HLZA1407Tablet Computer

User’s Manual 2 - © 2014 All Rights Reserved Acer Iconia Tab 10 User’s Manual Covers: A3-A20FHD Regulatory Model Number (RMN): A1407 This revision: July 2014 Acer Iconia A3-A20FHD Model number: _______________________________________________ Serial number: _______________________________________________ Date of purchase: ____________________________________________ Place of purchase: ___________________________________________ Important This manual contains proprietary information that is protected by copyright laws. The information contained in this manual is subject to change without notice. Images provided herein are for reference only and may contain information or features that do not apply to your computer. Acer Group shall not be liable for technical or editorial errors or omissions contained in this manual. Sign up for an Acer ID and enjoy great benefits Open the Acer Portal app from the Start screen to sign up for an Acer ID or sign in if you already have an Acer ID. There are three great reasons for you to get an Acer ID: • Build Your Own Cloud with Acer BYOC. • Get the latest offers and product information. • Register your device for warranty service. For more information, please visit the AcerCloud website: www.acer.com/byoc-start Table of contents - 3 TABLE OF CONTENTS Getting started with your tablet 4 Features and functions ............................ 4 Unpacking your tablet.............................. 4 Getting to know your tablet...................... 5 Turning on for the first time...................... 6 Charging your tablet 8 Assembling the power adapter ................ 8 Using your tablet 10 Using the touchscreen........................... 10 The Home screen .................................. 10 The onscreen keyboard......................... 17 Editing text............................................. 18 Shutting down your tablet ...................... 19 Connecting devices to your tablet 20 Connecting to AC power ........................ 20 Inserting a microSD card ....................... 20 Transferring files between your tablet and a PC ................................................ 20 Connecting a Bluetooth device .............. 21 Accessories ........................................... 21 Specifications 22 End user license agreement 25 4 - Getting started with your tablet GETTING STARTED WITH YOUR TABLET Features and functions Your new tablet offers leading, easy-to-access multimedia and entertainment features. You can: • Connect to the Internet via Wi-Fi. • Access your email while on the move. • Keep in touch with your friends via your People an d social networking APPs. Unpacking your tablet Your new tablet comes packed in a protective box. Carefully unpack the box and remove the contents. If any of the following items are missing or damaged, contact your dealer immediately: • Acer Iconia A3-A20FHD tablet • Product setup and safety information • USB cable • AC adapter • Warranty card Note Before using your tablet for the first time, you need to charge it for at least four hours. After that y ou can recharge the battery as needed. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Getting started with your tablet - 5 Getting to know your tablet V 1 2 3 4 5 6 7 8 9 1012 11 iews No.ItemDescription 1Reset pinhole Insert a small thin object (such as a pape rclip) to reset the tablet. 2Volume control key Increases and decreases the t ablet volume . 3Power button Long press to turn the tablet on, press br iefly to turn the screen on/off or enter sleep mode; press and hold to turn the tablet off. 4Micro HDMI port Supports high-definition digital video connectio ns. 5 Micro USB port (Slave) Con nects to a computer via a USB cable. Also serves as the charging port for the AC adapter. For more information, see Charging your tablet on page 8. 6 3.5 mm headph one jack Con nects to stereo headphones. 6 - Getting started with your tablet Turning on for the first time To turn on your tablet, press and hold the power button until you see the Acer logo. Wait a moment for your tablet to boot up. You will then be asked some questions before you can use your tablet. To start, tap to select your language then tap Start. Follow the rest of the instructions as they are displayed. If the tablet’s screen turns off, it has entered sleep mode. Briefly press the power button to wake it up. For more information see Waking your tablet on page 19. 7MicroSD card slotInsert a microSD card into the slot. 8Front-facing camera A 2-megapixel camera for video chat s and self -portrait images. 9Touchscreen 10.1", 1920 x 1200 pixel capacitive touchscreen. 10Microphone Receives audio for video chats and Intern et calls. 11Rear-facing camera A 5-megapixel camera for taking high- resolution image s. 12Speakers Emit audio. No.ItemDescription Getting started with your tablet - 7 Sign in to or create a Google account If you have Internet access, your tablet allows you to synchronize information with a Google account. During the start-up process, you may create or sign in to an account, which will be used to synchronize your contact list, email, calendar and other information. If you do not yet have Internet access, or do not want to use this feature, then tap Skip. If you have multiple Google accounts, such as separate accounts for personal and business contacts, you can access and synchonize them from the Accounts settings section. See Multiple Google accounts on page 63 Important You must sign in to a Google Account to use Gmail, Hangouts, Google Calendar, and other Google Apps; to download APPs from Google Play; to back up your settings to Google servers; and to take advantage of other Google services on your tablet. If you want to restore existing settings from another device with Android 2.0 (or later) installed, you must sign in to your Google account during setup. If you wait until after set…
