IHDP56JM1Portable Cellular/ PCS CDMA Transceiver with Bluetooth

INSTRUCTION MANUAL A preliminary draft of the User’s Manual follows this page. The text on the following 5 pages will be added to the user manual. APPLICANT: MOTOROLA,INC. FCC ID: IHDP56JM1 EXHIBIT 8 Motorola Confidential Proprietary User’s Guide MOTO TM VE465 v558440.eps 8/4/2008 8:19:18 AM 1 HELLOMOTOThanks for purchasing the MOTO TM VE465 CDMA wireless phone! It’s an affordable phone with a sleek design that’s sure to get attention. Impressive Inside and Out — Sleek styling with all the right features, including rich imaging and multimedia. Take pictures and video in a snap with the 1.3 megapixel camera with 4x digital zoom. Listen to your favorite music with the digital music player, and watch your music come to life with stunning visual effects on the large display. Features at Your Fingertips — Without opening the flip you can activate the music player, turn on Bluetooth® power, or quickly mute your phone, using external control buttons. My Phone, My Way – It’s your phone—make it that way. Customize your home screen with personal pictures, change wallpapers, and use your favorite song as your ringtone. 2Here’s a quick anatomy lesson. Left Soft Key Perfor m function in lower left display. C a mer a / C a m c order Key Send Key Make & answer calls. Volume Keys R ig ht Soft Key Perfor m function in lower right display. B ac k Key Power/End KeyTurn phone on/off,end calls, exit m enus. 4-W a y N a v iga t i on Key w i th Center Sele c t Press the center key toopen the m ain m enu. Extern a l D i s p l a y See inco m ing calls & status infor m ation. C a mer a Lens Sm a rt/S p e a ker- p hone Key Vo ic e Key He a d p hones Port M i n i USB Port Insert stereo headset, battery charger, & other accessories. xz y 3 Press and hold the Power Key P for a few seconds, or until the display lights up, to turn on your phone. 1 Press the Navigation Key u p , down, left, or r ig ht ( S ) to highlight a m enu feature. 3 Press the Center Key ( s ) to select it. 4 Press the Center Key to open the M ai n Menu . 2 Home S c reen M ai n Menu Message Tue 05/06/08 1:56pm Contacts MENU Ö Messag i ng Web Browser E Datebook To o l s Sett i ngs Phone Info Phonebook L Recent Calls q Mult i med i a j Mus i c Player Ü m u Û 1X 1X Û BREW à R i ngtones G 4 Motorola, Inc.Consumer Advocacy Office1307 East Algonquin RoadSchaumburg, IL 60196www.hellomoto.comNote: Do not ship your phone to the above address. If you need to return your phone for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at:1-800-331-6456 (United States)1-888-390-6456 (TTY/TDD United States for hearing impaired)1-800-461-4575 (Canada)Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user’s guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other product or service names are the property of their respective owners. © 2008 Motorola, Inc. All rights reserved. Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. Software Copyright NoticeThe Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.Manual Number: 68000201306-A 5 c ontents c ontents menu map . . . . . . . . . . . . . . . . 7Use and Care . . . . . . . . . . . . . . 9get started . . . . . . . . . . . . . . . 10 about this guide . . . . . . . . . 10battery. . . . . . . . . . . . . . . . . 11 basics . . . . . . . . . . . . . . . . . . . 15 status indicators . . . . . . . . . 15external display . . . . . . . . . . 18adjust volume . . . . . . . . . . . 18handsfree . . . . . . . . . . . . . . 18lock & unlock phone . . . . . . 19keypad lock . . . . . . . . . . . . . 20lock side keys & external control buttons . . . . . . . . . . 21lock application . . . . . . . . . . 22codes . . . . . . . . . . . . . . . . . 22if you forget a code . . . . . . . 23 manage memory . . . . . . . . 23TTY operation . . . . . . . . . . . 25airplane mode. . . . . . . . . . . 26 tips & tricks . . . . . . . . . . . . . . 27personalize . . . . . . . . . . . . . . 28 voice readout . . . . . . . . . . . 28key volumes . . . . . . . . . . . . 28alert reminders . . . . . . . . . . 28ring & vibrate . . . . . . . . . . . 28answer options. . . . . . . . . . 29backlight . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDP56JM1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDP56JM1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Don Lemersal TITLE: Engineering Manager Motorola Mobile Devices Business Date: 01-Oct-2008 Page 1 of 5 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56JM1 Page 2 of 5 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56JM1) is in compliance with all applicable parts of the FCC Rules. NAME: Don Lemersal TITLE: Engineering Manager Motorola Mobile Devices Business Date: 01-Oct-2008 APPLICANT: MOTOROLA INC. FCC ID: IHDP56JM1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Don Lemersal TITLE: Engineering Manager Motorola Mobile Devices Business Date: 01-Oct-2008 Page 3 of 5 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56JM1 ATTESTATION STATEMENT Motorola hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance for FCC ID: IHDP56JM1. Model and Features FCC ID: IHDP56JM1 Model Number: VE465 Key Features: • CDMA800 & 1900 • EV-DO release 0 • Handsfree Speaker • Voice Commands • Talking Pho ne • Photo Camera • Video Camera • Video Player • Stereo Bluetooth • Music Player • HTML Browser • Text Messaging NAME: Don Lemersal TITLE: Engineering Manager Motorola Mobile Devices Business Date: 01-Oct-2008 Exhibit 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56JM1 Page 5 of 5 EXHIBIT 2 911 Call Processing Method Compliance Statement Method Used Pursuant to 47 CFR Sec. 22.921, this Motorola CDMA phone at the time of commercial distribution will use a call completion method for 911 calls that is approved or endorsed by the FCC. At this time Motorola intends that this phone will incorporate either the Automatic A/B-Intelligent Retry method or the Automatic A/B-Intelligent Retry, Version 2 method for providing 911 emergency calling support. NAME: Don Lemersal TITLE: Engineering Manager Motorola Mobile Devices Business Date: 01-Oct-2008

