H8N-PKE1331BPCable Modem

The Cable Modem, TC8305C / PKE1331BP-D49 (US-Dory-RoHS) is a cable gateway device including following functionalities:  DOCSIS 3.0 Cable Modem  PacketCable2.0 eDVA  4 port Gigabit Ethernet switch with advanced routing capability  802.11n single band WiFi (2.4 GHz)  USB 2.0 port with host controller  2 FXS ports, compliant with Comcast ringing requirements  Internal PSU  Rackable 2-cell battery 2600maH  eMTA supporting PacketCable 2.0 or EuroPacketCable  IPv4/IPv6 router  Remote management capabilities (SNMP, TR069, HNAP) Wideband Full Solution with Battery Backup This new generation of high-speed data service solutions introduces up to eight bonded downstream channels and four bonded upstream channels, allowing operators to provide their customers with four channels for data and four channels for dedicated Internet Protocol TeleVision (IPTV). High-Speed Wireless Interface The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) has an IEEE 802.11n wireless interface, bring home networking to a completely new level and enabling real-time multimedia content streaming over a Wi-Fi network everywhere in the home. The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) also supports multiple SSIDs. Voice Performance The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) is PacketCable 2.0 compliant and is equipped with basic and extended CLASS features such as caller ID and call waiting. Advanced Security The integrated firewall provides Stateful Packet Inspection (SPI), and an integrated Intrusion Detection and Prevention System (IDS) engine monitors a wide range of attack patterns, and logs potential security breaches to a local cache or remote server. To secure data exchange between the gateways and the cable operators’ servers, BPI+ communications privacy is used. WPS With Wi-Fi Protected Setup (WPS) users can easily connect with the TC8305C / PKE1331BP-D49 (US-Dory-RoHS) wireless network by simply pushing a button or entering a PIN code. It allows home users to easily connect to a secure network without any complex configuration and eliminates the need to remember or store their security information in an unsafe way. Easy to Use The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) with four GE LAN ports is an easy to use, easy to install gateway. For convenience of the end user, the easy-to-access multi-colored LEDs provide a clear indication of start-up sequence, connectivity status and channel bonding status (number of used downstream and upstream channels). Multiple integrated web pages allow direct access to the status and settings, including privacy and security information. Video Streaming The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) contains an MPEG2 over IP encapsulation solution allowing the support of IPTV with existing QAM (digital video) broadcast infrastructure. It supports voice using the PacketCable 2.0 standard and call control with the PacketCable standard NCS protocol. ECO The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) benefits from an unique combination of hardware and software features that reduce power consumption substantially. For instance, the The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) supports a lower power mode thanks to a split uner solution, an integrated upstream power amp and the auto power down feature on the external GE interfaces. Additional power control features are supported with the ability to turn off any or all modules to slow down or turn off processors and to turn off all external interfaces, reducing the power consumption even more.

Date: July 9, 2012 Subject: Ad Hoc Mode Function Declaration FCC ID: H8N-PKE1331BP To Whom it may concern, We, Askey Computer Corp, declare that the device (FCC ID: H8N-PKE1331BP) 1. is able to be operated on master mode/ 2.4 GHz band. 2. Ad Hoc function is not available. 3. does not work in non-US/Canada frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Applicant : Askey Computer Corp Address : 10F, No. 119, Chienkang Rd., Chung-Ho 235 Taipei Taiwan Signature : _________________________________ Name and Job Title. : John Chiou / Manager E-mail : [email protected] Tel. : + 886 2 2228-7588

Confidentiality Request Letter Date: 2012/6/8 Federal Communications Commission Authorization and Evaluation Division FCC ID：H8N-PKE1331BP Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Askey Computer Corp Applicant’s company address : 10F, No. 119, Chienkang Rd., Chung-Ho 235 Taipei Taiwan Signature : _________________________________ Job Title and Dept. : John Chiou / Manager E-mail : [email protected] Tel. : + 886 2 2228-7588

