H8NTN230A2Smart watch

Power key Return key Wrist Band clip 2.3“ Touch screen Camera USB type-C Connector (for charging & data transmit) BIO Sensor (Option) Charging Connector TurboMate E2 –TN230A2 Quick Start Guide 1. Package  TurboMate E2 device  Type-C USB Cable  Plug + Adapter (5.35V/2A)  Wrist Band with 2 size of length 2. Product View (1) Front view Charging Connector: The charging connector slot should put properly and touch pogo pins on the charging base. (2) Rear View BIO Sensor (Option): The function of BIO sensor is to detect the heart rate. It should be touched well with wrist when wearing with the wrist band. Latch Charging Indicator Wearing Wrist Band 1) Bond with the clip on device 2) Release by using the latch of band Multiple slot charger (Model: DS40310) Slide device from the top of cradle Pogo Pin: When charging, pogo pin on the charger should be snapped properly with the charging connector on the device. LED indicator: LED (red) is enlightened while power in. DC-in adaptor: Plug DC into the DC-in connector for charging. Please use the adaptor (2A/12V) which is included the package. Notice: Use only a TN230Ax approved Power Adaptor with electrical ratings: Output 5VDC, 1A for each of port with a maximum ambient temperature of at least 35°C on altitude 2000m . Power Key Option: Wall Mount Mounted on the wall by using screw kit (M3.5*20L, P head) which is included the package. Then slide the cradle from the front and fix the location. 3. Boot the device Press Power key for few second and device will boot up. 4. Shut down the device Press Power key and holding for few second to see the power off screen shows up. You can choose “power off” or “Restart” the device. Press the latch when need to release the cradle 5. Home Screen (please slide from right to left) 1 st page: Clock 2 nd page: Recent message 3 rd page: Quick Switch Bar When slide down from the top of screen, you can see the status bar to indicate: 6. App Screen (Slide from bottom to top can enter app page) 7. Function description: (“” “” “Back” in screen means “Back/Esc”) Icon Function Description and Remark Gallery Browse photos and videos Cellular Small Cellular Clock Setup alarm, clock, timer, stopwatch Calendar Check date only because there is no GMS support. Adding action on calendar is not available and also can’t sync up Google calendar. File Manager To browse file on deivce AudioRecord Press button for start recording and press again for stop recording Scanner apk Not available in released version Setting 1. Setting of BT, Wifi, NFC, Display, Sound, Location, Date and Time 2. Factory Reset 3. About the device 4. System Update 5. Battery status Camera Press camera icon to capture picture, video recording and Panoramic photo (Warning!! Please do not open the camera for too long time to avoid the increased temperature from device will make your skin uncomfortable.) Sensors To read the measurement of: Pressure, Biosensor (HRM), GPS, Pedometer, G-sensor, Gyroscope. 4. Charging indicator a. TurboMate E2 is OFF Symbol Description LED Indicator Battery capacity 0% ~ 10% Charging Red: On Green: Off Battery capacity 11% ~ 20% Charging Red: On Green: Off Battery capacity 21% ~ 40% Charging Red: On Green: Off Battery capacity 41% ~ 60% Charging Red: On Green: Off Battery capacity 61% ~ 80% Charging Red: On Green: Off Battery capacity 81%~100% Then discharging Red: Off Green: On b. TurboMate E2 is ON Description LED Indicator Discharging Red: Off Green: Off Charging Red: On Green: Off Full Charge Red: Off Green: On Over Temperature Discharging (if the device is with 55 degree-c,it will be stopped charging) Red: Off Green: Off 5. E-Label Where to find the e-label Settingabout deviceApproval/More FCC ID: H8NTN230A2 6. Caution 1. If device runs out of battery (can’t boot up), please charge USB cable (by using adaptor in TN230Ax package). When start charging, device will boot up automatically. 2. In some cases, if the device crash or hang on certain screen, please press power key until feeling vibration from device then the device will be hard-reset. 3. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Regulatory Information Caution: Only use TURBONET approved accessories. Battery Safety 1. The area in which the units are charged should be clear of debris and combustible materials or chemicals. Particular care should be taken where the device is charged in a non -commercial environment. 2. Follow battery usage, storage, and charging guidelines found in the user guide. 3. Improper battery use may result in a fire, explosion, or other hazard. 4. To charge the device battery, the battery and charger temperature must be between 0°C~+45°C. 5. Do not use incompatible batteries and chargers. Use of an incompatible battery or charger may present a risk of fire, explosion, leakage, or the hazard. 6. Do not disassemble or open, crush, bend or deform, puncture, or shred. 7. Severe impact from dropping any battery-operated device on a hard surface could cause the battery to overheat. 8. Do not short circuit a battery or allow metallic or conductive objects to contact the battery terminals. 9. Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, or expose to fire, explosion, or other hazard. 10. Do not leave or store the equipment in or near areas that might get very hot, such as in a parked vehicle or near a radiator or other heat source. Do not place battery into a microwave oven or dryer. 11. Battery usage by children should be supervised. 12. Please follow local regulations to promptly dispose of used re-chargeable batteries. 13. Do not dispose of batteries in fire. 14. Seek medical advice immediately if a battery has been swallowed. In the event of a battery leak, do not allow the liquid to come in contact with the skin or eyes. If contact has been made, wash the affected area with large amounts of wa…

