H8NWLC060Wireless LAN PCMCIA Card

Askey Computer Corp
Wireless LAN PCMCIA Card - FCC ID H8NWLC060 - Askey Computer Corp
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Mar 20, 2003
Application Purpose
Original Equipment
Date of Application
Mar 09, 2003
Equipment Note
Wireless LAN PCMCIA Card
Frequency Range
2412.00000000 - 2462.00000000
Company
Askey Computer Corp
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

[email protected] www.adt.com.tw ADVANCE DATA TECHNOLOGY CORPORATION FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: Wireless LAN PCMCIA Card (Receiver Part) MODEL NO.: WLC060 TRADE NAME: Askey IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: D920213R05 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION: ManufacturerUSA Local Representative Company name: ASKEY COMPUTER CORP. To Be Determined. Address: 10F,NO.119, CHIENKANG RD., CHUNG- HO, TAIPEI TAIWAN R.O.C. Contact Person: John Chiou Title: Manager Tel/Fax: Tel: +886-2-2228-7588 Fax: +886-2-3234-9340

Users Manual

11Mbps Wireless LAN Card User’s Manual Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of the seller. The seller provides this documentation without warranty, term, or condition of any kind. The seller may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time. Other product and company names herein may be trademarks of their respective owners. ? 2002 All rights reserved. Rev: 01 December 2002 I Contents Chapter 1 Introduction....................................................................................................................................1 Wireless LAN Basics........................................................................................................................................2 Local Area Network (LAN)..........................................................................................................................................................................2 Peer-to-Peer Group......................................................................................................................................................................................3 Infrastructure Network.................................................................................................................................................................................3 Roaming..........................................................................................................................................................................................................3 Chapter 2 Installing the Wireless LAN Card....................................................................................................5 System Requirements......................................................................................................................................6 Wireless LAN Card Status LEDs.......................................................................................................................6 Part 1: PnP Driver Installation............................................................................................................................7 For Windows 98.............................................................................................................................................................................................8 For Windows Me............................................................................................................................................................................................9 For Windows 2000.....................................................................................................................................................................................10 For Windows XP.........................................................................................................................................................................................11 Part 2: Installing Wireless Client Manager........................................................................................................12 Chapter 3 Wireless Client Manager...............................................................................................................17 11Mbps Wireless LAN Card User Manual II Accessing the Wireless Client Manager...........................................................................................................17 Note to Windows XP Users.......................................................................................................................................................................18 Configuration for Peer-to-Peer Group...............................................................................................................19 Configuration for Base Station Connection.......................................................................................................23 Site Monitor....................................................................................................................................................28 Customizing the Display of the Site Monitor.........................................................................................................................................29 Modifying or Adding a Name to the Base Stations List.......................................................................................................................32 Link Test........................................................................................................................................................34 Viewing Liink Test Results........................................................................................................................................................................36 Displaying Link Test History in Graphical Line-Chart.......................................................................................................................37 Creating Measurements Log File.....................................................................................................................39 Card Diagnostics............................................................................................................................................42 Verifying Software Components Version..........................................................................................................44 Checking Connection Status...........................................................................................................................45 PART 2. Configuration Utility for Windows XP................................................................................................47 Connecting to an Access Poin…

Text truncated - open the document above for the full version.

External Photos

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

ID Label/Location Info

FCC ID FOR LABEL LOCATION

Internal Photos

Page 3 Page 4 Page 5

Operational Description

FCC ID: H8NWLC060 ADT No.920213R05 Operational Description The transmitter of the EUT is powered by host equipment. The antenna is Chip antenna without antenna connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

