HLZA1408Tablet PC

acer.com Product and safety information Informations sur le produit et la sécurité Información del producto y de seguridad Informações de segurança e do produto Iconia One 7 B1-750 *NC.L8811.00B* NC.L8811.00B Product overview 12 3 10 4 5 6 8 7 9 1. Audio jack 2. Micro USB port 3. Microphone 4. microSD card slot 5. Front camera 6. Power button 7. Volume button 8. Touchscreen 9. Camera 10. Speakers * Components may vary. Home screen 1 2 3 4 5 4 6 Note: Your tablet may have a different wallpaper to the one shown. 1. Notification bar 2. Search 3. Widgets 4. App shortcuts 5. Navigation (Back, Home, Recent) 6. Application menu (also known as "Apps") Getting started Using your tablet 1. Connect the power adapter Charge your tablet for at least four hours. Note: It is normal for the device surface to become warm during charging or long periods of use. 2. Press the power button Hold until you see the Acer logo. Connecting to the Internet via Wi-Fi To connect to a Wi-Fi network, tap the Application menu , then tap Settings . Under Wireless & networks, ensure Wi-Fi is ON. Tap Wi-Fi and then tap a wireless network; if necessary enter a security password to access the network. How to register To register your Acer product, visit our website at registration.acer.com. After we receive your product registration, you will be sent a confirmation email with important data that you should keep in a safe place. Your tablet's User's Manual To download the User's Manual, go to www.acer.com and click Support > DRIVERS AND MANUALS. Select the appropriate items from Group > Series > Products. In the Documents tab, click Download next to the User’s Manual. Connecting a Bluetooth device To connect to a bluetooth device, tap the Application menu , then tap Settings . Under Wireless & networks, ensure Bluetooth is ON. Tap Bluetooth and then SEARCH FOR DEVICES to scan for available devices. Then tap an available device to select a device. Note: A2DP stereo headsets are supported for playback only. Please check for updates to the tablet's software that may add support for additional Bluetooth devices. Restoring to factory settings Tap the Application menu , then tap Settings . Tap Backup & reset > Factory data reset; tap Reset tablet and then Erase everything to format your tablet. Updating your tablet’s operating system To check for updates, tap the Application menu , then tap Settings . Then tap About tablet > System updates > Check now. Acer Touch WakeApp Touch WakeApp is a convenient application that allows you to easily wake up your tablet from sleep mode and launch a defined app, using simple gestures. Enable Touch WakeApp Gestures 1. Pull down the notification area from the right corner. - Alternatively, you may also tap Apps > Settings. 2. Tap the Touch WakeApp icon to bring up Gesture Configure. 3. Slide ON to enable your desired item. 4. Tap and hold the item you have enabled to open a list of apps that can be automatically launched after the tablet is woken up. Note: Only portrait mode is supported when using the 2-thumb gesture. Hold the tablet with both thumbs near the edge of the screen to wake your tablet. 5. Select your app and tap OK. Note: If there are multiple user accounts on your tablet, the Application Shortcuts function will only be available on the Administrator account. All other users will only be able to wake up the system to the Home screen. For more information on Acer Touch WakeApp, refer to the User’s Manual. 5-finger gesture2-thumb gesture2-finger gestureDouble-tap gesture Safety and comfort SAFETY INSTRUCTIONS Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. Turning the product off before cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. WARNINGS Accessing the power plug Be sure that the power outlet you plug the power cord into is easily accessible and located as close to the equipment operator as possible. When you need to disconnect power to the equipment, be sure to unplug the power plug from the electrical outlet. Mark sure the power plug is fixed at right position with the adaptor before plugging to the socket on the wall. Input rating: Refer to the rating label on the bottom of the computer and ensure that your power adapter complies with the specified rating. Under no circumstances should the user attempt to disassemble the power supply. The power supply has no user-replaceable parts. Inside the power supply are hazardous voltages that can cause serious personal injury. A defective power supply must be returned to your dealer. Using electrical power - If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse rating. - Do not overload a power outlet, strip or receptacle by plugging in too many devices. The overall system load must not exceed 80% of the branch circuit rating. If power strips are used, the load should not exceed 80% of the power strip's input rating. General - Do not use this product near water. - Do not place this product on an unstable cart, stand or table. If the product falls, it could be seriously damaged. - Slots and openings are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heat register, or in a built-in installation unless proper ventilation is provided. - Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or shor…

Text truncated - open the document above for the full version.

