H79DFZM-TS210ZigBee module

Delta Electronics Incorporated
ZigBee module - FCC ID H79DFZM-TS210 - Delta Electronics Incorporated
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Nov 25, 2013
Application Purpose
Original Equipment
Date of Application
Nov 14, 2013
Equipment Note
ZigBee module
Frequency Range
2405.00000000 - 2480.00000000
Company
Delta Electronics Incorporated
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗
↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

D F Z M- T S 2 x x Data Sheet Sheet 1 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change Data sheet DFZM-TS2xx An IEEE 802.15.4 System–On-Chip Zigbee module D F Z M- T S 2 x x Data Sheet Sheet 2 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change Contents 1. Features ............................................................................................................................................... 4 2. Zigbee Model No. Definition.............................................................................................................. 6 3. Architecture......................................................................................................................................... 7 3-1.Block Diagram.............................................................................................................................. 7 3-2.Block Diagram Description .......................................................................................................... 8 3-2-1.Overview ........................................................................................................................... 8 3-2-2.CPU and Memory.............................................................................................................. 8 3-2-3.Clocks and Power Management ........................................................................................ 9 3-2-4.Peripherals ......................................................................................................................... 9 3-3.Power Management .................................................................................................................... 13 4. Pin-out and Signal Description ......................................................................................................... 15 4-1.Device Pin-out Diagram (Module top view) .............................................................................. 15 4-2.Module Pins Description ............................................................................................................ 16 5. Electrical Characteristics .................................................................................................................. 18 5-1.Absolute Maximum Rating......................................................................................................... 18 5-2.Recommended Operating Conditions......................................................................................... 18 5-3.Power Consumption.................................................................................................................... 18 5-4.DC Characteristics ...................................................................................................................... 20 5-5.Wake-up and Timing................................................................................................................... 20 5-6.Radio Parameters ........................................................................................................................ 21 5-7.ADC Parameters ......................................................................................................................... 22 5-8.SPI AC Characteristics ............................................................................................................... 24 6. Package and Layout Guidelines........................................................................................................ 26 6-1.Recommended PCB Footprint and Dimensions ......................................................................... 26 6-2.Layout Guidelines....................................................................................................................... 30 6-2-1.Surface Mount Assembly ................................................................................................ 32 6-3.Recommended Stencil Aperture ................................................................................................. 34 7. Ordering Information ........................................................................................................................ 36 D F Z M- T S 2 x x Data Sheet Sheet 3 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change Revision History Version Date Reason of change Maker 0.1 2013/3/11 Initial release Fred 0.2 2013/4/26 Add Peripheral I/O Pin Mapping Fred 0.3 2013/7/1 Add “Not available for DFZM-TS21X-DT0R” at 4-2. Module Pins Description( Pins 10、13、25) JunRu 0.4 2013/8/22 Update power consumption and radio parameters JunRu D F Z M- T S 2 x x Data Sheet Sheet 4 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change DFZM-TS2xx IEEE802.15.4 System-On-Chip Zigbee Module HIS DOCUMENT describes the DFZM-TS2xx Zigbee module hardware specification. The CC2530 based modules provide cost effective, low power, and flexible platform to add Zigbee connectivity for embedded devices for a variety of applications, such as wireless sensors and energy monitoring. It combines 8051-based processors, in-system programable flash memory, 8-KB RAM, 256KB flash memory and off module certified antenna options, and various RF front end options for end customer range needs in order to provide a Zigbee and regulatory certified. The module has various operating modes, making it highly suit for system where ultralow power consumption is required. Short transition times between operating modes further ensure low energy consumption. 1. Features ► Family of modules with different antenna and output power options: • DFZM-TS22x 22 mm by 16 mm by 3.3mm (Length * Width * Height) 28-pin Dual Flat pack PCB Surface Mount Package. • DFZM-TS21x 27 mm by 16 mm by 3.3 mm (Length * Width * Height) 28-pin Dual Flat pack PCB Surface Mount Package. • DFZM-TS220, DFZM-TS221, DFZM-TS210, and DFZM-TS211 are all pin to pin compatible (see section…

Text truncated - open the document above for the full version.

