H8NWLC020PCMCIA Wireless LAN Card

PCMCIA Wireless LAN PC Card User’s Manual Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of the seller. The seller provides this documenta tion without warranty, term, or condition of any kind. The seller may make improvements or changes in the product( s) and/or the program(s) described in this documentation at any time. Other product and company names herein may be trademarks of their respective owners.  2001 All rights reserved. I Contents Chapter 1 In troducti on......................................................................................................... ........ 1 Local Area Netw ork (LAN) ....................................................................................................... ................................... 1 Ad Hoc Network ................................................................................................................. ......................................... 2 Infrastructure Network ......................................................................................................... ........................................ 2 Chapter 2 Installing the Wireless L AN Card .............................................................................. 3 System Requirements ............................................................................................................ ..................................... 3 Installing t he Hard ware ........................................................................................................ ....................................... 3 Wireless LAN Card Status LEDs.................................................................................................. ............................... 4 Installing the De vice Driver ................................................................................................... ...................................... 5 Installing the Wireless LAN Card Software ...................................................................................... ........................... 7 Chapter 3 Configuring th e Wireless L AN Card ........................................................................ 11 Connecting to Other Comput ers with WLAN (Ad Hoc) ............................................................................... .............. 12 Connecting to Access Po ints (Infrastructure)................................................................................... ......................... 14 Setting Security ............................................................................................................... .......................................... 16 PCMCIA Wireless LAN Card II Setting Power Save Mode........................................................................................................ ................................. 18 Checking Link Quality (Inf rastructure Mode Only) ............................................................................... ..................... 20 Chapter 4 Uninstalling th e Wireless L AN Card ........................................................................ 21 Removing the Wire less LAN Card ................................................................................................. ........................... 21 Chapter 5 Updating th e Device Dr iver ...................................................................................... 25 Chapter 6 Tr oubleshoot ing ...................................................................................................... .27 Radio Inte rference............................................................................................................. ........................................ 27 Card Not Detected.............................................................................................................. ....................................... 28 Cannot Connect to Anot her Wireless LAN Ca rd.................................................................................... ................... 28 Poor Link Quality .............................................................................................................. ......................................... 29 Cannot Connect to Access Point ................................................................................................. ............................. 29 Appendix A Limite d Warranty ................................................................................................... 3 1 Wireless LAN Hardwa re .......................................................................................................... .................................. 31 Wireless LAN Software .......................................................................................................... ................................... 32 Appendix B Regulator y Complian ce ........................................................................................ 33 FCC Part 15 Declaration of Conformity (DoC) .................................................................................... ...................... 33 FCC Rules and Regulat ions - Part 15............................................................................................ ........................... 34 FCC Radiation Ex posure St atement ............................................................................................... .......................... 35 Contents III Appendix C Setting Up TCP/IP .................................................................................................. 3 7 Glossary....................................................................................................................... ............... 39 Index..................................................…

Text truncated - open the document above for the full version.

WLC020 方塊圖 44MHz crystal oscillator U16 Medium Controll Access & Baseband Processor ISL3873 U10 BPF MDR642E U2 Rx/Tx SWUPG152TA U5 PA HFA3984 U24 BPF MDR642E U3 MMCX Buffer UPG2754B U7 VCO ENFVHIK2S81 U9 REG2.9VMAX8867 U14 VCO ENFVHIK2S80 U17 PLL RF/IF Converter & Synthesizer HFA3685 U6 2412~2484MHz PLL F0=748MHz PCMCIASocket P1 Flash SST39VF010-90 U13 SRAM 128K16-55 U11 VCCS Rx I Rx Q Tx ITx Q REG2.9VMAX8867 U4 SAW U8 F0=374MHz External memory Freq range:2038~2110MHz 3.3V Power Supply Power Supply Baseband Controller R31 Ft Fr Ft Fr Ft Fr Ft Ft Synthesizer Synthesizer Synthesizer Transmitter frequency(Ft)& Receiver frequency(Fr)=2412MHz-2484MHz Reference frequency 3.3V Referencefrequency Referencefrequency 3.3V 3.3V 3.3V PC Regulator U51 VCCS VCCS VCCS Transmitter & Receiver Quadrature modem & Synthesizer HFA3783 U15

Report No.: 026H007FI Page: 1 of 4 Version:1.0 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo

FCC ID.: H8NWLC020 10F, No. 119, Chienkang Rd, Chung-Ho, Taipei, Taiwan, R.O.C. Tel: 886 2 2228 7588 Fax: 886 3 552 6589 LabelLoc The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. FCC ID Label Sample PCMCIA Wireless LAN Card Model No.: WLC020 F F C C C C I I D D : : H H 8 8 N N W W L L C C 0 0 2 2 0 0 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan DoC PCMCIA Wireless LAN Card ASKEY Model No.: WLC020 TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan

FCC ID.: H8NWLC020 10F, No. 119, Chienkang Rd, Chung-Ho, Taipei, Taiwan, R.O.C. Tel: 886 2 2228 7588 Fax: 886 3 552 6589 LabelLoc The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. FCC ID Label Sample PCMCIA Wireless LAN Card Model No.: WLC020 F F C C C C I I D D : : H H 8 8 N N W W L L C C 0 0 2 2 0 0 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan DoC PCMCIA Wireless LAN Card ASKEY Model No.: WLC020 TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan

Report No.: 026H007FI Page: 2 of 4 Version:1.0 (3) EUT Photo (4) EUT Photo Report No.: 026H007FI Page: 3 of 4 Version:1.0 (5) EUT Photo (6) EUT Photo Report No.: 026H007FI Page: 4 of 4 Version:1.0 (7) EUT Photo

1.1. Operational Description EUT is a PCMCIA Wireless LAN Card with 11 channels. This device provided four kind of transmitting speed 1,2,5.5 and 11Mbps. The device of RF carrier is DQPSK, DB PSK and CCK. The device adapts direct sequence spread spectrum modulation. The SMD antenna was Soldered on PCB provides diversity function to improve the receiving function. The PCMCIA interface provides the connection to pc for data can be transmitted by the radio signal connect to the Internet or Local network. This Wireless LAN Card is an IEEE 802.11b PCMCIA Wireless LAN Card adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direst Sequence Spread Spectrun (DSSS) radio transmission, the Wireless LAN Card transfers data at speeds up to 64/128-bit Wired Equivalent Protection (WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any 802.11b network.

Report No. 026H007FI Page: 1 of 48 Version:1.0 Test Report Product Name : PCMCIA Wireless LAN Card Model No.: WLC020 FCC ID.: H8NWLC020 Applicant : ASKEY COMPUTER CORP. Address : 10F, No. 119, Chienkang Rd, Chung-Ho, Taipei, Taiwan, R.O.C. Date of Receipt : May 30, 2002 Date of Test : June 19, 2002 Report No. : 026H007FI The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 026H007FI Page: 3 of 48 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................6 1.3. Tested System Datails....................................................................................................................6 1.4. Configuration of tested System .....................................................................................................7 1.5. EUT Exercise Software .................................................................................................................7 1.6. Test Facility ...................................................................................................................................8 2. Conducted Emission....................................................................................................................9 2.1. Test Equipment..............................................................................................................................9 2.2. Test Setup ......................................................................................................................................9 2.3. Limits ............................................................................................................................................9 2.4. Test Procedure .............................................................................................................................10 2.5. Test Result of Conducted Emission.............................................................................................11 3. Peak Power Output ...................................................................................................................12 3.1. Test Equipment............................................................................................................................12 3.2. Test Setup ....................................................................................................................................12 3.3. Test Condition .............................................................................................................................12 3.4. Standard Reqirement ...................................................................................................................12 3.5. Test Result of Peak Power Output...............................................................................................13 4. RF Exposure Evaluation ...........................................................................................................14 4.1. Friis Formula ...............................................................................................................................14 4.2. EUT Operation condition ............................................................................................................14 4.3. Test Result of RF Exposure Evaluation.......................................................................................15 5. Radiated Emission .....................................................................................................................16 5.1. Test Equipment............................................................................................................................16 5.2. Test Setup ....................................................................................................................................16 5.3. Test Condition .............................................................................................................................17 5.4. Limits ..........................................................................................................................................17 5.5. Test Procedure .............................................................................................................................18 5.6. Test Result of Radiated Emission................................................................................................19 6. Band Edge ..................................................................................................................................31 6.1. Test Equipment............................................................................................................................31 6.2. Test Setup ....................................................................................................................................31 6.3. Test Condition .............................................................................................................................32 6.4. Standard Reqirement ...................................................................................................................32 6.5. Test Result of Band Edge ............................................................................................................33 7. Occupied Bandwidth .................................................................................................................37 7.1. Test Equ…

Text truncated - open the document above for the full version.

Report No.: 026H007FI Page: 1 of 3 Version:1.0 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 026H007FI Page: 2 of 3 Version:1.0 Front View of Radiated Test Back View of Radiated Test Report No.: 026H007FI Page: 3 of 3 Version:1.0 Front View of Radiated Test-Horn Back View of Radiated Test-Horn
