H8N-8822CSWIFI+BT Combo Module

8822CS user manual 產品中文名稱: 無線藍牙模組 產品英文名稱: WIFI+BT Combo Module 產品商標: ASKEY 產品型號: 8822CS 額定電壓、電流: DC 3.3V 頻率范围: 2.4~2.483GHz，5.15 GHz ~ 5.850 GHz 信道: Ch1- Ch11,Ch36-48,CH52-64,Ch100-140,Ch149-165 天线类型: PIFA ANTENNA 產品硬件版本: V2.0 產品軟件版本: V5.9 Features Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ 802.11ac, or 2.4G/5G 802.11n WLAN applications. Dual-stream spatial multiplexing up to 867 Mbps data rate. Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz Supports low power SDIO3.0 interface for WLAN and UART/PCM interface for Bluetooth. Supports Bluetooth V5.0 system. Supports WLAN-Bluetooth coexistence. BT host digital interface: - HCI UART (up to 4 Mbps) - PCM for audio data Module have 2 antenna port, BT port combine with WLAN1. Wi-Fi RF Specification 2.4GHz RF Specification Frequency Range: 802.11b/g/n-HT20: 2412 ~ 2462MHz 802.11n-HT40: 2422 ~ 2452MHz Channel Number: 802.11b/g/n-HT20: 11 802.11n-HT40: 7 Type of Modulation: 802.11b: DSSS 802.11g/n: OFDM Data Rate: 802.11b: 1/2/5.5/11Mbps 802.11g: 6/9/12/18/24/36/48/54Mbps 802.11n: up to 300Mbps 5GHz RF Specification Note: The frequencies that fall in the 5600MHz to 5650MHz band will not be used in Canada. Bluetooth Specification Antenna Specification Antenna Type Frequency Band (GHz) T X Paths Per Chain Max Antenna Gain (dBi) Directional Gain (dBi) Ant 0 Ant 1 For Power For PSD Wi-Fi Internal Antenna PIFA 2412 ~ 2462 2 2.1 1.9 2.1 5.11 5180 ~ 5240 2 4.2 1.9 4.2 7.21 5260 ~ 5320 2 3.8 3.0 3.8 6.81 5500 ~ 5720 2 3.8 2.9 3.8 6.81 5745 ~ 5825 2 3.4 2.3 3.4 6.41 Bluetooth Internal Antenna PIFA 2402 ~ 2480 1 1.9 -- Frequency Range: For 802.11a/n-HT20/ac-VHT20: 5180~5240MHz, 5260~5320MHz, 5500~5720MHz, 5745~5825MHz For 802.11n-HT40/ac-VHT40: 5190~5230MHz, 5270~5310MHz, 5510~5710MHz, 5755~5795MHz For 802.11ac-VHT80: 5210MHz, 5290MHz, 5530MHz, 5610MHz, 5690MHz, 5775MHz Type of Modulation: 802.11a/n/ac: OFDM Data Rate 802.11a: 6/9/12/18/24/36/48/54Mbps 802.11n: up to 300Mbps 802.11ac: up to 866.6Mbps Operating Frequency: 2402~2480MHz Channel Number: BR/EDR: 79 BLE: 40 Type of modulation: GFSK, Pi/4 DQPSK, 8DPSK Data Rate: 1Mbps, 2Mbps, 3Mbps Dimensions Marking Description Label The Key Material List Recommended Reflow Profile Package Information 、 Moisture sensitivity The Modules is a Moisture Sensitive Device level 3, in according with standard IPC/JEDEC J-STD-020, take care all the relatives requirements for using this kind of components. Moreover, the customer has to take care of the following conditions: a) Calculated shelf life in sealed bag: 12 months at <40°C and <90% relative humidity (RH). b) Environmental condition during the production: 30°C / 60% RH according to IPC/JEDEC J-STD-033A paragraph 5. c) The maximum time between the opening of the sealed bag and the reflow process must be 168 hours if condition b) “IPC/JEDEC J-STD-033A paragraph 5.2” is respected d) Baking is required if conditions b) or c) are not respected e) Baking is required if the humidity indicator inside the bag indicates 10% RH or more U.S. FCC Statement FCC ID: H8N-8822CS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: o Reorient or relocate the receiving antenna. o Increase the separation between the equipment and receiver. o Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. o Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Canada (IC) Notices IC: 1353A-8822CS CAN ICES-3 (B)/NMB-3(B) This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. l’appareil ne doit pas produire de brouillage 2. l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement. Caution: The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. Avertissement: Le dispositif fonctionnant dans la bande 5150-5250 MHz es…

Text truncated - open the document above for the full version.

