HLZTD070VA1Tablet Computer

1 Product overview 6 1 2 3 4 5 87 9 10 11 12 1. Front camera 2. Touchscreen 3. Volume key 4. Power button 5. Rear camera 6. Audio jack 7. Microphone 8. microSD card slot 9. Micro USB port 10. Reset pin hole 11. HDMI Micro Connector 12. Speaker * Components may vary. 2 Home screen 1 2 3 45 3 6 Note: Your tablet may have a different wallpaper to the one shown. 1. Search 2. Widgets 3. Application dock 4. Navigation (Back, Home, Recent) 5. Notification area 6. Application menu (also known as "Apps") 3 Getting started Using your tablet 1. Connect the power adapter Charge your tablet for at least four hours. Note: It is normal for the device surface to become warm during charging or long periods of use. 2. Press the power button Hold until you see the Acer logo. Connecting to the Internet via Wi-Fi To connect to a Wi-Fi network, tap Apps, then Settings. Tap Wireless & networks > Wi-Fi settings; if necessary enter a security password to access the network. Your tablet's User's Manual To download the User's Manual, go to www.acer.com and click Support > DRIVERS AND MANUALS. Select the appropriate items from Select Product Family > Select Product Line > Select Product Model. Select the operating system from the pop-up list, and then click Document to find the User's Manual. Restoring to factory settings Open Settings from the application menu, then tap Backup & reset > Factory data reset; tap Reset tablet and then Erase everything to format your tablet. Updating your tablet’s operating system To check for updates, tap APPS > Settings > About tablet > System update > Check now. 4 Safety and comfort SAFETY INSTRUCTIONS Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. Turning the product off before cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. WARNINGS Accessing the power plug Be sure that the power outlet you plug the power cord into is easily accessible and located as close to the equipment operator as possible. When you need to disconnect power to the equipment, be sure to unplug the power plug from the electrical outlet. Mark sure the power plug is fixed at right position with the adaptor before plugging to the socket on the wall. Input rating: Refer to the rating label on the bottom of the computer and ensure that your power adapter complies with the specified rating. Under no circumstances should the user attempt to disassemble the power supply. The power supply has no user-replaceable parts. Inside the power supply are hazardous voltages that can cause serious personal injury. A defective power supply must be returned to your dealer. Using electrical power - If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse rating. - Do not overload a power outlet, strip or receptacle by plugging in too many devices. The overall system load must not exceed 80% of the branch circuit rating. If power strips are used, the load should not exceed 80% of the power strip's input rating. General - Do not use this product near water. - Do not place this product on an unstable cart, stand or table. If the product falls, it could be seriously damaged. - Slots and openings are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heat register, or in a built- in installation unless proper ventilation is provided. - Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or shortout parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product. - To avoid damage of internal components and to prevent battery leakage, do not place the product on a vibrating surface. - Your device and its enhancements may contain small parts. Keep them out of the reach of small children. Product servicing Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel. Unplug this product from the wall outlet and refer servicing to qualified service personnel when: - The power cord or plug is damaged, cut or frayed. - Liquid was spilled into the product. - The product was exposed to rain or water. - The product has been dropped or the case has been damaged. - The product exhibits a distinct change in performance, indicating a need for service. - The product does not operate normally after following the operating instructions. Note: Adjust only those controls that are covered by the operating instructions, since improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal condition. DISPOSAL INSTRUCTIONS Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit www.acer-group.com/public/Sustainability/sustainability01.htm REGULATORY INFORMATION CAUTION when listening To protect your hearing, follow these instructions. - Increase the volume gradually until you can hear clearly and comfortably. - Do not increase the volume level after your ears have adjusted. - Do not listen to music at high volumes for extended periods. - Do not increase …

Text truncated - open the document above for the full version.

FCC INFORMATION (additional) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. RF Exposure: The highest measured Body SAR (1g) value is 1.041 W/kg .
