IHDP56LB1GSM 1900 TRANSCEIVER W/BT & WLAN

APPLICANT MOTOROLA INC. FCC ID: IHDP56LB1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 User’s Guide MOTOROLA MT716 Dummy Page - To be discarded before printing Use this template with A6MotoLandscapeProduct1 StructApps. See the Reference Pages for template user instructions. MOTOROLA LANTANA MT716 User Guide Final DRAFT 10/07/30 1Congratulations Congratulations MOTOROLAMT716 Do it all—work, answer emails, watch TV, browse the web, find a restaurant—all on your MOTOROLAMT716. •Don’t miss your favorite program, watch TV when and where you want (“Mobile TV” on page 29). •Surf the Internet to your heart’s content (“Web” on page 29). •Enjoy yourself with powerful features, such as, Mobile Market, Fetion, 139Mail, Monternet, DCD, Navigation and Mobile Stock (“Apps for all” on page 32). •Run your business. Get access to great business features, such as Mobile Reader, Notes, and Business Card Reader. Caution: Before assembling, charging, or using your phone for the first time, please read the important legal and safety information packaged with your product. More Accessories: Find accessories for your phone at www.motorola.com/products. 2Your phone Your phone the important keys & connectors 2010-01-12 Wed Beijing 14:18 Jan. 07:51 12 BrowserCalendar File Man Alarm Cl Volume Keys TV Key Back Key Menu Key Micro USB Connector Charge or connect to PC. TV Aerial To uchscreen Camera Key Power Key Press - sleep. Hold - on/off. Home Key Note: Your phone might look a little different. 2010-01-12 Wed Jan. 07:51 12 BrowserCalendar File Manager Alarm Clock A A Delete Return Space Alternate Symbols Back Shift When you open your phone, the screen adjusts for you. Text input Scroll Select 3Let’s go Contents Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5 Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 App menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Business tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 32 Wi-Fi™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 35 Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 42 Let’s go let’s get you up and running Assemble & charge Caution: Please read “Battery Use & Safety” on page 42. 1cover off2SIM in 3battery in4microSD in 5cover on6charge up 3H 4Let’s go Turn it on & off To turn on your phone, press Power (on the top right). To turn off your phone, press and hold Power, then touchPower off in the menu that opens. Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. Wi-Fi™ connect If you want to use a Wi-Fi network for even faster Internet access, press Home > Settings > Wireless Lan Settings. TouchWLAN to turn on, search for and connect to wireless networks. There’s more in “Wi-Fi™” on page 34. Cool content & more Browse and download the coolest apps on the planet from the Internet. On top of that, you get a full HTML browser, so you can surf in style. Download new apps from the “Web” on page 29. Your phone comes with 122 MB of internal memory, and an optional microSD memory card (upto 16 GB) can be installed—you can load it up with photos, videos, and music from your computer using “USB drag & drop” on page 35. Security There are plenty of ways to protect your phone and your information, in “Security” on page 39. 5Touchscreen & keys Touchscreen & keys a few essentials Touch tips Here are some tips on how to navigate around your phone. To u ch To choose an icon or option, touch it. Try it: In the home screen, touch Contacts. Touch & hold To open special options, touch and hold an icon or other item. Try it: In the home screen, touch Contacts, then touch and hold a contact to open options. BrowserCalendarFile manAlarm Cl May. Andrew Carmody Allen Smith Anu Shah Andrea Shunney Alex Pico Angelique Bukvic Ashok Hemdev SIM - 1112223333 SIM - 3334445555 SIM - 2552552525 SIM - 2223334444 SIM - 8887773333 Please input name All A FrequentGroups SIM - 3223223232 SIM - 4554554545 Voice call Video call IP call Send msg Send contact Delete Alex Pico Drag To scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, touch Contacts, then drag your contacts list up or down. Tip: When you drag or flick a list, a scroll bar appears on the right. Drag the scroll bar to move the list to a letter A - Z. Flick To scroll through a list or move quickly, flick across the touchscreen (drag quickly and release).…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDP56LB1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Zhang Xianmin TITLE: Engineering Manager Motorola Mobile Devices Business Date: 2010-07-30 EXHIBIT 2 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56LB1) is in compliance with all applicable parts of the FCC Rules. NAME: Zhang Xianmin TITLE: Engineering Manager Motorola Mobile Devices Business Date: 2010-07-30 EXHIBIT 2 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 EXHIBIT 2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Zhang Xianmin TITLE: Engineering Manager Motorola Mobile Devices Business Date: 2010-07-30

