Acer DA221HQL User Guide 2 © 2014. All Rights Reserved. Acer DA221HQL User Guide Model: DA221HQL This Revision: 03/2014 Acer DA221HQL Model number: ______________________________ Serial number*: ______________________________ Date of purchase: ____________________________ Place of purchase: ___________________________ *Note: See the back of the DA221HQL 3 ENERGY STAR Acer ENERGY STAR qualified products save your money by reducing energy cost and protecting the environment without sacrificing features or performance. Acer is proud to offer our customers products with the ENERGY STAR mark. What is ENERGY STAR? Products that are ENERGY STAR qualified use less energy and prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency. Acer is committed to offering products and services worldwide that help customers save money, conserve energy and improve the quality of our environment. The more energy we can save through higher energy efficiency, the more we reduce greenhouse gases and the risks of climate change. More information refers to www.energystar.gov or www.energystar.gov/ powermanagement. - Note: Information in this section may not apply to your computer. Acer ENERGY STAR qualified products: - produce less heat and reduce cooling loads in warmer climates. - automatically go into "display Sleep" and "computer Sleep" mode after 10 minutes of inactivity. - wake from "Sleep" mode by pressing the power button. - save more than 80% energy when in "Sleep" mode. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. 4 Table of contents ENERGY STAR Getting to know your DA221HQL Features and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Product registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Setting up Unpacking your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Getting to know your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Using your DA221HQL Setting up your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Turning on for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Using the touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 The Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 The onscreen keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Editing text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Locking your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Shutting down your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Connecting devices to your DA221HQL Connecting to AC power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Connecting to a PC as a monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Inserting a Micro SD card (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Connecting a USB device to your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Transferring files between your DA221HQL and a PC . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Connecting to a router or modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Connecting a Bluetooth device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Using the webcam Using the webcam as a camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Using the webcam to record a video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Viewing photos and videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Advanced settings Wireless & Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Personal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Updating your DA221HQL’s operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 5 Resetting your DA221HQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 FAQ and troubleshooting Other sources of help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 6 Getting to know your DA221HQL Features and functions Your new DA221HQL offers leading, easy-to-access multimedia and entertainment features. You can: • Connect to the Internet. • Access your email. • Play music and video. • Keep in touch with your friends via your People and social networking apps. • View content from an HDMI device. • Use touch to control a PC. Product registration When using your product for the first time, it is recommended that you immediately register it. This will give you access to useful benefits, such as: • Faster service from our trained representatives. • Me…

Text truncated - open the document above for the full version.

Antenna Photo BTWiFi Avg. Gain BTWiFi Frequency (MHz) Avg. Gain (dBi)Frequency (MHz) Avg. Gain (dBi) 2300‐2.812300‐3.82 2310‐3.312310‐3.63 2320‐3.252320‐3.81 2330‐3.102330‐3.70 2340‐3.222340‐3.68 2350‐2.972350‐3.46 2360‐2.732360‐3.21 2370‐2842370‐3162370‐2.842370‐3.16 2380‐2.872380‐3.23 2390‐2.972390‐3.23 2400‐2.982400‐3.22 2410‐2.762410‐3.08 2420‐2.622420‐2.98 2430‐2.542430‐2.84 2440‐2.612440‐2.89 2450‐2.542450‐2.82 2460‐2.472460‐2.81 2470‐2.812470‐2.89 2480‐2.922480‐3.25 2490‐2.972490‐3.23 2500‐2.742500‐2.95 Peak. Gain BTWiFi Frequency (MHz) Avg. Gain (dBi)Frequency (MHz) Avg. Gain (dBi) 24000.3724000.23 24100.5124100.34 24200.6824200.63 24300.7024300.63 24400.7224400.71 24500.8224500.72 24600.8524600.73 24700.6124700.59 24800.4124800.34 24900.4124900.30 25000.5925000.59 Radiation Pattern2450 MHz BTWiFi VSWR BT WiFi

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih New Taipei City 22181, Taiwan, R.O.C. TEL: +886-2-2696-3131 ext.3089 Fax : 886-2-8691-3120 www.acer.com Date:2011/8/22 To who may concern, I, the undersigned, responsible for the designated person in FCC grant communicator / IC company code contactor, hereby authorized RU Jan to sign the FCC / IC application form for certification process. Thank you, Sincerely Yours, Contact Person: Harriot S.L. Lee Company Name: Acer Incorporated E-Mail: [email protected]

Equipment: Android All-in-One Trademark(s) and Model(s): Acer, DA221HQL Manufacturer: Tech-Full Computer (Changshu) Co., Ltd. FCC ID in case other parts of this equipment are subject to certification: HLZDA221HQL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number: Issue date: FD140106D01 March 25, 2014 Company name: Acer Incorporated Name/Title (legal representative): RU Jan Address: 8F, 88, Sec 1, Hsin Tai Wu Rd, New Taipei City, Taiwan Phone: +886-2-2696-3131 Fax: +886-2-2696-3535 E-mail: [email protected] Date: 2014/03/28 Signature:

Acer Incorporated 8F., No. 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 22181, Taiwan (R.O.C) Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Date: 2014/03/28 Federal Communications Commission Authorization and Evaluation Division Subject: Request for Confidentiality FCC ID: HLZDA221HQL To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s Rules ( 47 CFR §§ 0.457,0.459),we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description BOM list Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in oder to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments 180 days. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, _____________________________________ RU Jan / Sr. Manager Acer Incorporated

