HBOIMW885Portable Bluetooth Speaker

Item # IMW855 Owner’s Manual Introduction Thank you for purchasing the Altec Lansing IMW855 XLSOUNDBLADE Portable Bluetooth Speaker. You can use this speaker to listen to audio wirelessly from devices such as smart phones, computers, iPods, tablets and most other Bluetooth sound sources. Please read this manual carefully FIRST in order to get the most out of your speaker. Important Safety Precautions When using your speaker basic safety precautions should always be followed, including the following: 1. READ ALL INSTRUCTIONS BEFORE USING YOUR SPEAKER. 2. Never expose your speaker to high temperatures or undue moisture or humidity. 3. In order to avoid the risk of electric shock, never attempt to open your speaker or repair it without the assistance of certified professionals. 4. If your speaker is exposed to water, please power it off immediately. 5. If you do not intend on using your speaker for an extended period of time, please unplug the AC power adapter from the power outlet and also disconnect it from your speaker. Features -Seamlessly stream music from your iPad, iPhone, Android device, laptop, tablet or other Bluetooth enabled device. -Class-D digital amplifier offers high energy efficiency and superior sound. -Supports Bluetooth protocol V 2.1+EDR and A2DP1.2 audio streaming profile. -AUX IN port allows you to connect additional audio sources using the included 3.5mm Auxiliary Cable. -Charge Smartphones or tablets by connecting them to the built in 5V USB port. Package Contents 1. IMW855 XLSOUNDBLADE Portable Bluetooth Speaker 2. AC Adapter 3. 3.5mm Auxiliary Cable 4. Owner’s Manual with Warranty Information Technical Specifications Speaker Units: 2”*2 Input: 100V-240V~50/60Hz Output: 9V 2A Dimensions: W 338 × D 80 × H 103mm A Quick Look at Your Device Charging Your Speaker 1. Connect one end of the included AC adapter to the DC IN jack on your speaker. Then plug the other end of the AC adapter into a suitable power outlet. The red POWER light on your speaker will flash slowly to indicate the internal battery is being charged. You can also use your speaker to steam music while it is charging. NOTE: The internal battery of your speaker takes approximately four hours to charge when completely drained. It can last up to seven hours before needing to be recharged. Understanding the LED Status Indicators Bluetooth PAIR Indicator Light Blinking Blue LED = Bluetooth not connected. (Ready to pair.) Solid Blue LED = Bluetooth connected. POWER Indicator Light Solid Red LED (speaker connected to AC adapter) =Battery Fully Charged Red LED Blinking Slowly (speaker connected to AC adapter) = Battery Charging Solid Red LED (speaker not connected to AC adapter)=Battery Ready for Use Red LED Blinking Rapidly (speaker not connected to AC adapter) = Battery Power Low Powering Your Speakers ON & OFF 1. Press and hold the “POWER” button for 2 seconds to turn on the unit. The POWER Indicator Light will illuminate. The Bluetooth PAIR Indicator Light will start blinking slowly. Now you can pair your audio source with your IMW855 speaker. 2. Press and hold the “POWER” button for 2 seconds to turn off the unit. Adjusting Volume When listening to audio, press the VOLUME UP or VOLUME DOWN buttons to increase or decrease the volume of your speaker. Press and hold either the VOLUME UP or VOLUME DOWN button to more rapidly increase or decrease the volume. Note that you can also control the volume using your audio source. In addition, note that some audio sources have separate Bluetooth volume control. Setting Up Your IMW855 Bluetooth Music Receiver Bluetooth Device Compatibility Your speaker connects with all Bluetooth devices that support the A2DP profile including iPads, iPhones, iPod touches, and most smart phones, laptops and tablets. Pairing a Bluetooth Device with Your Speaker Press and hold the “POWER” button for two seconds to turn on the unit. The Bluetooth LED light will start blinking slowly. Now you are ready to pair your device with your iMW855 speaker. A) If your audio source supports Near Field Communication (NFC), make sure that the NFC feature is activated. Touch the NFC area on your audio source with the NFC area located on the top of your speaker in order to automatically pair your speaker with your audio device. To unpair your speaker and audio source, you can again touch the NFC area on your audio source with the NFC area located on the top of your speaker. NOTE: If your phone has NFC support but is running an OS below Android 4.1, you will need to download an NFC Bluetooth APP from Google Play or a similar online store. B) If your Bluetooth audio source does not support Near Field Communication (NFC), follow the steps below. 1. Press the Bluetooth button on your speaker. The blue LED light will start blinking rapidly to indicate it is ready to pair to a suitable audio source. 1. Go to the Bluetooth Manager of your Bluetooth device. 2. Search Bluetooth devices and select “iMW855” to start connecting. 3. Enter “0000” if your device asks for the PIN code. 4. Once paired, the unit will beep and the Blue LED light will turn on steadily. Out of Range or Lost Signal If the music device is out of range (beyond 30 feet) of your speaker or if there is something blocking the Bluetooth signal, the LED light will flash slowly to indicate that the Bluetooth connection with the music device has been lost. To avoid a lost connection: 1. Move the music device back into range (within 30 feet), and/or make sure there’s a clear line of sight between the unit and the Bluetooth device. 2. If the connection is lost, the connection will need to be reestablished. FAQ: Frequently Asked Questions 1. I am having Bluetooth pairing or connection problems, what do I do? A.) Make sure your Bluetooth device is turned on and is on the discoverable mode.(blinking blue light denotes that the speaker is ready to accept connections) B.) Make sure your speaker is not already connected with another device (easiest way to determ…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 SHENZHEN FENDA TECHNOLOGY CO., LTD. 2013-7-22 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN FENDA TECHNOLOGY CO., LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID: HBOIMW885 (Portable Bluetooth Speaker Model No.: IMW885) We affirm that between SIEMIC and SHENZHEN FENDA TECHNOLOGY CO., LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Frank Chenzhonghua/Engineer E-mail: [email protected] Phone: +86-0755-27486668 Fax: +86-0755-27486663 Address: Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China