Users Manual

D F Z M- T S 2 x x Data Sheet Sheet 1 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change Data sheet DFZM-TS2xx An IEEE 802.15.4 System–On-Chip Zigbee module D F Z M- T S 2 x x Data Sheet Sheet 2 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change Contents 1. Features ............................................................................................................................................... 4 2. Zigbee Model No. Definition.............................................................................................................. 6 3. Architecture......................................................................................................................................... 7 3-1.Block Diagram.............................................................................................................................. 7 3-2.Block Diagram Description .......................................................................................................... 8 3-2-1.Overview ........................................................................................................................... 8 3-2-2.CPU and Memory.............................................................................................................. 8 3-2-3.Clocks and Power Management ........................................................................................ 9 3-2-4.Peripherals ......................................................................................................................... 9 3-3.Power Management .................................................................................................................... 13 4. Pin-out and Signal Description ......................................................................................................... 15 4-1.Device Pin-out Diagram (Module top view) .............................................................................. 15 4-2.Module Pins Description ............................................................................................................ 16 5. Electrical Characteristics .................................................................................................................. 18 5-1.Absolute Maximum Rating......................................................................................................... 18 5-2.Recommended Operating Conditions......................................................................................... 18 5-3.Power Consumption.................................................................................................................... 18 5-4.DC Characteristics ...................................................................................................................... 20 5-5.Wake-up and Timing................................................................................................................... 20 5-6.Radio Parameters ........................................................................................................................ 21 5-7.ADC Parameters ......................................................................................................................... 22 5-8.SPI AC Characteristics ............................................................................................................... 24 6. Package and Layout Guidelines........................................................................................................ 26 6-1.Recommended PCB Footprint and Dimensions ......................................................................... 26 6-2.Layout Guidelines....................................................................................................................... 30 6-2-1.Surface Mount Assembly ................................................................................................ 32 6-3.Recommended Stencil Aperture ................................................................................................. 34 7. Ordering Information ........................................................................................................................ 36 D F Z M- T S 2 x x Data Sheet Sheet 3 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change Revision History Version Date Reason of change Maker 0.1 2013/3/11 Initial release Fred 0.2 2013/4/26 Add Peripheral I/O Pin Mapping Fred 0.3 2013/7/1 Add “Not available for DFZM-TS21X-DT0R” at 4-2. Module Pins Description( Pins 10、13、25) JunRu 0.4 2013/8/22 Update power consumption and radio parameters JunRu D F Z M- T S 2 x x Data Sheet Sheet 4 of 37 AUG 22, 2013 Proprietary Information and Specifications are Subject to Change DFZM-TS2xx IEEE802.15.4 System-On-Chip Zigbee Module HIS DOCUMENT describes the DFZM-TS2xx Zigbee module hardware specification. The CC2530 based modules provide cost effective, low power, and flexible platform to add Zigbee connectivity for embedded devices for a variety of applications, such as wireless sensors and energy monitoring. It combines 8051-based processors, in-system programable flash memory, 8-KB RAM, 256KB flash memory and off module certified antenna options, and various RF front end options for end customer range needs in order to provide a Zigbee and regulatory certified. The module has various operating modes, making it highly suit for system where ultralow power consumption is required. Short transition times between operating modes further ensure low energy consumption. 1. Features ► Family of modules with different antenna and output power options: • DFZM-TS22x 22 mm by 16 mm by 3.3mm (Length * Width * Height) 28-pin Dual Flat pack PCB Surface Mount Package. • DFZM-TS21x 27 mm by 16 mm by 3.3 mm (Length * Width * Height) 28-pin Dual Flat pack PCB Surface Mount Package. • DFZM-TS220, DFZM-TS221, DFZM-TS210, and DFZM-TS211 are all pin to pin compatible (see section…

Text truncated - open the document above for the full version.

Cover Letter(s)

Rev. 3.0 AR007 WLAN Antenna Specification 1 / 3 Wellshow ® For more information, contact [email protected] TEL: +886 2-2427-0488 FAX: +886 2-2426-0387 9F., No.181, Nanrong Rd., Ren-ai Dist., Keelung City 200, Taiwan (R.O.C.) www.Wellshow.com www.wellshow.com www.rfcoaxcable.com For more information, contact [email protected] TEL: +886 2-2423-9376 FAX: +886 2-2426-0387 9F., No.181, Nanrong Rd., Ren-ai Dist., Keelung City 200, Taiwan (R.O.C.) 2.4GHz WLAN Antenna Swivel type with extended 1.13mm Cable and I-PEX Plug Product No. AR007WSW01A03 Structure Figure DescriptionSpecification Frequency Range2.4GHz Impedance50 Ω VSWR2.0 Max Return Loss- 10 dB Max Certain directionOmin Gain2 dBi DescriptionSpecification Antenna CoverTPEE (Black) Antenna HolderPC (Black) Antenna Base PBT (Black) Captive latchABS (Black) Operating Temperature-20°C~+65°C Storage Temperature -30°C~+75°C ConnectorI-PEX MHF Plug 20278-112R-13 (U.FL) Cable Type 1.13mm RF coaxial cable (Gray) L=100mm Electrical SpecificationMechanical Specification AR007 Antenna Captive latch for AR007 Antenna P/N W0V0054R007-01 Option CoverHolderBase Rev. 3.0 AR007 WLAN Antenna Specification 2 / 3 Wellshow ® For more information, contact [email protected] TEL: +886 2-2427-0488 FAX: +886 2-2426-0387 9F., No.181, Nanrong Rd., Ren-ai Dist., Keelung City 200, Taiwan (R.O.C.) www.Wellshow.com www.wellshow.com www.rfcoaxcable.com For more information, contact [email protected] TEL: +886 2-2423-9376 FAX: +886 2-2426-0387 9F., No.181, Nanrong Rd., Ren-ai Dist., Keelung City 200, Taiwan (R.O.C.) Test results Reture Loss VSWR Radiation Pattern of H Plane 2.4~2.5GHzRadiation Pattern of V Plane 2.4~2.5GHz

