H8NWLL2202.4GHz/5GHz Mini - PCI Card

802.11a/b Wireless LAN CardUser’s Manual Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, el ectronic or mechanical, for any purpose, without the express written permission of the seller. The seller provides this documentation without warranty, term, or condition of any kind. The seller may make improvements or ch anges in the product(s) and/or the program(s) described in this documentation at any time.Atheros and the Atheros logo are registered trademarks of Atheros Communications, Inc. Cisco, Cisco Systems, and the Cisco Sys tems logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. A ll other trademarks mentioned in this document are the property of their respective owners.  2002 All rights reserved. I ContentsChapter 1 Introduction ............................................................................................................................... .................. 1 Wireless LAN Basics ............................................................................................................................... .................... 2 Local Area Network (LAN) ............................................................................................................................... ........ 2 Wireless Network Topologies ............................................................................................................................... ... 3 Chapter 2 Installing the Driver and Utility Software ................................................................................................. 5 System Requirements ............................................................................................................................... .................. 6 Installing Wireless LAN Driver and Software ............................................................................................................... 6 Chapter 3 Station Configuration ............................................................................................................................... 11 Accessing the Atheros Configuration Utility .............................................................................................................. 11 Note to Windows XP Users ............................................................................................................................... ..... 12 Basic Configuration for Ad Hoc Network ................................................................................................................... 12 Basic Configuration for Infrastructure Network .......................................................................................................... 13 Edit the Security Tab ............................................................................................................................... .................. 14 Edit the Advanced Tab ............................................................................................................................... ............... 15 To Connect to an Existing Network ........................................................................................................................... 17 To Modify a Configuration Profile .............................................................................................................................. 1 7 To Remove a Configuration Profile ........................................................................................................................... 17 To Switch to a Different Profile ............................................................................................................................... ... 17 Chapter 4 Checking Status or Statistics .................................................................................................................. 19 Link Status ............................................................................................................................... .................................. 19 Advanced Link Status ............................................................................................................................... ............. 21 Driver Information ............................................................................................................................... ....................... 22 WLAN Status ............................................................................................................................... .............................. 22 Statistics ............................................................................................................................... ..................................... 23 Tools ............................................................................................................................... ........................................... 24 Chapter 5 Tools ............................................................................................................................... ............................ 27 Changing Display Settings ............................................................................................................................... ......... 27 Select the Country Code ............................................................................................................................... ............ 27 Status Monitor Tray Icon ............................................................................................................................... ............ 28 Chapter 4 Uninstalling the Wireless LAN Card ....................................................................................................... 31 802.11a/b Mini PCI Wireless LAN Card User's ManualII 1 Chapter 1 Introduction This Wireless LAN Card is an IEEE 802.11a/b d…

Text truncated - open the document above for the full version.

FCC ID: H8NWLL220 ADT No.911220R07 Modular Approval Request Letter Advance Data Technology Jan. 07, 2003 Dear Application Examiner, ASKEY COMPUTER CORP.’s 2.4GHz/5GHz Mini – PCI Card, FCC ID: H8NWLL220, would like to have your authorization as a limited modular approval specific to mobile device such as wireless ADSL / wireless Router / wireless cable modem and the notebook with antenna mounted around the LCD panel. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR5211. 3. “The modular transmitter must have its own power supply regulation.” The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 2.5V DC powered. The mini-pci interface provides 3.3VDC, so there are regulators in front of these chips, the part number of this regulator is TK71725SCL. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a PCMCIA to mini-PCI extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: H8NWLL220 ADT No.911220R07 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards,

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 11, 2003 RE: FCC ID: I have a few comments on this Application. 1.) This device is a 2.4GHz/5GHz Mini – PCI Card for general use and installation by OEM integrators in final products. Therefore, this device qualifies under the Modular Approval rules. Please upload Modular Approvals request letter. 2.) It is unclear if this device will be bundled into specific equipment exclusively or not. If only Wireless ADSL/Wireless Router/Wireless Cable Modems are to be used, then a Limited Modular Approval (LMA) would apply 3.) No instructions are given in the Manual for how OEM integrators should make the antenna “integral”. Please revise manual accordingly. William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

For FCC ID Label Location

Page 4 Page 5 Page 6

FCC ID: H8NWLL220 ADT No.911220R07 Technical Description The transmitter of the EUT is powered by host equipment. The antenna is PIFA antenna. The antenna connector is UFL connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This device is a 2.4GHz/5GHz Mini – PCI Card operates in both the 5GHz and 2.4GHz bands, the maximum data rate could be 108Mbps in turbo mode. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states : The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

