IHDP56LJ3GSM / EGPRS Mobile Phone

Motorola Mobility LLC

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jun 10, 2010
Application Purpose: Original Equipment
Date of Application: Jun 09, 2010
Equipment Note: GSM / EGPRS Mobile Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: Motorola Mobility LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Dummy Page - To be discarded before printing ITC Notes: Use this template with A7MotoQSG StructApps. Starling GSM GSG 6/1/10 1 congratulations The MOTO Starling is a phone with several premium features including personalization, music, message, browsing, and more...all in a streamlined QWERTY design. •Personaliztion: Unify your work and personal life with calendar, email and contacts. •Message: Use the QWERTY keypad to quickly edit and exchange messages anywhere. •Dual SIM slot: Enable you to use two SIM cards at the same time without changing them. We’ve crammed all the main features of your phone into this handy guide, and in a matter of minutes we’ll show you just how easy your phone is to use. You may be surprised at what you discover. If you’d like to get more information about how to use your new phone, please visit www.motorola.com. Caution: Before using your phone for the first time, please read the important legal and safety information at the back of the Getting Started Guide. 2 contents my phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 menu map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 let’s go. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 customize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 e-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 media player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 personal organizer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Legal, Safety & Regulatory . . . . . . . . . . . . . . . . . . . . . . . . 34 my phone 3 my phone Note: All the illustrations, simulated screen and related images used in this manual are for reference only. There may be slight defference between the phone and keys and content of display used in this manual and those of your phone. Please refer to your phone for actuality. home screen 4 home screen keep you updated at all times... The home screen appears when you turn on the phone. It gives you all your latest information in one place. Status indicators can appear on the top of the home screen. Note: Your home screen may look different. status indicators Single StrengthGeneral Profile Active Voice CallMeeting Profile Phone LockOutdoor Profile Alarm LockHeadset Roaming ServiceBluetooth New MessagesBatteryt menu map 5 menu map File Manager •Phone •Memory Card* Phonebook •Add New Contact •Contact List Fun & Games •Java •Java Settings •Java Network •Games Extra •Calculator •Currency Converter Call Center •Call History •Call Settings Messaging •Write Message •Inbox •Drafts •Outbox •Sent Messages •Archive •Delete Messages •Email •Broadcast Message •Templates •Message Settings Multimedia •Camcorder •Image Viewer •Media Player •Photo Editor •Sound Recorder •FM Radio •Schedule FM Record •Melody Composer •Slide Show * Available only when memory card is intalled. menu map 6 Services •Internet Service •License Manager Organizer •Calendar •Tasks •Alarm •World Clock •Synchronization •Phone Sync Settings •Dual SIM Switch •Dual SIM Settings •Phone Settings •Network Settings •Security Settings •Connectivity •Restore Factory Settings •Sound Effects User Profile •General •Meeting •Outdoor •Indoor •Headset •Bluetooth Media Player •Now Playing •All Media Files •My Playlists •Artist •Album •Video This is the standard main menu layout. Your phone’s menu may be different . let’s go 7 let’s go Note: Your battery is intentionally tight fitting. basics 8 basics here’s a few essentials: about this guide Press the Left Soft Key to open the Main Menu and select Options. Use the Navigation Key up, down, left, or right to scroll to an item, then press the Center Key to select the highlighted item. Press the Right Soft Key to select Back and move up to the previous level. This guide shows how to locate a menu eature as follows: Find it: Press Menu > Messaging > (received call) 1Press the Left Soft Key to open the Main Memu. 2Press the Navigation Key to scroll to Call Center, then press the Center Key to select it. 3Press the Navigation Key to scroll to a received call. then press the Center Key to select the call. basics 9 turn it on & off Press and hold the Power/End Key for a few seconds to turn the phone on and off. If prompted, enter your unlock code to turn it on. activate SIM cards Your phone supports the Dual SIM cards mode, enabling you to use two SIM cards at the same time without changing them. When two SIM cards are both installed, you can activate one of two or both SIM cards as well as the flight mode. Find it: Press Menu > Settings > Dual SIM Settings Note: If only one SIM card is installed, this SIM card would be activated as default. access the main menu 1From the home screen, press the Left Soft Key to open the Main Menu. 2You can press the Right Soft Key to move up the previous level. You also can press the Power/End Key to return to the home screen at anytime. basics 10 menu shortc…

Text truncated - open the document above for the full version.

