HBOESI-P410Portable Bluetooth wireless speaker

Instruction Manual and Warranty Information ESI-P410 stream portable Bluetooth ® wireless speaker THE SHARPER IMAGE ® name and logo are registered trademarks. Marketed and distributed by SI Products under license. ©The Sharper Image. All rights reserved. IB-ESIP410 ONE YEAR LIMITED WARRANTY SI PRODUCTS sells its products with the intent that they are free of defects in manufacture and workmanship for a period of one year from the date of original purchase, except as noted below. SI PRODUCTS warrants that its products will be free of defects in material and workmanship under normal use and service. This warranty extends only to consumers and does not extend to Retailers. To obtain warranty service on your Sharper Image product, contact a consumer relations representative by telephone at 1-888-856-6781 for assistance. Please make sure to have the model number of the product available. SI PRODUCTS does not authorize anyone, including, but not limited to, Retailers, the subsequent consumer purchaser of the product from a Retailer or remote purchasers, to obligate SI PRODUCTS in any way beyond the terms set forth herein. This warranty does not cover damage caused by misuse or abuse; accident; the attachment of any unauthorized accessory; alteration to the product; improper installation; unauthorized repairs or modifications; improper use of electrical/power supply; loss of power; dropped product; malfunction or damage of an operating part from failure to provide manufacturer’s recommended maintenance; transportation damage; theft; neglect; vandalism; or environmental conditions; loss of use during the period the product is at a repair facility or otherwise awaiting parts or repair; or any other conditions whatsoever that are beyond the control of SI PRODUCTS. This warranty is effective only if the product is purchased and operated in the country in which the product is purchased. A product that requires modifications or adoption to enable it to operate in any other country than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications is not covered under this warranty. THE WARRANTY PROVIDED HEREIN SHALL BE THE SOLE AND EXCLUSIVE WARRANTY. THERE SHALL BE NO OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS OR ANY OTHER OBLIGATION ON THE PART OF THE COMPANY WITH RESPECT TO PRODUCTS COVERED BY THIS WARRANTY. SI PRODUCTS SHALL HAVE NO LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. IN NO EVENT SHALL THIS WARRANTY REQUIRE MORE THAN THE REPAIR OR REPLACEMENT OF ANY PART OR PARTS WHICH ARE FOUND TO BE DEFECTIVE WITHIN THE EFFECTIVE PERIOD OF THE WARRANTY. NO REFUNDS WILL BE GIVEN. IF REPLACEMENT PARTS FOR DEFECTIVE MATERIALS ARE NOT AVAILABLE, SI PRODUCTS RESERVES THE RIGHT TO MAKE PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR OR REPLACEMENT. This warranty does not extend to the purchase of opened, used, repaired, repackaged and/or resealed products, including but not limited to sale of such products on Internet auction sites and/or sales of such products by surplus or bulk resellers. Any and all warranties or guarantees shall immediately cease and terminate as to any products or parts thereof which are repaired, replaced, altered, or modified, without the prior express and written consent of SI PRODUCTS. This warranty provides you with specific legal rights. You may have additional rights which may vary from state to state. Because of individual regulations, some of the above limitations and exclusions may not apply to you. For more information regarding our product line in the USA, please visit: www.siproducts.com SI Products Service Center 1.888.856.6781 8:30a.m. – 7:00p.m. (EST) M – F e-mail: [email protected] P l e a s e T a k e A M o m e n t N o w Register Your Product At: www.siproducts.com/register Your valuable input regarding this product will help us create the products you will want in the future. 23 Thank you for purchasing Sharper Image Stream Portable Bluetooth ® Wireless Speaker for smartphones, tablets, notebook computers and other Bluetooth enabled devices. This product, along with the entire Sharper Image Electronics lineup, combines high-tech innovation with design to provide you with years of dependability and enjoyment. Getting Started Unpack the unit carefully. Remove all the accessories from the display carton. Do not remove any labels or stickers on the rear of the unit and adaptor. Before setting up the unit, verify that the following accessories are present: • Instruction manual x 1 • AC power adapter x 1 • Main unit x 1 • 3.5mm audio cable x 1 Power Source This unit is supplied with an AC adapter; take the following steps to connect the adapter. 1. Connect the DC plug of the AC adapter to the DC socket on the rear of the unit. 2. Plug the AC adapter to the AC outlet (100v – 240VAC 50/60 Hz). Connecting this system to any other power source may cause damage to the system. 3. To switch the unit off completely, withdraw the AC adapter from the wall outlet and remove batteries from product. Battery Operation • Before installing batteries (not included), ensure that the unit is disconnected from the main power supply. • Remove the battery compartment cover on the back of the unit by carefully pushing off the battery cover. • Insert 4 AA size batteries(not included), referring to the polarity markings inside the battery compartment. Never mix old and new batteries. • Replace the cover. • For battery operation, switch off the main supply and remove the cable from the power socket, battery operation will be selected automatically. Controls 34251 3 12 Speaker Phone Button Bluetooth Button Play/Pause Button Volume Controls Power Button DC IN AUX IN Battery Compartment 3 3 4 5 2 2 1 1 Battery Precautions • Use only the size and type of batteries specified. • When installing batteries, observe proper +/- polarities. Incorrect installation of batt…

