H8N9961V1Femtocell

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. FOR MOBILE DEVICE USAGE (>20cm/low power) Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Attention: Important Information This device must be installed at your registered address with T-Mobile. Failure to maintain this address could affect your ability to contact emergency services and result in device deactivation. Visit https://my.t-mobile.com , MyAccount on your handset or call CARE at *611 from your handset or 1-800-937-8997 to update the device use address. 4G LTE CellSpot ™ Quick Start Guide You now have a powerful, simple way to create your own personal T-Mobile 4G LTE mini-tower in your home or small office. It can provide improved indoor 4G LTE coverage, more dependable voice calls and more consistent data speeds. FRONT COVER 8.25” 11.7” PRINTING STATIONS: PROCESS MIX: TMO Magenta Black FILE NAME RM2_4GPersonalCellSpot_QSG_TCS525167_1.ai DATE 12.04.14 CLIENT T-Mobile DIELINE FILE NAME 8.25” wide x 11.7” tall CREATIVE APPROVAL DRAWN BY vl PRINTER TBD DIELINE SOURCE Drawn by SB PRODUCTION APPROVAL SB JOB NUMBER 1600634 PRINTING TYPE TBD DIELINE DATE n/a PROOFREADING APPROVALNOTES: MECHANICAL 55 Union Street | 3rd Floor San Francisco, CA 94111 T 415 427 1200 | F 415 348 0063 sterlingbecker.com 4-COLOR Process Reset 1. Press and hold for 5s for reboot 2. Press and hold for 10s for power off 3. Press and hold for 15s for factory setting reset and software update Yellow WAN Port (Connect to Wi-Fi router or Wi-Fi cable modem router) Grey LAN Port (Connect to other devices if needed) Power (Power on when AC Adaptor is plugged in) Round GPS Port (Connect to GPS Antenna & Cable) Stand/Wall Mount Wall Mounting Kit CellSpot Device in Stand GPS Cable Bracket (Attach GPS cable here after installation is complete) What’s Inside Getting to know your 4G LTE CellSpot ™ Quick Start Guide (This document) Stand/Wall Mount Ethernet CableGPS Cable Bracket 4G LTE CellSpot Device AC Power Adaptor GPS Antenna & Cable (15 ft) Wall Mounting Kit (2 Cheese Screws and 2 Wall Anchors) CellSpot Device with Wall Mount 1 INSIDE - LEFT 8.25” 11.7” Quick Setup Connect your CellSpot to the Internet Connect the yellow Ethernet cable from the “WAN” yellow port on your CellSpot to an available Ethernet port on your Wi-Fi router or Wi-Fi cable modem router. Connect GPS antenna to the CellSpot Connect the GPS antenna cable to the GPS port. Position the antenna as close to a window as possible. (You'll attach the GPS antenna and cable to the bracket after installation is complete.) Power on your 4G LTE CellSpot Plug in your AC power adaptor into the power outlet and connect the power cable to the CellSpot power port. Let your CellSpot set up After you power on your CellSpot, the CellSpot will go through self-installation process. It can take up to 45 minutes to complete the device setup. Your CellSpot may download updates and could restart during this time. • Power (Solid Green): Power on. Device self testing and update complete. • Internet (Solid Green): Successful internet connection. • Status (Solid Green): Successful connection established with T-Mobile network. • GPS (Solid Green Optional): GPS position locked if GPS signal is present. Device can still proceed through setup without GPS signal lock and operate normally. • 3G/4G (Solid Green): Device is ready to provide 3G/4G service. • 4G LTE (Solid Green): Device is ready to provide 4G LTE service. Congratulations! Your CellSpot setup is complete. Make your first 4G LTE CellSpot call with your 3G, 4G or 4G LTE capable devices. Just use your mobile device as you normally do and enjoy the improved coverage, more dependable voice calls and a more reliable high speed data connection. 1 2 3 4 2 1 4 3 2 INSIDE - RIGHT 8.25” 11.7” Common Troubleshooting Procedures Have More Questions? For additional information about T-Mobile 4G LTE CellSpot installation go to http://4GLTECellSpotSetup.T-Mobile.com Call T-Mobile customer service at *611 from your handset or 1-800-937-8997. Deposit, qualifying wireless service, compatible phone & broadband Internet connection required. May require plan change. All data, messaging and other services billed according to your regular rate plan and other pricing. Non-return fee applied if device is not returned; damage fee may apply. Current location address required for device use. See T-Mobile.com for details and restrictions including important 9-1-1 limitations. Property of T-Mobile USA, Inc. Not For Resale. TCS525167.1 Device has a hardware issue. Contact T-Mobile for resolution. Solid Orange Solid Orange Solid Orange Solid Orange Solid Orange Solid Orange Device unable to capture GPS signal. Without GPS signal lock, device is still able to proceed through setup and operate normally. AnyAnyAny Solid Orange AnyAny Device connection issue with the Wi-Fi router or Wi-Fi cable modem router. Check Wi-Fi router or Wi-Fi cable modem router connection. Flashing Green Solid Orange OffAnyOffOff Device is unable to reach T-Mobile network. Check with Internet Service Provider on network settings. Ensure ports UDP 500, UDP 4500 and UDP 123 are opened. Flashing Green Flashing Orange OffAnyOffOff Unable to activate the device with T-Mobile network. Contact T-Mobile for resolution. Flashing Green Solid Green AnyOffOff 3G, 4G, 4G LTE service is not available. Device may not be used in T-Mobile market or remote disabled by T-Mobile. Contact T-Mobile for resolution. Solid Green Solid Green Solid or Flashing Green AnyOffOff Device has reached maximum number of 8 active voice and data connections for each technology. Attempt to call again after existing calls are terminated. Solid Green Solid Green Flashing Green Any Flashing Green Flashing Green The device is overheated. Move device to a cooler location Flashing Orange Flashing Orange Flashing Orange Flashing Orange Flashing Orange Flashing Orange Issue Description and ResolutionPowerInternetStatusGPS3G/4G4G LTE Solid or Flashing Orange BACK COVER 8.25” 11.7”

