H8NWLF010Wireless CF Card

Wireless CF Card User Manual Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of the seller.The seller provides this documentation without warranty, term, or condition of any kind. The se ller may make improvements or ch anges in the product(s) and/or the program(s) described in this documentation at any time.Other product and company names herein may be trademarks of their respective owners. 2003/04/01Rev:01 i Safety Notes Warning • This equipment must be installed and operated in accordance with pr ovided instructions and a minimum 20 cm spacing must be prov ided between computer mounted antenna and person’s body (excluding extremities of hands , wrist and feet) during wireless modes of operation. • This device complies with Part 15 of the FCC Rules. Operation is subject to the follo wing two conditions: (1) this device may n ot cause harmful interference, and (2) this device must accept any interference received, incl uding interference that may cause undesired operation. Caution • Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Wireless CF Card User ManualiiAbout This User Manual For brevity, throughout this manual the “Wireless CF Card” wi ll be referred to as “the wireless adapter” or “the card” and foll owing terms or abbreviations are used interchangeably: • Access Point – AP • Ad-Hoc – Peer-to-Peer • Wireless LAN – WLAN • Ethernet network – LAN – network This User’s Manual contains information on how to install and co nfigure your Wireless CF Card. From now on, we will guide you t hrough the correct configuration steps to get your device up and run. iii Contents 1 Introduc tion .......................................................1 1.1 Over view ........................................................................... 1 1.2 System R equiremen ts ....................................................... 1 1.3 Unpa cking ......................................................................... 2 2 Wireless LA N Basi cs.........................................1 2.1 Local Area Ne twork (LAN)................................................. 1 2.2 Ad-Hoc Mode .................................................................... 1 2.3 Infrastruc ture Mode ........................................................... 2 2.4 Roam ing ............................................................................ 2 3 Installing the Driv er and CF Card......................3 3.1 Installing Micros oft ActiveSynch ........................................ 3 3.2 Installing the Driv er............................................................ 3 3.3 Inserting the Wi reless CF Cart .......................................... 5 4 Using Client Manger .........................................7 4.1 Accessing the Wi reless PC Card....................................... 7 4.2 Configuration for P eer-to-Peer Group................................ 9 4.3 Configuration for A ccess Point Co nnection ..................... 13 4.4 Site M onitor ..................................................................... 16 4.5 Link Test .......................................................................... 17 4.6 Network Troubl eshootin g................................................. 19 4.6.1 Viewing Current IP Addr ess ................................... 20 4.6.2 Renewing IP Addres s............................................. 21 4.6.3 Contacting a Comput er .......................................... 21 4.7 Tool s ................................................................................ 22 4.8 Checking Connec tion St atus ........................................... 24 5 Setting Up TCP/IP........................................... 25 Wireless CF Card User Manualiv 6 Troubleshoot ing .............................................. 27 Appendix A: Glossary ............................................ 29 Appendix B: Specifications ...... 錯誤 ! 尚未定義書籤。 Software .................................................. 錯誤 ! 尚未定義書籤。 Hardware................................................. 錯誤 ! 尚未定義書籤。 1 1 1 I I n n t t r r o o d d u u c c t t i i o o n n 1 1 . . 1 1 O O v v e e r r v v i i e e w w This Wireless CompactFlash Card is designed for Windows CE–based Pocket PC to easily join an 802.11b wireless network with a ra nge of up to 550 meters. With its CF Type II extended form factor, low power consumption, advanced power ma nagement, and rugged design (with antenna on the card), the ca rd is ideally suited for integration into your Pocket PC. It allows your Pocket PC to wi relessly gain access to corporate networks and thereby to share resources on the netwo rk, such as file transfers or Internet Access. This card features acknowledgment protocol and the option to be tuned to another fr equency channel to ensure the wireless conne ctivity in environments with radio interference.This card transfers data at speeds of up to 11Mbps. Both Peer-to-Peer Group (also re ferred to as Ad-Hoc mode) and Access Point connection (also referred to as Infrastructure mode) are supported. For network security concern, it also provides 64-bit or 128-bi t WEP (Wired Equivalent Privacy) encryption to ensure data security. 1 1 . . 2 2 S S y y s s t t e e m m R R e e q q u u i i r r e e m m e e n n t t s s To use this Wireless CF Card, you will need: • A computer to load driver: − Windows  9x or higher with CD-ROM − Microsoft ActiveSynch  3.0 or higher installed • Pocket PC with Type II CompactFlash Slot • Windows CE your Pocket PC Wireless CF Card User Manual2 1 1 . . 3 3 U U n n p p a a c c k k i i n n g g The Wireless CF Card package contains the following items: • One Wireless CF Card • One Software and Utility CD-ROM • Quick Start Guide 1 2 2 W W i i r r e e l l…

Text truncated - open the document above for the full version.