Confidentiality Request Letter SHENZHEN FENDA TECHNOLOGY CO., LTD. 2013-7-22 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality Request for FCC ID: HBOIMW885 We hereby request confidential treatment of information accompanying this application as outlined below: - Block diagram - Operation description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Frank Chenzhonghua/Engineer E-mail: [email protected] Phone: +86-0755-27486668 Fax: +86-0755-27486663 Address: Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China

W260 20130710 见上面 规格贴纸 W260 GM13187 哑特兰斯 MID#2450713 不变 每单不同，按实际日期填写 月 年 63X22MM 亮银龙 黑底 PMS 877 C银字 位 置 要 求贴于机体指定位置 光面处理 用酒精测试不掉色 MODEL: IMW855 FCC ID: HBOIMW855 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MID#2450713 MODEL: IMW855 FCC ID: HBOIMW855 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MID#2450713 335.5 W260A 20130710 见上面 丝印 W260A GM13187 黑色和白色外壳 丝印：PMS 431C 哑特兰斯 30mm 丝印：431C 9V 2000mA AUX IN 5V 1A USB CHARGING

Bluetooth module Antenna

FCC ID: HBOIMW885 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: Transmit Frequency (GHz) Mode Max Conducted Power (dBm) Result calculation 1-g SAR 2.441 Bluetooth 3.91 0.769 3.0 Conclusion: For the max result : 0.769≤ 3.0 for 1-g SAR extremity SAR, No SAR is required.

TRF No：FCC 15.247/A Page 1 of 52 Report No: ES130711079E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPARTC REQUIREMENT OF Portable Bluetooth Speaker MODEL No.: IMW885 FCC ID: HBOIMW885 Trademark: ALTEC LANSING REPORT NO: ES130711079E ISSUE DATE: July 19, 2013 Prepared for SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL : 86-755-26954280 FAX: 86-755-26954282 TRF No：FCC 15.247/A Page 2 of 52 Report No: ES130711079E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World VERIFICATION OF COMPLIANCE Applicant: SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China Manufacturer: SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China. Product Description: Portable Bluetooth Speaker Model Number: IMW885 Trade Mark: ALTEC LANSING Serial Number: N/A File Number: ES130711079E Date of Test: July 15, 2013 to July 17, 2013 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : July 15, 2013 to July 17, 2013 Prepared by : Jack.Li/Editor Reviewer : June xie/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No：FCC 15.247/A Page 3 of 52 Report No: ES130711079E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World Ta b l e o f C o n t e n t s 1 GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2 SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 11 2.6 EQUIPMENT USED IN TESTED SYSTEM................................................................................................... 11 2.7 DESCRIPTION OF TEST MODES................................................................................................................ 12 3 SUMMARY OF TEST RESULTS ............................................................................................... 13 4 CONDUCTED EMISSIONS TEST ..................................................................................... 14 4.1 MEASUREMENT PROCEDURE:................................................................................................................ 14 4.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 14 4.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 14 4.4 CONDUCTED EMISSION LIMIT.................................................................................................................. 14 4.5 MEASUREMENT RESULT:....................................................................................................................... 15 5 RADIATED EMISSION TEST ............................................................................................ 16 5.1 MEASUREMENT PROCEDURE................................................................................................................. 16 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 17 5.3 MEASUREMENT EQUIPMENT USED:…
