Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 1 Application Note of 2.4GHz Antenna [Cheetah] Yageo 3216 PIFA mode at 2.4GHz Chip Antenna for Compal Version 04 LTCC R&D, Wireless Components BU 2013/04/17 Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 2 Application Note of 2.4GHz Antenna Purpose Our customer need Yageo to evaluate dual band ceramic chip antenna in 2.4 GHz application. Therefore Yageo carried out an evaluation report for reference. Test condition: (A)Chip antenna information: -Type: 3216 PIFA (3.2 * 1.6 * 1.2 mm) -Part number: CAN4311712112453K -Clearance size: 5 * 6 mm Fig.1 System overview 3216 PIFA Chip antenna Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 3 Application Note of 2.4GHz Antenna 3216 PIFA mode antenna matching circuit: -Shunt: 1 pF[P/N: CC0402CRNP09BN1R0(Yageo)] -Series: 0 ohm -Chip antenna: 3216 PIFA mode (P/N: CAN4311712112453K) Fig.2 Position and Matching Circuit P 3 Matching Circuit Feeding 0 ohm 1 pF 3216 PIFA Chip antenna Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 4 Application Note of 2.4GHz Antenna Antenna Window Improvement To modify antenna window for improving antenna efficiency as do not change original matching circuit value. Fig.3 Original antenna windowFig.4 Original antenna window 33 mm 40 mm Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 5 Application Note of 2.4GHz Antenna -4.02400 2484 2450 Frequency (MHz) 2484 2450 2400 Frequency (MHz) S22 (dB) Modify copper dimension of rear cover -5.8 -9.4 -5.3 -3.4 Original rear cover -8.3 S11 (dB) The Measurement of S-Parameter Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 6 Application Note of 2.4GHz Antenna ETS Chamber Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 7 Application Note of 2.4GHz Antenna Conclusion 43.3-3.6-0.4-9.42484 39.7-4.0-0.3-5.82450 26.7 Efficiency (%) -5.7 Ave. gain (dBi) -2.3 Peak gain (dBi) -4.0 S22 (dB) 2400 Frequency (MHz) Modify copper dimension of rear cover 41.7 38.8 26.2 Efficiency (%) 0.1 -0.2 -2.2 Peak gain (dBi) -4.1-5.32450 -5.8-3.42400 Original rear cover -3.7-8.32484 Ave. gain (dBi) S11 (dB) Frequency (MHz) From the test result, only modify copper of rear cover, thatfrequency bandwidth just has a little shift to lower band. Yageo still suggest customer to change matching circuit as V3 report. Application Note of 2.4GHz Antenna LTCC R&D, Wireless Components BU 2013P 8 Application Note of 2.4GHz Antenna
