IHDP56KZ1Portable Cellular/ PCS GSM/ EDGE AWS WCDMA Transceiver with WLAN and Bluetooth

APPLICANT MOTOROLA INC. FCC ID: IHDP56KZ1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 FOCUS ONWHAT MATTERS. MOTOROLA ZEPPELIN™ with MOTOBLUR ™ 1 Congratulations CongratulationsMOTOROLA ZEPPELIN with MOTOBLURMOTOROLA ZEPPELIN with MOTOBLUR is the first touch tablet with social skills.• Streamlined Messaging: Sync messages, feeds and updates from your office to today’s most popular social sites. • Contacts Connected: Contact updates are delivered automatically without your raising a finger. • More Web: The enhanced browser lets you see more of the Web, while pinch-and-zoom and front-nav-pad features give you more control of it. • Music Connectivity: The music player directly connects online for instant music, such as Internet radio; Widgets and applications let you share preferences and see lyrics. Caution: Before assembling, charging or using your phone for the first time, please read the Safety, Regulatory, & Legal Information provided with your phone. Once your phone is up and running, press Menu > Settings > About phone > Safety & regulatory to read the full information. More informationOn your phone —> My Account . On any phone —Call 1-800-734-5870. On your computer —Go to www.motorola.com/support/MB501 . After you create a MOTOBLUR account, you can also log in and find help with MOTOBLUR: www.motorola.com/mymotoblur . So, whether you want to talk, read, watch, or play, we can help. 2 Your phone Your phone Trevor GilleyBlack turtleneck and a beret, and he thought I was serious?5 min ago 298 minutes away from cake. 15 min ago Browser Vanessa EskridgeUltra secret double-agent party agenda LondonPartly Sunny 20 ̊ 11:35 3G Market B M arket ̊ Power Key Press to put the display to sleep, or hold to turn off. OMTP 3.5mm He a dset J ac k Home KeyB ac k Key M ic ro p hone Se a r c h Key M ic ro USB Conne c tor Charge or connect to PC. Not i f ica t i on LED On=Charged Flashing= Charging or notification Volume Keys To u c hs c reen C a mer a Key Menu Key * If you use a wired headset with built-in m icrophone, you'll need to use an OMTP ( Open Mobile Ter m inal Platfor m ) co m pliant headset such as the Motorola OH15. Look for the OMTP logo shown here, or go to www. m otorola.co m /wired for additional infor m ation. Tip: To change the Notification LED, press Menu > Settings > Display & security > Notification LED . To change your home screen, see “Set up & manage your home screen” on page 7.Note: Your phone might look a little different. 11:35 3G Enter message here DeleteReturn S pac e Sym b ols Sh i ft W hen you turn your phone, the ho m e screen adjusts for you. To open the display keypad, toucha text field, or press and hold MenuTo close the keypad, press Back 3 Contents ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12MOTOBLUR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 14Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16myFaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19Contacts & Mobile Backup . . . . . . . . . . . . . . . . . . . 21Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25Voicemail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28Personalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Camera & video recorder . . . . . . . . . . . . . . . . . . . . 31Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Web browsing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42Android Market™ . . . . . . . . . . . . . . . . . . . . . . . . . . 44Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44Voice Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47Bluetooth® wireless . . . . . . . . . . . . . . . . . . . . . . . . 47Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48Memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 57Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 58 Let’s golet’s get you up and runningAssemble & charge 1 cover off 2 SIM in 3 battery in 4 microSD in (already done) 5 cover on 6 charge up 3H 4 Let’s go Caution: Please read the battery use and safety text in the Safety, Regulatory & Legal guide provided with your phone.Tip: To save battery life, see “Battery tips” on page 13. Set up & goCreate or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on page 14. Registration is secure, and should only take a few minutes: 1 Turn on. 2 Select a language.Tip: For product support, you can touch Emergency Call and dial 611. After you sign in, your phone imports your contacts from your T-Mobile Mobile Backup 3 Register or log in.Tip: Touch a text field to open the touchscreen keypad. If you have not created a MOTOBLUR account, you’ll need to register: Enter your name, your current email address (where MOTOBLUR can send account information), and a new MOTOBLUR account password. 4 Add your accounts. To add an account, touch it and enter the user name or email and password that you set up on that account.Tip: For more, or to add accounts anytime, go to “Add accounts” on page 15. MOTOBLUR ID: Enter email add…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDP56KZ1) has been tested in accordance with the requirements contained in the appropriate Commission regulations . To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Chad Kurszewski TITLE: Engineering Manager Motorola Mobile Devices Business Date: 12/12/2009 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56KZ1) is in compliance with all applicable parts of the FCC Rules. NAME: Chad Kurszewski TITLE: Engineering Manager Motorola Mobile Devices Business Date: 12/12/2009 Page 2 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1)  The hopping sequence must be pseudorandom  All Channels are used equally on average  The receiver input bandwidth is approximately equal to the transmit bandwidth  The receiver hops in sequence with the transmitted signal  15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Chad Kurszewski TITLE: Engineering Manager Motorola Mobile Devices Business Date: 12/12/2009 Page 3 of 3 EXHIBIT 2