User’s Manual 2 - © 2014 All Rights Reserved Acer Iconia One 7 User’s Manual Covers: B1-750 Regulatory Model Number (RMN): A1408 This revision: September 2014 Acer Iconia One 7 Model number: _______________________________________________ Serial number: _______________________________________________ Date of purchase: ____________________________________________ Place of purchase: ___________________________________________ Important This manual contains proprietary information that is protected by copyright laws. The information contained in this manual is subject to change without notice. Images provided herein are for reference only and may contain information or features that do not apply to your computer. Acer Group shall not be liable for technical or editorial errors or omissions contained in this manual. Sign up for an Acer ID and enjoy great benefits Open the Acer Portal app from the Start screen to sign up for an Acer ID or sign in if you already have an Acer ID. There are three great reasons for you to get an Acer ID: • Build Your Own Cloud with Acer BYOC. • Get the latest offers and product information. • Register your device for warranty service. For more information, please visit the AcerCloud website: www.acer.com/byoc-start Getting started with your tablet - 3 GETTING STARTED WITH YOUR TABLET Features and functions Your new tablet offers leading, easy-to-access multimedia and entertainment features. You can: • Connect to the Internet via Wi-Fi. • Access your email while on the move. • Keep in touch with your friends via your People and social networking APPs. Unpacking your tablet Your new tablet comes packed in a protective box. Carefully unpack the box and remove the contents. If any of the following items are missing or damaged, contact your dealer immediately: • Acer Iconia tablet • Product setup and safety information • USB cable • AC adapter • Warranty card Note Before using your tablet for the first time, you need to charge it for at least four hours. After that you can recharge the battery as needed. 4 - Getting started with your tablet Getting to know your tablet 12 3 10 4 5 6 8 7 9 Views No.ItemDescription 1 3.5 mm headphone jack Connects to stereo headphones. 2 Micro USB port (Slave) Connects to a computer via a USB cable. Also serves as th e charging port for the AC adapter. For more information, see Charging your tablet on page 7. 3Microphone Receives audio for video chats and Intern et calls. 4microSD card slotInsert a microSD card into the slot. 5Front-facing camera A 0.3-megapixel camera for video chats and self -portrait images. Getting started with your tablet - 5 Turning on for the first time To turn on your tablet, press and hold the power button until you see the Acer logo. Wait a moment for your tablet to boot up. You will then be asked some questions before you can use your tablet. To start, tap to select your language then tap Start. Follow the rest of the instructions as they are displayed. If the tablet’s screen turns off, it has entered sleep mode. Briefly press the power button to wake it up. For more information see Waking your tablet on page 19. 6Power button Long press to turn the tablet on, press briefly to turn the screen on/off or enter sleep mode; press and hold to turn the tablet off. 7Volume control key Increases and decreases the tablet volume. 8Touchscreen7" capacitive touchscreen. 9Rear-facing camera A 5-megapixel camera for taking high- resolution images. 10SpeakersEmit audio. No.ItemDescription 6 - Getting started with your tablet Sign in to or create a Google account If you have Internet access, your tablet allows you to synchronize information with a Google account. During the start-up process, you may create or sign in to an account, which will be used to synchronize your contact list, email, calendar and other information. If you do not yet have Internet access, or do not want to use this feature, then tap Skip. If you have multiple Google accounts, such as separate accounts for personal and business contacts, you can access and synchonize them from the Accounts settings section. See Multiple Google accounts on page 41 Important You must sign in to a Google Account to use Gmail, Hangouts, Google Calendar, and other Google Apps; to download APPs from Google Play; to back up your settings to Google servers; and to take advantage of other Google services on your tablet. If you want to restore existing settings from another device with Android 2.0 (or later) installed, you must sign in to your Google account during setup. If you wait until after setup is complete, your settings will not be restored. Charging your tablet - 7 CHARGING YOUR TABLET Assembling the power adapter Your tablet is bundled with one of two types of USB power adapters: a fixed-prong type or a removable-prong type. Both types are described in this manual. Fixed-prong type The prongs and power adapter body form a complete piece, no assembly required. Simply slide the large end of the USB cable into the power adapter body (it will fit in only one direction). You cannot remove or switch the prongs with this type of adapter. Removable-prong type Align arrows on the power adapter head and body. Insert the head onto the power adapter body and turn the head towards "CLOSE" printed on the head until it clicks into place. Simply slide the large end of the USB cable into the power adapter body (it will fit in only one direction). CLOSE OPEN 1 C OPEN 2 8 - Charging your tablet Connecting power Connect the power connector to your tablet and plug the AC adapter into any AC outlet. Warning Only use an Acer-approved adapter to charge your device. Note It is normal for the tablet surface to become warm during charging or long periods of use. Connecting devices to your tablet - 9 CONNECTING DEVICES TO YOUR TABLET Connecting to AC power See Charging your tablet on page 7 Inserting a microSD card You may install a microSD card to expand your device's storage space. Ensure that th…

Text truncated - open the document above for the full version.