Askey Computer Corporation 10F, No. 119, Jiankang Rd., Zhonghe Dist., New Taipei City, Taiwan Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: ASKEY COMPUTER CORPORATION Address: 10F, No.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY 23585, TAIWAN Declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. Product: WIFI+BT Combo Module FCC ID: H8N-8822CS Model: 8822CS Sincerely, _________________ Name: John Chiou Position: Manager Date: 2021-03-05

Askey Computer Corporation 10F, No. 119, Jiankang Rd., Zhonghe Dist., New Taipei City, Taiwan Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: H8N-8822CS Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: John Chiou Position: Manager Date: 2021-03-05

Askey Computer Corporation 10F, No. 119, Jiankang Rd., Zhonghe Dist., New Taipei City, Taiwan Declaration of Authorization We Name: ASKEY COMPUTER CORPORATION Address: 10F, No.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY 23585, TAIWAN. Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: WIFI+BT Combo Module FCC ID: H8N-8822CS Model: 8822CS Sincerely, _________________ Name: John Chiou Position: Manager Date: 2021-03-05

070920-02b Askey Computer Corporation 10F, No. 119, Jiankang Rd., Zhonghe Dist., New Taipei City, Taiwan Request for Modular/Limited Modular Approval Date: March 5, 2021 Subject: Manufacturer’s Declaration for ☒ - Modular Approval ☐ - Split Modular Approval ☐ - Limited Modular Approval ☐ - Limited Split Modular Approval Confidentiality Request for: _H8N-8822CS 8 Basic Requirements – FCC Part 15.212(a)(1) For Items Marked “NO(*)”, the Limited Module Description Must be Filled Out on the Following Pages Modular Approval Requirement Requirement Met 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with FCC limits. It is also intended to prevent coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. The physical crystal and tuning capacitors may be located external to the shielded radio elements. 15.212(a)(1)(i) ☒ - YES ☐ - NO(*) The radio portion of this module has been shielded, please see exhibition External Photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with FCC requirements under conditions of excessive data rates or over-modulation. 15.212(a)(1)(ii) ☒ - YES ☐ - NO(*) Data to the modulation circuit is buffered as described in the operational description provided with the application. 3. The modular transmitter must have its own power supply regulation on the module. This is intended to ensure that the module will comply with FCC requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. 15.212(a)(1)(iii) ☒ - YES ☐ - NO(*) The module contains its own power supply regulation. Please refer to schematic filed with this application. 4. The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b), 15.204(c), 15.212(a), and 2.929(b). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph 15.212(b). 15.212(a)(1)(iv) ☒ - YES ☐ - NO(*) The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified or commercially available (see Section 15.31(i)). 15.212(a)(1)(v) ☒ - YES ☐ - NO(*) The EUT was tested in a stand-alone configuration via a test tool. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 070920-02b Askey Computer Corporation 10F, No. 119, Jiankang Rd., Zhonghe Dist., New Taipei City, Taiwan Modular Approval Requirement Requirement Met 6. The modular transmitter must be labeled with its own FCC ID number, or use an electron display (see KDB Publication 784748). If using a permanently affixed label with its own FCC ID number, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. 15.212(a)(1)(vi) ☒ - YES ☐ - NO(*) There is a label on the module as shown in the labeling exhibit filed with this application. Host specific labeling instructions are shown in the installation manual .filed with this application. 7. The modular transmitter must comply with all specific rule…

Text truncated - open the document above for the full version.

Askey Computer Corporation 10F, No. 119, Jiankang Rd., Zhonghe Dist., New Taipei City, Taiwan Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: H8N-8822CS Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request short-term confidential treatment for the following information until 180 days after the grant date of equipment authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: Attachments: 1. External Photo 2. Internal Photo 3. Test Setup Photo 4. User Manual Sincerely, _________________ Name: John Chiou Position: Manager Date: 2021-03-05

Report No.: 2101RSU052-UE 1 of 3 External Photograph (1) Test Fixture & Module Photo (2) Module Photo Report No.: 2101RSU052-UE 2 of 3 (3) Module Photo (4) Antenna Photo Report No.: 2101RSU052-UE 3 of 3 (5) Antenna Photo

