HLZJMS120Smart HandHeld

Specifications Specifications Performance •Qualcomm MSM 7230-1, 800 MHz •System memory: • 512 MB of RAM • 512 MB of ROM •Google Android operating system Display •3.61” WVGA TFT-LCD, capacitive multi-touch screen •800 x 480 resolution •65K colors support Multimedia •CD-quality stereo output •Mono speaker •Dual microphone •Dolby Mobile •Formats supported USB connector •Micro USB connector •USB Client •DC power-in (5 V, 1 A) Connectivity •Bluetooth 2.1+EDR & A2DP support TypeFormats Audio playbackMP3, AMR, WMA RingtoneMP3, MIDI, iMelody, WAVE, WMA Video recording3GP, MPEG-4, H.263 Video playback3GP, MPEG-4, H.263, H.264, WMA 2 •IEEE Wi-Fi 802.11b/g/n WLAN •GSM 850 / 900 / 1800 / 1900 •UMTS 900 / 1900 / 2100 (EU models) •UMTS 850 / 1900 / 2100 (US models) •HSDPA / HSUPA / HSPA+ / EDGE / GPRS •GPS / AGPS Camera •5-megapixel •Auto-focus •Flash Expansion •microSD memory card (up to 32 GB) Battery •High density, rechargeable 1500 mAh Lithium-ion battery (replaceable) Note: Length of battery operation will depend on power consumption which is based on system resource use. For example, constantly using the backlight or using power-demanding applications will shorten battery life between charges. Dimensions Height115 mm Width63 mm Thickness13.55 mm Weight<135 g (with battery) 3 Battery information This product uses a Lithium-ion battery. Do not use it in a humid, wet and/or corrosive environment. Do not put, store or leave your product in or near a heat source, in a high temperature location, in strong direct sunlight, in a microwave oven or in a pressurized container, and do not expose it to temperatures over 60 °C (140 °F). Failure to follow these guidelines may cause the battery to leak acid, become hot, explode or ignite and cause injury and/or damage. Do not pierce, open or disassemble the battery. If the battery leaks and you come into contact with the leaked fluids, rinse thoroughly with water and seek medical attention immediately. For safety reasons, and to prolong the lifetime of the battery, charging will not occur at low (below 0 °C/32 °F) or high (over 40 °C/104 °F) temperatures. The full performance of a new battery is achieved only after two or three complete charge and discharge cycles. The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times are noticeably shorter than normal, buy a new battery. Use only Acer approved batteries, and recharge your battery only with Acer approved chargers designated for this device. Unplug the charger from the electrical plug and the device when not in use. Do not leave a fully charged battery connected to the ac charger, since overcharging may shorten its lifetime. If left unused, a fully charged battery will lose its charge over time. If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made. Use the battery only for its intended purpose. Never use any charger or battery that is damaged. 4 Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object such as a coin, clip, or pen causes direct connection of the positive (+) and negative (-) terminals of the battery. (These look like metal strips on the battery.) This might happen, for example, when you carry a spare battery in your pocket or purse. Short- circuiting the terminals may damage the battery or the connecting object. Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions, will reduce the capacity and lifetime of the battery. Always try to keep the battery between 15 °C and 25 °C (59 °F and 77 °F). A device with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing. Do not dispose of batteries in a fire as they may explode. Batteries may also explode if damaged. Dispose of batteries according to local regulations. Please recycle when possible. Do not dispose as household waste. Replacing the battery pack Your smartphone uses lithium batteries. Replace the battery with the same type as that which came bundled with your product. Use of another battery may present a risk of fire or explosion. Warning! Batteries may explode if not handled properly. Do not disassemble or dispose of them in fire. Keep them away from children. Follow local regulations when disposing of used batteries. 5 Disposal and recycling information Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit www.acer-group.com/public/Sustainability/ sustainability01.htm Regulatory information Compliant with Russian regulatory certification RoHS compliance This product is in compliance with Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003, on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) and its amendments. Prevention of hearing loss Caution: Permanent hearing loss may occur if earphones or headphones are used at high volume for prolonged periods of time. This device have been tested to comply with the Sound Pressure Level requirement laid down in the applicable EN 50332-1 and/or EN 50332-2 standards. Note: For France, mobile headphones or earphones for this device have been tested to comply with the Sound Pressure requirement laid down in the applicable NF EN 50332- 6 1:2000 and/or NF EN 50332-2:2003 standards as required by French Article L. 5232-1. Wireless operation channels for different domains France: Restricted wireless frequency bands Some areas of France have a restricted frequency band. The worst case maximum authorized power indoors is: •10 mW for the entire 2.4 GHz band (2…

Text truncated - open the document above for the full version.

