IHDP56KZ2Portable Cellular/ PCS WCDMA/ GSM/ EDGE Transceiver with WLAN and Bluetooth

APPLICANT MOTOROLA INC. FCC ID: IHDP56KZ2 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 FOCUS ONWHAT MATTERS. MOTOROLA QUENCH™ with MOTOBLUR ™ 1 Congratulations CongratulationsMOTOROLA QUENCH with MOTOBLUR MOTOROLA QUENCH with MOTOBLUR is the first touch tablet with social skills.• Streamlined Messaging: Sync messages, feeds and updates from your office to today’s most popular social sites. • Contacts Connected: Contact updates are delivered automatically without your raising a finger. • More Web: The enhanced browser lets you see more of the Web, while pinch-and-zoom and front-nav-pad features give you more control of it. • Music Connectivity: The music player directly connects online for instant music, such as Internet radio; Widgets and applications let you share preferences and see lyrics. Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your phone. Once your phone is up and running, press Menu > Settings > About phone > Safety & regulatory to read the full information. More informationOn your phone —Touch > Help Center . You can also flick your home screen left or right to see two widgets called Getting Started and Tips & Tr i c k s . Touch them for helpful advice. On your computer —Go to www.motorola.com/support/quench . After you create a MOTOBLUR account, you can also log in and find help with MOTOBLUR: www.motorola.com/mymotoblur So, whether you want to read, watch, or play, we can help. 2 Your phone Your phone 15 minutes ago Barry SmythCheck out my gig on Friday night. 2 minutes ago Browser Market Br Mar ket Mary MorganMy coffee is broken. Doesn’t seem to be doing the trick today.5 minutes ago Rocking out to "I Stand for Nothing" by The Ropes, can't wait for the show tomorrow. 11:35 3G Power Key Press to put the display to sleep, or hold to turn off. OMTP 3.5mm He a dset J ac k Home KeyB ac k Key M ic ro p hone Se a r c h Key M ic ro USB Conne c tor Charge or connect to PC. Not i f ica t i on LED On=Charged Flashing= Charging or notification Volume Keys To u c hs c reen C a mer a Key Menu Key * If you use a wired headset with built-in m icrophone, you'll need to use an OMTP ( Open Mobile Terminal Platform ) co m pliant headset such as the Motorola OH15. Look for the OMTP logo shown here, or go to www. m otorola.co m /wired for additional infor m ation. Note: Your phone might look a little different. Tip: To change the Notification LED, press Menu > Settings > Display & security > Notification LED . Set your status Post Done 11:35 3G is heading to Matt's birthday party. 15 minutes ago has hired Kat Bleser as his Music Advisor. And in return she gets dating advice. 1 day ago is so glad he doesn't have a paper to write! 2 days ago , . Q W ASDFGH J K ZXCVBNM L ERT YUIOP ?123 Enter message here Set your status Post Done 11:35 3G is heading to Matt's birthday party. 15 minutes ago has hired Kat Bleser as his Music Advisor. And in return she gets dating advice. 1 day ago is so glad he doesn't have a paper to write! 2 days ago , . Q W ASDFGH J K ZXCVBNM L ERT YUIOP ?123 Enter message here Send To: ?123 . , QW ASDFGHJ K ZXCVBNM L ERTYUIOP Enter message here 11:35 3G Delete Return Tou c h P a d Num b ers/ Sym b ols Sh i ft W hen you turn your phone, the keypad adjusts for you. S pac e To open the display keypad, touch a text field, or press and hold Menu.To close the keypad, press Back. 3 Let’s go ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7App menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 26Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 38Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Memory card & file transfer . . . . . . . . . . . . . . . . . . 40Synchronize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 49Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 50 Let’s golet’s get you up and runningAssemble & charge 1 cover off 2 SIM in 3 battery in 4 microSD in (already done) 5 cover on 6 charge up 3H 4 Let’s go Caution: Please read the battery use and safety text in the important legal and safety information packaged with your phone.Tip: To save battery life, see “Battery tips” on page 23. Set up & goCreate or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ2 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDP56KZ2) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my know ledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Chad Kurszewski TITLE: Engineering Manager Motorola Mobile Devices Business Date: 1/12/2010 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this applic ation was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56KZ2) is in compliance with all applicable parts of the FCC Rules. NAME: Chad Kurszewski TITLE: Engineering Manager Motorola Mobile Devices Business Date: 1/12/2010 Page 2 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1)  The hopping sequence must be pseudorandom  All Channels are used equally on average  The receiver input bandwidth is approximately equal to the transmit bandwidth  The receiver hops in sequence with the transmitted signal  15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Chad Kurszewski TITLE: Engineering Manager Motorola Mobile Devices Business Date: 1/12/2010 Page 3 of 3 EXHIBIT 2

