Telephone Handset connector Mini-jack: audio-IN Mini-jack: audio-OUT Internal Port(s):4-pin audio connector (x2) Cable(s):Unshielded Telco wires Bus Compatibility:PCI Bus interface Power Supply:from host computer EMI suppression device(s) installed in production: *see schematics (Attachment G) EMI suppression device(s) added and/or modified during testing: *none Test Report S/N: B.980609407.H4TFCC Class B Test Dates: June 16-17, 1998Certification © 1998 PCTEST LabZOLTRIX, Inc. FCC ID: H4TFM-RIB3HC3 PCI B…

Text truncated - open the document above for the full version.

Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc. Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc. Test Report S/N: B.980609407.H4TFCC Class B Test Date(s): June 16-17, 1998Certification © 1998 PCTEST LabFCC ID: H4TFM-RIB3HC NVLAP Lab Code: 100431-0 ZOLTRIX, Inc.
