H8NWLL070Wireless LAN Mini PCI Card

11Mbps Wireless LAN CardUser’s Manual Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of the seller.The seller provides this documentation without warranty, term, or condition of any kind. The seller may make improvements or ch anges in the product(s) and/or the program(s) described in this documentation at any time.Other product and company names herein may be trademarks of their respective owners. 2003 All rights reserved. Date: April 2003 Part No. A196XPRev02 I ContentsAbout This Manual ............................................................................................................................... ........................ III Chapter 1 Introduction ............................................................................................................................... ................ 1 Wireless LAN Basics ............................................................................................................................... .................... 2 Local Area Network (LAN) ............................................................................................................................... ......................... 2 Ad-Hoc Mode ............................................................................................................................... ............................................. 2 Infrastructure Mode ............................................................................................................................... ................................... 3 Roaming ............................................................................................................................... ..................................................... 4 Chapter 2 Installing the Wireless LAN Card ............................................................................................................ 5 System Requirements ............................................................................................................................... .................. 5 Installing Wireless LAN Card Driver and Software ..................................................................................................... 6 Chapter 3 Wireless LAN Monitor Utility ................................................................................................................. 13 Accessing the Wireless LAN Monitor Utility .............................................................................................................. 13 Note to Windows XP Users ............................................................................................................................... ...................... 14 Status Tab ............................................................................................................................... .................................. 15 Configuration Tab ............................................................................................................................... ....................... 17 Encryption ............................................................................................................................... ................................................ 17 Advanced ............................................................................................................................... .................................................. 20 Profile Tab ............................................................................................................................... .................................. 22 Site Monitor Tab ............................................................................................................................... ......................... 23 About Tab ............................................................................................................................... ................................... 25 Chapter 4 Using Wireless Tray Icon Functions .................................................................................................... 27 Viewing Signal Strength and Speed ......................................................................................................................... 27 Tray Icon Color Indication ............................................................................................................................... .......... 28 Other Functions ............................................................................................................................... .......................... 29 Chapter 5 Windows XP Wireless Zero Configuration Utility ............................................................................... 31 Connecting to an Access Point or Wireless LAN Card ........................................................................................................... 31 Viewing Wireless Connection Status ............................................................................................................................... ........ 33 Configuring Your Wireless Properties ............................................................................................................................... ..... 33 Chapter 6 Uninstalling the Wireless LAN Card ..................................................................................................... 39 11Mbps Wireless LAN Card User's ManualII Uninstalling the Wirele ss LAN Card Software ........................................................................................................... 39 Removing the Wireless LAN Card (For PCMCIA Adapter) ....................................................................................... 41 Chapter 7 Updating the Device Driver and Software .…

Text truncated - open the document above for the full version.

FCC ID: H8NWLL070 ADT No.920218R04 Modular Approval Request Letter Advance Data Technology May 5, 2003 Dear Application Examiner, Askey Computer Corp’s Wireless LAN Mini PCI Card, FCC ID: H8NWLL070, would like to have your authorization as a limited modular approval specific to the mobile device such as notebook, access point and router. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip WL6001012Y. 3. “The modular transmitter must have its own power supply regulation.” The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 2.5V DC powered. The mini-pci interface provides 3.3VDC, so there are regulators in front of these chips, the part number of this regulator is PSC0152. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a PCMCIA to mini-PCI extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: H8NWLL070 ADT No.920218R04 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Dr. Alan Lane J. VP Advance Data Technology

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 May 22, 2003 RE: ASKEY COMPUTER CORP. FCC ID: H8NWLL070 I have a few comments on the above referenced Application. These comments are all made upon the assumption that the EUT's maximum conducted output power is 44.4 mW and the antenna gain is 3.1 dBi. 1) The photographs contained in the file "EXTPHO-3_H8NWLL070" did not show up properly. Please fix this file and send again. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT

Page 3 (Antenna 1: Arima M7N) Page 4 Page 5 (Antenna 2: R0322-034-L) Page 6 Page 7 (Antenna 2: R0322-034-R) Page 8 Page 9 (Antenna 3: Arima W720) Page 10

Page 11 (Antenna 4: CAL-R) Page 12 Page 13 (Antenna 5: 8375P) Page 14 Page 15 (Antenna 6: Arima A520) Page 16 Page 17 (Antenna 7: ArimaA520) Page 18