Acer Liquid Metal (S120) User Guide © 2010 All Rights Reserved Acer Liquid Metal (S120) User Guide First issue: 10/2010 Acer Liquid Metal (S120) Smartphone Model number: __________________________________ Serial number: ___________________________________ Date of purchase: ________________________________ Place of purchase: ________________________________ 3 End User License Agreement IMPORTANT - READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("AGREEMENT") IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR A SINGLE ENTITY), AND ACER INC. INCLUDING ITS SUBSIDIARIES ("ACER") FOR THE SOFTWARE (WHETHER PROVIDED BY ACER OR BY ACER'S LICENSORS OR SUPPLIERS) THAT ACCOMPANIES THIS AGREEMENT, INCLUDING ANY ASSOCIATED MEDIA, PRINTED MATERIALS AND RELATED USER ELECTRONIC DOCUMENTATION WHICH MAY BE BRANDED "ACER" ("SOFTWARE"). AGREEMENTS RELATING TO ANY OTHER PRODUCT OR TOPIC ARE NEITHER INTENDED NOR SHOULD THEY BE IMPLIED. BY INSTALLING THE ACCOMPANYING SOFTWARE OR ANY PORTION THEREOF, YOU AGREE TO BE BOUND BY THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO ALL OF THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT CONTINUE THE INSTALLATION PROCESS AND IMMEDIATELY DELETE ALL INSTALLED FILES, IF ANY, OF THE ACCOMPANYING SOFTWARE FROM YOUR PHONE. IF YOU DO NOT HAVE A VALIDLY-LICENSED COPY OF THE APPLICABLE SOFTWARE, YOU ARE NOT AUTHORIZED TO INSTALL, COPY OR OTHERWISE USE THE SOFTWARE, AND HAVE NO RIGHTS UNDER THIS AGREEMENT. The Software is protected by U.S. and international copyright laws and conventions as well as other intellectual property laws and treaties. The Software is licensed, not sold. GRANT OF LICENSE Acer grants to you the following non-exclusive and non-transferable rights with respect to the Software. Under this Agreement, you may: 1. Install and use the Software only on a single designated phone. A separate license is required for each phone on which the Software will be used; 2. Make one copy of the Software solely for backup or archival purposes; 3. Make one hardcopy of any electronic documents included in the Software, provided that you receive the documents electronically. RESTRICTIONS You may NOT: 1. Use or copy the Software except as provided in this Agreement; 2. Rent or lease the Software to any third party; 3. Modify, adapt, or translate the Software in whole or in part; 4. Reverse engineer, decompile, or disassemble the Software or create derivative works based upon the Software; 5. Merge the Software with any other program or modify the Software, except for your personal use; and 6. Sublicense or otherwise make the Software available to third parties, except that you may, after prior written notification to Acer, transfer the Software as a whole to a third party so long as you do not retain any copies of the Software and such third party accepts the terms of this Agreement. 7. Transfer your rights under this Agreement to any third parties. 8. Export the Software in contravention of applicable export laws and regulations, or (i) sell, export, re-export, transfer, divert, disclose technical data, or dispose of, any Software to any prohibited person, entity, or destination including, without limitation, Cuba, Iran, North Korea, Sudan and Syria; or (ii) use any Software for any use prohibited by the laws or regulations of the United States. SUPPORT SERVICES Acer is not obligated to provide technical or other support for the Software. ACER LIVE UPDATE Certain of the software contains elements that enable the use of the Acer Live Update service, which allows for updates for such software to be automatically downloaded and installed on your phone. By installing the software, you hereby agree and consent that Acer (or its licensors) may automatically check the version of such software that you are using on your phone and may provide upgrades to such software that may be automatically downloaded on to your phone. OWNERSHIP AND COPYRIGHT Title, ownership rights and intellectual property rights in and to the Software and all copies thereof shall remain with Acer or Acer's licensors or suppliers (as applicable). You do not have or shall not gain any proprietary interest in the Software (including any modifications or copies made by or for you) or any related intellectual property rights. Title and related rights in the content accessed through the Software is the property of the applicable content owner and may be protected by applicable law. This license gives you no rights to such contents. You hereby agree 1. Not to remove any copyright or other proprietary notices from the Software; 2. To reproduce all such notices on any authorized copies you make; and 3. To use best efforts to prevent any unauthorized copying of the Software. TRADEMARKS This Agreement does not grant to you any rights in connection with any trademarks or service marks of Acer or of Acer's licensors or suppliers. DISCLAIMER OF WARRANTIES TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ACER, ITS SUPPLIERS, AND ITS LICENSORS, PROVIDE THE SOFTWARE "AS IS" AND WITH ALL FAULTS, AND HEREBY DISCLAIM ALL OTHER WARRANTIES AND CONDITIONS, EITHER EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES, DUTIES OR CONDITIONS OF MERCHANTABILITY, OF FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY OR COMPLETENESS OF RESPONSES, OF RESULTS, OF WORKMANLIKE EFFORT, OF LACK OF VIRUSES, AND OF LACK OF NEGLIGENCE, ALL WITH REGARD TO THE SOFTWARE AND THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES. ALSO, THERE IS NO 4 WARRANTY OR CONDITION OF TITLE, QUIET ENJOYMENT, QUIET POSSESSION, CORRESPONDENCE TO DESCRIPTION OR NON-INFRINGEMENT WITH REGARD TO THE SOFTWARE. EXCLUSION OF INCIDENTAL, CONSEQUENTIAL AND CERTAIN OTHER DAMAGES TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ACER, ACER'S SUPPLIERS, OR ACER'S LICENSORS, BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, PUNITIVE, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR…