[email protected] www.adt.com.tw ADVANCE DATA TECHNOLOGY CORPORATION FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: Wireless CF Card (Receiver Part) MODEL NO.: WLF010 TRADE NAME: Askey IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: D9203270R01 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION： ManufacturerUSA Local Representative Company name: ASKEY COMPUTER CORP. To Be Determined. Address: 10F,NO.119, CHIENKANG RD., CHUNG- HO, TAIPEI TAIWAN R.O.C. Contact Person: John Chiou Title: Manager Tel/Fax: Tel: +886-2-2228-7588 Fax: +886-2-3234-9340

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4

LABEL LOCATION FOR FCC ID

Page 4 Page 5 Page 6 Page 7

FCC ID: H8NWLF010 ADT No.920327R01 Operational Description The transmitter of the EUT is powered by host equipment. The antenna used in this product is Micro Dieiectric antenna without connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: H8NWLF010 ADT No.: 920327R01 RF EXPOSURE REPORT REPORT NO.: RF920327R01 MODEL NO.: WLF010 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Askey Computer Corp. ADDRESS: 10F, No.119, ChienKang Rd., Chung-Ho, Taipei, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: H8NWLF010 ADT No.: 920327R01 RF Exposure Measurement (Portable Device) 1. Introduction 2.4GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: H8NWLF010 ADT No.: 920327R01 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: H8NWLF010 ADT No.: 920327R01 5. Test Results 5.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.258 (numeric). 5.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( R ) FROM SKIN (Centi-Meter) 1241218.711.37 6243718.841.37 11246218.971.38 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: H8NWLF010 Report No.: RF920327R01 1 Issued: April 19, 2003 FCC TEST REPORT REPORT NO.: RF920327R01 MODEL NO.: WLF010 RECEIVED: Mar. 27, 2003 TESTED: Apr. 2 ~ Apr. 8, 2003 APPLICANT: ASKEY COMPUTER CORP. ADDRESS: 10F, No. 119, CHIENKANG RD., CHUNG-HO, TAIPEI, TAIWAN, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: H8NWLF010 Report No.: RF920327R01 2 Issued: April 19, 2003 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS.................................................................11 4.1.6TEST RESULTS.......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT................................. 18 4.2.2TEST INSTRUMENTS ................................................................................ 19 4.2.3TEST PROCEDURES................................................................................. 20 4.2.4TEST SETUP .............................................................................................. 21 4.2.5EUT OPERATING CONDITIONS................................................................ 21 4.2.6TEST RESULTS.......................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 27 4.3.2TEST INSTRUMENTS ................................................................................ 27 4.3.3TEST PROCEDURE................................................................................... 28 4.3.4TEST SETUP .............................................................................................. 28 4.3.5EUT OPERATING CONDITIONS................................................................ 28 4.3.6TEST RESULTS.......................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 33 4.4.2TEST INSTRUMENTS ................................................................................ 33 4.4.3TEST PROCEDURES................................................................................. 34 4.4.4TEST SETUP .............................................................................................. 34 4.4.5EUT OPERATING CONDITIONS................................................................ 34 FCC ID: H8NWLF010 Report No.: RF920327R01 3 Issued: April 19, 2003 4.4.6TEST RESULTS.......................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 36 4.5.2TEST INSTRUMENTS ................................................................................ 36 4.5.3TEST PROCEDURE................................................................................... 37 4.5.4TEST SETUP .............................................................................................. 37 4.5.5EUT OPERATING CONDITIONS................................................................ 37 4.5.6TEST RESULTS.......................................................................................... 38 4.6BAND EDGES MEASUREMENT ................................................................ 42 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 42 4.6.2TEST INSTRUMENTS ................................................................................ 42 4.6.3TEST PROCEDURE................................................................................... 42 4.6.4EUT OPERATING CONDITION .................................................................. 42 4.6.5TEST RESULTS.......................................................................................... 43 4.7ANTENNA REQUIREMENT........................................................................ 46 4.7.1STANDARD APPLICABLE ..........................................................…

Text truncated - open the document above for the full version.

FCC ID: H8NWLF010 Report No.: RF920327R01 47 Issued: April 19, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: H8NWLF010 Report No.: RF920327R01 48 Issued: April 19, 2003 RADIATED EMISSION TEST