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih New Taipei City 22181, Taiwan, R.O.C. TEL: +886-2-2696-3131 ext.3089 Fax : 886-2-8691-3120 www.acer.com Date:2011/8/22 To who may concern, I, the undersigned, responsible for the designated person in FCC grant communicator / IC company code contactor, hereby authorized RU Jan to sign the FCC / IC application form for certification process. Thank you, Sincerely Yours, Contact Person: Harriot S.L. Lee Company Name: Acer Incorporated E-Mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

D D 1 2 3 4 5 6 7 ABCE 7 6 5 4 3 2 1 ECBA NAME MODEL MATERIAL FINISH DATE SCALE UNIT MM DWG. NO. APPROVED DESIGNED DRAWING 2B TOL. + - 1 PLC2 PLCANGLE ITEMDESCRIPTION REVISIONS LTRDESCRIPTION DATE APP THE 3RD PROJECTION PART NO. Quanta Computer Inc. 2 1 FIRST RELEASE Ling Hsu Ling Hsu Ling Hsu S/N 1/1 2B HNKW006010 HCNKW006 DEVICE LB PL 10W WW NKW SEE NOTES No.211,Wen Hwa 2nd Ra.,Kuei Shan Tao Yuan 33377,TAIWAN, R.O.C. 5.LABEL BACKGROUND COLOR :TRANSPARENT 103.10.09 103.10.09 6.File No.:HCNKW006010 4.TEXT COLOR:PANTONE COOL GRAY 6C NOTE: 2.ADHESIVE BASE:ACRYLIC 3.DIMENSION TOLERENCE:+-0.2 1.MATIRAL :25#PET+COATING 25#PET Model:A1408

D D 1 2 3 4 5 6 7 ABCE 7 6 5 4 3 2 1 ECBA NAME MODEL MATERIAL FINISH DATE SCALE UNIT MM DWG. NO. APPROVED DESIGNED DRAWING 2A TOL. + - 1 PLC2 PLCANGLE ITEMDESCRIPTION REVISIONS LTRDESCRIPTION DATE APP THE 3RD PROJECTION PART NO. Quanta Computer Inc. 2 1 FIRST RELEASE Ling Hsu Ling Hsu Ling Hsu S/N 1/1 2A HCNKW003010 HCNKW003 DEVICE LB PL WW NKW SEE NOTES No.211,Wen Hwa 2nd Ra.,Kuei Shan Tao Yuan 33377,TAIWAN, R.O.C. 5.LABEL BACKGROUND COLOR :TRANSPARENT 103.10.09 103.10.09 6.File No.:HCNKW003010 4.TEXT COLOR:PANTONE COOL GRAY 6C NOTE: 2.ADHESIVE BASE:ACRYLIC 3.DIMENSION TOLERENCE:+-0.2 1.MATIRAL :25#PET+COATING 25#PET Model:A1408

Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16

FCC ID: HLZA1408 Report No.: RF 141002C15 Operational Description This device is a Tablet Computer, which operates in 2.4GHz bands for WLAN and Bluetooth; the maximum data rate could be up to 72.2Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 72.2Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 3.8Vdc from battery, 5Vdc from host equipment or 5.35Vdc, 5.2Vdc form adapter. The antenna is PIFA antenna with IPEX MHF 4L antenna connectors. The other instruction, please have a look at the users manual.

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 24 Report No. : SA141002C15 Issued Date : Oct. 22, 2014 FCC SAR Test Report Report No. : SA141002C15 Applicant : Acer Incorporated Address : 8F., No.88, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan Product : Tablet Computer (BT+Wi-Fi) FCC ID : HLZA1408 Brand : Acer Model No. : A1408 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 KDB 248227 D01 v01r02 / KDB 447498 D01 v05r02 / KDB 616217 D04 v01r01 Sample Received Date : Oct. 02, 2014 Date of Testing : Oct. 09, 2014 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Vera Huang / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 24 Report No. : SA141002C15 Issued Date : Oct. 22, 2014 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot .................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 Volume Scan Procedure ................................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................................... 16 3.4.5 SAR Averaged Methods…
