H8N-WLL6190802.11g / 802.11n WLAN PCI-E Mini Card

Askey Computer Corp

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Jan 19, 2011
Application Purpose: Original Equipment
Date of Application: Jan 19, 2011
Equipment Note: 802.11g / 802.11n WLAN PCI-E Mini Card
Company: Askey Computer Corp
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Introduction: Askey WLL6190 802.11g / 802.11n WLAN PCI-E Mini Card User's Guide Before you begin Things you should know WLL6190 network Before you begin Obtain the following information from your network administrator (if you are a home user, obtain this information from the person that installed your wireless access point): l Network names (SSID) of the specific wireless networks that you want to connect to. l WEP (Wired Equivalent Privacy) key information (if any) for the networks you want to connect to. l For Microsoft® Windows® networking, your customer name and workgroup name. l For your network account, your user name and password. l Your IP address (if not using a DHCP server) Things you should know When you start your computer, your Askey WLL6190 802.11g / 802.11n WLAN PCI-E Mini Card detects certain wireless networks that are within range. Before you can connect to these and other wireless networks, you must configure a profile for each network using the information you obtained from your network administrator. WEP is a security protocol for wireless local area networks (defined in the IEEE 802.11g standard) that encrypts data sent over radio waves. The use of the WEP key is optional and can be enabled or disabled. If the network you are connecting to has enabled WEP, you must also enable WEP in the network profile and set the WEP key to match the WEP key used by the network. Otherwise, you cannot connect to the network. Askey WLL6190 network Askey 802.11g / 802.11n WLAN PCI-E Mini Card (Model name : WLL6190) using Broadcom Wireless Utility to connect network. The Askey WLL6190 solution allows you to make a wireless connection to a network, as illustrated below. Back to top Using the Broadcom Wireless Utility: Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide Back to Contents Page Using the Broadcom Wireless Utility: Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide Overview Utility Components Overview The Broadcom Wireless Utility enables you to do the following network tasks: l Manage your wireless networks and create network connection profiles (Wireless Networks tab) l Connect to available networks (utility icon in notification area) l Get information about the network status and signal and noise of your network connection (Link Status tab) l View current and accumulated statistics (Statistics tab) l Find out which broadcasting networks are in range and search for nonbroadcasting networks (Site Monitor tab) l Run tests on the wireless network adapter (Diagnostics tab) l Get date and version information about the utility, and software, hardware, and location details about your wireless network adapter ( Information tab) l Manually add or delete trusted servers and enable the manual acceptance or rejection of auto- provisioning and A-ID group changes ( Wireless Networks tab) l Manually import EAP-FAST PACs (Wireless Networks tab) In the utility, you can open Wireless Network Wizard to connect to a basic network or create an ad hoc network, or you can open the Wireless Network Connection Settings tool to connect to an advanced network. To do any of the other tasks, click the tab that is associated with the described task. To start using the utility, right-click the utility icon in the notification area, and then click Open Utility. If the icon is not available, open Broadcom Wireless Utility in Control Panel. NOTE: The utility icon may not appear exactly as shown here. See " Table 1. Signal Strength Indicated by the Broadcom Wireless Utility Icon." Utility Components Utility components include the utility icon in the notification area, the six utility tabs, and Wireless Network Connection Settings. file:///P|/User%20Manuals/WLANCard-UM302_LaLa/HTML/utility.htm (1 of 12)4/25/2006 1:57:41 PM Using the Broadcom Wireless Utility: Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide Utility Icon To do any of the following tasks or operations, right-click the utility icon, and then click the appropriate item. l Open the on-line Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide (Help Files) l Open About WLAN Card Utility to view links to Broadcom and Broadcom Customer Support websites and to view the version and date of the utility (About) l Hide the utility icon (Hide Tray Icon) l Disable or enable the radio (Disable/Enable Radio) l Connect to any of the networks for which you have created a connection profile and are within range (Connect To) l Open the utility to the Wireless Networks tab (Open Utility) l Open the utility to the Link Status tab to view information about the connection (Status) l Display a log of your wireless network events (Display Log) Wireless Networks Tab The Wireless Networks tab has tools that enable you to do the following: l Use the utility to manage your wireless networks l Add a network connection profile l Edit or remove a network connection profile l Change the order in which profiles are listed under Preferred network connections l Connect to any listed network without changing its order in the list l Disable or enable the radio (Disable/Enable Radio) l Show or hide the utility icon in the notification area l Choose which type of network to access l Lock or unlock a preferred network connection profile l Save your wireless network connection profiles as a WPN file l Import a WPN file l Manually add or delete trusted servers and enable the manual acceptance or rejection of auto- provisioning and A-ID group changes l Manually import EAP-FAST PACS On the Add menu, you can use either the wireless network wizard that is available from Broadcom Wireless Utility (see Connecting to a Basic Network or Creating an Ad Hoc Network Using the Wireless Network Wizard") or the utility (see "Connecting to an Advanced Network Using the Broadcom Wireless Utility") to add a network connection profile. To use the utility to manage your wireless networks, select the Let this…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: 2011/1/13 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Product Certification Representative Authorization Letter FCC ID: H8N-WLL6190 Product name: 802.11g / 802.11n WLAN PCI-E Mini Card To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model WLL6190 to the FCC Rules and Regulations. Sporton International Inc. Address : No. 52, Hwa Ya 1st Road., Kwei-Shan Hsiang, TaoYuan Hsien Taiwan R.O.C. Name : Wayne Hsu Job Title : Vice Manager e-mail : [email protected] We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Askey Computer Corp Address : 10F, No. 119, Chienkang Rd., Chung-Ho 235 Taipei Taiwan Signature : _________________________________ Name and Job Title. : John Chiou / Manager E-mail : [email protected] Tel. : + 886 2 2228-7588