Date: 2012/6/8 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Product Certification Representative Authorization Letter FCC ID: H8N-PKE1331BP Product name: Cable Modem To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model TC8305C to the FCC Rules and Regulations. Sporton International Inc. Address : No. 52, Hwa Ya 1st Road., Kwei-Shan Hsiang, TaoYuan Hsien Taiwan R.O.C. Name : Wayne Hsu Job Title : Vice Manager e-mail : [email protected] We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Askey Computer Corp Address : 10F, No. 119, Chienkang Rd., Chung-Ho 235 Taipei Taiwan Signature : _________________________________ Name and Job Title. : John Chiou / Manager E-mail : [email protected] Tel. : + 886 2 2228-7588

RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B1 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B2 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B3 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B4 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B19 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B20 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973

客戶製作 Emma_Feng Paper / Other Label (外購+自印) V1 PART NO. DRAFTER PART NAME MODEL NO. MATERIAL 材質 代號 Product Unit K100 : Notes: 1.供應商:求精 2.被貼物材質:ABS 3. 黏貼位置:底座凹槽(平面) 4.PGJI2的UL原材代碼:QJCY3B 5.碳帶型號:Ricoh B110CR V5 1510-0LPW000 V2 V3 V4 V5 101.05.25 PKE1331BP-D49(US-DORY-RoHS) 50#白色特多龍(亮面壓花膠) Model Name: TC8305C Input: 120V AC, 60Hz, 1.2A Output : 12V DC, 3.5A FCC ID: H8N-PKE1331BP This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inerference received, including interference that may cause undesired operation. 1 1 1 4 2.4 2.4 2.4 1 1 4 2.4 1 1 Made in PRC Factory ID: 2 1 1 1 Network Name (SSID):HOME-XXXX SN: 1248400001 GW: CMGZBB8305CRB Encryption: WPA-TKIP Network Key: 1234567890123456 WPS PIN: 12341234 1 3.8 URL H/W Ver.: 1.0 : http://10.0.0.1 7.954mm=0.3131” 0.3131”>0.25” 6.934mm=0.2729” 0.2729”>0.25” 15mm=0.5905” 0.5905”>0.578” 1510-0LMQ000S/W Ver. 2012/03/09 2012/03/12 1.Wifi logo bgn 2.SN1248400001 3.GWCMGZBB8305CRB 2012/04/18 1.Rating, : Input Output 2. 2012/05/09 2012/05/24 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inerference received, including interference that may cause undesired operation. T-HTLW50J(EB) 1R*4 40.5 84.9 請注意：認證尚未完成，LABEL不能貼在機器上！~

RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B5 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B6 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B7 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B8 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B9 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B10 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B11 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B12 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B13 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B14 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B15 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B16 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B17 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973 RADIO TEST REPORT Report No.: FR253104 SPORTON International Inc. Page No. : B18 OF B20 TEL : 886-3-327-3456 ISSUED DATE : Jul. 09, 2012 FAX : 886-3-327-0973

SPORTON INTERNATIONAL INC. Page No. : 1 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR253104 1 Human Exposure Assessment 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 SPORTON INTERNATIONAL INC. Page No. : 2 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR253104 RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   SPORTON INTERNATIONAL INC. Page No. : 3 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR253104 1.1.3 Result of Maximum Permissible Exposure Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location b 3 3 N/A 24.36 N/A g 3 3 Correlated 24.51 N/A n (HT20) 3 3 Uncorrelated 24.60 N/A Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz and 5GHz.) Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 3 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 Chain- Port 3 - Sum Chain Gain (dBi) EIRP Power PD (S) (mW/cm²) 11B-20M 3 19.23 19.51 19.99 - 24.36 7.5 31.86 0.3055 11G-20M 3 18.95 19.80 20.34 - 24.516.9 31.41 0.2754 11N2.4G-20M 3 19.20 19.68 20.50 - 24.602.2 26.80 0.0953 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains

SPORTON INTERNATIONAL INC. Page No. : 1 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR253104 1 Human Exposure Assessment 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 SPORTON INTERNATIONAL INC. Page No. : 2 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR253104 RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   SPORTON INTERNATIONAL INC. Page No. : 3 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR253104 1.1.3 Result of Maximum Permissible Exposure Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location b 3 3 N/A 24.36 N/A g 3 3 Correlated 24.51 N/A n (HT20) 3 3 Uncorrelated 24.60 N/A Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz and 5GHz.) Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 3 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 Chain- Port 3 - Sum Chain Gain (dBi) EIRP Power PD (S) (mW/cm²) 11B-20M 3 19.23 19.51 19.99 - 24.36 7.5 31.86 0.3055 11G-20M 3 18.95 19.80 20.34 - 24.516.9 31.41 0.2754 11N2.4G-20M 3 19.20 19.68 20.50 - 24.602.2 26.80 0.0953 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains

SPORTON INTERNATIONAL INC. Page No. : 1 of 117 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RADIO TEST REPORT Report No. : FR253104 RADIO TEST REPORT According to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : Cable Modem Model Name : TC8305C PKE1331BP-D49 (US-Dory-RoHS) Frequency Range : 2400 MHz – 2483.5 MHz Applicant : Askey Computer Corporation 10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI, TAIWAN, 23585 R.O.C. FCC ID : H8N-PKE1331BP The product sample received on May 30, 2012 and completely tested on Jul. 30, 2012. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager SPORTON INTERNATIONAL INC. Page No. : 2 of 117 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RADIO TEST REPORT Report No. : FR253104 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Testing Applied Standards ..................................................................................................................... 9 1.3 Testing Location Information .................................................................................................................. 9 1.4 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION OF EUT ...................................................................................................... 11 2.1 The Worst Case Modulation Configuration .......................................................................................... 11 2.2 Test Channel Frequencies Configuration ............................................................................................. 12 2.3 The Worst Case Power Setting Parameter .......................................................................................... 12 2.4 The Worst Case Measurement Configuration ...................................................................................... 14 3 TRANSMITTER TEST RESULT .......................................................................................................... 17 3.1 AC Power-line Conducted Emissions .................................................................................................. 17 3.2 6dB Bandwidth ..................................................................................................................................... 20 3.3 RF Output Power .................................................................................................................................. 25 3.4 Power Spectral Density ........................................................................................................................ 34 3.5 Transmitter Radiated Bandedge Emissions ......................................................................................... 43 4 TEST EQUIPMENT AND CALIBRATION DATA .............................................................................. 115 5 CERTIFICATION OF TAF ACCREDITATION ................................................................................... 117 APPENDIX A. TEST PHOTOS ....................................................................................................................... A5 APPENDIX B. PHOTOGRAPHS OF EUT .................................................................................................... B20 SPORTON INTERNATIONAL INC. Page No. : 3 of 117 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RADIO TEST REPORT Report No. : FR253104 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna RequirementAntenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions 0.15485MHz: 23.89dBuV (31.85dB) - AV 50.60dBuV (15.14dB) - QP FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth 6dB Bandwidth Unit [MHz] 11B-20M: 8.24 11G-20M: 16.72 11N2.4G-20M: 17.84 ≥500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Conducted (Average) Output Power) Power [dBm] 11B-20M: 24.36 11G-20M: 24.51 11N2.4G-20M: 24.60 Power [dBm] 11B-20M: 28.5 11G-20M: 29.1 11N2.4G-20M: 30 Complied 3.4 15.247(d) Power Spectral Density PSD [dBm/3kHz] 11B-20M: -6.54 11G-20M: -10.13 11N2.4G-20M: -10.41 PSD [dBm/3kHz] 8 Complied 3.5 15.247(c) Transmitter Radiated Bandedge Emissions Non-Restricted Bands: 2399.50 MHz: 30.22dB Restricted Bands [dBuV/m at 3m]: 2484.56MHz: 69.86 (Margin 4.14dB) - PK 53.43 (Margin 0.57dB) - AV Non-Restricted Bands: > 30 dB Restricted Bands: FCC 15.209 Complied 3.5.6 15.247(c) Transmitter Radiated Unwanted Emissions Restricted Bands [dBuV/m at 3m]: 3732.77MHz: 53.45 (Margin 20.55dB) - PK 50.71 (Margin 3.29dB) - AV Non-Restricted Bands: > 30 dB Restricted Bands: FCC 15.209 Complied SPORTON INTERNATIONAL INC. Page No. : 4 of 117 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RADIO TEST REPORT Report No. : FR253104 Revision History Report No. Version Description Issued Date FR253104 Rev. 01 Initial issue of report Aug. 01, 2012 2500-2690 SPORTON INTERNATIONAL INC. Page No. : 5 of 117 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RADIO TEST REPORT Report No. : FR253104 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (MHz) IEEE Std. 802.11 Protocol Ch. Frequency…