APPLICANT: MOTOROLA FCC ID: IHDP56JM1 August 30, 2008 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular/PCS Transceiver, FCC ID: IHDP56JM1. Confidentiality : Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in both the 800 MHz and the 1900 MHz PCS bands. The unit also contains a 2.4 GHz Bluetooth transmitter (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDP56J M1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: November 6, 2008 Subject: Request for additional information regarding FCC ID: IHDP56JM1 Reference: Correspondence Reference Number: IHD80846 Confirmation Number: 809090846-8 Date of Original Email: November 4, 2008 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Key Features list does not appear to represent the application in question. It shows GSM modes. Please clarify. Response: Please refer to revised exhibit 2 attached. 2. Please clarify about the operations of the secondary PCS/AWS antenna. It is not addressed for EMC or SAR. Response: The "secondary antenna" is receive only, as described on page 11 of the operational description exhibit. 3. Schematics contain an incorrect FCC ID (first character). Please amend. Response: Please refer to revised exhibit 5. 4. Final SAR reading in the Users Manual is incorrect. Please amend to match data given in Exhibit 11 (SAR Report). Response: Please refer to revised exhibit 8 attached. 1 2 5. Please include the SAR result for left cheek using the SNN5782A and SNN5813A battery with the mid and high channels. It appears the SAR may be higher, than what was measured for the other channels. Response: Please refer to revised SAR report attached. We actually did test them at high channel on Left cheek since the high channel had the highest. The SAR data on high channels are reported in the tables on page 9 and 10. 6. Please update band edge markers with values at the limit (i.e. 824 MHz and 849 MHz) in Exhibit 6, page 11. Response: As allowed in 22.917(b), a narrow resolution bandwidth was used to improve measurement accuracy and the measured power was integrated over the full required measurement bandwidth. The markers refer to the adjacent narrow bandwidth channels which are properly aligned to the actual band edges. 7. Schematics indicate AWS band is available. Please clarify for this application. Response: The AWS band is not applicable in this submission. 8. BT plots indicate 22282-1 as the device reference but the report indicates 22299- 1BT. Please clarify for the plots contained in Exhibit 6A1. Response: Motorola confirms that the device reference “22282-1” in the plots is applicable to test report 22299-1BT (Exhibit 6A1).

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 EXHIBIT 3 1 0F 3 FRONT OF PHONE BACK OF PHONE FLIP OPEN APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 FRONT OF PHONE BACK OF PHONE EQUIPMENT ID LABEL LOCATION BACK OF PHONE WITH BATTERY COVER REMOVED EXHIBIT 3 2 OF 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 EXHIBIT 3 3 OF 3 LEFT SIDE OF PHONE FLIP CLOSED RIGHT SIDE OF PHONE FLIP OPEN RIGHT SIDE OF PHONE FLIP CLOSED LEFT SIDE OF PHONE FLIP OPEN

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 Main Board Bottom Without Shields Main Board Bottom With Shields EXHIBIT 9 1 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 Main Board Top Without Popples Main Board Top With Popples EXHIBIT 9 2 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 EXHIBIT 9 3 of 4 Flip Board Flip LCD APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JM1 EXHIBIT 9 4 of 4 Inside Back Housing Inside Front Housing
