Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 103.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesPower output is conducted. This is an OEM module approved for use in products operating as a mobile transmitting device with respect to 2.1091. MPE compliance was demonstrated with a typical antenna as shown in the filing. Final antenna installation and operating configurations of this transmitter including antenna gain and cable loss must not exceed the ERP of the configuration used for MPE testing. Products operating with this module are required to provide a minimum separation distance of at least 20 cm between the antenna and all persons during normal operation. Grantee must coordinate with OEM integrators to ensure the end-users of products operating with this module are provided with operating instructions to satisfy RF exposure requirements. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations.