Label Label Location

Report No.: 2101RSU052-UE 1 of 1 Internal Photograph (1) Module Photo (2) Module Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2101RSU052-U6 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 03-06-2021 Page Number: 1 of 9 RF Exposure Evaluation Declaration Application Type: Certification Product: WIFI+BT Combo Module Model No.: 8822CS Brand Name: ASKEY FCC Classification: FCC Part 15 Spread Spectrum Transmitter (DSS) Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) Test Procedure(s): KDB 447498 D01v06 Test Date: March 04, 2021 Reviewed By: Kevin Guo Approved By: Robin Wu FCC ID: H8N-8822CS Applicant: Askey Computer Corp. The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2101RSU052-U6 Page Number: 2 of 9 Revision History Report No. Version Description Issue Date Note 2101RSU052-U6 Rev. 01 Initial Report 03-06-2021 Valid Report No.: 2101RSU052-U6 Page Number: 3 of 9 CONTENTS Description Page 1. General Information ............................................................................................................ 4 1.1. Applicant ............................................................................................................................. 4 1.2. Manufacturer ...................................................................................................................... 4 1.3. Testing Facility ................................................................................................................... 4 2. PRODUCT INFORMATION ................................................................................................... 5 2.1. Equipment Description........................................................................................................ 5 2.2. Description of Available Antennas .................................................................................... 5 2.3. Description of Antenna RF Port ........................................................................................ 6 3. RF Exposure Evaluation ..................................................................................................... 7 3.1. Limits ..................................................................................................................................... 7 3.2. Test Result of RF Exposure Evaluation ........................................................................... 8 Appendix A - EUT Photograph ................................................................................................... 9 Report No.: 2101RSU052-U6 Page Number: 4 of 9 1. General Information 1.1. Applicant Askey Computer Corp. 10F, No.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY, TAIWAN 1.2. Manufacturer Askey Computer Corp. 10F, No.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY, TAIWAN 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025, G-20034, C-20020, T-20020 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: L3261-190725 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2101RSU052-U6 Page Number: 5 of 9 2. PRODUCT INFORMATION 2.1. Equipment Description 2.2. Description of Available Antennas Antenna Type Frequency Band (GHz) T X Paths Per Chain Max Antenna Gain (dBi) Directional Gain (dBi) Ant 0 Ant 1 For Power For PSD Wi-Fi Internal Antenna PIFA 2412 ~ 2462 2 2.1 1.9 2.1 5.11 5180 ~ 5240 2 4.2 1.9 4.2 7.21 5260 ~ 5320 2 3.8 3.0 3.8 6.81 5500 ~ 5720 2 3.8 2.9 3.8 6.81 5745 ~ 5825 2 3.4 2.3 3.4 6.41 Bluetooth Internal Antenna PIFA 2402 ~ 2480 1 1.9 -- Note 1: The EUT supports Cyclic Delay Diversity (CDD) technology and CDD signals are correlated. For CDD transmissions, directional gain is calculated as follows, N ANT = 2, N SS = 1. If all antennas have the same gain, G ANT , Directional gain = G ANT + Array Gain, where Array Gain is as follows. ⚫ For power spectral density (PSD) measurements on all devices, Array Gain = 10 log (N ANT / N SS ) dB = 3.01; ⚫ For power measurements on IEEE 802.11 devices, Array Gain = 0 dB for N ANT ≤ 4; If antenna gains are not equal, Directional gain may be calculated by using the formulas applicable to equal gain antennas with G ANT set equal to the gain of the antenna having the highest gain. Note 2: All information was provided by manufacturer. Product Name: WIFI+BT Combo Module Model No.: 8822CS Brand Name: ASKEY Wi-Fi Specification: 802.11a/b/g/n/ac Bluetooth Specification: V5.0 dual mode Report No.: 2101RSU052-U6 Page Number: 6 of 9 2.3. Description of Antenna RF Port Wi-Fi & Bluetooth Antenna Software Control Port Ant 0 (Wi-Fi) Ant 1 (Wi-Fi & Bluetooth) Note: A temporary RF connector to test conveniently in Ant 1 was provided by manufacturer Report No.: 2101RSU052-U6 Page Number: 7 of 9 3. RF Exposure Evaluation 3.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field …

Text truncated - open the document above for the full version.

