H9M4079FLPCI Parallel Serial Card

4079FL Low Profile PCI 32 bit P&P 2S (16C650 32FIFO) 1P (ECP/EPP 32FIFO) Version 1.1 u Description: 2 The 4079FL 32Bit PCI bus Plug & Play 2S/1P I/O card is equipped with two High-Speed RS-232.V24 Standard Serial-Interface, The serial port include 32 Byte FIFO, The speed Up to 921Kb/Sec. one ECP/EPP/SPP/BPP IEEE 1284c CENTRONICS Parallel Interface. The 4079AL includes two 9 pin male connector for attaching peripheral's unit with Serial RS-232 Standard Interface and one 25 pin female connector for peripherals' unit’s with IEEE 1284C CENTRONICS Parallel Interface. u Check your packing listing: 44Pin-2(9Pin male)&1(25Pin female) cable one set u Hardware Specification u Hardware Jumper and Connect u Hardware installation guide: ÿ ÿ ÿ... ÿ ... ÿ ’ 4 u PIN ASSIGNMENTS: Parallel 25 Pin female connector (P1): Pin Signal Pin Signal Pin Signal 1 STROBE 10 ACKNOWLEDGE 19 GROUND 2 DATA 0 11 BUSY 20 GROUND 3 DATA 1 12 PAPER EMPTY 21 GROUND 4 DATA 2 13 SELECT 22 GROUND 5 DATA 3 14 AUTO FEED 23 GROUND 6 DATA 4 15 ERROR 24 GROUND 7 DATA 5 16 INIT 25 GROUND 8 DATA 6 17 SELECT INPUT 26 GROUND 9 DATA 7 18 GROUND Serial 9 Pin male connector (S1 and S2): Pin Signal Pin Signal Pin Signal Pin Signal 1 CD 4 DTR 6 DSR 8 CTS 2 RD 5 GROUND 7 RTS 9 RI 3 TD u TECHNICAL SPECIFICATION: Compatibility: -PCI 32Bit card for 486/586/Pentium/Pentium-II/ P-III/C5/K6 Operating system: -WIN31/95/98/98SE/ME/NT/2000/XP, and LINUX,DOS Chips: -1 x SUN1889, 1 x SUN1689 Connections: connector serial -2 x 9 Pin D-SUB male parallel -1 x 25 Pin D-SUB female connector PCB: - 2 Layer / 120 x 64 mm 5 FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment

5 5 4 4 3 3 2 2 1 1 DD CC BB AA REV Engineer STATUS InitialAMOS.LIU DATE ENGINEERING HISTORY 1.0 1889 1689 EEPRON(24LC01) Cardbus Reset Reset Circuit PCI BUS slot re-schematic2.0JUSTIN.HUANG 04/02/04 CRYSTAL 14.7456MHz I/OPort1 P1284 SERIA L PORT I/OPort I/OPort SERI AL POR T BlockDiagram2.0 4079FL B 15Friday, March 05, 2004 Title SizeDocument NumberRev Date:Sheet of

Compliance Certification Services Inc. Report No: C31217403 Date of Issue: March 9, 2004 Page PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: C31217403 Date of Issue: March 9, 2004 Page

FCC ID LABEL FORMAT AND LOCATION Applicant: SUNIX CO., LTD. FCC ID: H9M4079FL FCC ID: H9M4079FL This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No: C31217403 Date of Issue: March 9, 2004 Page PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: C31217403 Date of Issue: March 9, 2004 Page

Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page 1 FCC 47 CFR PART 15 SUBPART B TEST REPORT For PCI Parallel Serial Card FCC ID Number: H9M4079FL Model: 4079FL Trade Name: N/A Issued for SUNIX CO., LTD. 10FL., No. 205-3 Sec. 3, Pei Sin Road, Sindien City, Taipei County, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION..........................................................................................3 2 EUT DESCRIPTION..................................................................................................................4 3 TEST METHODOLOGY...........................................................................................................5 3.1 EUT SYSTEM OPERATION.............................................................................................5 3.2 DECISION OF FINAL TEST MODE...............................................................................5 4 SETUP OF EQUIPMENT UNDER TEST................................................................................5 5 FACILITIES AND ACCREDITATIONS.................................................................................6 5.1 FACILITIES.........................................................................................................................6 5.2 LABORATORY ACCREDITATIONS AND LISTINGS.................................................6 6 INSTRUMENT AND CALIBRATION.....................................................................................7 6.1 MEASURING INSTRUMENT CALIBRATION.............................................................7 6.2 TEST AND MEASUREMENT EQUIPMENT.................................................................7 7 LINE CONDUCTED & RADIATED EMISSION TEST........................................................8 7.1 LIMIT ...............................................................................................................................8 7.2 TEST PROCEDURE OF LINE CONDUCTED EMISSION..........................................9 7.3 TEST PROCEDURE OF RADIATED EMISSION........................................................11 7.4 TEST RESULTS................................................................................................................13 APPENDIX I - PHOTOGRAPHS OF TEST SETUP..................................................................15 APPENDIX II - TEST RESULT OF FINAL DATAS.................................................................17 Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page 1 TEST RESULT CERTIFICATION Applicant: SUNIX CO., LTD. 10FL., No. 205-3 Sec. 3, Pei Sin Road, Sindien City, Taipei County, Taiwan, R. O. C. Manufacturer: SUNIX CO., LTD. 10FL., No. 205-3 Sec. 3, Pei Sin Road, Sindien City, Taipei County, Taiwan, R. O. C. Equipment Under Test: PCI Parallel Serial Card Trade Name: N/A Model: 4079FL Deviation: None Detailed EUT Description: See Item 2 of this report FCC ID: H9M4079FL Date of Test: December 18, 2003 & December 23, 2003 Applicable Standard Class / Limit Test Result FCC Part 15 Subpart B Class B No non-compliance noted Deviation from Applicable Standard None The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart B and the measurement procedures were according to ANSI C63.4. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. Approved by: Reviewed by: David Wang Vince Chiang Manager of Hsintien Laboratory Section Manager of Hsintien Laboratory Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page 2 EUT DESCRIPTION Product PCI Parallel Serial Card Trade Name N/A Model 4079FL Housing Type N/A EUT Power Rating DC 5V from Host PC AC Power During Test 120VAC / 60 Hz Power Supply Manufacturer MSI Power Supply Model Number N/A AC Power Cord Type Unshielded, 1.8m (Detachable) EUT I/O Cable Type Shielded, 0.25m (Detachable) OSC/Clock Frequency 14.7456MHz I/O PORT OF EUT I/O PORT TYPE Q’TY TESTED WITH 1) PIO Port 1 1 DB44 Pin 2) SIO Port 2 2 Note: Client consigns only one model sample (Model Number is 4079FL) to test. Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page 3 TEST METHODOLOGY 3.1 EUT SYSTEM OPERATION 1. Windows XP Boots System. 2. Run Emctest.exe to activate all peripherals and display “H” pattern on monitor screen. 3. Run Winemc.exe then select “com7” & “com8” for testing. 3.2 DECISION OF FINAL TEST MODE 1. The following test mode(s) were scanned during the preliminary test: Mode 1 Normal Mode 2. After the preliminary scan, the following test mode was found to produce the highest emission level. Mode 1 Then, the EUT configuration and cable configuration of the above highest emission mode was recorded for all final test items. 4 SETUP OF EQUIPMENT UNDER TEST Setup Diagram See test photographs attached in Appendix I for the actual connections between EUT and support equipment. Support Equipment No Equipment Model Serial No. FCC ID Trade Name Data Cable Power Cord 1. PS/2 Mouse M-S34 LNA11806870 DZL211029 BSMI ID: 4862A011 LOGITECH Shielded, 1.8m N/A 2. PS/2 Ke…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page APPENDIX I - PHOTOGRAPHS OF TEST SETUP LINE CONDUCTED EMISSION TEST Compliance Certification Services Inc. Report No: C31217403-D1 Date of Issue: March 11, 2004 Page RADIATED EMISSION TEST
