H8NEAI2304PIndoor AP

2.Installation Wireless Router EAI2304P Quick Installation Guide Power Router 3. .LED Indicators. 2 2 1 1 5. 6. 7. x 1 8. port s . Connect the power to the Router’s . Plug power s Package Contents Check the contents of the package Router LEDs Drilling Template .SIM Card and Battery .GPS Cable (This page intentionally left blank.) 1.Turn the device upside down. 2.Remove the SIM Card & Battery cover by loosening the two Philip screws. Philip screws SIM Card & Battery Cover 3.Set aside the removed SIM Card & Battery cover. SIM Card & Battery Cover SIM Card slot Battery compartment Philip screws SIM Card & Battery Cover 4.Insert the SIM Card. Make sure the SIM Card is pushed all the way into the slot. 5.Insert the Battery. Micro SIM 6.Place the SIM Card & Battery Cover on the Battery compartment, tighten the Philips screws till the cover is tightly secured. 1.Connect the GPS Cable to the GPS-marked mini co-axial (SMC) connector located on the front panel of the wireless router. 2.Locate a nearby window. Mount the GPS Antenna on the window glass. (Remove adhesive film on the back of the GPS Antenna prior to mounting in on the window glass.) GPS Antenna Wireless Router GPS Antenna Window LEDActivityDescription OFFLTE service is not connected. Solid BLUELTE connected and signal level good. [ RSRP Range -105 dbm to -40 dbm] Solid YELLOW Intermittent LTE signal [ RSRP Range -106 dbm to -120 dbm ] or DATA Connection failed casealso Solid RED 1. LTE is not functional. 2. SIM card is not provisioned or not properly provisioned. 3. SIM card is not inserted or not inserted properly. Solid GREENReserved Flashing GREENDevice is under firmware upgrading process. Flashing LED ( Color depends on LTE state ) Flashing LED ( Color depends on LTE state ) Device is under Battery mode, LED Flashing period 5 seconds once OFFDevice is not connected to internet. Solid BLUEInternet is connected thru multiple WAN. Solid GREENInternet is connected thru single WAN. Solid REDDevice is under error state other than LTE error. Flashing GREENDevice is under firmware upgrading process. Device is under Battery mode, LED Flashing period 5 seconds once OFF Wi-Fi is not on and not operational, Wi-Fi disabled by default in Battery Mode Solid GREENWi-Fi is on and operating normally. Flash GREENDevice is under firmware upgrading process. OFFDevice is not receiving power. Solid GREENDevice is completely power on. Flashing GREENDevice is under power on process. Flashing YELLOWDevice is under Battery mode. Flashing period 5 seconds once Solid REDBattery needs to be replaced. Flashing RED 5 times Device cannot be power on for any reasons. (Critical low battery, High temperature) LTE System Status POWER 2.4GHz/5GHz *Wall Mount Caution: To ensure proper installation, use three M3.5 screws with a minimum length of 21.8 mm. The input connector Pour garantir une installation correcte, utilisez trois vis M3,5 d'une longueur minimale de 21,8 mm. Le connecteur d'entrée doit être orienté vers le sol. must face toward the floor. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 45cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. * Do not open the system’s cover. If opening the cover for maintenance is a must, only a skill person should do so. Battery Caution: - If the battery is incorrectly replaced, there is a danger of explosion. - Replace only with the same or equivalent type recommended by the manufacturer. - Discard used batteries according to the manufacturer's instructions. * N'ouvrez pas le capot du système. Si l'ouverture du couvercle pour l'entretien est indispensable, seule une personne qualifiée doit le faire. MISE EN GARDE: - Si la batterie n'est pas remplacée correctement, il existe un risque d'explosion. - Remplacez uniquement par un type identique ou équivalent recommandé par le fabricant. - Jetez les piles usagées conformément aux instructions du fabricant. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: o o o o Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