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 July 29, 2010 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDP56LB1. Motorola is also the manufacturer of this equipment. Confidentiality : Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the GSM 1900 MHz PCS band. The unit also employs EDGE/GPRS and contains Bluetooth and WLAN transmitters (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDP56LB1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 EXHIBIT 3 1 of 3 APPLICANT: MOTOROLA MOBILITY , INC. FCC ID: IHD P56LB1 FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITH BATTERY COVER REMOVED EXHIBIT 3 3 of 3 APPLICANT: MOTOROLA MOBILITY , INC. FCC ID: IHD P56LB1 EXHIBIT 3 3 of 3 SIDE OF PHONE

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LB1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDP56LB1

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHD P56LB1 Main Board Bottom Without Shields Main Board Bottom With Shields EXHIBIT 9 1 of 4 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHD P56LB1 Main Board Top Without Shield Main Board Top With Shield Daughter PCB Flex Daughter PCB Flex EXHIBIT 9 2 of 4 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHD P56LB1 Slider FPC Slider FPC Daughter PCB Back 8MP Imager Flex 8MP Imager Flex Daughter PCB Front EXHIBIT 9 3 of 4 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHD P56LB1 EXHIBIT 9 4 of 4 Inside Back Housing Inside Slider

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23882-1F FCC ID: IHDP56LB1 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 23882-1F Date of Report: Jul-21-2010 Date of Test: Jul-01-2010 to Jul-21-2010 FCC ID #: IHDP56LB1 Generic Name: MAQ6-34411B11 Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Thomas Knipple Senior RF Engineer Accreditation: TESTING CERT #2518-02 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23882-1F FCC ID: IHDP56LB1 Exhibit 11 Page 2 of 15 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 9 6.2 Body Worn Test Results 12 References 15 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23882-1F FCC ID: IHDP56LB1 Exhibit 11 Page 3 of 15 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1 g average set in [3] and 2.0 W/kg in a 10 g average set in [2]. For ANSI / IEEE C95.1 (1 g), the final SAR reading for this phone is 0.38 W/kg for head-adjacent use and 0.58 W/kg for body-worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23882-1F FCC ID: IHDP56LB1 Exhibit 11 Page 4 of 15 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of Transceiver Width 55 mm Dimensions Length 20 mm Configuration FICA 2.2 Device description Serial Number(s) 352791040002188, 862031980002010 Mode(s) of Operation GSM 900 GSM 1800 GSM 1900 TD-SCDMA Band A TD-SCDMA Band B Wi-Fi 802.11b/g Bluetooth Modulation Mode(s) GSMK GSMK GSMK QPSK QPSK BPSK GFSK Maximum Output Power Setting 33.3 dBm 30.5 dBm 30.5 dBm 24.5 dBm 24.5 dBm 18.5 dBm 10 dBm Duty Cycle 1:8.3 1:8.3 1:8.3 1:7.4 1:7.4 1:1 1:1 Transmitting Frequency Range(s) 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz 1880.8 - 1919.2 MHz 2010.8 - 2024.2 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Mode(s) of Operation GPRS 900 GPRS 1800 GPRS 1900 Modulation GMSK GMSK GMSK Maximum Output Power Setting 33.3 33.3 30.5 30.5 30.5 30.5 Duty Cycle 1:8.3 2:8.3 1:8.3 2:8.3 1:8.3 2:8.3 Transmitting Frequency Range(s) 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Mode(s) of Operation EDGE 900 EDGE 1800 EDGE 1900 Modulation 8PSK 8PSK 8PSK Maximum Output Power Setting 27.5 27.5 27.0 27.0 27.0 27.0 Duty Cycle 1:8.3 2:8.3 1:8.3 2:8.3 1:8.3 2:8.3 Transmitting Frequency Range(s) 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Note: Bolded entries indicate data mode configurations of highest time-average power output per band and data mode type. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23882-1F FCC ID: IHDP56LB1 Exhibit 11 Page 5 of 15 3. Test Equipment Used 3.1 Dosimetric System The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.7) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerl…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report Number: 23881-1 WLAN Page 1 of 16 EXHIBIT 6A3 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT - Addendum Test Report Number – 23881-1 WLAN Report Date –2010-07-16 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2010-07-12 to 2010-07-16 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated . Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2010-07-16 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report Number: 23881-1 WLAN Page 2 of 16 EXHIBIT 6A3 Table of Contents Test Report Details .............................................................................................................3 Applicable Standards .......................................................................................................... 4 Summary of Testing............................................................................................................ 5 General and Special Conditions.......................................................................................... 5 Equipment and Cable Configurations ................................................................................. 6 Measuring Equipment and Calibration Information ........................................................... 6 Measurement Procedures and Data..................................................................................... 8 FIELD STRENGTH OF SPURIOUS EMISSIONS....................................................... 8 Measurement Procedure.............................................................................................. 8 Measurement Results .................................................................................................. 9 WLAN Band (b) ......................................................................................................... 9 WLAN Band (g) ....................................................................................................... 11 BAND-EDGE COMPLIANCE OF RF RADIATED EMISSIONS............................. 13 Measurement Procedure............................................................................................ 13 Measurement Results ................................................................................................ 13 WLAN Band (b) ....................................................................................................... 