FCC ID: H8NWLL220 ADT No.: 911220R07 FCC TEST REPORT REPORT NO.: RF911220R07 MODEL NO.: WLL220 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: ASKEY COMPUTER CORP. ADDRESS: 10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI TAIWAN R.O.C ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: H8NWLL220 ADT No.: 911220R07 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) FCC ID: H8NWLL220 ADT No.: 911220R07 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 6. Climate Condition The temperature and related humidity: 20 deg. C and 63 % RH FCC ID: H8NWLL220 ADT No.: 911220R07 7. Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are –0.44dBi or 0.9036(numeric) for 5GHz and 0.39dBi or 1.094(numeric) for 2.4GHz. 7.2 Output Power Into Antenna & RF Exposure Distance : For Part 802.11b: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241241.1141.892 6243745.7081.994 11246242.4021.922 For Part 802.11a: Normal Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1518042.1691.741 4524040.8321.713 5526043.2511.763 8532044.5651.790 9574544.9771.801 12580551.8801.934 Turbo Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1521047.6431.851 2525046.1311.821 3529044.6681.792 4576045.9191.817 5580026.6681.384 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: H8NWLL220 Report No.: RF911220R071Issued: Jan. 05, 2003 FCC TEST REPORT REPORT NO.: RF911220R07 MODEL NO.: WLL220 RECEIVED: Dec. 20, 2002 TESTED: Dec. 25, 2002 ~ Jan. 04, 2003 APPLICANT: ASKEY COMPUTER CORP. ADDRESS: 10F, NO. 119, CHIENKANG RD., CHUNG-HO, TAIPEI TAIWAN R.O.C ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 145 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: H8NWLL220 Report No.: RF911220R072Issued: Jan. 05, 2003 Table of Contents 1.CERTIFICATION........................................................................................................5 2.SUMMARY OF TEST RESULTS...............................................................................6 3.GENERAL INFORMATION........................................................................................8 3.1GENERAL DESCRIPTION OF EUT..........................................................................8 3.2DESCRIPTION OF TEST MODES............................................................................9 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS.........................................10 3.4DESCRIPTION OF SUPPORT UNITS....................................................................11 4.TEST TYPES AND RESULTS (FOR PART 802.11b)..............................................12 4.1CONDUCTED EMISSION MEASUREMENT..........................................................12 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.......................................12 4.1.2TEST INSTRUMENTS.............................................................................................12 4.1.3TEST PROCEDURES..............................................................................................13 4.1.4DEVIATION FROM TEST STANDARD....................................................................13 4.1.5TEST SETUP...........................................................................................................14 4.1.6EUT OPERATING CONDITIONS.............................................................................14 4.1.7TEST RESULTS.......................................................................................................15 4.2RADIATED EMISSION MEASUREMENT...............................................................21 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT............................................21 4.2.2TEST INSTRUMENTS.............................................................................................22 4.2.3TEST PROCEDURES..............................................................................................22 4.2.4DEVIATION FROM TEST STANDARD....................................................................23 4.2.5TEST SETUP...........................................................................................................24 4.2.6EUT OPERATING CONDITIONS.............................................................................24 4.2.7TEST RESULTS.......................................................................................................25 4.36dB BANDWIDTH MEASUREMENT.......................................................................29 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT....................................................29 4.3.2TEST INSTRUMENTS.............................................................................................29 4.3.3TEST PROCEDURE................................................................................................30 4.3.4DEVIATION FROM TEST STANDARD....................................................................30 4.3.5TEST SETUP...........................................................................................................30 4.3.6EUT OPERATING CONDITIONS.............................................................................30 4.3.7TEST RESULTS.......................................................................................................31 4.4MAXIMUM PEAK OUTPUT POWER.......................................................................35 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT......................35 4.4.2INSTRUMENTS........................................................................................................35 4.4.3TEST PROCEDURES..............................................................................................36 4.4.4DEVIATION FROM TEST STANDARD....................................................................36 4.4.5TEST SETUP...........................................................................................................36 4.4.6EUT OPERATING CONDITIONS.............................................................................36 4.4.7TEST RESULTS.......................................................................................................37 4.5POWER SPECTRAL DENSITY MEASUREMENT.................................................38 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT..............................38 4.5.2TEST INSTRUMENTS.............................................................................................38 4.5.3TEST PROCEDURE................................................................................................39 4.5.4DEVIATION FROM TEST STANDARD....................................................................39 4.5.5TEST SETUP...........................................................................................................39 4.5.6EUT OPERATING CONDITION....................................................................…

Text truncated - open the document above for the full version.