RF Exposure Info

FCC ID: H8NWLC060 Report No.: SA920113R01A 1 Issued: Feb. 25 th 2003 SAR TEST REPORT REPORT NO.: SA920113R01A MODEL NO.: WLC060 RECEIVED: Feb. 20, 2003 TESTED: Feb. 25, 2003 APPLICANT: ASKEY COMPUTER CORP. ADDRESS:10F, No.119, CHIENKANG RD, CHUNG-HO, TAIPEI TAIWAN R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 15 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. FCC ID: H8NWLC060 Report No.: SA920113R01A 2 Issued: Feb. 25 th 2003 Table of Contents 1.CERTIFICATION .................................................................................................................3 2.GENERAL INFORMATION ................................................................................................. 4 2.1GENERAL DESCRIPTION OF EUT ................................................................................... 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................... 4 2.3GENERAL INOFRMATION OF THE SAR SYSTEM .......................................................... 5 2.4GENERAL DESCRIPTION OF THE PROBE SCAN RULE................................................ 7 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ........................................... 8 4.DESCRIPTION OF SUPPORT UNITS ............................................................................... 9 5.TEST RESULTS................................................................................................................ 10 5.1TEST PROCEDURES....................................................................................................... 10 5.2MEASURED SAR RESULT .............................................................................................. 10 5.3SAR LIMITS ...................................................................................................................... 11 5.4EUT CONDUCTED POWER VARIATION ........................................................................ 11 5.5TISSUE ............................................................................................................................. 12 5.6TEST EQUIPMENT FOR TISSUE PROPERTY ............................................................... 12 6.SYSTEM VALIDATION...................................................................................................... 13 7.MEASUREMENT UNCERTAINTIES ................................................................................ 14 8.INFORMATION ON THE TESTING LABORATORIES ..................................................... 15 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: H8NWLC060 Report No.: SA920113R01A 3 Issued: Feb. 25 th 2003 1. CERTIFICATION PRODUCT : Wireless LAN PCMCIA Card MODEL NO. : WLC060 BRAND NAME : Askey APPLICANT : ASKEY COMPUTER CORP. STANDARDS : 47 CFR Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on 24 th Feb. 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate, and it was tested according to the standards listed above. This device was found to be in compliance with the Specific Absorption Rate (SAR) requirement specified in FCC part 2.1093 under General Population / Uncontrolled Exposure condition. FCC ID: H8NWLC060 Report No.: SA920113R01A 4 Issued: Feb. 25 th 2003 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless LAN PCMCIA Card MODEL NO.WLC060 POWER SUPPLY3.3VDC powered by host equipment CLASSIFICATIONPortable device, production unit MODULATION TYPE BPSK, QPSK, CCK RADIO TECHNOLOGY DSSS TRANSFER RATE 1/2/5.5/11Mbps FREQUENCY RANGE2412MHz ~ 2462MHz NUMBER OF CHANNEL11 CONDUCTED OUTPUT POWER 49.31mW ANTENNA TYPEChip Antenna PEAK SAR0.465W/kg DATA CABLENA I/O PORTSPCMCIA ASSOCIATED DEVICESNA 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS According to the specifications of the manufacturer, this product must comply with the requirements of the following standards: FCC 47 CFR Part 2 (2.1093) FCC OET Bulletin 65, Supplement C (01- 01) RSS-102 All tests have been performed and recorded as per the above standards. FCC ID: H8NWLC060 Report No.: SA920113R01A 5 Issued: Feb. 25 th 2003 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM DASY3 (software 3.1d) consists of high precision robtics system, probe alignment sensor, phantom, robot controller, controlled PC and near-field probe. The robot includes six axis that can move to the precision position of the DASY3 software defined. The DASY3 software can define the area which is detected by the probe. The robot is connected to controlled box. Controlled PC is connected to the controlled robot box. The DAE includes amplifier, signal multiplexing, AD converter, offset measurement, surface detection. It is connected to the Electro-optical coupler (ECO). The ECO performs the conversion form the optical into digital electric signal of the DAE and transfers data to the PC. ET3DV6 ISOTROPIC E-FIELD PROBE Construction Symmetrical design with triangular core. Built-in optical fiber for surface detection system. Built-in shielding against static charges. PEEK enclosure material (resistant to organic solvents, e.g., glycolether). Calibration Basic Broad Band Calibration in air: 10-2500 MHz Conversion Factors (CF) for HSL 900 and HSL 1800 CF-Calibration for other liquids and frequencies upon request F…

Text truncated - open the document above for the full version.