14 WLAN Band (g) ....................................................................................................... 15 APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report Number: 23881-1 WLAN Page 3 of 16 EXHIBIT 6A3 Test Report Details Tests Performed By: Motorola (China) Technologies Ltd. Asia Global Compliance Labs No.1 Wang Jing East Road Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola (China) Technologies Ltd. Mobile Devices business No.1 Wangjing East Road Chao Yang District Beijing, 100102, P. R. China Product Type: Cell phone with embedded WLAN Signaling Capability: GSM 1900, Standalone GPS/aGPS, Bluetooth, 802.11b & g IMEI: 352791040002113 FCC ID: 23881-1 Project number: IHDP56LB1 Testing Complete Date: 2010-07-16 APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report Number: 23881-1 WLAN Page 4 of 16 EXHIBIT 6A3 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart C – Intentional Radiators Part 22 Subpart H - Public Mobile Services Part 24 - Personal Communications Services Part 27 - Wireless Communications Service Part 90 - Private Land Mobile Radio Service Applicable Standards: ANSI C63.4-2003, RSS-Gen Issue 2, RSS-210 Issue 7. The following tests were performed according to the regulations: • The spurious radiated emission requirements of § 15.247 and § 15.249 of CFR47 Part 15 2007, specifically” radiated emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the radiated emission limits specified in Section 15.209(a) (see Section 15.205(c)). • Under this project only 30 to 1000 MHz, 1 to 26.5 GHz radiated and radiated band-edge measurements were performed. • For frequencies below 1 GHz a 100 kHz RBW (6 dB) is used and above 1 GHz a 1 MHz RBW (6 dB) is used. APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report Number: 23881-1 WLAN Page 5 of 16 EXHIBIT 6A3 Summary of Testing Test Test Name Pass/Fail _____________________________________________________________________ 1 Field Strength of Spurious Emissions Pass 2 Band-edge Compliance of RF Radiated Emissions Pass Test Test Name Results ______________________________________________________________________ 1 Field Strength of Spurious Emissions See plots 2 Band-edge Compliance of RF Radiated Emissions See plots The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The 23881-1 test sample was tested using a fully charged Model SNN5851A 1380mAH battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. Special test SW was used for these tests. Radiated testing was done in …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report 23881-1 WLAN 1 of 40 EXHIBIT 6A5 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23881-1 WLAN Report Date – July 22, 2010 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Albert J. Patapack Title: EMC Engineer Date: July 22, 2010 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 2518-02 APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report 23881-1 WLAN 2 of 40 EXHIBIT 6A5 Table of Contents Test Report Details .............................................................................................................3 Applicable Standards .......................................................................................................... 3 Summary of Testing............................................................................................................ 4 General and Special Conditions.......................................................................................... 4 Equipment and Cable Configurations ................................................................................. 5 Measuring Equipment and Calibration Information ........................................................... 5 Description of WLAN Transmitter ..................................................................................... 5 Measurement Procedures and Data..................................................................................... 6 Spectrum Bandwidth....................................................................................................... 6 Measurement Procedure.............................................................................................. 6 Measurement Results .................................................................................................. 6 Peak Output Power ....................................................................................................... 13 Measurement Procedure............................................................................................ 13 Measurement Results ................................................................................................ 13 Power Spectral Density................................................................................................. 17 Measurement Procedure............................................................................................ 17 Measurement Results ................................................................................................ 17 Spurious RF Conducted Emissions............................................................................... 18 Measurement Procedure............................................................................................ 18 Measurement Results ................................................................................................ 18 AC Line Conducted Emissions ..................................................................................... 33 Measurement Procedure............................................................................................ 33 Measurement Results ................................................................................................ 33 APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report 23881-1 WLAN 3 of 40 EXHIBIT 6A5 Test Report Details Tests Performed By: Motorola Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola MDb FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: 109O-1 Tests Requested By: Motorola Inc. Mobile Devices Business 600 North US Hwy 45 Libertyville, IL 60048 Product Type : Cellular Phone Signaling Capability: GSM 1900, Bluetooth, 802.11b & g FCC ID: IHDP56LB1 Serial Numbers: 862031980002010 Testing Complete Date: July 15, 2010 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart C – Intentional Radiators Applicable Standards: ANSI 63.4 2003, RSS-210 Issue 7 APPLICANT: MOTOROLA INC FCC ID: IHDP56LB1 Test Report 23881-1 WLAN 4 of…

Text truncated - open the document above for the full version.
