IHDP56KX1Portable PCS GSM/ EDGE Transceiver with WLAN and Bluetooth

APPLICANT MOTOROLA INC. FCC ID: IHDP56KX1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 User’s Guide MOTO MT710 TM 1 Congratulations CongratulationsMOTOROLA MT710 The MOTOROLA MT710 lets you multi-task, so you spend less time managing your life and more time living it.• Don’t miss your favorite program, watch TV when and where you want (“Mobile TV” on page 28). • Surf the Internet, to your heart’s content (“Web” on page 29). • Enjoy yourself with powerful features, such as, Fetion , 139Mail , Monternet , DCD , and Mobile Stock (“Apps for all” on page 31). • Instant access to messages, email, and IM. • Back up all your information and relax (“Synchronize” on page 36). Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your phone. Your phonethe important keys & connectors Power Key Press to put the display to sleep, or hold to turn off. OMTP 3.5mm He a dset J ac k * Home KeyB ac k Key M ic ro p hone Menu Key M ic ro USB Conne c tor Charge or connect to PC. Not i f ica t i on LED On=Charged. Flashing=New notification. Volume Keys F a vor i tes Key Stylus a nd St a nd To u c hs c reen C a mer a Key * If you use a wired headset with built-in m icrophone, you'll need to use an OMTP ( Open Mobile Ter m inal Platfor m ) co m pliant headset such as the Motorola SJYN0182A. Look for the OMTP logo shown here, or go to www. m otorola.co m /wired for additional infor m ation. 2 Let’s go contentsYour phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 4Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 32Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 34Synchronize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 40Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 41 Let’s golet’s get you up and runningAssemble & charge Caution: Please read the battery use and safety text at the back of this guide. 1 cover off 2 SIM in 3 battery in 4 microSD in 5 cover on 6 charge up 3H 3 Let’s go Turn it on & offTo turn on your phone, press Power (on the top right).To turn off your phone, press and hold Power , then tap Power off in the menu that opens. Tip: When charging, press and hold Power to exit charging mode. Wi-Fi connectIf you want to use a Wi-Fi network for even faster Internet access, press Home > Settings > WLAN settings . Tap WLAN to turn on, search for and connect to wireless networks. There’s more in “Wi-Fi” on page 33. Cool content & moreBrowse and download thousands of the coolest apps on the planet from the Internet. On top of that, you get a full HTML browser, so you can surf in style.Download new apps with “Web” on page 29. Your phone comes with 512 MB of internal memory, and an optional microSD memory card (upto 16 GB) can be installed—you can load it up with photos, videos, and music from your computer using “USB drag & drop” on page 34. SecurityThere are plenty of ways to protect your phone and your information, in “Security” on page 38.Stylus & standSlide the stylus out and use to tap the touchscreen. Turn the phone on its side (red edge down), then insert the stylus and place on your desk, to watch mobile TV or a slideshow of your photos. Phone Given name Family name Phone Home Home Email Email IM Phon hon ee Given name Family nameFamily n ame Phone hone Home HomHome Email EmaiEmai ll IMI M IM me E 4 Touchscreen & keys Touchscreen & keysa few essentialsTouch tipsHere are some tips on how to navigate around your phone.Ta pTo choose an icon or option, Ta p it. Try it: In the home screen, tap Contacts . Tip: You can use your finger to tap the touchscreen.Tap & holdTo open special options, tap and hold an icon or other item. Try it: In the home screen, tap Contacts , then tap and hold a contact to open options. Browser Phone Messaging Contacts Phonebook... Monternet Navigation My Favorites DragTo scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, tap Contacts , then drag your contacts list up or down.Tip: When you drag or flick a list, a scroll bar appears on the right. Drag the scroll bar to move the list to a letter A-Z.FlickTo scroll through a list or move quickly, flick across the touchscreen (drag quickly and release).Tip: When you flick a long list, tap the screen to stop it from scrolling. Key tipsMenu, home, & backPress Home to close any menu or app and return to the home screen. Press B Home Key B ac k Key Menu …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDP56KX1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDP56KX1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Qian Chen TITLE: Engineering Manager Motorola Mobile Devices Business Date: 20091202 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56KX1 Page 2 of 3 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56KX1) is in compliance with all applicable parts of the FCC Rules. NAME: Qian Chen TITLE: Engineering Manager Motorola Mobile Devices Business Date: 20091202 APPLICANT: MOTOROLA INC. FCC ID: IHDP56KX1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Qian Chen TITLE: Engineering Manager Motorola Mobile Devices Business Date: 20091202 Page 3 of 3 EXHIBIT 2

