FCC ID: I2Z-MH-4000B Report No.: RF900621R02 1 Issued: July 17, 2001 ANNEX PHOTOGRAPHS OF EUT FCC ID: I2Z-MH-4000B Report No.: RF900621R02 2 Issued: July 17, 2001 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 3 Issued: July 17, 2001 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 4 Issued: July 17, 2001 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 5 Issued: July 17, 2001

FCC ID: Label Location

FCC ID: I2Z-MH-4000B Report No.: RF900621R02 6 Issued: July 17, 2001 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 7 Issued: July 17, 2001 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 8 Issued: July 17, 2001

FCC ID: I2Z-MH-4000B ADT No.900621R02 Operational Description This product is the base set of the wireless earphone. It is a transciver and using the rechargeable battery. The voice signal of cellular phone is conducted transmitted into the base set via wire, and the microphone installed in the base set can send the voice to the cellular phone via air.

FCC ID: I2Z-MH-4000B Report No.: RF900621R02 1 Issued: July 17, 2001 FCC TEST REPORT REPORT NO.: RF900621R02 MODEL NO.: MH-4000B RECEIVED: June 21, 2001 TESTED: July 12, 2001 APPLICANT:FAN SHAING ELECTRONICS CO., LTD ADDRESS:No 54 Wu-Chuang RD, WU-KU Industrial Park Taipei Hsien TAIWAN R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 22 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 2 Issued: July 17, 2001 Table of Contents 1CERTIFICATION..............................................................................................3 2SUMMARY OF TEST RESULTS .....................................................................4 3GENERAL INFORMATION..............................................................................5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .................................6 3.4DESCRIPTION OF SUPPORT UNITS ............................................................6 4TEST PROCEDURE AND RESULT ................................................................7 4.1CONDUCTED EMISSION MEASUREMENT...................................................7 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................7 4.1.2 TEST INSTRUMENT .......................................................................................8 4.1.3 TEST PROCEDURE........................................................................................8 4.1.4 TEST SETUP...................................................................................................9 4.1.5 EUT OPERATING CONDITION.......................................................................9 4.1.6 TEST RESULT...............................................................................................10 4.2RADIATED EMISSION MEASUREMENT......................................................12 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...................................12 4.2.2 TEST INSTRUMENT .....................................................................................13 4.2.3 TEST PROCEDURE......................................................................................14 4.2.4 TEST SETUP.................................................................................................15 4.2.5 EUT OPERATING CONDITION.....................................................................15 4.2.6 TEST RESULT...............................................................................................16 4.3BAND EDGES MEASUREMENT ..................................................................18 4.3.1 LIMITS OF BAND EDGES MEASUREMENT ................................................18 4.3.2 TEST INSTRUMENTS...................................................................................18 4.3.3 TEST PROCEDURE......................................................................................18 4.3.4 EUT OPERATING CONDITION.....................................................................18 4.3.5 TEST RESULTS ............................................................................................19 5PHOTOGRAPHS OF THE TEST CONFIGURATION ....................................20 6INFORMATION ON THE TESTING LABORATORIES ..................................22 FCC ID: I2Z-MH-4000B Report No.: RF900621R02 3 Issued: July 17, 2001 1 CERTIFICATION PRODUCT : Wireless earphone base BRAND NAME : MONIX MODEL NO : MH-4000B APPLICANT : FAN SHAING ELECTRONICS CO., LTD STANDARDS : 47 CFR Part 15, Subpart C (15.235), ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on July 12, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: I2Z-MH-4000B Report No.: RF900621R02 4 Issued: July 17, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Minimum passing margin is –18.53dBuV at 0.59700MHz 15.235Radiated Emission TestPASS Minimum passing margin is –10.5dBuV at 448.17MHz 15.235(b)Band Edge TestPASS Meet the requirement of limit NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: I2Z-MH-4000B Report No.: RF900621R02 5 Issued: July 17, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless earphone base MODEL NO.MH-4000B POWER SUPPLY 3.6VDC from battery 9VDC from AC/DC adapter for charged mode of transceiver MODULATION TYPEFM FREQUENCY RANGENA CARRIER FREQUENCY OF EACH CHANNEL 49.845 MHz BANDWIDTH OF EACH CHANNEL NA NUMBER OF CHANNEL1 ANTENNA TYPEWired Antenna DATA CABLENA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The power adapter below was used while the battery of EUT is being charged. Model Name : SCP35-9060 Input Power : 110V 60Hz Output Power : 9VDC 60mA 2. For more detailed features description, please refer to the manufacturer's specifications or the User's Manual. FCC ID: I2Z-MH-4000B Report No.: RF900621R02 6 Issued: July 17, 2001 3.2 DESCRIPTION OF TEST MO…