FCC ID Label Location

FCC ID: H8NWLL070 Report No.: RF920218R04 1 Issued: May 5, 2003 FCC TEST REPORT REPORT NO.: RF920218R04 MODEL NO.: WLL070 RECEIVED: Feb. 18, 2003 TESTED: Feb. 20, 2003 ~ Mar. 30, 2003 APPLICANT:Askey Computer Corp. ADDRESS:10F, No.119, ChienKang Rd., Chung-Ho, Taipei, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 54 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: H8NWLL070 Report No.: RF920218R04 2 Issued: May 5, 2003 Table of Contents 1CERTIFICATION ........................................................................................ 4 2SUMMARY OF TEST RESULTS................................................................ 5 3GENERAL INFORMATION ........................................................................ 6 3.1GENERAL DESCRIPTION OF EUT .......................................................... 6 3.2DESCRIPTION OF TEST MODES ............................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................ 7 3.4DESCRIPTION OF SUPPORT UNITS....................................................... 8 4TEST TYPES AND RESULTS ................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ............................................. 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .......................... 9 4.1.2TEST INSTRUMENTS ............................................................................... 9 4.1.3TEST PROCEDURES.............................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD .................................................... 10 4.1.5TEST SETUP ........................................................................................... 11 4.1.6EUT OPERATING CONDITIONS............................................................. 11 4.1.7TEST RESULTS....................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................ 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ............................. 18 4.2.2TEST INSTRUMENTS ............................................................................. 19 4.2.3TEST PROCEDURES.............................................................................. 20 4.2.4DEVIATION FROM TEST STANDARD .................................................... 20 4.2.5TEST SETUP ........................................................................................... 21 4.2.6EUT OPERATING CONDITIONS............................................................. 21 4.2.7TEST RESULTS....................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT ....................................................... 30 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT..................................... 30 4.3.2TEST INSTRUMENTS ............................................................................. 30 4.3.3TEST PROCEDURE ................................................................................ 31 4.3.4DEVIATION FROM TEST STANDARD .................................................... 31 4.3.5TEST SETUP ........................................................................................... 31 4.3.6EUT OPERATING CONDITIONS............................................................. 31 4.3.7TEST RESULTS....................................................................................... 32 4.4MAXIMUM PEAK OUTPUT POWER ....................................................... 36 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........ 36 4.4.2TEST INSTRUMENTS ............................................................................. 36 4.4.3TEST PROCEDURES.............................................................................. 37 4.4.4DEVIATION FROM TEST STANDARD .................................................... 37 FCC ID: H8NWLL070 Report No.: RF920218R04 3 Issued: May 5, 2003 4.4.5TEST SETUP ........................................................................................... 37 4.4.6EUT OPERATING CONDITIONS............................................................. 37 4.4.7TEST RESULTS....................................................................................... 38 4.5POWER SPECTRAL DENSITY MEASUREMENT .................................. 39 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................ 39 4.5.2TEST INSTRUMENTS ............................................................................. 39 4.5.3TEST PROCEDURE ................................................................................ 40 4.5.4DEVIATION FROM TEST STANDARD .................................................... 40 4.5.5TEST SETUP ........................................................................................... 40 4.5.6EUT OPERATING CONDITIONS............................................................. 40 4.5.7TEST RESULTS....................................................................................... 41 4.6BAND EDGES MEASUREMENT............................................................. 45 4.6.1LIMITS OF BAND EDGES MEASUREMENT .......................................... 45 4.6.2TEST INSTRUMENTS ............................................................................. 45 4.6.3TEST PROCEDURE ................................................................................ 45 4.6.4DEVIATION FROM TEST STANDARD .................................................... …

Text truncated - open the document above for the full version.

FCC ID: H8NWLL070 Report No.: RF920218R04 39 Issued: May 5, 2003 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 24, 2003 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: H8NWLL070 Report No.: RF920218R04 40 Issued: May 5, 2003 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3kHz RBW and 30kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 4.5.4 DEVIATION FROM TEST STANDARD No deviation 4.5.5 TEST SETUP 4.5.6 EUT OPERATING CONDITIONS Same as 4.3.6 EUT SPECTRUM ANALYZER FCC ID: H8NWLL070 Report No.: RF920218R04 41 Issued: May 5, 2003 4.5.7 TEST RESULTS EUT Wireless LAN Mini PCI Card MODEL WLL070 INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 23deg. C, 60%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-10.068PASS 62437-10.218PASS 112462-9.918PASS FCC ID: H8NWLL070 Report No.: RF920218R04 42 Issued: May 5, 2003 CH1 FCC ID: H8NWLL070 Report No.: RF920218R04 43 Issued: May 5, 2003 CH6 FCC ID: H8NWLL070 Report No.: RF920218R04 44 Issued: May 5, 2003 CH11 FCC ID: H8NWLL070 Report No.: RF920218R04 45 Issued: May 5, 2003 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 24, 2003 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 1MHz and 300Hz with suitable frequency span including 100kHz bandwidth from band edge. The band edges was measured and recorded. 4.6.4 DEVIATION FROM TEST STANDARD No deviation FCC ID: H8NWLL070 Report No.: RF920218R04 46 Issued: May 5, 2003 4.6.5 EUT OPERATING CONDITION Same as Item 4.3.6 4.6.6 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following pages shows 61.22dB / 61.38dB delta between carrier maximum power and local maximum emission in restrict band (2.3877GHz / 2.4844GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.8 is 99.2dBuV/m, so the maximum field strength in restrict band is 99.2-61.22=37.98dBuV/m which is under 54dBuV/m limit. FCC ID: H8NWLL070 Report No.: RF920218R04 47 Issued: May 5, 2003 FCC ID: H8NWLL070 Report No.: RF920218R04 48 Issued: May 5, 2003 FCC ID: H8NWLL070 Report No.: RF920218R04 49 Issued: May 5, 2003 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna types used in this product are Inverted F with UFL connector. The maximum Gain of this antenna is 3.1274dBi. FCC ID: H8NWLL070 Report No.: RF920218R04 50 Issued: May 5, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: H8NWLL070 Report No.: RF920218R04 51 Issued: May 5, 2003 FCC ID: H8NWLL070 Report No.: RF920218R04 52 Issued: May 5, 2003 RADIATED EMISSION TEST FCC ID: H8NWLL070 Report No.: RF920218R04 53 Issued: May 5, 2003 FCC ID: H8NWLL070 Report No.: RF920218R04 54 Issued: May 5, 2003 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USAFCC, NVLAP GermanyTUV Rheinland JapanVCCI New ZealandMoC NorwayNEMKO R.O.C.BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: H8NWLL070 Report No.: RF920218R04 50 Issued: May 5, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: H8NWLL070 Report No.: RF920218R04 51 Issued: May 5, 2003 FCC ID: H8NWLL070 Report No.: RF920218R04 52 Issued: May 5, 2003 RADIATED EMISSION TEST FCC ID: H8NWLL070 Report No.: RF920218R04 53 Issued: May 5, 2003