Cover Letter(s)

RF_734_00, Issue 1 Modular Approval Request FCC (per DA 00-1407) FCC ID: H79DFZM-TS210 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. Yes, The EUT provides the RF shielding 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Yes. The EUT has FIFO buffer. 3. The modular transmitter must have its own power supply regulation. The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The EUT was tested in a stand-alone configuration via a test kit. Please see section photographs of test configuration in the test report. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The EUT comply with RF exposure requirement. RF exposure is addressed in the RF exposure exhibition. Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or authorized representative): Ray Chen

External Photos

Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group All View of EUT (External Antenna-DFZM-TS210-DT0R) Front View of EUT Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Back View of EUT Open View of EUT – 1 Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistric…

Text truncated - open the document above for the full version.

ID Label/Location Info

DFZM-TS210-DT0R 外觀尺寸圖 FRAME NAME: DF-PSLA4V-1R01.DOC SHEET 1 OF 2 Mechanical Dimensions DFZM-TS210-DT0R FCC ID : H79DFZM-TS210 YYWWNNNNN D F Z M - T S 2 1 0 - D T 0 R F C C I D : H 7 9 D F Z M - T S 2 1 0 Y Y W W N N N N N DFZM-TS210-DT0R 外觀尺寸圖 FRAME NAME: DF-PSLA4V-1R01.DOC SHEET 2 OF 2 Product Label : (3263974900) DFZM-TS210-DT0R FCC ID : H79DFZM-TS210 YYWWNNNNN Note.7 Note.8 Note.9 Note.10 4. THE LABEL STICKY LOCATION OF MATERIAL : SS (NI-PLTED / TIN-PLATED) 3. LABEL MUST BE UL RECOGNIZED AND CSA CERTIFIED OR UL/CUL CERTIFIED. 1. MATERIAL: POLYIMIDE , (耐耐耐260°C) , t=0.1mm 2. BACKGROUNDS COLOR : WHITE. WORD COLOR : BLACK NOTES : 6. MATERIAL MUST MEET DELTA GENERAL SPEC,10000-0162 5. LABEL MUST BE WITHSTAND OPERATING TEMPERATURE Min. 85°C 72-HOUR HIGH TEMPERATURE TEST. COPPER(NI-PLATED / TIN-PLATED) ; LCP ; SPTE(NI-PLATED) 7. PRODUCT PART NUMBER : DFZM-TS210-DT0R 8. FCC ID NUMBER : H79DFZM-TS210 10. THE BARCODE TYPE : CODE128 ; THE WORD TYPE : ARIAL NARROW/SIZE:MUST BE 6 9. DATE CODE ; LOT NUMBER :YYWWNNNNN YYWW NNNNN NNNNN FOR PRODUCTION SEQUENTIAL LOT NUMBER(00001~99999) YY=YEAR ; WW=WEEK

Internal Photos

Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 2 INTERNAL PHOTOGRAPHS OF EUT Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Internal View of EUT – 1 (External Antenna-DFZM-TS210-DT0R) Internal View of EUT – 2 Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Internal View of EUT – 3 Internal View of EUT – 4 Report No.: ER/2013/80008 FCC ID: H79DFZM-TS210 Issue Date: Oct. 04, 2013 Unless otherwise stated the results sh…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ray Chen(Manager)
[email protected]886 3 4526107Fax: 886 3 4528707

Technical Contact

SGS Taiwan Ltd.Willis Chen
[email protected]886222993279

No. 134, Wu Kung Rd., New Taipei · Taiwan

Non-Technical Contact

SGS Taiwan Ltd.Willis Chen
[email protected]

Test Firm

SGS TAIWAN LTD.NELSON BAI
[email protected]886-2-22993279Fax: 886-2-22999489

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz110.00 mW
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antenna's as listed in this application must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