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KX1 September 16, 2009 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDP56K X1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM transceiver operating in the 900, 1800 and 1900 MHz PCS band, it also has the capability to operate in the TD-SCDMA standard in both the 2010 and 2025 MHz band. The unit also contains a 2.4 GHz Bluetooth and 802.11b&g functions(Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KX1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDP56K X1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: December 14, 2009 Subject: Request for additional information regarding FCC ID: IHDP56KX1 Reference: Correspondence Reference Number: IHD91367 Confirmation Number: 911091367 Date of Original Email: December 3, 2009 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Please provide a detailed Bluetooth block diagram including the values of all clocks/oscillators. Response: Please refer to the revised BT block diagram on EX04 submitted online. 2. The Exhibit 12 operational description includes Cellular band GSM and UMTS features of the Snapper TD (MT710). Please confirm that these are not implemented in the EUT. Response: Cellular band GSM and UMTS are not implemented in this EUT. Please refer to the revised Operational Description EX12 submitted online. 3. Please provide the Bluetooth antenna peak gain. Response: Please refer to the revised BT report EX6A1 submitted online to address the antenna gain issue. 4. Please change the results of the ERP test on page 4 to N/A in the Part 24 report (Exhibit 6). Response: Please refer to the revised EMC report EX06 submitted online. 1

Applicant: Motorola,Inc. FCC ID: IHDP56KX1 Front of phone Back of phone Back of phone with battery cov er removed EXHIBIT 3 Applicant: Motorola,Inc. FCC ID: IHDP56KX1 Side of phone Top of phone Bottom of phone EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDP56KX1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDP56KX1

FCC ID: IHDP56KX1 Main PCB top with shields Main PCB top without shields APPLICANT: MOTOROLA, INC. EXHIBIT 9 FCC ID: IHDP56KX1 Main PCB bottom with shields Main PCB bottom without shields APPLICANT: MOTOROLA, INC. EXHIBIT 9 FCC ID: IHDP56KX1 Inside front housing Inside back housing APPLICANT: MOTOROLA, INC. EXHIBIT 9

APPLICANT: MOTOROLA LTD FCC ID: IHDP56KX1 Test Report Number: 23288-2 Supplement 1 of 9 EXHIBIT 6A4 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23288-2 Supplement Report Date – 2009-09-10 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2009-09-02 to 2009-09-10 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated. Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2009-09-15 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA LTD FCC ID: IHDP56KX1 Test Report Number: 23288-2 Supplement 2 of 9 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA LTD FCC ID: IHDP56KX1 Test Report Number: 23288-2 Supplement 3 of 9 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola (China) Technologies Ltd. Asia Global Compliance Labs No. 1 Wang Jing East Road, Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola (China) Technologies Ltd. Mobile Devices Business No.1 Wang Jing East Road, Chao Yang District Beijing, 100102, P. R. China Product Type: Cellular Phone Signaling Capability: GSM 900/1800/1900, TD-SCDMA 2010/2025, Standalone GPS/aGPS, Bluetooth, Version 2.0+EDR, 802.11b/802.11g FCC ID: IHDP56KX1 IMEI: 35669403005003, 35669403005004 Testing Complete Date: 09-10-2009 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI C63.4: 2003, RSS-Gen APPLICANT: MOTOROLA LTD FCC ID: IHDP56KX1 Test Report Number: 23288-2 Supplement 4 of 9 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4: 2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA LTD FCC ID: IHDP56KX1 Test Report Number: 23288-2 Supplement 5 of 9 EXHIBIT 6A4 Equipment List Through the test, the EUT was installed in an evaluation board. Equipment Model/type Serial number Operational range Date of calibration EMI analyzers ESU 40 100036 20 Hz – 40 GHz 12.11.2008 PA-02-0001: 2007343 (10 kHz – 3 GHz) 06.26.2009 PA-02-218 2007344 3 GHz – 18 GHz 06.26.2009 Pre Amplifiers PA-02-5 2007345 18 GHz – 40 GHz 06.26.2009 Radio com. Tester CMU 200 112790 GSM 850/900/1800/1900 UMTS, CDMA, Bluetooth N/A WRCD N/A GSM 850/900/1800/1900 UMTS, CDMA N/A Band Reject Filter 4N45-24241/3/6 N/A WLAN N/A EMI analyzers R&S ESCI 100650 9 kHz – 3 GHz 12.11.2008 LISN ENV216 100055 9 kHz – 30 MHz 12.16.2008 The antennas used in the various tests are listed in the below table. Antenna Type Serial number Operational range Date of calibration Hybrid-log periodic TDK HLP 3003C 130361 30 MHz – 3 GHz 11.07.08 Double ridged Horn TDK HRN0118130303 1 GHz – 18 GHz 03.26.09 Double ridged Horn ETS HRN3116 0007193818 GHz – 40 GHz 10.17.08 All test equipment was within their calibration date during the time of testing. When equipment went out of calibration during testing it was replaced using a similar piece of calibrated equipment. All these equipments are listed in the equipment list. The Dell 610 Laptop Computer, SSK Card Reader and the Sony D-600 L Camera are labeled as DoC. APPLICANT: MOTOROLA LTD FCC ID: IHDP56KX1 Test Report Number: 23288-2 Supplement 6 of 9 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a Styrofoam table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain, and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (1/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4: 2003. The EUT was connected to a laptop computer using a USB data cable. The USB data cable is 1 m in length. The parallel and the serial ports of the computer were populated. The EUT was communicating with the laptop computer continuously. APPLICANT: MOTOROLA LTD FCC ID: IH…

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions Radiated Emissions – Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDP56KC4 EXHIBIT 7 AC Line Conducted Emissions AC Line Conducted Emissions – Computer Perihperal APPLICANT: MOTOROLA, INC.FCC ID: IHDP56KC4 EXHIBIT 7