FCC ID: H8NWLL220 Report No.: RF911220R0751Issued: Jan. 05, 2003 5.1.5 TEST SETUP For the actual test configuration, please refer to the related item – Photographs of the Test Configuration. 5.1.6 EUT OPERATING CONDITIONS Same as 4.1.6. FCC ID: H8NWLL220 Report No.: RF911220R0752Issued: Jan. 05, 2003 5.1.7 TEST RESULTS MODEL WLL220 EUT 2.4GHz/5GHz Mini - PCI Card 6dB BANDWIDTH9 kHz INPUT POWER (SYSTEM) 120Vac, 60 Hz PHASELine (L) ENVIRONMENTAL CONDITIONS 25deg. C, 60RH, 1005 hPa TESTED BY: Gary Chang Freq. Corr. Factor Reading Value [dB (uV)] Emission Level [dB (uV)] Limit [dB (uV)] Margin (dB) No [MHz](dB)Q.P.AV.Q.P.AV.Q.P.AV.Q.P.AV. 10.1700.1049.88-49.98-64.9854.98-15.00- 20.2280.1043.56-43.66-62.5252.52-18.86- 30.2870.1037.43-37.53-60.6250.62-23.09- 43.7620.3825.78-26.16-56.0046.00-29.84- 513.5000.7424.58-25.32-60.0050.00-34.68- 620.9181.1230.05-31.17-60.0050.00-28.83- NOTE: 1. Q.P. and AV. are abbreviations of quasi-peak and average individually. 2. "-": The Quasi-peak reading value also meets average limit and measurement with the average detector is unnecessary. 3. The emission levels of other frequencies were very low against the limit. 4. Margin value = Emission level - Limit value 5. Correction factor = Insertion loss + Cable loss 6. Emission Level = Correction Factor + Reading Value. FCC ID: H8NWLL220 Report No.: RF911220R0753Issued: Jan. 05, 2003 MODEL WLL220 EUT 2.4GHz/5GHz Mini - PCI Card 6dB BANDWIDTH9 kHz INPUT POWER (SYSTEM) 120Vac, 60 Hz PHASENeutral (N) ENVIRONMENTAL CONDITIONS 25deg. C, 60RH, 1005 hPa TESTED BY: Gary Chang Freq. Corr. Factor Reading Value [dB (uV)] Emission Level [dB (uV)] Limit [dB (uV)] Margin (dB) No [MHz](dB)Q.P.AV.Q.P.AV.Q.P.AV.Q.P.AV. 10.1730.1050.22-50.32-64.7954.79-14.47- 20.2280.1044.48-44.58-62.5252.52-17.94- 30.2870.1038.84-38.94-60.6250.62-21.68- 40.5520.1321.91-22.04-56.0046.00-33.96- 53.7770.2930.85-31.14-56.0046.00-24.86- 620.5940.7930.80-31.59-60.0050.00-28.41- NOTE: 1. Q.P. and AV. are abbreviations of quasi-peak and average individually. 2. "-": The Quasi-peak reading value also meets average limit and measurement with the average detector is unnecessary. 3. The emission levels of other frequencies were very low against the limit. 4. Margin value = Emission level - Limit value 5. Correction factor = Insertion loss + Cable loss 6. Emission Level = Correction Factor + Reading Value. FCC ID: H8NWLL220 Report No.: RF911220R0754Issued: Jan. 05, 2003 5.2 RADIATED EMISSION MEASUREMENT 5.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT Emissions radiated outside of the specified bands, shall be according to the general radiated limits in 15.209 as following: Frequencies (MHz) Field strength (microvolts/meter) Measurement distance (meters) 0.009-0.4902400/F(kHz)300 0.490-1.70524000/F(kHz)30 1.705-30.03030 30-881003 88-2161503 216-9602003 Above 9605003 NOTE: 1. The lower limit shall apply at the transition frequencies. 2. Emission level (dBuV/m) = 20 log Emission level (uV/m). 3. As shown in 15.35(b), for frequencies above 1000MHz, the field strength limits are based on average detector, however, the peak field strength of any emission shall not exceed the maximum permitted average limits, specified above by more than 20dB under any condition of modulation. FCC ID: H8NWLL220 Report No.: RF911220R0755Issued: Jan. 05, 2003 5.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS Frequencies (MHz) EIRP Limit (dBm) Equivalent Field Strength at 3m (dBμV/m) *note 3 5150~5250-2768.3 5250~5350-2768.3 -27 *note 168.3 5725~5825 -17 *note 278.3 NOTE: 1. For frequencies 10MHz or greater above or below the band edge. 2. All emissions within the frequency range from the band edge to 10MHz above or below the band edge. 3. The following formula is used to convert the equipment isotropic radiated power (eirp) to field strength E= 3 301000000P μV/m, where P is the eirp (Watts) FCC ID: H8NWLL220 Report No.: RF911220R0756Issued: Jan. 05, 2003 5.2.3 TEST INSTRUMENTS DESCRIPTION & MANUFACTURER MODEL NO.SERIAL NO. CALIBRATED UNTIL * HP Spectrum Analyzer8590L3544A01176May 13, 2003 * HP Preamplifier8447D2944A08485Apr. 29, 2003 * HP Preamplifier8449B3008A01201Dec. 01, 2003 * HP Preamplifier8449B3008A01292Aug. 07, 2003 * ROHDE & SCHWARZ TEST RECEIVER ESMI 839013/007 839379/002 Jan. 27, 2003 SCHAFFNER Tunable Dipole Antenna SCHWARZBECK Tunable Dipole Antenna VHBA 9123 UHA 9105 459 977 Nov. 22, 2003 * CHASE BILOG AntennaCBL6112A2221Aug. 2, 2003 * SCHWARZBECK Horn Antenna BBHA9120- D1 D130July 3, 2003 * EMCO Horn Antenna31159312-4192April 9, 2003 * EMCO Turn Table10601115NA * SHOSHIN TowerAP-4701A6Y005NA * Software ADT_Radiate d_V5.09 NANA * ANRITSU RF SwitchesMP59BM35046July 11. 2003 * TIMES RF cableLMR-600CABLE-ST5-01July. 11. 2003 NOTE:1. The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. 2. “*” = These equipment are used for the final measurement. 3. The horn antenna and HP preamplifier (model: 8449B) are used only for the measurement of emission frequency above 1GHz if tested. 4. The test was performed in ADT Open Site No. 5. 5. The VCCI Site Registration No. is R-1039. FCC ID: H8NWLL220 Report No.: RF911220R0757Issued: Jan. 05, 2003 5.2.4 TEST PROCEDURES a. The EUT was placed on the top of a rotating table 0.8 meters above the ground at a 10 meter open area test site. The table was rotated 360 degrees to determine the position of the highest radiation. b. The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top of a variable-height antenna tower. c. The antenna is a broadband antenna, and its height is varied from one meter to four meters above the ground to determine the maximum value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the measurement. d. For each suspected emission, the EUT was arranged to its worst case and then the antenna was tuned to heights from 1 meter to 4 meters and the rotatabl…