Users Manual

Text truncated - open the document above for the full version.

Cover Letter(s)

April 15, 2010 Authorization of Agent Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Grantee Code IHD Authorization: I, Andrew Bachler, the FCC contact for Grantee Code “IHD”; hereby authorize the following company (agent) to act on behalf of Motorola Inc. Mobile Devices for the application specified below. This includes: • Form 731, Attestation Statement Exhibit, and Confidentiality Request Signatures • Technical Contact • Non-Technical Contact • Test Firm Contact Information The grant should still be mailed to the applicant of record for Grantee Code “IHD”. Authorized Agent: Ellis Wu, Senior Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch No.19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan Specific Applications: • FCC ID: IHDP56LJ3 • FCC ID: IHDP56LJ2 Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this authorization. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

Cover Letter(s)

FCC ID : IHDP56LJ3 No simultaneous SAR justification Per “648474 D01 SAR Handsets Multi Xmiter and Ant, v01r05”, Test mode of SAR is as below Test mode Test channel Max sar value ( W/kg ) Remark Mobile phone Middle 0.786 SAR value of middle channel is less than 0.8 W/kg , test for other channels is unnecessary. Bluetooth NA NA Distance between Bluetooth and CDMA antenna is 2.01209 cm < 5cm and highest output power is 3.6 mW < 60/f(GHz) mW. Therefore, stand-alone SAR is unnecessary Max SAR value ( W/ kg ) of each mode : Test mode Head Body Mobile phone 0.746 0.786 Bluetooth na na Distance between antennas ( cm ) : Distance between mobile and bluetooth antenna is 2.01209 cm Note : Please refer to” OpDes-Antenna_ IHDP56LJ3 “ for antenna separation distance Conclusion: 1. Sum SAR value is 0.786 < 1.6 W/kg Accordingly, simultaneous Transmission SAR is not required for this EUT

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

ID Label/Location Info

10/02/26 Label 44.94±0.1 3 7 . 2 5 ± 0 . 1 8 31.94 3 2 . 2 5 0.1 adhesive side painting black 8205(Starling)_P3 MB:004 SB : 004 8205 S/N:1025846031B IMEI:354644030013624-1 Engineering Samples IMEI:354644030013624-2 Moto FCC ID: IHDP56LJ3 7.5mm

Internal Photos

Page 6 FOR DUAL SIM Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 FOR SINGLE SIM Page 15 Page 16 Page 17 Page 18 Page 19 Page 20

RF Exposure Info

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: PHANTOM D2: DOSIMETRIC E-FIELD PROBE D3: DAE

RF Exposure Info

D4: SYSTEM VALIDATION DIPOLE

RF Exposure Info

Report No.: SA990421C04-1 Report Format Version 3.0.1 1 RF EXPOSURE REPORT ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Motorola Inc ADDRESS: Mobile Devices 600 N. U.S. Highway 45, Libertyville, Illinois, United States, 60048-5343 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Y a 2nd Rd, Wen Hwa T suen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. REPORT NO.: SA990421C04-1 MODEL NO.: EX115, EX112 FCC ID: IHDP56LJ3 Report No.: SA990421C04-1 Report Format Version 3.0.1 2 1. Conclusion No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.480 24.580 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power 5.5 3.6 EIRP Power 1.56 1.4 *Note: The antenna is Embedded inverted-F antenna with -3.94dBi gain. Threshold for no SAR evaluation is 24.580mW Transmitter power is 3.6m W Conclusion: No SAR e valuation required since Transmitter Pout is below FCC threshold

RF Exposure Info

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: PHANTOM D2: DOSIMETRIC E-FIELD PROBE D3: DAE