Text truncated - open the document above for the full version.

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih Taipei Hsien 221, Taiwan, R.O.C. Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Date: September 16, 2010 Federal Communications Commission Authorization and Evaluation Division RE : Declaration To whom it may concern, S120 is a WLAN/BT combination antenna with FCC ID: HLZJMS120. This WLAN/BT co-existence mechanism is to ensure that the WLAN and BT transmitters would not simultaneously operate. Therefore, WLAN and BT antenna in S120 should not be considered to be able to transmit simultaneously. Though the users can use WLAN and BT simultaneously, but the real situation is that WLAN and BT are used by time sharing and no overlap transmission. Should you have any questions, please have my best attention. Sincerely, ____________________ Harriot S.L. Lee Acer Inc. Tel: +886-2-66063131 Fax: +886-2-66065353 E-Mail: [email protected]

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih Taipei Hsien 221, Taiwan, R.O.C. Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Date: September 16, 2010 Federal Communications Commission Authorization and Evaluation Division We, Acer Incorporated, states that our device, FCC ID: HLZJMS120, has no space to put the label except battery compartment as shown in the label location. The label will put under the battery compartment, so the label is visible to the users as they purchase the products and install the battery. ________________________ Harriot S.L. Lee Attached: Copy of FCC Confidentiality Policy

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih Taipei Hsien 221, Taiwan, R.O.C. Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: September 16, 2010 SUBJECT: FCC Application for FCC ID: HLZJMS120 To Whom It May Concern: Please be notified that we, the undersigned, Acer Inc. declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is FD081915-02. Testing in regards to this report was done by Sporton International Inc., located at No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827. Regards, Harriot S.L. Lee Acer Inc Email: [email protected]

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih Taipei Hsien 221, Taiwan, R.O.C. Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Date: September 16, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: HLZJMS120 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (file: Schem.pdf) Block Diagram (file: BlkDia.pdf) Parts List (file: PartsLst.pdf) Operation Description (file: OpDes.pdf) Tune up Procedure (file: TunPro.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ________________________ Harriot S.L. Lee Attached: Copy of FCC Confidentiality Policy

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih Taipei Hsien 221, Taiwan, R.O.C. Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Power of Attorney To whom it may concern, I, the undersigned, Easy Lai , hereby authorize the person listed below to act in behalf of me to sign all related documents for Acer FCC application. Name : Harriot Lee Company : Acer Incorporated Company Address : 8F, No. 88, Sec. 1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan Tel : 886-2-6606-3131 ext. 3811 FAX : 886-2-6606-5353 Authorization period : Jan. 1 st , 2010 ~ Dec. 31th, 2010 Should you have any question regarding this power of attorney, please don’t hesitate to contact me. Sincerely, _______________ Easy Lai/ Acer Incorporated Tel : +886-2 86913089 FAX : +886-2 86913120 E-Mail: [email protected]