Text truncated - open the document above for the full version.

FCC ID: H8NWLL220 Report No.: RF911220R0782Issued: Jan. 05, 2003 CHANNEL 5 FCC ID: H8NWLL220 Report No.: RF911220R0783Issued: Jan. 05, 2003 CHANNEL 8 FCC ID: H8NWLL220 Report No.: RF911220R0784Issued: Jan. 05, 2003 CHANNEL9 FCC ID: H8NWLL220 Report No.: RF911220R0785Issued: Jan. 05, 2003 CHANNEL12 FCC ID: H8NWLL220 Report No.: RF911220R0786Issued: Jan. 05, 2003 EUT 2.4GHz/5GHz Mini - PCI Card MODEL WLL220 MODETurbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 20eg. C, 60RH, 1005 hPa TESTED BYSteven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) 26dBc Occupied Bandwidth (MHz) PASS/FAIL 1521016.7817.0071.82PASS 2525016.6424.0065.58PASS 3529016.5024.0070.86PASS 4576016.6230.0051.90PASS 5580014.2630.0046.57PASS NOTE: The 26dBc Occupied Bandwidth plot, please refer to the following pages. FCC ID: H8NWLL220 Report No.: RF911220R0787Issued: Jan. 05, 2003 CHANNEL 1 FCC ID: H8NWLL220 Report No.: RF911220R0788Issued: Jan. 05, 2003 CHANNEL 2 FCC ID: H8NWLL220 Report No.: RF911220R0789Issued: Jan. 05, 2003 CHANNEL 3 FCC ID: H8NWLL220 Report No.: RF911220R0790Issued: Jan. 05, 2003 CHANNEL 4 FCC ID: H8NWLL220 Report No.: RF911220R0791Issued: Jan. 05, 2003 CHANNEL 5 FCC ID: H8NWLL220 Report No.: RF911220R0792Issued: Jan. 05, 2003 CHANNEL 1 FCC ID: H8NWLL220 Report No.: RF911220R0793Issued: Jan. 05, 2003 CHANNEL 2 FCC ID: H8NWLL220 Report No.: RF911220R0794Issued: Jan. 05, 2003 CHANNEL 3 FCC ID: H8NWLL220 Report No.: RF911220R0795Issued: Jan. 05, 2003 CHANNEL 4 FCC ID: H8NWLL220 Report No.: RF911220R0796Issued: Jan. 05, 2003 CHANNEL 5 FCC ID: H8NWLL220 Report No.: RF911220R0797Issued: Jan. 05, 2003 5.4 PEAK POWER EXCURSION MEASUREMENT 5.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT Frequency BandLimit 5.15 – 5.25 GHz13dB 5.25 – 5.35 GHz13dB 5.725 – 5.825 GHz13dB 5.4.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE&SCHWARZ SPECTRUM ANALYZER FSEK30100049July 24, 2003 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: H8NWLL220 Report No.: RF911220R0…