RF Exposure Info

D4: SYSTEM VALIDATION DIPOLE

RF Exposure Info

Test Report

Report No.: RF990421C04 1 Report Format Version 3.0.1 FCC TEST REPORT (Bluetooth) REPORT NO.: RF990421C04 MODEL NO.: EX115, EX112 RECEIVED: Apr. 21, 2010 TESTED: Apr. 23 ~ May 07, 2010 ISSUED: May 13, 2010 APPLICANT: Motorola Inc ADDRESS: Mobile Devices 600 N. U.S. Highway 45, Libertyville, Illinois, United States, 60048-5343 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 63 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990421C04 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION.......................................................................................................4 2. SUMMARY OF TEST RESULTS ..............................................................................5 2.1 MEASUREMENT UNCERTAINTY ...........................................................................5 3. GENERAL INFORMATION .......................................................................................6 3.1 GENERAL DESCRIPTION OF EUT.........................................................................6 3.2 DESCRIPTION OF TEST MODES...........................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ...................................................... 8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................... 9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................ 11 3.4 DESCRIPTION OF SUPPORT UNITS ................................................................... 11 4. TEST TYPES AND RESULTS ................................................................................12 4.1 RADIATED EMISSION MEASUREMENT ..............................................................12 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................ 12 4.1.2 TEST INSTRUMENTS ........................................................................................... 13 4.1.3 TEST PROCEDURES ............................................................................................ 14 4.1.4 DEVIATION FROM TEST STANDARD .................................................................. 14 4.1.5 TEST SETUP ......................................................................................................... 15 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 15 4.1.7 TEST RESULTS ..................................................................................................... 16 4.2 CONDUCTED EMISSION MEASUREMENT .........................................................24 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 24 4.2.2 TEST INSTRUMENTS ........................................................................................... 24 4.2.3 TEST PROCEDURES ............................................................................................ 25 4.2.4 DEVIATION FROM TEST STANDARD .................................................................. 25 4.2.5 TEST SETUP ......................................................................................................... 26 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 26 4.2.7 TEST RESULTS ..................................................................................................... 27 4.3 NUMBER OF HOPPING FREQUENCY USED ......................................................31 4.3.1 LIMIT OF HOPPING FREQUENCY USED ............................................................ 31 4.3.2 TEST INSTRUMENTS ........................................................................................... 31 4.3.3 TEST PROCEDURES ............................................................................................ 31 4.3.4 DEVIATION FROM TEST STANDARD .................................................................. 32 4.3.5 TEST SETUP ......................................................................................................... 32 4.3.6 TEST RESULTS ..................................................................................................... 32 4.4 DWELL TIME ON EACH CHANNEL ......................................................................35 4.4.1 LIMIT OF DWELL TIME USED............................................................................... 35 4.4.2 TEST INSTRUMENTS ........................................................................................... 35 4.4.3 TEST PROCEDURES ............................................................................................ 35 4.4.4 DEVIATION FROM TEST STANDARD .................................................................. 35 4.4.5 TEST SETUP ......................................................................................................... 36 4.4.6 TEST RESULTS ..................................................................................................... 36 4.5 CHANNEL BANDWIDTH........................................................................................44 4.5.1 LIMITS OF CHANNEL BANDWIDTH ..................................................................... 44 4.5.2 TEST INSTRUMENTS ........................................................................................... 44 4.5.3 TEST PROCEDURE .................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF990421C04-1 1 Report Format Version 3.0.1 FCC TEST REPORT (PART 22) REPORT NO.: RF990421C04-1 MODEL NO.: EX115, EX112 RECEIVED: Apr. 21, 2010 TESTED: Apr. 23 ~ May 07, 2010 ISSUED: May 13, 2010 APPLICANT: Motorola Inc ADDRESS: Mobile Devices 600 N. U.S. Highway 45, Libertyville, Illinois, United States, 60048-5343 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990421C04-1 2 Report Format Version 3.0.1 TABLE OF CONTENTS 1 CERTIFICATION ........................................................................................................4 2 SUMMARY OF TEST RESULTS ................................................................................5 2.1 MEASUREMENT UNCERTAINTY .............................................................................5 3 GENERAL INFORMATION.........................................................................................6 3.1 GENERAL DESCRIPTION OF EUT...........................................................................6 3.2 DESCRIPTION OF TEST MODES.............................