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 1 Rev 2.0 SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw 1/18/2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SPORTON International Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: 802.11g / 802.11n WLAN PCI-E Mini Card Model Number: WLL6190 We affirm that between SIEMIC and SPORTON International Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Name / title: Wayne Hsu / Vice Manager Contact information / address: No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. / Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw

Cover Letter(s)

Confidentiality Request Letter Date: 2011/1/13 Federal Communications Commission Authorization and Evaluation Division FCC ID：H8N-WLL6190 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Askey Computer Corp Applicant’s company address : 10F, No. 119, Chienkang Rd., Chung-Ho 235 Taipei Taiwan Signature : _________________________________ Job Title and Dept. : John Chiou / Manager E-mail : [email protected] Tel. : + 886 2 2228-7588

External Photos

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C2 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C5 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C6 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C7 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C8 OF C8 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255

ID Label/Location Info

WLL6190 Label drawing and Location Label size : 14 * 6mm Label location (pasted on shield cover as below area) Model: WLL6190 FCC ID: H8N-WLL6190 IC: 1353A-WLL6190 Model: WLL6190 FCC ID: H8N-WLL6190 IC: 1353A-WLL6190

Internal Photos

Test Report

FCC TEST REPORT Report No.: FC0N1124 SPORTON International Inc. Report Format Version: a FCC EMC TEST REPORT CERTIFICATE according to 47 CFR FCC Part 15 Subpart B Equipment : 802.11g / 802.11n WLAN PCI-E Mini Card Model No. : WLL6190 Brand Name : Askey Filing Type : New Application Applicant : Askey Computer Corporation 10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI, TAIWAN, 23585 R.O.C. FCC ID : H8N-WLL6190 Manufacturer : ASKEY COMPUTER CORP. 10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI, TAIWAN, 23585 R.O.C. Received Date : Nov. 30, 2010 Final Test Date : Dec. 31, 2010 Statement The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart B. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FC0N1124 SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 17, 2011 FAX : 886-2-2696-2255 Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION ..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Table for Filed Antenna ........................................................................................................................................................................... 3 2.3 Table for Test Modes .............................................................................................................................................................................. 4 2.4 Table for Testing Locations ..................................................................................................................................................................... 4 2.5 Table for Supporting Units ....................................................................................................................................................................... 4 2.6 EUT Operation during Test ..................................................................................................................................................................... 5 2.7 Test Configuration ................................................................................................................................................................................... 6 3 TEST RESULT ........................................................................................................................................................ 7 3.1 AC Power Line Conducted Emissions Measurement .............................................................................................................................. 7 3.2 Radiated Emissions Measurement ........................................................................................................................................................ 11 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 21 5 TEST LOCATION .................................................................................................................................................. 22 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 23 APPENDIX A. TEST PHOTOS ........................................................................................................................ A1 ~ A5 APPENDIX B. PHOTOGRAPHS OF EUT ....................................................................................................... B1 ~ B8 FCC TEST REPORT Report No.: FC0N1124 SPORTON International Inc. Page No. : ii of ii TEL : 886-2-2696-2468 Issued Date : Jan. 17, 2011 FAX : 886-2-2696-2255 History of This Test Report Original Issue Date: Jan. 17, 2011 Report No.: FC0N1124 ■ No additional attachment. □ Additional attachment were issued as following record: Report No. Issue Date Description Receiver Frequency 2412~2462MHz 30~88 40 88~216 43.5 216~960 5th harmonic of highest frequency. 46 Above 960 54 3 FCC TEST REPORT Report No.: FC0N1124 SPORTON International Inc. Page No. : 1 of 23 TEL : 886-2-2696-2468 Issued Date : Jan. 17, 2011 FAX : 886-2-2696-2255 FCC ID : H8N-WLL6190 CERTIFICATE OF COMPLIANCE CERTIFICATE according to 47 CFR FCC Part 15 Subpart B Equipment : 802.11g / 802.11n WLAN PCI-E Mini Card Model No. : WLL6190 Brand Name : Askey Applicant : Askey Computer Corporation 10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI, TAIWAN, 23585 R.O.C. WE HEREBY CERTIFY THAT: The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4-2003 and the energy emitted by this equipment were passed 47 CFR FCC Part 15 Subpart B. Testing was carried out on Dec. 31, 2010 at SPORTON International Inc. LAB. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. ____________________________ Wayne Hsu / Vice Manager Reviewed Data: Jul. 30, 2004 FCC TEST REPORT Report No.: FC0N1124 SPORTON International Inc. Page No. : 2 of 23 TEL : 886-2-2696-2468 Issued Date : Jan. 17, 2011 FAX : 886-2-2696-2255 FCC ID : H8N-WLL6190 1 SUMMARY…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC TEST REPORT Report No.: FC0N1124 Page No. : A1 of A5 Appendix A. Test Photos FCC TEST REPORT Report No.: FC0N1124 Page No. : A2 of A5 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FC0N1124 Page No. : A3 of A5 SIDE VIEW FCC TEST REPORT Report No.: FC0N1124 Page No. : A4 of A5 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FC0N1124 Page No. : A5 of A5 REAR VIEW Test Fixture FRONT VIEW