Askey Computer Corp 10F, No. 119, Chienkang Rd Chung-Ho,Taipei, 235, Taiwan, R.O.C. TEL: +886-2-2228-7588 Date: 2014-12-31 FCC ID: H8N9961V1 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Part list Tune-up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ----------------------------------- Askey Computer Corp Name: John Chiou Title: Director TEL: +886-2-2228-7588 E-mail: [email protected]

Askey Computer Corp 10F, No. 119, Chienkang Rd Chung-Ho,Taipei, 235, Taiwan, R.O.C. TEL: +886-2-2228-7588 Date: 2014-12-22 FCC ID: H8N9961V1 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ----------------------------------- Askey Computer Corp Name: John Chiou Title: Director TEL: +886-2-2228-7588 E-mail: [email protected]

Askey Computer Corp 10F, No. 119, Chienkang Rd Chung-Ho,Taipei, 235, Taiwan, R.O.C. TEL: +886-2-2228-7588 Date: 2014-12-22 FCC ID: H8N9961V1 A U T H O R I Z A T I O N L E T T E R To whom it may concern: We, the undersigned, hereby authorize Andrea Hsia / Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Andrea Hsia / Senior Specialist of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------- Askey Computer Corp Name: John Chiou Title: Director TEL: +886-2-2228-7588 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7

Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14

Report No.: SA141119C42 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA141119C42 MODEL NO.: 9961 Home Cell V1 FCC ID: H8N9961V1 RECEIVED: Nov. 19, 2014 TESTED: Dec. 09 ~ Dec. 12, 2014 ISSUED: Dec. 15, 2014 APPLICANT: ASKEY COMPUTER CORP. ADDRESS: 10F, NO.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY 23585, TAIWAN, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan (R.O.C) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-com pliance to the specification Report No.: SA141119C42 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................................. 3 1. CERTIFICATION .......................................................................................................... 4 2. RF EXPOSURE ............................................................................................................ 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ...................................... 5 2.2 MPE CALCULATION FORMULA ................................................................................. 5 2.3 CLASSIFICATION ........................................................................................................ 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .............................. 6 Report No.: SA141119C42 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA141119C42 Original release Dec. 15, 2014 Report No.: SA141119C42 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT:Femtocell MODEL NO.:9961 Home Cell V1 BRAND:Askey APPLICANT:ASKEY COMPUTER CORP. TESTED: Dec. 09 ~ Dec. 12, 2014 TEST SAMPLE:ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment (Model: 9961 Home Cell V1) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Dec. 15, 2014 Pettie Chen / Senior Specialist APPROVED BY : , DATE : Dec. 15, 2014 Dylan Chiou / Project Engineer Report No.: SA141119C42 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA141119C42 6 of 6 Report Format Version 5.0.0 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) EIRP (dBm) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) WCDMA Band 2 (Channel Bandwidth: 5MHz) 1932.4MHz ~ 1987.6MHz 25.18 20 0.066 1 FREQUENCY BAND (MHz) EIRP (dBm) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) LTE Band 4 (Channel Bandwidth: 5MHz) 2112.5MHz ~ 2152.5MHz 27.56 20 0.113 1 LTE Band 4 (Channel Bandwidth: 10MHz) 2115MHz ~ 2150MHz 27.76 20 0.119 1 LTE Band 4 (Channel Bandwidth: 15MHz) 2117.5MHz ~ 2147.5MHz 25.53 20 0.071 1 LTE Band 4 (Channel Bandwidth: 20MHz) 2120MHz ~ 2145MHz 27.81 20 0.120 1 CONCULSION: Both of the WCDMA and LTE can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density 1. WCDMA + LTE = 0.066 + 0.120 = 0.186 Therefore, the maximum calculation of this situation is 0.186, which is less than the “1” limit. ---END---

Report No.: RF141119C42 1 of 35 Report Format Version 5.0.0 FCC TEST REPORT (PART 24) REPORT NO.: RF141119C42 MODEL NO.: 9961 Home Cell V1 FCC ID: H8N9961V1 RECEIVED: Nov. 19, 2014 TESTED: Dec. 09 ~ Dec. 12, 2014 ISSUED: Dec. 15, 2014 APPLICANT: ASKEY COMPUTER CORP. ADDRESS: 10F, NO.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY 23585, TAIWAN, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF141119C42 2 of 35 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 4 1 CERTIFICATION ....................................................................................................... 5 2 SUMMARY OF TEST RESULTS ............................................................................... 6 2.1 MEASUREMENT UNCERTAINTY .................................................................... 6 2.2 TEST INSTRUMENTS ...................................................................................... 7 3 GENERAL INFORMATION ........................................................................................ 8 3.1 GENERAL DESCRIPTION OF EUT ................................................................. 8 3.2 CONFIGURATION OF SYSTEM UNDER TEST .............................................. 9 3.3 DESCRIPTION OF SUPPORT UNITS ............................................................. 9 3.4 DESCRIPTION OF TEST MODES ................................................................. 10 3.5 EUT OPERATING CONDITIONS ................................................................... 11 3.6 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................ 11 4 TEST TYPES AND RESULTS ................................................................................. 12 4.1 OUTPUT POWER MEASUREMENT .............................................................. 12 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT ........................................... 12 4.1.2 TEST PROCEDURES .................................................................................... 12 4.1.3 TEST SETUP .................................................................................................. 13 4.1.4 TEST RESULTS ............................................................................................. 14 4.2 FREQUENCY STABILITY MEASUREMENT .................................................. 15 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT .............................. 15 4.2.2 TEST PROCEDURE ....................................................................................... 15 4.2.3 TEST SETUP .................................................................................................. 15 4.2.4 TEST RESULTS ............................................................................................. 16 4.3 OCCUPIED BANDWIDTH MEASUREMENT ................................................. 17 4.3.1 TEST PROCEDURES .................................................................................... 17 4.3.2 TEST SETUP .................................................................................................. 17 4.3.3 TEST RESULTS ............................................................................................. 18 4.4 PEAK TO AVERAGE RATIO ........................................................................... 19 4.4.1 LIMITS OF PEAK TO AVERAGE RATIO MEASUREMENT ........................... 19 4.4.2 TEST SETUP .................................................................................................. 19 4.4.3 TEST PROCEDURES .................................................................................... 19 4.4.4 TEST RESULTS ............................................................................................. 20 4.5 BAND EDGE MEASUREMENT ...................................................................... 21 4.5.1 LIMITS OF BAND EDGE MEASUREMENT ................................................... 21 4.5.2 TEST SETUP .................................................................................................. 21 Report No.: RF141119C42 3 of 35 Report Format Version 5.0.0 4.5.3 TEST PROCEDURES .................................................................................... 21 4.5.4 TEST RESULTS ..................…

