HBOSPEAKOUTWIRELESS SPEAKER

917703_917725 INS Speak OutSize:80mmWx80mmH_Output:100%_Prints:1/1,Blk SPEAK OUT ™ XXXXXXXX NEED FINAL NAME AND PHOTO FROM PACKAGE CAUTION • TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. THERE ARE NO SERVICEABLE PARTS INSIDE. • TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. The lightning flash with arrow-head symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the unit’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the unit. IMPORTANT SAFETY INSTRUCTIONS All of the safety and operating instructions should be read, adhered to and followed before the unit is operated. 1 917703_917725 INS Speak OutSize:80mmWx80mmH_Output:100%_Prints:1/1,Blk TABLE OF CONTENTS Warnings and Cautions ........................................1 FCC Information.............................................5 Location of Parts and Controls ...............................7 Setting Up the Speaker ......................................8 Using the Nigh Light.........................................8 Pairing Your Device..........................................9 Listening to Audio ..........................................11 Using Pair2 for Stereo or Left/Right Sound..................12 Care and Maintenance......................................15 Specifications ..............................................17 Troubleshooting.............................................18 Warranty ...................................................20 SAFETY AND HANDLING INFORMATION For maximum product life, do not drop, throw, or crush the speaker. Do not expose it to humidity, dust, or operating temperatures outside 25°F to 120°F (-4°C to 49°C). SAVE THESE INSTRUCTIONS DANGER To reduce the risk of electric shock, burns, fire or injury: 1. Do not use while bathing or in a shower. 2. Do not place or store unit where it can fall or be pulled into a tub or sink. 3. Do not place in, drop or submerge in water or other liquid. 4. Do not reach for a unit that has fallen into water. Unplug it immediately. 5. Care should be taken so that objects do not fall and liquids are not spilled onto the unit. WARNING 1. Close supervision is necessary when this appliance/ product is used by or near children or mentally disabled individuals. 2. Use this unit only for its intended use as described in this manual. 3. Unplug this unit during lightning storms or when unused for long periods of time. 4. Never drop or insert an object into any opening. 5. Protect the power cord from being walked on or pinched, particularly at plug outlets, convenience receptacles and the point where it exits the unit. 6. Do not allow cord to touch hot surfaces. Wrap cord loosely around the unit when storing. 7. The unit should be situated away from direct sunlight or heat sources such as radiators, electric heaters, heat registers, stoves, or other units (including amplifiers) that produce heat. Avoid placing on top of stereo equipment that radiates heat. 23 917703_917725 INS Speak OutSize:80mmWx80mmH_Output:100%_Prints:1/1,Blk 8. Never block the air openings of the unit with materials such as clothing, plastic bags or papers, or place it on a soft surface such as a bed or couch, where the air openings may be blocked. 9. Do not overload the electrical outlet. Use only the power source as indicated. 10. Do not carry this unit by its cord or use the cord as a handle. 11. Never operate this unit if it has a damaged cord or plug, if it is not working properly, or if it has been dropped or damaged, or dropped into water. If the unit’s power supply cord or plug is damaged, do not attempt to fix it yourself. 12. To avoid the risk of electric shock, do not disassemble or attempt to repair the unit. Incorrect repair can cause risk of electric shock or injury to persons when the unit is used. 13. Do not operate in the presence of explosive and/or flammable fumes. 14. Never remove the plug from the outlet by pulling the power cord. FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the distance between the equipment and receiver. 45 917703_917725 INS Speak OutSize:80mmWx80mmH_Output:100%_Prints:1/1,Blk • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This equipment may not cause harmful interference. 2. This equipment must accept any interference received, including interference that may cause undesired operation. Modifications not authorized by the manufacturer may void the user’s authority to operate this device. FCC ID: HBOSPEAKOUT 67 917703_917725 INS Speak OutSize:80mmWx80mmH_Output:100%_Prints:1/1,Blk LOCATION OF PARTS AND CONTROLS 1. Power/Pairing Button 2. Pair2™ Button 3. Night Light Button 4. Volum…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 SHENZHEN FENDA TECHNOLOGY CO., LTD. 2015-08-27 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ SHENZHEN FENDA TECHNOLOGY CO., LTD.__ _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： WIRELESS SPEAKER Trade Name： Brookstone Model Name： Speak Out Serial Model： N/A FCC ID： HBOSPEAKOUT Sincerely, Signature Client’s name / title : frank Chenzhonghua / Engineer Contact information / address : Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City,Guangdong,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 SHENZHEN FENDA TECHNOLOGY CO., LTD. 2015-08-27 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: HBOSPEAKOUT We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Client’s name / title : frank Chenzhonghua / Engineer Contact information / address : Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City,Guangdong,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5