APPLICANT: MOTOROLA FCC ID: IHDP56KZ1 Exhibit 13 December 24, 2009 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiv er, FCC ID: IHDP56K Z1. Motorola is also the manufacturer of this equipment. Confidentiality : Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, wh ich operates in the 850, 900,1800 and 1900 MHz PCS band. It also operates in WCDMA 900, 1700 and 2100 MHz and contains EDGE/GPRS Class 12 and a 2.4 GHz Bluetooth and 802.11b&g functions (Part 15.247). The unit may also be connected to a computer via a USB connection (Part 15 Class B Computing Device Peripheral). Note: This device also contains functions that are not operational in U.S. territories. This filing is only applicable for US operations. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDP56K Z1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: February 3, 2010 Subject: Request for additional information regarding FCC ID: IHDP56KZ1 Reference: Correspondence Reference Number: IHD91486 Confirmation Number: 912101486-9 Date of Original Email: January 22, 2010 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. In the PCE, DTS, DSS and JBP test reports, multiple pieces of test equipment are listed as being past cal due with no replacement equipment listed. Please address. Response: Please refer to all the revised PCE, DTS, DSS and JBP test reports submitted online. 2. Please specify the settings (RBW, VBW, detector function) used to make the cellular and PCS GSM and EDGE bandedge measurements. Response: Please refer to the revised EMC report submitted online. 3. Please provide plots demonstrating compliance with the 13 PAR limit for the PCS (GSM and EDGE) and AWS WCDMA emissions (p.8 of the PCE EMC test report states that an average detector was used to make the EIRP measurements, hence, this is required). Response: Please refer to the cellular EMC report submitted online. 4. Please confirm the detector used to make the output power measurements in the DTS test report. I note that the top of p.13/40 states “PEAK”, but an average detector 1 2 was apparently active in the first plot. In addition, the oob limit (as shown by the DL) is not consistent- it is 20 dBc in some plots and 30 dBc in others. The specific limit for which compliance is being tested should always be clearly explained in the test report. Response: Please refer to revised DTS report submitted online. 5. Please provide DTS peak field strength data for the restricted bands near each bandedge (only average f.s. plots were provided). Response: Please refer to the DTS report submitted online. 6. Please specify the DTS data rate used to perform SAR measurements. Response: Please refer to the updated SAR report submitted online. 7. Please provide the additional DTS (low and hi) channel SAR measurement data as specified in the FCC’s 802.11 SAR testing procedure. Response: Please refer to the updated SAR report submitted online. 8. Please provide DTS output power measurement data at all data rates prescribed in the FCC’s 802.11 SAR testing procedure, so that the proper configurations for SAR testing may be determined (only 802.11b 11 Mbps and 802.11g 54 Mbps conducted output power data is provided in the DTS test report). Response: Please refer to the updated SAR report submitted online. 9. The SAR probe used for PCS (and AWS) testing was calibrated at a point more than 50 MHz from the measured band. The tissue parameters for PCS head measurements on 12-13-09 do not meet the tighter requirements for this condition. Please provide compensated results for PCS head SAR measurements performed on this day. Response: Please refer to the updated SAR report submitted online. 10. FYI: in the future, it would be most helpful if tabular data for the DTS and DSS radiated emissions was provided- this would greatly speed up the technical review (one or 2 tables, instead of dozens of plots). Response: Noted.