RF_160, Issue 03 Declaration of Authorization We Name: Acer Incorporated Address: 8F, 88, Sec 1, Hsin Tai Wu Rd, New Taipei City, Taiwan City: New Taipei City Country: Taiwan Declare that: Name Representative of agent: Willis Chen Agent Company name: SGS Taiwan Ltd. ) Address: 134, Wu Kung Rd, Wuku Industrial Zone City: New Taipei City Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Android All-in-One Type designation: DA221HQL Trademark: Acer on our behalf. Date: 2014/3/28.. City: New Taipei City.. Name: RU Jan.. (2) Function: .........Sr. Manager...................... Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

All View of EUT Front View of EUT Back View of EUT Side View of EUT – 1 Side View of EUT – 2 Side View of EUT – 3 Side View of EUT – 4 Adapter-1 (Model No.: ADP-40KD BB, Supplier: Delta) Adapter-2 (Model No.: DA-40C19, Supplier: APD)

Model No. : Version : Power Input : Part Number : Mfg Date : Serial Number : SNID :34500051146 Made in ChinaCT1 DA221HQL DA221HQL bmjcz 19Vdc , 2.1A UM.XXXXX.001 Nov 2013 XXXXXXXXXX345001FF4600 Android All-in-One UPC : 8 87899 xxxxx x E142692 CS70 LISTED I.T.E CAN ICES-3 (B) / NMB-3 (B) FCC ID: HLZDA221HQL

Open View of EUT – 1 Open View of EUT – 2 Open View of EUT – 3 Internal View of EUT – 1 Internal View of EUT – 2 Internal View of EUT – 3 Internal View of EUT – 4 Internal View of EUT – 5 Internal View of EUT – 6 Internal View of EUT – 7 Internal View of EUT – 8 Internal View of EUT – 9 Internal View of EUT – 10 Internal View of EUT – 11 Internal View of EUT – 12 Internal View of EUT – 13 Internal View of EUT – 14 BT Antenna WLAN Antenna

1 MAXIMUM PERMISSIBLE EXPOSURE (MPE) 1.1 STANDARD APPLICABLE According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Mobile device, the MPE is required. According to §1.1310 and §2.1093 RF exposure is calculated. Limits for Maximum Permissive Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-15000 / / 1.0 30 F = frequency in MHz * = Plane-wave equipment power density 1.2 MAXIMUM PERMISSIBLE EXPOSURE (MPE) EVALUATION 802.11b Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit 1 2 5.5 11 1 2412 17.89 17.82 17.75 17.72 1 Watt = 30 dBm 6 2437 18.31 18.19 18.08 18.01 1 Watt = 30 dBm 11 2462 18.21 18.08 18.05 18.03 1 Watt = 30 dBm MPE Prediction (802.11b) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 18.31 (dBm) Maximum peak output power at antenna input terminal: 67.76415076 (mW) Duty cycle: 100 (%) Maximum Pav : 67.76415076 (mW) Antenna gain (typical): 0.73 (dBi) Maximum antenna gain: 1.183041556 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.015957 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.015957mW/cm 2 . This is below the uncontrolled exposure limit of 1mW/cm 2 at 2437MHz. 802.11g Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit 6 9 12 18 24 36 48 54 1 2412 22.05 22.01 21.91 21.86 21.77 21.73 21.63 21.56 1 Watt = 30 dBm 6 2437 23.37 23.27 23.18 23.11 22.99 22.96 22.83 22.82 1 Watt = 30 dBm 11 2462 22.51 22.48 22.40 22.33 22.27 22.23 22.20 22.16 1 Watt = 30 dBm MPE Prediction (802.11g) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 23.37 (dBm) Maximum peak output power at antenna input terminal: 217.2701179 (mW) Duty cycle: 100 (%) Maximum Pav : 217.2701179 (mW) Antenna gain (typical): 0.73 (dBi) Maximum antenna gain: 1.183041556 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.051162 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.051162mW/cm2. This is below the uncontrolled exposure limit of 1mW/cm2 at 2437MHz. 802.11n_20M Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 MCS6 MCS7 1 2412 20.32 20.27 20.14 20.11 20.05 19.98 19.95 19.86 1 Watt = 30 dBm 6 2437 22.78 22.66 22.65 22.59 22.51 22.42 22.37 22.31 1 Watt = 30 dBm 11 2462 20.82 20.76 20.66 20.52 20.49 20.35 20.29 20.23 1 Watt = 30 dBm MPE Prediction (802.11 n_20M) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 22.78 (dBm) Maximum peak output power at antenna input terminal: 189.6705921 (mW) Duty cycle: 100 (%) Maximum Pav : 189.6705921 (mW) Antenna gain (typical): 0.73 (dBi) Maximum antenna gain: 1.183041556 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.044663 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.044663mW/cm2. This is below the uncontrolled exposure limit of 1mW/cm2 at 2437MHz. 802.11n_20M Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 MCS6 MCS7 1 2412 20.32 20.27 20.14 20.11 20.05 19.98 19.95 19.86 1 Watt = 30 dBm 6 2437 22.78 22.66 22.65 22.59 22.51 22.42 22.37 22.31 1 Watt = 30 dBm 11 2462 20.82 20.76 20.66 20.52 20.49 20.35 20.29 20.23 1 Watt = 30 dBm MPE Prediction (802.11 n_20M) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 22.78 (dBm) Maximum peak output power at antenna input terminal: 189.6705921 (mW) Duty cycle: 100 (%) Maximum Pav : 189.6705921 (mW) Antenna gain (typical): 0.73 (dBi) Maximum antenna gain: 1.183041556 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.044663 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.044663mW/cm2. This is below the uncontrolled exposure limit of 1mW/cm2 at 2437MHz. 802.11n_20M Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit MCS0 MCS1 MCS…