Text truncated - open the document above for the full version.

Report No.: RF141119C42-1 1 of 77 Report Format Version 5.0.0 FCC TEST REPORT (PART 27) REPORT NO.: RF141119C42-1 MODEL NO.: 9961 Home Cell V1 FCC ID: H8N9961V1 RECEIVED: Nov. 19, 2014 TESTED: Dec. 09 ~ Dec. 12, 2014 ISSUED: Dec. 15, 2014 APPLICANT: ASKEY COMPUTER CORP. ADDRESS: 10F, NO.119, JIANKANG RD., ZHONGHE DIST., NEW TAIPEI CITY 23585, TAIWAN, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF141119C42-1 2 of 77 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 3 1 CERTIFICATION ........................................................................................................ 4 2 SUMMARY OF TEST RESULTS ................................................................................ 5 2.1 MEASUREMENT UNCERTAINTY ............................................................................. 5 2.2 TEST SITE AND INSTRUMENTS .............................................................................. 6 3 GENERAL INFORMATION ......................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ........................................................................... 7 3.2 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 9 3.3 DESCRIPTION OF SUPPORT UNITS ....................................................................... 9 3.4 DESCRIPTION OF TEST MODES ........................................................................... 10 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................... 11 4 TEST TYPES AND RESULTS .................................................................................. 12 4.1 OUTPUT POWER MEASUREMENT ....................................................................... 12 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT ..................................................... 12 4.1.2 TEST PROCEDURES .............................................................................................. 12 4.1.3 TEST SETUP ........................................................................................................... 13 4.1.4 TEST RESULTS ....................................................................................................... 14 4.2 FREQUENCY STABILITY MEASUREMENT ........................................................... 19 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT ........................................ 19 4.2.2 TEST PROCEDURE ................................................................................................ 19 4.2.3 TEST SETUP ........................................................................................................... 19 4.2.4 TEST RESULTS ....................................................................................................... 20 4.3 EMISSION BANDWIDTH MEASUREMENT ............................................................ 21 4.3.1 LIMITS OF EMISSION BANDWIDTH MEASUREMENT .......................................... 21 4.3.2 TEST SETUP ........................................................................................................... 21 4.3.3 TEST PROCEDURES .............................................................................................. 21 4.3.4 TEST RESULTS ....................................................................................................... 22 4.4 CHANNEL EDGE MEASUREMENT ........................................................................ 24 4.4.1 LIMITS OF CHANNEL EDGE MEASUREMENT ...................................................... 24 4.4.2 TEST SETUP ........................................................................................................... 24 4.4.3 TEST PROCEDURES .............................................................................................. 24 4.4.4 TEST RESULTS ....................................................................................................... 25 4.5 CONDUCTED SPURIOUS EMISSIONS .................................................................. 29 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT .................. 29 4.5.2 TEST PROCEDURE ...........................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST (Test Mode A) 2 RADIATED EMISSION TEST (Test Mode B)