Acer Incorporated 8F., No. 88, Sec. 1, Hsin Tai Wu Rd. Hsichih Taipei Hsien 221, Taiwan Tel: 886-2-66063131 ; Fax: 886-2-66065353 Date: September 16, 2010 Power of Attorney To whom it may concern, Please be notified that I, Harriot S.L. Lee, have designated Roy Wu in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Roy Wu in Sporton International Inc., on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: HLZJMS120 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Contact Person: Harriot S.L. Lee Company: Acer Incorporated TEL: 886-2-66063131 FAX: 886-2-66065353 E-mail: [email protected]

Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih Taipei Hsien 221, Taiwan, R.O.C. Tel : 886-2-2696-1234 Fax : 886-2-2696-3535 www.acer.com Date: September 16, 2010 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : HLZJMS120 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos  Internal Photos  Test set-up photos  Users Manual The application contains technical information, which Acer Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, ________________________ Harriot S.L. Lee Acer Inc. Tel: +886-2-66063131 Fax: +886-2-66065353 E-Mail: [email protected]

Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 1 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 1. External Photograph of EUT Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 2 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 720510 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 3 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 List of Accessory: Specification of Accessory AC Adapter Brand Name PHIHONG Model Name PSAI05R-050Q Battery 1 Brand Name Simplo Model Name BAT-510 (P/N : BT.00107.010) Battery 2 Brand Name TWS Model Name BAT-510 (P/N : BT.0010S.001) Earphone Brand Name KINGSTATE Model Name KJAH4028AENCB-2 USB Cable Brand Name MEC IMEX Model Name 60-4721-100 LCD Panel Brand Name AUO Model Name H361VL01 V3 Memory 1 Brand Name Samsung Model Name KA100O015C-AJTT Memory 2 Brand Name Hynix Model Name H8KES0XU0MRR-4EM Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 4 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 5 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 6 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 7 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Battery 1 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 8 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 720510 Battery 2

Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 9 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 3. Internal Photograph of EUT Sample 1 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 10 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 11 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 12 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 13 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 14 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Sample 2 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 15 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 16 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 17 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 18 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 720510 Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 19 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 WWAN Antenna <Tx/Rx> GPS Antenna <Rx> WLAN & Bluetooth Antenna <Tx / Rx> 9 cm Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 20 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 WWAN Antenna <Tx/Rx> Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 21 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 Bluetooth & WLAN Antenna <Tx/Rx> Photographs of EUT Report No.: EP081915-02 Brand Name: Acer / Model Name: S120 SPORTON INTERNATIONAL INC. Page Number : 22 of 22 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 720510 GPS Antenna <Rx>

SPORTON INTERNATIONAL INC. Page Number : 1 of 36 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 FCC SAR Test Report Report No. : FA081915-02A FCC SAR Test Report APPLICANT : Acer Incorporated EQUIPMENT : Smart HandHeld BRAND NAME : Acer MODEL NAME : S120 FCC ID : HLZJMS120 STANDARD : FCC 47 CFR Part 2 (2.1093) IEEE C95.1-1999 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was received on Aug. 19, 2010 and completely tested on Oct. 11, 2010. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Roy Wu / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 36 TEL : 886-3-327-3456 Report Issued Date : Oct. 20, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : HLZJMS120 FCC SAR Test Report Report No. : FA081915-02A Table of Contents Revision History ................................................................................................................................................................ 3 1. Statement of Compliance .......................................................................................................................................... 4 2. Administration Data ................................................................................................................................................... 5 2.1 Testing Laboratory ............................................................................................................................................ 5 2.2 Applicant ........................................................................................................................................................... 5 2.3 Manufacturer .................................................................................................................................................... 5 2.4 Application Details ............................................................................................................................................ 5 3. General Information ................................................................................................................................................... 6 3.1 Description of Device Under Test (DUT) ........................................................................................................... 6 3.2 Product Photos ................................................................................................................................................. 7 3.3 Applied Standards ............................................................................................................................................ 8 3.4 Device Category and SAR Limits ..................................................................................................................... 8 3.5 Test Conditions ................................................................................................................................................. 8 3.5.1 Ambient Condition .................................................................................................................................. 8 3.5.2 Test Configuration ................................................................................................................................... 8 4. Specific Absorption Rate (SAR) ...............................................................................................................................10 4.1 Introduction ......................................................................................................................................................10 4.2 SAR Definition .................................................................................................................................................10 5. SAR Measurement System .......................................................................................................................................11 5.1 …