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.............................8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ..........................................10 3.4 DESCRIPTION OF SUPPORT UNITS .....................................................................10 4 TEST TYPES AND RESULTS .................................................................................. 11 4.1 OUTPUT POWER MEASUREMENT ....................................................................... 11 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT..................................................... 11 4.1.2 TEST INSTRUMENTS .............................................................................................12 4.1.3 TEST PROCEDURES ..............................................................................................13 4.1.4 TEST SETUP ...........................................................................................................14 4.1.5 EUT OPERATING CONDITIONS .............................................................................14 4.1.6 TEST RESULTS .......................................................................................................15 4.2 FREQUENCY STABILITY MEASUREMENT ...........................................................17 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT ........................................17 4.2.2 TEST INSTRUMENTS .............................................................................................17 4.2.3 TEST PROCEDURE ................................................................................................18 4.2.4 TEST SETUP ...........................................................................................................18 4.2.5 TEST RESULTS .......................................................................................................19 4.3 OCCUPIED BANDWIDTH MEASUREMENT...........................................................20 4.3.1 LIMITS OF OCCUPIED BANDWIDTH MEASUREMENT ........................................20 4.3.2 TEST INSTRUMENTS .............................................................................................20 4.3.3 TEST SETUP ...........................................................................................................20 4.3.4 TEST PROCEDURES ..............................................................................................21 4.3.5 EUT OPERATING CONDITION ...............................................................................21 4.3.6 TEST RESULTS .......................................................................................................22 4.4 BAND EDGE MEASUREMENT ...............................................................................24 4.4.1 LIMITS OF BAND EDGE MEASUREMENT.............................................................24 4.4.2 TEST INSTRUMENTS .............................................................................................24 4.4.3 TEST SETUP ...........................................................................................................24 4.4.4 TEST PROCEDURES ..............................................................................................25 4.4.5 EUT OPERATING CONDITION ...............................................................................25 4.4.6 TEST RESULTS .......................................................................................................26 4.5 CONDUCTED SPURIOUS EMISSIONS..................................................................28 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT ..................28 4.5.2 TEST INSTRUMENTS .............................................................................................28 4.5.3 TEST PROCEDURE ................................................................................................29 Report No.: RF990421C04-1 3 Report Format Version 3.0.1 4.5.4 TEST SETUP ...........................................................................................................29 4.5.5 EUT OPERATING CONDITIONS .................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF990421C04-2 1 Report Format Version 3.0.1 FCC TEST REPORT (Part 24) REPORT NO.: RF990421C04-2 MODEL NO.: EX115, EX112 RECEIVED: Apr. 21, 2010 TESTED: Apr. 23 ~ May 07, 2010 ISSUED: May 13, 2010 APPLICANT: Motorola Inc ADDRESS: Mobile Devices 600 N. U.S. Highway 45, Libertyville, Illinois, United States, 60048-5343 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 47 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990421C0…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jeff Narducci(Director Product Compliance)

[email protected]847-687-6928Fax: 847-687-6928

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchGary Chang

[email protected]886-3-3183232

No. 19, Hwa Ya 2nd Rd., Kwei Shan Hsiang · Taoyuan Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchWendy Liao

[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen

[email protected]886-3-3183232Fax: 886-3-2115834

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	24E	1.85 GHz - 1.91 GHz	1.175 W	248KG7W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Output power is ERP for Part 22 and EIRP for Part 24. Collocated transmitter operating configurations have been evaluated as described in this filing; other collocation configurations require separate evaluation. SAR compliance for body-worn operating configurations is limited to the specific to belt-clips, holsters or similar accessories configurations tested for this filing, and to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for single and co-transmit configurations under this FCC ID are: Part 22 - head 0.7 W/kg, body 0.8 W/kg; Part 24 - head 0.7 W/kg, body 0.5 W/kg.