From: Lillian Li Sent: Friday, February 12, 2010 1:03 PM To: PCTEST TCB/CB; Subject: Re: Follow-Up Questions Regarding FCC ID: IHDP56KZ1 H i Greg, again :-) We have tested SAR again and revised full SAR report. Please find our response to your questions below and attached, and let us know if you have any further questions. RE: FCC ID: IHDP56KZ1 Applicant: Motorola Inc. Correspondence Reference Number: IHD091486 -A Co nfirmation Number: 912101486-9 Date of Original Email: February 4 , 2010 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1 . Thank you for your email. Regarding your response to question #1, the revised DTS and DSS test reports referenced were not submitted- please do so (only the revised DSS and DTS radiated emission reports were submitted). Response: Please refer to the DTS & DSS conducted reports submitted online on Feb. 5. 2. Regarding your response to question #1, the revised PCE EMC report lists a n ew testing completion date. Based on this, the environmental chamber shown in the equipment list was past its cal due date at the time of testing. Please address. Response: Ple ase refer to the revised EMC report submitted online on Feb.5. 3. Regarding your response to question #4, the revised DTS report was not s ubmitted (see #1, above). Please submit it. Response: DTS conducted report submitted online on Feb.5. 4. Regarding your response to question #7, based on the DTS output power data on p.9/90 of the revised SAR report, FCC procedure requires that the following channel / data rates be tested for SAR: Ch 1: 1 Mbps, 5.5 Mbps Ch 6: 1 Mbps Ch 11: 1 Mbps, 2 Mbps, 5.5 Mbps All of these are in 802.11b mode. Please provide this additional SAR data. Response: Please refer to the revised SAR report (rev.B) attached. Th anks! Lillian Li Certification and Approvals

Back side view Front view APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 3 Backside view without battery/battery door APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 3 Right side view Left side view APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 3 lower side view Upper side view APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDP56KZ1

ICB Top Side ICB Bottom Side APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 9 Main PCB Top Side Main PCB Bottom Side APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ1 EXHIBIT 9

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. A FCC ID: IHDP56KZ1 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 23494-2F Rev. A Date of Report: Feb-02-2010 Date of Test: Dec-02-2009 to Dec-22-2009, Jan-15-2010 to Jan-27-2010 FCC ID #: IHDP56KZ1 Generic Name: MVTQ4-3334411B11 Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Thomas Knipple Senior RF Engineer Accreditation: TESTING CERT #2518-02 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. A FCC ID: IHDP56KZ1 Exhibit 11 Page 2 of 18 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 10 6.2 Body Worn Test Results 14 References 18 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. A FCC ID: IHDP56KZ1 Exhibit 11 Page 3 of 18 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1 g average set in [3] and 2.0 W/kg in a 10 g average set in [2]. For ANSI / IEEE C95.1 (1 g), the final SAR reading for this phone is 1.20 W/kg for head-adjacent use and 0.93 W/kg for body-worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. A FCC ID: IHDP56KZ1 Exhibit 11 Page 4 of 18 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of Transceiver Dimensions Length 130 mm Width 13 mm Configuration EB-FICA 2.2 Device description Serial Number(s) TA1130011W, TA113000VH, TA113000VR Mode(s) of Operation GSM 850 GSM 900 GSM 1800 GSM 1900 WCDMA 900 WCDMA 1700 WCDMA 2100 Wi-Fi 802.11b/g Bluetooth Modulation Mode(s) GSMK GSMK GSMK GSMK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 32.5 dBm 33.0 dBm 30.5 dBm 31.5 dBm 24.0 dBm 24.5 dBm 24.0 dBm 22 dBm 10 dBm Duty Cycle 1:8 1:8 1:8 1:8 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz 826.4 - 846.6 MHz 1712.4 - 1752.6 MHz 1922.4 - 1977.6 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Mode(s) of Operation GPRS 850 GPRS 900 GPRS 1800 GPRS 1900 Modulation GMSK GMSK GMSK GMSK Maximum Output Power Setting 32.5 30.5 28.5 26.5 33.0 31.0 29.0 27.0 30.5 28.5 26.5 24.5 31.5 29.5 27.5 25.5 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Mode(s) of Operation EDGE 850 EDGE 900 EDGE 1800 EDGE 1900 Modulation 8PSK 8PSK 8PSK 8PSK Maximum Output Power Setting 27.5 25.5 23.5 21.5 28.0 26.0 24.0 22.0 27.0 25.0 23.0 21.0 28.0 26.0 24.0 22.0 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Note: Bolded entries indicate data mode configurations of highest time-average power output per band and data mode type. MOTO…