Test Report

FCC ID: H8NWLC060 Report No.: RF920113R01A 1 Issued: Feb. 25, 2003 FCC TEST REPORT REPORT NO.: RF920113R01A MODEL NO.: WLC060 RECEIVED: Feb. 13, 2003 TESTED: Feb. 13 ~ Feb. 20, 2003 APPLICANT:ASKEY COMPUTER CORP. ADDRESS:10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI TAIWAN R.O.C ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: H8NWLC060 Report No.: RF920113R01A 2 Issued: Feb. 25, 2003 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5TEST SETUP ...............................................................................................11 4.1.6EUT OPERATING CONDITIONS.................................................................11 4.1.7TEST RESULTS.......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 18 4.2.2TEST INSTRUMENTS ................................................................................ 19 4.2.3TEST PROCEDURES................................................................................. 20 4.2.4DEVIATION FROM TEST STANDARD ....................................................... 20 4.2.5TEST SETUP .............................................................................................. 21 4.2.6EUT OPERATING CONDITIONS................................................................ 21 4.2.7TEST RESULTS.......................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 26 4.3.2TEST INSTRUMENTS ................................................................................ 26 4.3.3TEST PROCEDURE ................................................................................... 27 4.3.4DEVIATION FROM TEST STANDARD ....................................................... 27 4.3.5TEST SETUP .............................................................................................. 27 4.3.6EUT OPERATING CONDITIONS................................................................ 27 4.3.7TEST RESULTS.......................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 32 4.4.2TEST INSTRUMENTS ................................................................................ 32 FCC ID: H8NWLC060 Report No.: RF920113R01A 3 Issued: Feb. 25, 2003 4.4.3TEST PROCEDURES................................................................................. 33 4.4.4DEVIATION FROM TEST STANDARD ....................................................... 33 4.4.5TEST SETUP .............................................................................................. 33 4.4.6EUT OPERATING CONDITIONS................................................................ 33 4.4.7TEST RESULTS.......................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 35 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 35 4.5.2TEST INSTRUMENTS ................................................................................ 35 4.5.3TEST PROCEDURE ................................................................................... 36 4.5.4DEVIATION FROM TEST STANDARD ....................................................... 36 4.5.5TEST SETUP .............................................................................................. 36 4.5.6EUT OPERATING CONDITIONS................................................................ 36 4.5.7TEST RESULTS.......................................................................................... 37 4.6BAND EDGES MEASUREMENT ................................................................ 41 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 41 4.6.2TEST INSTRUMENTS ................................................................................ 41 4.6.3TEST PROCEDURE ...............…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: H8NWLC060 Report No.: RF920113R01A 46 Issued: Feb. 25, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: H8NWLC060 Report No.: RF920113R01A 47 Issued: Feb. 25, 2003 RADIATED EMISSION TEST

Contact Information

Applicant

Jack Po(Manager)
[email protected]886 2 2228-7588Fax: 886 2 3234-9340

Technical Contact

Advance Data Technology CorporationEllis Wu
[email protected]+886-3-327-0910

13-1, Lane 19, WenShan 3rd., St. · Taoyuan · Taiwan

Non-Technical Contact

Advance Data Technology CorporationEllis Wu
[email protected]+886-3-327-0910

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchTommy Wu
[email protected]886-2-2605-2180-3Fax: 886-2-2605-2943

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz49.00 mW
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. SAR compliance has been established in a laptop computer configuration with side PCMCIA slot configurations as tested in this filing, and can be used in laptop computers with substantially similar physical dimensions, construction, and electrical and RF characteristics. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users must be provided with specific information required to satisfy RF exposure compliance for all final host devices. The highest reported SAR values is: 0.465 W/kg