FCC ID Label FCC ID Label Location

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 ANT Photo 5 Photo 6

FCC ID: HBOSPEAKOUT FCC §15.247 (i), §2.1091 – RF Exposure FCC ID:HBOSPEAKOUT Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS FCC ID: HBOSPEAKOUT BT: 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) LIMIT (dBm) CH00 2402 0.42 30 CH39 2441 0.43 30 CH78 2480 0.67 30 2Mbps CH00 2402 -0.20 20.96 CH39 2441 -0.25 20.96 CH78 2480 -0.23 20.96 3Mbps CH00 2402 -0.27 20.96 CH39 2441 -0.44 20.96 CH78 2480 -0.43 20.96 Mode Range Maximum peak output power (dBm) Output power (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result BT -1~1 1 1.26 1(1.26) 0.0003 1 Pass

FCC RADIO TEST REPORT-BT FCC ID: HBOSPEAKOUT Product： WIRELESS SPEAKER Trade Name： Brookstone Model Name： Speak Out Serial Model： N/A Report No.： NTEK-2015NT0507815F Prepared for SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City,Guangdong,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 69 Report No.:NTEK-2015NT0507815F TEST RESULT CERTIFICATION Applicant’s name ................. : SHENZHEN FENDA TECHNOLOGY CO., LTD. Address ................................. : Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City,Guangdong,China Manufacture's Name ............ : SHENZHEN FENDA TECHNOLOGY CO., LTD. Address ................................. : Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City,Guangdong,China Product description Product name ........................... : WIRELESS SPEAKER Model and/or type reference : Speak Out Serial Model： N/A Standards ............................. : FCC Part15.247: 01 Oct. 2014 Test procedure .............................. ANSI C63.10-2013 and Public Notice-DA 00-705 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 07 May 2015~15 May 2015 Date of Issue ........................................... : 15 May 2015 Test Result ............................................... : Pass Testing Engineer : (Denny Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 69 Report No.:NTEK-2015NT0507815F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 19 3.2.1 RADIATED EMISSION LIMITS 19 3.2.2 TEST PROCEDURE 20 3.2.3 DEVIATION FROM TEST STANDARD 20 3.2.4 TEST SETUP 21 3.2.5 EUT OPERATING CONDITIONS 22 3.2.6 TEST RESULTS (BELOW 30 MHZ) 23 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 24 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 4 . NUMBER OF HOPPING CHANNEL 27 4.1 APPLIED PROCEDURES / LIMIT 27 4.1.1 TEST PROCEDURE 27 4.1.2 DEVIATION FROM STANDARD 27 4.1.3 TEST SETUP 27 4.1.4 EUT OPERATION CONDITIONS 27 4.1.5 TEST RESULTS 28 5 . AVERAGE TIME OF OCCUPANCY 29 5.1 APPLIED PROCEDURES / LIMIT 29 Page 4 of 69 Report No.:NTEK-2015NT0507815F Table of Contents Page 5.1.1 TEST PROCEDURE 29 5.1.2 DEVIATION FROM STANDARD 29 5.1.3 TEST SETUP 30 5.1.4 EUT OPERATION CONDITIONS 30 5.1.5 TEST RESULTS 31 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 37 6.1 APPLIED PROCEDURES / LIMIT 37 6.1.1 TEST PROCEDURE 37 6.1.2 DEVIATION FROM STANDARD 37 6.1.3 TEST SETUP 37 6.1.4 EUT OPERATION CONDITIONS 37 6.1.5 TEST RESULTS 38 7 . BANDWIDTH TEST 44 7.1 APPLIED PROCEDURES / LIMIT 44 7.1.1 TEST PROCEDURE 44 7.1.2 DEVIATION FROM STANDARD 44 7.1.3 TEST SETUP 44 7.1.4 EUT OPERATION CONDITIONS 44 7.1.5 TEST RESULTS 45 8 . PEAK OUTPUT POWER TEST 51 8.1 APPLIED PROCEDURES / LIMIT 51 8.1.1 TEST PROCEDURE 51 8.1.2 DEVIATION FROM STANDARD 51 8.1.3 TEST SETUP 51 8.1.4 EUT OPERATION CONDITIONS 51 8.1.5 TEST RESULTS 52 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 58 9.1 DEVIATION FROM STANDARD 58 9.2 TEST SETUP 58 9.3 EUT OPERATION CONDITIONS 58 9.4 TEST RESULTS 59 10 . ANTENNA REQUIREMENT 67 10.1 STANDARD REQUIREMENT 67 10.2 EUT ANTENNA 67 11 . EUT TEST PHOTO 68 Page 5 of 69 Report No.:NTEK-2015NT0507815F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 69 Report No.:NTEK-2015NT0507815F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 69 Report No.:NTEK-2015NT0507815F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment WIRELESS SPEAKER Trade Name Brookstone Model Name Speak Out Serial Model N/A Model …