Text truncated - open the document above for the full version.

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. B FCC ID: IHDP56KZ1 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 23494-2F Rev. B Date of Report: Feb-12-2010 Date of Test: Dec-02-2009 to Dec-22-2009, Jan-15-2010 to Jan-27-2010, Feb-08-2010 to Feb-11-2010 FCC ID #: IHDP56KZ1 Generic Name: MVTQ4-3334411B11 Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Thomas Knipple Senior RF Engineer Accreditation: TESTING CERT #2518-02 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. B FCC ID: IHDP56KZ1 Exhibit 11 Page 2 of 18 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 10 6.2 Body Worn Test Results 14 References 18 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. B FCC ID: IHDP56KZ1 Exhibit 11 Page 3 of 18 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1 g average set in [3] and 2.0 W/kg in a 10 g average set in [2]. For ANSI / IEEE C95.1 (1 g), the final SAR reading for this phone is 1.20 W/kg for head-adjacent use and 0.93 W/kg for body-worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23494-2F Rev. B FCC ID: IHDP56KZ1 Exhibit 11 Page 4 of 18 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of Transceiver Dimensions Length 130 mm Width 13 mm Configuration EB-FICA 2.2 Device description Serial Number(s) TA1130011W, TA113000VH, TA113000VR, 358338030005955 Mode(s) of Operation GSM 850 GSM 900 GSM 1800 GSM 1900 WCDMA 900 WCDMA 1700 WCDMA 2100 Wi-Fi 802.11b/g Bluetooth Modulation Mode(s) GSMK GSMK GSMK GSMK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 32.5 dBm 33.0 dBm 30.5 dBm 31.5 dBm 24.0 dBm 24.5 dBm 24.0 dBm 22 dBm 10 dBm Duty Cycle 1:8 1:8 1:8 1:8 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz 826.4 - 846.6 MHz 1712.4 - 1752.6 MHz 1922.4 - 1977.6 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Mode(s) of Operation GPRS 850 GPRS 900 GPRS 1800 GPRS 1900 Modulation GMSK GMSK GMSK GMSK Maximum Output Power Setting 32.5 30.5 28.5 26.5 33.0 31.0 29.0 27.0 30.5 28.5 26.5 24.5 31.5 29.5 27.5 25.5 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Mode(s) of Operation EDGE 850 EDGE 900 EDGE 1800 EDGE 1900 Modulation 8PSK 8PSK 8PSK 8PSK Maximum Output Power Setting 27.5 25.5 23.5 21.5 28.0 26.0 24.0 22.0 27.0 25.0 23.0 21.0 28.0 26.0 24.0 22.0 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8…

Text truncated - open the document above for the full version.