MRT Technology (Suzhou) Co., Ltd Report No.: 2101RSU052-U2 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 03-06-2021 Page Number: 1 of 73 FCC ID: H8N-8822CS IC: 1353A-8822CS Applicant: Askey Computer Corp. Application Type: Certification Product: WIFI+BT Combo Module Model No.: 8822CS Brand Name: ASKEY FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part15 Subpart C (Section 15.247) ISED Rule(s): RSS-247 Issue 2, RSS-GEN Issue 5 Test Procedure(s): ANSI C63.10-2013, KDB 558074 D01v05r02 Test Date: January 21 ~ March 04, 2021 Reviewed By: Kevin Guo Approved By: Robin Wu MEASUREMENT REPORT FCC PART 15.247 / ISED RSS-247 Bluetooth-LE The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2101RSU052-U2 Page Number: 2 of 73 Revision History Report No. Version Description Issue Date Note 2101RSU052-U2 Rev. 01 Initial Report 03-06-2021 Valid Report No.: 2101RSU052-U2 Page Number: 3 of 73 CONTENTS Description Page 1. General Information ............................................................................................................... 5 1.1. Applicant ...................................................................................................................... 5 1.2. Manufacturer ................................................................................................................ 5 1.3. Testing Facility .............................................................................................................. 5 2. PRODUCT INFORMATION ...................................................................................................... 6 2.1. Equipment Description ................................................................................................. 6 2.2. Product Specification Subjective to this Report ............................................................ 6 2.3. Working Frequencies for this report .............................................................................. 6 2.4. Description of Available Antennas ................................................................................ 7 2.5. Description of Antenna ................................................................................................. 7 2.6. Test Mode .................................................................................................................... 8 2.7. Configuration of Test System ....................................................................................... 8 2.8. Test System Details ..................................................................................................... 8 2.9. Test Software ............................................................................................................... 8 2.10. Test Environment Condition .......................................................................................... 9 2.11. Duty Cycle .................................................................................................................... 9 2.12. EMI Suppression Device(s)/Modifications ..................................................................... 9 2.13. Labeling Requirements ............................................................................................... 10 3. ANTENNA REQUIREMENTS................................................................................................. 11 4. TEST EQUIPMENT CALIBRATION DATE ............................................................................. 12 5. MEASUREMENT UNCERTAINTY ......................................................................................... 16 6. TEST RESULT ....................................................................................................................... 17 6.1. Summary .................................................................................................................... 17 6.2. Occupied Bandwidth Measurement ............................................................................ 18 6.2.1. Test Limit ................................................................................................................ 18 6.2.2. Test Procedure used ............................................................................................... 18 6.2.3. Test Setting ............................................................................................................. 18 6.2.4. Test Setup .............................................................................................................. 19 6.2.5. Test Result .............................................................................................................. 20 6.3. Output Power Measurement ....................................................................................... 24 6.3.1. Test Limit ................................................................................................................ 24 6.3.2. Test Procedure Used .............................................................................................. 24 6.3.3. Test Setting ............................................................................................................. 24 6.3.4. Test Setup .............................................................................................................. 25 Report No.: 2101RSU052-U2 Page Number: 4 of 73 6.3.5. Test Result .............................................................................................................. 26 6.4. Power Spectral Density Measurement ......................…

Text truncated - open the document above for the full version.

MRT Technology (Suzhou) Co., Ltd Report No.: 2101RSU052-U3 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 03-09-2021 Page Number: 1 of 154 FCC ID: H8N-8822CS IC: 1353A-8822CS Applicant: Askey Computer Corp. Application Type: Certification Product: WIFI+BT Combo Module Model No.: 8822CS Brand Name: ASKEY FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part15 Subpart C (Section 15.247) ISED Rule(s): RSS-247 Issue 2, RSS-GEN Issue 5 Test Procedure(s): ANSI C63.10-2013, KDB 558074 D01v05r02 KDB 662911 D01v02r01 Test Date: February 01 ~ March 09, 2021 Reviewed By: Kevin Guo Approved By: Robin Wu MEASUREMENT REPORT FCC PART 15.247 / ISED RSS-247 WLAN 802.11b/g/n The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2101RSU052-U3 Page Number: 2 of 154 Revision History Report No. Version Description Issue Date Note 2101RSU052-U3 Rev. 01 Initial Report 03-09-2021 Valid Report No.: 2101RSU052-U3 Page Number: 3 of 154 CONTENTS Description Page 1. General Information ............................................................................................................... 5 1.1. Applicant ...................................................................................................................... 5 1.2. Manufacturer ................................................................................................................ 5 1.3. Testing Facility .............................................................................................................. 5 2. PRODUCT INFORMATION ...................................................................................................... 6 2.1. Equipment Description ................................................................................................. 6 2.2. Product Specification Subjective to this Report ............................................................ 6 2.3. Working Frequencies for this report .............................................................................. 6 2.4. Description of Available Antennas ................................................................................. 7 2.5. Description of Antenna ..........................................................................…

Text truncated - open the document above for the full version.