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDP56KZ 2 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: February 11, 2010 Subject: Request for additional information regarding FCC ID: IHDP56KZ2 Reference: Correspondence Reference Number: IHD100143 Confirmation Number: Y1002040143-46 Date of Original Email: February 05, 2010 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Multiple pieces of test equipment in the PCE EMC and DSS test reports are listed as being past their cal due date at the time of testing, with no replacement equipment listed. Please address. Response: Please refer to the revised PCE, DSS test reports submitted online on Feb.5. 2. Please confirm the detector used to make the output power measurements in the DTS test report. I note that the top of p.13/40 states “PEAK”, but an average detector was apparently active in the first plot. In addition, the oob limit (as shown by the DL) is not consistent- it is 20 dBc in some plots and 30 dBc in others. The specific limit for which compliance is being tested should always be clearly explained in the test report. Response: Please refer to the revised DTS test report submitted online on Feb. 5. 3. Please provide Average conducted output power measurement data for the DTS at the various data rates and channels specified in the FCC IEEE 802.11 SAR testing procedures. Please use this data to determine the required data rates to be tested for each channel and submit any missing SAR data as well. Response: Please refer to the SAR Supplement Response attached. 1 2 4. FYI: please note that the maximum PCS GSM head SAR value is scaled by more than 5% from the actual measurement, and its power drift exceeds 5%, neither of which is permitted. In the future, please be sure to address these issues. Response: Noted. 5. FYI: In the future, please include a copy of the KDB response from the FCC where they accepted your explanation re your implementation of MPR in WCDMA operation as sufficient to permit SAR test reduction for this mode. Response: Noted.

Back side view Front view APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 3 Backside view without battery/battery door APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 3 Right side view Left side view APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 3 lower side view Upper side view APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDP56KZ2 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDP56KZ2

ICB Top Side ICB Bottom Side APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 9 Main PCB Top Side Main PCB Bottom Side APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDP56KZ2 EXHIBIT 9

APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 1 of 10 EXHIBIT 6A4 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23558-1 Supplement Report Date – January 21, 2010 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Thanigaiselvan Palaniswami Title: EMC Engineer Date: January 21, 2010 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 2518-02 APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 2 of 10 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 3 of 10 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola MDb FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC109O-1 Tests Requested By: Motorola Inc. Mobile Devices business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 850 & 1900, EDGE 850 & 1900, WCDMA 850 & 1900, Bluetooth, WLAN FCC ID: IHDP56KZ2 Serial Numbers: TA1130013C, TA113000Z7 Testing Complete Date: December 11, 2009 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI 63.4 2003, RSS-210 Issue 7 APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 4 of 10 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4 2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 5 of 10 EXHIBIT 6A4 Equipment List Manufacturer Equipment Type Model No. Serial Number Calibration Due Date Rohde Schwarz Receiver ESIB40 100226 1/30/10 Rohde & Schwarz Receiver ESIB26 100001 12/02/10 Rohde Schwarz Receiver ESI26 838786/010 5/01/10 ETS DRG Horn Antenna SAS 200/571265 4/29/10 ETS Log-Periodic Antenna 3148 1189 6/12/10 ETS Biconical Antenna 3110B 3370 10/02/10 Agilent Microwave Preamplifier8449B 3008A01442 2/25/10 Attenuator Weinschel AS-6 6675 NCR Attenuator Weinschel AS-6 6677 NCR ETS LISN 3810/2NM 00062907 12/10/09 ETS LISN 3810/2NM 00062912 12/10/09 ETS LISN 3810/2NM 0023630 10/5/10 ETS LISN 3810/2NM 2179 10/6/10 Dell Laptop Computer M20 NA NA Iomega Zip Drive Z250S P9HM1992CK NA Olympus Camera D-600L 4020727 NA All equipment is on a one-year calibration cycle. All test equipment was within their calibration date during the time of testing. When equipment went out of calibration during testing it was replaced using a similar piece of calibrated equipment. All these equipments are listed in the equipment list. The Dell M20 Laptop Computer, Iomega Z250S Zip Drive and the Olympus D-600L Camera are labeled as DoC. APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 6 of 10 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a wooden table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (1/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4- 2003. The EUT was connected to a laptop computer using a USB data cable. The USB data cable is 1 m in length. The parallel and the serial ports of the computer were populated. The EUT was communicating with the laptop computer continuously. APPLICANT: MOTOROLA INC FCC ID: IHDP56KZ2 Test Report Number: 23558-1 Supplement 7 of 10 EXHIBIT 6A4 Measurement Results Operating Mode – Rx Mode, Data Transfer Mode. Notes: Worst Case emissions reported. 30 MHz – 1000 MHz Frequency Level Measured Transd Cables Limit Margin Height Angle Pol. MHz dBuV/m dBuV dB dB dBuV/m dB …

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions APPLICANT: MOTOROLA, INC.FCC ID: IHDP56KZ2 EXHIBIT 7 AC Line Conducted Emissions APPLICANT: MOTOROLA, INC.FCC ID: IHDP56KZ2 EXHIBIT 7 Antenna - Substitution APPLICANT: MOTOROLA, INC.FCC ID: IHDP56KZ2 EXHIBIT 7