Text truncated - open the document above for the full version.

Date: September 1, 2020 We, Askey Computer Corp declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: H8NTN230A2 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- John Chiou /Director Tel: 886 2 2228-7588 Fax: 886 2 3234-9340 E-mail: [email protected]

Date: 2020-09-01 FCC ID: H8NTN230A2 FCC E-Label Information: A. Information to be displayed 1. The information that will be displayed on the e-label and information that will remain in the user manual is shown below: Information on E-label In Manual FCC ID number Yes No FCC logo Yes No 15.19 statement (“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”) No Yes Class A / B Digital Device user manual statements No Yes Caution to the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment No Yes Images of the e-label screen are provided below: B. Access to the required information on the e-label 1. Users must be able to access the information in no more than three steps in a device’s menu. The actual steps are: Answer: Settingabout deviceApproval/More 2. The information is stored on the device, no special accessories or supplemental plug-ins (e.g., a SIM/USIM card) are required to access the information. Answer: the information is stored on the device and no special accessories or supplemental plug-ins (e.g., a SIM/USIM card) are required to access the information. 3. Users are provided specific instructions on how to access the information. Answer: The information to user is provided user manual as well as packaging inserts. 4. The equipment authorization application for the device must clearly include the instructions for accessing information as part of the exhibit showing the label information. Answer: Please see the e-label sample the exhibit showing the label information and will display of the device. More details please refer to A1 table for reference. C. Labeling for Importation and Purchasing 1. Products utilizing e-labels are required to have a physical label on the product at the time of importation, marketing and sales. For devices imported in bulk and not packaged individually, a removable adhesive label or, for devices in protective bags, a label on the bags is acceptable for this purpose. Any removable label shall be of a type intended to survive normal shipping and handling and must only be removed by the customer after purchase. For devices imported already in individual packages ready for sale, the information may alternatively be provided on the package. It shall contain: 1. The FCC ID and/or the DoC logo (if applicable); and 2. Any other information required by specific rule to be provided on the surface of the product unless such information is permitted to be included in the User’s manual or other packaging inserts. Answer: FCC ID and DoC logo are printed on product packaging and the compliance statement is included in the user manual. D. Other considerations 1. The above information must be programmed by the responsible party and the information must be secured in such a manner that third-parties cannot modify it. Answer: the e-label information is pre-programmed by the responsible party. The user cannot modify the e-label information. 2. All the applicable regulatory information required on the packaging or user instructions must be provided according to the rules even if it is displayed electronically. For example, hearing aid compatibility (HAC) ratings for the phones as specified in 47 C.F.R. § 20.19. Answer: All the applicable regulatory information required on the packing or user instructions must be provided according to the rules even if it is electronically. 3. E-label displays may include regulatory information required to be placed in the User’s Manual or on the packaging as required by the rules. The following considerations must be taken into account for such information distribution. a. If the primary user manual or user guide is provided by other electronic media (e.g.,CD, or online access) then as an option this information can also be provided as part of the e-label b. The e-label format must clearly differentiate between the information required to be on the surface of the product and the information required for the User’s Manual or on the packaging. Answer: the e-label format clearly differentiates between the information required to be on the surface of the product and the information required for the user manual or on the packaging. 4. Products subject to both certification and Declaration of Conformity or certification and Verification can use the e-label guidance by displaying both the FCC ID and an image of the FCC DoC Logo, or FCC ID and product identification as required by the rules. Answer: Please see the e-label sample the exhibit showing the label include FCC ID / DoC logo also will display of the device. ----------------------------------- Askey Computer Corp. Name: John Chiou Title: Director TEL: +886-2-2228-7588 E-mail: [email protected]