Text truncated - open the document above for the full version.

Confidentiality Request Letter Confidentiality Request Letter Confidentiality Request Letter SHENZHEN FENDA TECHNOLOGY CO., LTD. (2012-5-15) To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: HBOESI-P410 We hereby request confidential treatment of information accompanying this application as outlined below: - Block diagram - Operation description - Schematic The applicant understands that pursuant to Section 0.457 and 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Signature Frank.chenzhonghua/Engineer E-mail: Frank.chenzhonghua @fenda.com Phone: +86-0755-27486668 Fax: +86-0755-27486663 Address Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, China

A0 LIHONG 2012-05-09 GM12204 ESI-P410ESI-P410 MODEL:ESI-P410 Made in China 2A 5.9V 3mm 24.5mm 51.3mm 46.3mm 16.9mm FCC ID: HBOESI-P410

BT Module Antenna

FCC ID : HBOESI-P410 BT (Speaker device) According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2402 2480 2441 25 Maximum measured transmitter power: Conducted Power (dB) Max Antenna Gain (dBi) EIRP (mw) -0.30 0 0.93 Threshold at which no SAR required is 25 mW. Maximum Tx power is 0.93mw EIRP Conclusion: No SAR is required. Sincerely, Signature Frank.chenzhonghua/Engineer E-mail: : Frank.chenzhonghua @fenda.com Phone: +86-0755-27486668 Fax: +86-0755-27486663 Address : Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, China

SHENZHEN EMTEK CO., LTD. REPORT NO: ES120426109F FCC ID: HBOESI-P410 DATE: 05/05/2012 Page 1 of 51 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPARTC REQUIREMENT OF Stream MODEL No.: ESI-P410 BRAND NAME: N/A FCC ID: HBOESI-P410 REPORT NO: ES120426109F ISSUE DATE: May 05, 2012 Prepared for SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, China Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL : 86-755-26954280 FAX: 86-755-26954282 SHENZHEN EMTEK CO., LTD. REPORT NO: ES120426109F FCC ID: HBOESI-P410 DATE: 05/05/2012 Page 2 of 51 VERIFICATION OF COMPLIANCE Applicant: SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, China Manufacturer: SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City , China Product Description: Stream Model Number: ESI‐P410 Serial Number: N/A File Number: ES120426109F Date of Test: April 1, 2012 to May 3, 2012 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : April 1, 2012 to May 3, 2012 Prepared by : (Engineer, Moira) Reviewer : (Quality Manager, June) Approve & Authorized Signer : (Manager, Violet) SHENZHEN EMTEK CO., LTD. REPORT NO: ES120426109F FCC ID: HBOESI-P410 DATE: 05/05/2012 Page 3 of 51 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 11 2.6 EQUIPMENT USED IN TESTED SYSTEM....................................................................................................... 11 2.7 DESCRIPTION OF TEST MODES.................................................................................................................... 12 3. SUMMARY OF TEST RESULTS ....................................................................................... 13 4. CONDUCTED EMISSIONS TEST ..................................................................................... 14 4.1 MEASUREMENT PROCEDURE:................................................................................................................ 14 4.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 14 4.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 14 4.4 CONDUCTED EMISSION LIMIT.................................................................................................................... 14 4.5 MEASUREMENT RESULT:....................................................................................................................... 15 4.6 CONDUCTED MEASUREMENT PHOTOS: ...................................................................................................... 16 5. RADIATED EMISSION TEST ............................................................................................ 17 5.1 MEASUREMENT PROCEDURE................................................................................................................. 17 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 18 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 19 5.4 MEASUREMENT RESULT........................................................................................................................ 20 5.5 RADIATED MEASUREMENT PHOTOS: .........................................................................................................…

Text truncated - open the document above for the full version.

Conducted Measurement Photos: Radiated Measurement Photos:
